GE GDT550HSDSS User manual

Dishwashers
Owner’s Manual
49-55082-4 01-13 GE
Safety Instructions............. 2-3
Operating Instructions
Care and Cleaning .................. 11
GettingStarted..................... 4-5
Loading and Place Settings ......... 8-9
Loading the silverware baskets ...... 10
UsingtheDishwasher...............6-7
Troubleshooting Tips.........12-14
Consumer Support
Consumer Support....................16
Warranty ............................15
GEAppliances.com
Write the model and serial
numbers here:
Model # _________________
Serial # __________________
You can find them on the tub wall
just inside the door.
FRONT CONTROL MODELS TOP CONTROL MODELS
Lave-vaisselle
Lavaplatos
Manuel d’utilisation
Manual del propietario
La section française commence à la page 17
La sección en español empieza en la página 33
Dishwashers
GDF510-540 Series
GDT530-550 Series

2
IMPORTANT SAFETY INFORMATION
5($'$//,16758&7,216%()25(86,1*³
SAVE THESE INSTRUCTIONS
WARNING!
For your safety, the information in this manual must be followed to minimize the risk of fire,
explosion, electric shock, and to prevent property damage, personal injury, or death.
WATER HEATER SAFETY
PROPER INSTALLATION AND MAINTENANCE
This dishwasher must be properly installed and located in accordance with the Installation Instructions
before it is used. If you did not receive an Installation Instructions sheet with your dishwasher, you can
receive one by visiting our Website at GEAppliances.com. In Canada, visit www.GEAppliances.ca.
Connect the dishwasher/appliance to a grounded
metal, permanent wiring system; or run an
equipment-grounding conductor with the circuit
conductors and connect to the equipment-
grounding terminal or lead of the appliance.
Improper connection of the equipment-grounding
conductor can result in a risk of electric shock. Check
with a qualified electrician or service representative
if you are in doubt whether the appliance is properly
grounded.
Dispose of discarded appliances and shipping
or packing material properly.
Do not attempt to repair or replace any part
of your dishwasher unless it is specifically
recommended in this manual. All other servicing
should be referred to a qualified technician.
To minimize the possibility of electric shock,
disconnect this appliance from the power supply
before attempting any maintenance.
NOTE: Turning the dishwasher off does not
disconnect the appliance from the power supply. We
recommend having a qualified technician service
your appliance.
WARNING!
Under certain conditions, hydrogen gas may be produced in a water heater that has not been used for two or
more weeks. HYDROGEN GAS IS EXPLOSIVE.
If the hot water has not been used for two or more weeks, prevent the possibility of damage or injury by turning
on all hot water faucets and allow them to run for several minutes. Do this before using any electrical appliance
connected to the hot water system. This simple procedure will allow any built-up hydrogen gas to escape. Since
the gas is flammable, do not smoke, use an open flame, or use the appliance during this process.
Use this appliance only for its intended purpose
as described in this Owner’s Manual.
Do not operate your dishwasher unless all enclosure
panels are properly in place.
Do not store or use combustible materials, including
gasoline or other flammable liquids or vapors in the
vicinity of this or any other appliance.
Do not abuse, sit on or stand on the door or dish rack
of the dishwasher.
Do not tamper with controls.
Do not wash plastic items unless marked
dishwasher safe or the equivalent. For plastic
items not so marked, check the manufacturer’s
recommendations.
WARNING! When using your dishwasher, follow basic precautions,
including the following:
WARNING!

