GE GSD2300N Manual

Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
Specification Created 4/07 350261
Panel
Thickness
Kit A B C
GPF325 18-7/8" 23-9/16" 3-11/16" 1/4"
GPF375 18-15/16" 23-5/8"* 4-1/4" to
3-3/4"**
3/4"
Listed by
Underwriters
Laboratories
This wall area
must be free of
pipes or wires
Countertop
4
6
Hot
water
line on
left
44
2Plumbing and electrical
service must enter
inside shaded area
24" From wall
24" MIN.
90°
19" MIN. from wall
24"
MIN.
6
34" to 34-3/4"
Underside
of countertop
to floor
5 5
90°
Electrical
wiring on
right
Electrical
wiring is
3" from
cabinet
24
25-3/4
MAX.
21-1/2
3-1/4 4 (Adjustable)
34 MIN.
adj. to 35
24-3/4
23-3/8
B
Access insert
Door insert A
C
Models/Kits A B C Thickness
GE Models
GPF325 Kit 18-7/8” 23-9/16” 3-11/16” 1/4”
GPF375 Kit 18-15/16” 23-5/8”* 3-3/4”** 3/4”
*Bottom of panel must be notched 1-1/2"x1/2" to clear
across panel
**Adjustment required to match adjcent cabinets fronts due to
leveling leg adjustment, 4" nominal.
4-1/4" to
Electrical Rating
Voltage AC.......................................................... 120
Hertz..................................................................... 60
Total connected load amperage............. 6.2
Calrod® heater watts max........................ 500
For use on adequately wired 120-volt,
15-amp circuit having 2-wire service
with a separate ground wire. This appliance
must be grounded for safe operation.
Note: Dishwasher must not be installed
more than 10 feet from sink for proper
drainage. All plumbing and electrical work
must be in accordance with local codes.
GSD2300/2301N
GE®Built-In Dishwasher
* Bottom of panel must be notched 1-1/2" x 1/2" to clear across panel
** Adjustment required to match adjacent cabinet fronts due
to leveling leg adjustment, 4" nominal

Features and Benefits
• Meets 2007 ENERGY STAR® Criteria - Can reduce utility bill by using less water
to get dishes clean
• 4-level PowerScrub™ wash system - Four wash levels quietly and efficiently
scrub dishes clean
• HotStart™ Option - Preheats water before the main wash cycle for dependable
performance every time
• Piranha™ Hard Food Disposer - Grinds leftover food into small particles that
are easily washed away
• Pots and Pans Cycle - Scours off baked-on food with a wall of water
• Heated Dry Option - Circulates warm air to quickly and gently dry dishes
• Plate Warmer cycle - Gently warms dinner plates for serving food at the
optimal temperature
• Model GSD2300NWW - White on white
• Model GSD2300NCC - Bisque on bisque
• Model GSD2300NBB - Black on black
• Model GSD2301NWW - White on white, has power cord attached
Specification Created 4/07 350261
GSD2300/2301N
GE®Built-In Dishwasher
GSD2300NWW/BB/CC
GSD2201NWW
GSD2400NWW/BB/CC
