  9. GE Monogram ZBD5700DBB User instructions

GE Monogram ZBD5700DBB User instructions

Monogram.
™
ZBD5700DBB—GE Monogram Dishwasher with Stainless Steel Interior
For answers to your Monogram,®
GE Profile Performance Series,™
GE Profile™or GE appliance questions, call
GE Answer Center®service, 800.626.2000.
R
Listed by
Underwriters
Laboratories
Revised 12/98
Dimensions and Specifications (in inches) Design Information: This dishwasher is supplied as
a Black model.
A toekick is supplied and may be covered with a
custom toekick to match kitchen decor.
Side trim is not required. Side filler strips are supplied
to fill a 24" wide opening.
Additional Specifications: A 120 Volt, 60 Hz power
supply is required. An individual properly grounded
branch circuit protected by a 15 or 20 amp circuit
breaker or time delay fuse is recommended. Install a
3-prong electrical receptacle at least 6" above the
floor and within 18" of the right or left adjacent
cabinet wall. Wiring must enter the cutout in shaded
area shown. A double, side-by-side installation
requires two separate circuits.
The hot water line must enter the cutout in the shaded
area from the right, left, rear or through the floor. The
water line should be 3/8" O.D. copper or 1/2" O.D.
plastic. Installation of an easily accessible hand
shut-off valve is strongly recommended.
The dishwasher should be placed no more than 10 feet
from the sink for proper drainage.
If the dishwasher is to be located in or near a corner
of base cabinets, allow 2" min. clearance from the
corner to prevent interference with adjacent door
handles.
Optional Trim Kits:
• ZPF25W, white or ZPF25B, black custom panel
kit–Provides for the installation of a 1/4”
thick custom door panel.
• ZPF75W, white or ZPF75B, black custom panel
kit–Provides for a trimless appearance using a 3/4”
thick custom door panel.
23-5/8"
5"
34" Min.
35" Max.
2-7/8" Min.
4" Max.
Toekick
25 1/4"
From
Cabinet Face 23 1/2"
3 1/4"
24"
1-3/4" Min.
6"
PlumbingandElectricService
MustEnterInsideThisArea
34" Min.
35" Max.
Underside of
Countertop
to Floor
23-5/8" Min.
24" Max.
This Wall Area
Must be Free of
Pipes or Wires
Monogram.
™
ZBD5700DBB—GE Monogram Dishwasher with Stainless Steel Interior
•Cut door panel to the dimensions shown.
•The bottom left and right corners should be
cut at 1/4” radius. See illustration.
NOTE: The trim will conceal the cut edges of
the panel.
1/4" Thick
Door Panel 25-1/2"
23-1/8"
1/4"
Radius
Cut
Custom Door and Access Panel Dimensions
For answers to your Monogram,®
GE Profile Performance Series,™
GE Profile™or GE appliance questions, call
GE Answer Center®service, 800.626.2000.
R
Listed by
Underwriters
Laboratories
Revised 12/98
Dim. A* *Height
23-1/8"
Custom
Panel Size
Floor
Cabinets
Countertop Top
3/4" Max.
3/4" Thick
Door Panel
Bottom of
Adjacent Cabinetry
*Height is equal to A minus 5-1/8" plus 1/4"
EXAMPLE:
*Height = 30-1/2" minus 5-1/8" plus 1/4" is equal to 25-5
The custom panel should be constructed in
the same manner as cabinet doors. All edges
can be seen and must be finished for the
best appearance.
• Measure dimension A, from underside of
countertop to bottom of adjacent cabinets.
–Subtract 5-1/8”. Control panel height is 5”.
Allow 1/8” for gap between bottom of
countertop and top of control panel.
–Add 1/4”. The custom panel will slide up,
behind control panel.
Monogram.
™
ZBD5700DBB—GE Monogram Dishwasher with Stainless Steel Interior
Features and Benefits
• Monogram Sound Insulation Package
• Stainless Steel Interior
• 4 Cycles / 3 Options - 19 Combinations
• Cycles: Pots & Pans Cycle, Normal Wash,
Glasses and Rinse & Hold
• Cycle Auto Memory
• 2/4/6-Hour Delay Start Option
• Wash Temp Options Include Norm, Boost
and Sani
• Three-Level Wash System
• Stainless Steel Mid-Level and Lower Wash Arm
• Stainless Steel 4-Way Filtration
• Adjustable Nylon Upper Rack
• Nylon Lower Rack with Fold-Down Tines
• Deluxe Silverware Basket with Cell Covers
• Utility Shelves
• Convection Drying
• Heated Dry On/Off
• Interior Light
• Electronic Child Lock-Out
• Rinse Aid Dispenser
• ZBD5700DWW - White on white
• ZBD5700DBB - Black on black
Revised 12/98