3
IMPORTANT SAFETY INFORMATION
5($'$//,16758&7,216%()25(86,1*³
SAVE THESE INSTRUCTIONS GEAppliances.com
During or after wash cycle, contents may be hot to
the touch. Use care before handling.
Using a detergent that is not
specifically designed for dishwashers
will cause the dishwasher to fill with
suds.
Non-Dishware Items: Do not wash items such
as electronic air cleaner filters, furnace filters
and paint brushes in your dishwasher. Damage
to the dishwasher and discoloration or staining
of the dishwasher may result.
Close supervision is necessary if this appliance
is used by or near children.
Load light-weight, plastic items so they do not
become dislodged and drop to the bottom of the
GLVKZDVKHU³WKH\PLJKWFRPHLQWRFRQWDFWZLWK
the heating element and be damaged.
Locate sharp items so that they are not likely to
damage the door seal.
Load sharp knives with the handles up to reduce the
risk of cut-type injuries.
Do not allow children to play around the dishwasher
when opening or closing the door due to the
possibility of small fingers being pinched in the door.
Do not touch the heating element during or
immediately after use.
CAUTION: To prevent minor injury and property damage
CAUTION: ELECTRICAL REQUIREMENTS
 This appliance must be supplied with 120V, 60 Hz,
and connected to an individual, properly grounded
branch circuit, protected by a 15 or 20 amp circuit
breaker or time-delay fuse.
If the electric supply provided does not meet the
above specifications, it is recommended that a
licensed electrician install an approved outlet.
Your dishwasher circuit should not be used for
any other appliance while the dishwasher is in
operation as the dishwasher requires the full
capacity of the circuit.
If the wall receptacle you plug the dishwasher’s
power cord into is controlled by a switch, turn on
the switch.
PROPER DISPOSAL OF THE DISHWASHER
Do not allow children to play with, on or inside this or any discarded appliance.
Junked or abandoned dishwashers are dangerous…even if they will sit for “just
a few days.” If you are getting rid of your old dishwasher, please follow the
instructions below to help prevent accidents.
Before You Throw Away Your Old Dishwasher:
Take off the door of the washing compartment or remove the latch by
removing the two screws from the latch receiver inside the tub (as shown).
WARNING! RISK OF CHILD ENTRAPMENT
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
If your dishwasher is connected to a wall
switch, ensure that the switch is on prior
to use.
If you choose to turn the wall switch
off between wash cycles, allow 5-10
seconds after turning the switch on before
touching Start to allow the control to
initialize.
Use only powder, Cascade®All-in-1 ActionPacs™,
liquid detergents or rinse agents recommended
for use in a dishwasher and keep them out of the
reach of children. Cascade®All-in-1 ActionPacs™
Automatic Dishwashing Detergent, and Cascade ®
Rinse Aid™ rinse agents have been approved for use
in all GE dishwashers.
NOTICE

4
Getting started!
Load Dishwasher
For best dishwashing results, follow the rack loading guidelines found in the Loading the dishwasher racks section. No pre-rinsing of
normal food soil is required. Scrape off hard soils, including bones, toothpicks, skins, and seeds. Remove leafy vegetables, meat trimmings,
and excessive amounts of grease or oil. Remove acidic food soils that can discolor stainless steel.
Add Detergent
Add needed amount of detergent to the detergent dispenser. Use a detergent such as Cascade Complete All-in-1 ActionPacs™. See Detergent
Dispenser in the Using the dishwasher section.
Add Rinse Agent
Add Rinse Agent to the rinse agent dispenser. See Use a Rinse Agent such as Cascade®Rinse Aid ™ in the Using the dishwasher section.
Select Cycle
Press the Select Cycle pad for the desired wash cycle. The light next to the Select Cycle pad will be on to indicate which wash cycle has been
selected.
The cycle may be selected with the door in the open position. The cycle will not start until after the door is closed and Start selected.
AutoSense This cycle automatically senses the soil level and adjusts the wash cycle accordingly.
(on some models)
Heavy This cycle is meant for heavily soiled dishes, cookware, pots, or pans with dried-on or baked-on soils.
Everyday dishes are safe to be used in this cycle.
Normal This cycle is meant for normal everyday soil levels and is designed to conserve both water and energy.
NOTE: Normal was used to rate the energy efficiency of this dishwasher.
Light This cycle is for light to medium soiled dishes. It is safe for china and crystal.
Rinse For rinsing partial loads that will be washed later. Do not use detergent. Detergent is not dispensed during the
(on some models) rinse cycle.
Select Options
The light by the selected pad will be ON to indicate which Option has been selected.
Wash Temp This option increases the temperature to help clean heavily soiled dishes and may increase the overall cycle time.
Boost Option may be turned On or Off during the wash cycle.
(on some models)
Wash Temp This option raises the water temperature in the final rinse to sanitize your dishware. The cycle length will
Sani vary depending on the temperature of your inlet water.
(on some models) NOTE:This option is monitored for sanitization requirements. If the cycle is interrupted during or after the main
wash portion or if the incoming water temperature is so low that adequate water heating cannot be achieved,
the sanitizing conditions may not be met. In these cases, the Sanitized light will not illuminate at the end of the
cycle. Utilizing this option will modify the cycle to meet the requirements of Section 6, NSF 184 for soil removal
and sanitization efficacy.
NOTE: NSF certified residential dishwashers are not intended for licensed food establishments.
Heated Dry Shuts off the heat drying option. Dishes air dry naturally and energy is saved. Open the dishwasher door to
Off speed drying.
Heated Dry Turns on the heater for faster drying. This cycle may extend the time to your wash cycle up to 48 minutes. This
On
option is not available with the Rinse cycle.
1
2
3
4
5
Features and appearance will vary throughout this manual

