Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
PDWT400/480P
GE Profile™Dishwasher with SmartDispense™Technology
Specification Created 8/08 250223
Listed by
Underwriters
Laboratories
This wall area
must be free of
pipes or wires
Countertop
4
6
Hot
water
line on
left
44
2Plumbing and electrical
service must enter
inside shaded area
24" From wall
24" MIN.
90°
19" MIN. from wall
24"
MIN.
6
34" to 34-3/4"
Underside
of countertop
to floor
5 5
90°
Electrical
wiring on
right
Electrical
wiring is
3" from
cabinet
24
24-3/4††
21-1/4
3-1/2
4" (Adjustable)
33-13/16" MIN.
adj. to 35"
27-1/2
22-1/2
††Add 1/2" for deepest part of contour door.
Allow and additional 2" for the handle on
PDW9900/9200 Series models.
Electrical Rating
VoltageAC.......................................................... 120
Hertz..................................................................... 60
Total connected load amperage............. 9.1
Calrod®heater watts max........................ 875
For use on adequately wired 120-volt,
15-amp circuit having 2-wire service
with a separate ground wire. This appliance
must be grounded for safe operation.
Installation Information: Before installing,
consult installation instructions packed with
product for current dimensional data.
†† Add 1/2" for deepest part of contour door.
Allow an additional 2” for the handle on
PDWT500/PDWT400/PDWT200 Series
models.

PDWT400/480P
GE Profile™Dishwasher with SmartDispense™Technology
Specification Created 8/08 250223
PDWT480PSS
Features and Benefits
• SmartDispense™Technology - Holds up to 47 fl. oz. of detergent and dispenses it based
on water hardness and soil levels
• 6-level BrilliantClean™Towerless Wash System - Multiple wash levels help to remove
tough food soils from dishes
• CleanSensor™- A laser measures soil and water temperature to adjust to the ideal
cycle time and optimize water usage
• Giant Tub with up to 16 Place Setting Capacity Nylon Racking - Holds tall and oversized
items and washes up to 16 place settings at once
• 2 Sets of Fold-Down Tines in Lower Rack - Flexible tines make it easier to load
the dishwasher
• 2/4/8-Hour Delay Start - Allows the dishwasher to be set to wash dishes at a later time
• Hand/Gentle Cycle - Gently cleans delicate items that would normally require
handwashing
• Model PDWT480PSS - Stainless steel (shown)
• Model PDWT400PWW - White on white
• Model PDWT400PBB - Black on black
