GE GE Triton GSD6600GCC User instructions

Specification Revised 6/04
350378
GSD6600/60G – GE Triton® XL Built-In Dishwasher
GE Appliances
For answers to your Monogram,
® GE Profile™ or
GE appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center® service, 800.626.2000.
Models/Kit A B C – Panel Thickness
GE Models
GPF625 Kit* 25-1/16" 23-1/2" 1/4"
GPF675 Kit** 25-7/16" 23-3/4" 3/4"
** GPF800 Heavy Spring Kit required for custom door panel
weighing more than 4 lbs.
** GPF800 Heavy Spring Kit included.
Wood Insert Cut-Out Dimensions
(flat door models only)
B
See Detail E for 3/4" Panel Detail E for 3/4 panel only
Door insert ABack ViewFront View
F
F
1-7/8 1-7/8
20
Section F-F
C
3/8
3/4
B
See Detail E for 3/4" Panel Detail E for 3/4 panel only
Door insert ABack ViewFront View
F
F
1-7/8 1-7/8
20
Section F-F
C
3/8
3/4
24
25-1/4
MAX.
21-1/4
4
4 (Adjustable)
33-13/16" MIN.
adj. to 35"
27-1/2
22-1/2
Built-In Dishwasher Dimensions
(in inches)
Electrical Rating
Voltage AC. . . . . . . . . . . . . . . . . . . . . . . 120
Hertz. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Total connected load amperage . . . . . . 9.1
Calrod® heater watts max.. . . . . . . . . . 875
For use on adequately wired 120-volt,
15-amp circuit having 2-wire service with
a separate ground wire. This appliance
must be grounded for safe operation.
R
Listed by
Underwriters
Laboratories
Dishwasher Rough-In Information
Note: Dishwasher must not be installed more than 10 feet
from sink for proper drainage. All plumbing and electrical
work must be in accordance with local codes.
The power cord and connections must comply with the
National Electrical Code Section 422 and/or local codes and
ordinances. The cord must be no longer than 6 ft. from the
junction box to the receptacle.
Installation Information
(in inches)
This wall area
must be free of
pipes or wires
Countertop
4
6
Hot
water
line on
left
44
2Plumbing and electrical
service must enter
inside shaded area
24" From wall
24" MIN.
90°
19" MIN. from wall
24"
MIN.
6
34" to 34-3/4"
Underside
of countertop
to floor
5 5
90°
Electrical
wiring on
right
Electrical
wiring is
3" from
cabinet
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.

Specification Revised 6/04
350378
GSD6600/60G – GE Triton® XL Built-In Dishwasher
GE Appliances
GSD6200GWW.EPS
T
riton XL
RINSE
ONLY
CHINA
CRYSTAL
NORMAL
WASH
POTS
& PANS
ANTI
BACTERIA
START
RESET
DELAY
HOURS
EXTRA
HOT WASH
HEATED
DRY
TO LOCK CONTROLS
PRESS HEATED DRY
FOR 3 SECONDS
ExtraClean Sensor Selections
SANITIZEDCLEAN
Extras
2 4 8
Features and Benefits
• Full-length flat door – Blends almost seamlessly with adjacent cabinetry
• ExtraClean™ wash system with 3 direct-feed wash arms – Provides multiple wash levels to clean
every spot on every dish
• ExtraClean™ sensor – Continually monitors every cycle adjusting to ensure dishes get
clean efficiently
• Giant tub with maximum capacity nylon racking – Holds tall and oversized items; washes 16 place
settings at once.
• 2 sets fold down tines – lower rack – Provides loading flexibility for pots, pans and large bowls
• QuietPower™ IV sound package – Delivers quiet performance with added sound-deadening materials
and extra insulation
• 2/4/8 hour delay start – Makes it easier than ever to wash dishes at any hour taking advantage of
reduced energy rates or washing dishes even when the family is asleep
• 16 place settings capacity – Accommodates up to 16 place settings in single load
• Super capacity 3-piece silverware basket – Holds more items to clean large loads at once and
separates for the ultimate in loading flexibility.
• Anti-bacteria cycle – Sanitizes tableware by reducing 99.999% of the bacteria found on dishes
• Model GSD6600GWW – White on white
• Model GSD6600KBB – Black on black
• Model GSD6600GCC – Bisque on bisque
• Model GSD6660GSS – Stainless steel
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