GEAppliances.com
Select Options (Continued)
Steam For use with heavily soiled and/or dried-on, baked-on soils. This option MUST be selected PRIOR to
(Prewash) starting the cycle. The Steam option adds approximately 30 minutes to the cycle time. This option is
(on some models) available with Heavy, Auto Sense, and Normal cycles.
Wash Selecting either the Upper or Lower Wash Zones will target dishwashing of just one rack. This will
Zones shorten the cycle time and conserve energy. This option can be used when there is only half a
(on some models) load of dishes.
Delay Delays the start of a wash cycle up to 8 to 12 hours depending on model. Press Delay Hours, to select
Hours the number of hours, then press Start one time to begin countdown. The cycle will start once allotted time
(on some models) has expired.
Control You can lock the controls to prevent selections from being made. You can also lock the controls
Lock after you have started a cycle to prevent cycle changes. For example, children cannot accidentally
start the dishwasher by pressing pads with this option selected.
To LOCK the dishwasher control,depending on the model, press and hold the Heated Dry pad for 3 seconds or
press and hold the Steam and Wash Temp pads at the same time for 3 seconds. The Control Lock light will turn
on to indicate the control is locked.
To UNLOCK the dishwasher control,depending on the model, press and hold the Heated Dry pad for 3 second
or press and hold the Steam and Wash Temp pads at the same time for 3 seconds. The Control Lock light
will turn off to indicate the control is unlocked.
Energy When connected to a smart meter and your electric company, the dishwasher will automatically delay starting
Smart a cycle during the more expensive peak demand times, and run when demand is low. However, you can override
the delay settings and use the dishwasher as needed. Learn more about Energy Smart under the Using the
Dishwasher section.
Start Dishwasher
Start Door can be open to select the desired options. Press the Start pad and close the door within 10 seconds
to start the cycle or begin the Delay Hours countdown. The wash cycle will begin shortly after closing
the door. If the door is open, the illuminated lights will turn off if a pad is not pressed within two minutes.
To activate the display, close and open the door or press any pad.
Interrupt To interrupt or pause a dish cycle, slowly open the door. Opening the door will cause the wash cycle to
or Pause pause. The dishwasher will beep every minute to remind you to close the door. To restart or resume
the cycle, press Start, and close the door.
Cancel To cancel a wash cycle, press and hold the Start pad for 3 seconds and close door. The dishwasher will drain,
emit a beep sound, and the wash cycle light will turn OFF.
Cycle Completion
Sanitized Displayed at the end of the cycle when Wash Temp Sani (Sanitize) has been selected and the dishwasher
has met the requirements for sanitization. See Wash Temp Sani, for complete option description.
Opening the door or pressing any key while the door is closed will turn off the light.
Clean Displayed when a wash cycle is complete. The light stays ON as a reminder that the dishes are clean. Opening
the door or pressing any key while the door is closed will turn the light off.
5
6
5
7

Using the dishwasher.
Check the Water Temperature
Use a Rinse Agent such as Cascade® Rinse Aid™
Rinse agents, such as Cascade®Rinse Aid™ are designed for great drying action and protect against spots
and film build-up on your dishes, glasses, flatware, cookware, and plastic.
Filling the Dispenser
The rinse agent dispenser holds 3.5 oz. (100 ml) of rinse agent. Under normal
conditions, this will last approximately one month.
1
Make sure the dishwasher door is fully open.
2
Open the RINSE AID dispenser door.
3
Slowly add rinse agent until the fill cup is full. May need to pause several times to
allow rinse aid to settle.
4
Clean up any spilled rinse agent with a damp cloth.
5
Close the RINSE AID dispenser door.
Rinse Aid Setting
The amount of rinse agent released into the final wash can be adjusted. The
factory setting is at the midpoint. If hard water spots appear on dishes, try a
higher setting. If you see foam in the dishwasher, move the indicator to a lower
setting.
To adjust the setting
Open the RINSE AID dispenser door; then turn the adjuster clockwise to
increase the amount of rinse agent, counterclockwise to reduce the amount of rinse agent.
The entering water should be at least 120°F (49°C) and
not more than 150°F (66°C) for effective cleaning and to
prevent dish damage. Check the water temperature with a
candy or meat thermometer. Turn on the hot water faucet
nearest the dishwasher, place the thermometer in a glass
and let the water run continuously into the glass until the
temperature stops rising.
Rinse
agent
adjuster
6
Indicator
window
Energy Smart
Energy Smart enables your dishwasher to reduce energy
consumption during periods of high energy costs. If you are
in an area where your electricity provider charges variable
rates at different times of the day, your dishwasher will
inform you of those times when you are paying the highest
rate. You can then either delay starting your dishwasher
until the rate goes down; or you can override the feature
and run your dishwasher at your convenience.
What you will need:
1
Smart Meter that will communicate with your
dishwasher. Consult your local electricity provider to
determine if the technology is available in your area.
2
An Energy Smart dishwasher model (GDF520, GDF540,
GDT530 or GDT550).
3
An Appliance Communication Module (ACM). Please
visit, gebrillion.com to order the communication device
that will need to be installed in the dishwasher.

GEAppliances.com
The detergent dispenser is located in the center of
the dishwasher door. It has two compartments. The
main wash compartment is found inside the detergent
dispenser. To open, press the blue button on the side of
the dispenser. The pre-wash compartment is on the lid of
the detergent dispenser. Use the pre-wash compartment
only when your water is extremely hard or when you have
a heavy soiled load.
You may use tablet, powder, liquid or gel automatic
dishwasher detergent. Make sure you use only detergents
specifically labeled for use in automatic dishwashers. Never
use liquid hand dish detergent in an automatic dishwasher.
Sudsing and poor wash performance will result with the use of
improper detergents.
Detergents should be stored in a dry location and in their
original container to prevent loss of effectiveness. Place
detergent in the cup just prior to starting the dishwasher and
then close the cover. The cover will open during the wash
cycle.
Filling the Detergent Dispenser
GE recommends using detergent in tablet or packet form.
Independent testing has shown this form of detergent is very
effective in the dishwasher. Cascade®All-in-1 ActionPacs™
are an example of this type of detergent. Simply put a tablet
or packet into the main wash compartment and close the
detergent cup cover. Please notice that the tablet or packet
must be placed in the main wash compartment of the
detergent cup. If the tablet or packet is tossed in the bottom of
the dishwasher, the detergent will be flushed down the drain
in a very short period of time and will thus be wasted. Wash
performance will be very poor as a result.
If you choose to use detergent in powder, liquid or gel form,
the amount of detergent you use will be determined by the
hardness of your water, the temperature of your water, and
the food soil load inside the dishwasher. Contact your water
company to get information about the hardness of the water
in your area. Water hardness is measured in grains per gallon.
Use this information and the table above to determine the
amount of detergent to use. You may purchase a hard water
test strip from GE. Call 1-800-626-2002 and ask for part
number WD01X10295. In Canada, call 1-800-661-1616
Using too much detergent with very soft and/or very
hot water may cause a condition called etching on your
glassware. Etching is a permanent cloudiness in your
glassware. This condition is irreversible. However, using too
little detergent will cause poor wash performance.
Use the table as a starting point and then adjust the amount
of detergent you use. Use just enough to get good wash
performance. Using just the right amount of detergent will
provide great wash performance without wasting detergent
or etching of glassware.
DO NOT USE HAND DISH DETERGENT
NOTE: Using a detergent that is not specifically designed
for dishwashers will cause the dishwasher to fill with suds.
During operation, these suds will spill out of the dishwasher
vents, covering the kitchen floor and making the floor wet.
Because so many detergent containers look alike, store the
dishwasher detergent in a separate space from all other
cleaners. Show anyone who may use the dishwasher the
correct detergent and where it is stored.
While there will be no lasting damage to the dishwasher, your
dishes will not get clean using a dishwashing detergent that is
not formulated to work with automatic dishwashers.
Detergent Dispenser
Number of
Grains/Gal. Detergent Cups to Fill
Less than 4 Fill cup to 1/3 full
4 to 8 Fill cup to 2/3 full
8 to 12 Fill cup completely full
Greater than 12 Fill both main wash cup and pre
wash cup
Detergent
Dispenser
7
Pre-Wash
Main
Wash
Rinse Agent

8
Loading and place settings.
For best dishwashing results, follow these loading guidelines. Features and appearance of racks and silverware
baskets may vary from your model.
Upper Rack
The upper rack is primarily for glasses, cups, and
saucers. However, other items such as pots, pans,
and plates may be placed in the upper rack. This is
also a secure place for dishwasher-safe plastic items.
The upper rack can be used for odd sized utensils.
Sauce pans, mixing bowls, and other similarly shaped
items should be placed face down for best wash
performance. Ensure small plastic items are secure
so that they cannot fall into the heater at the bottom
of the dishwasher, potentially damaging the item.
On some models, the upper rack may be adjusted
to accommodate larger items. To adjust the upper
rack, fully extend the upper rack and remove the two
plastic end caps on the front of the rails. Remove the
upper rack. Select the set of rollers on the side of the
rack that provides the desired height, and reinstall
the upper rack by guiding the rack rails between the
appropriate set of rollers. With the rack reinstalled,
replace the two plastic end caps, ensuring the snap
is properly engaged. Failure to properly engage
the end caps may result in the rack falling from the
dishwasher.
To add flexibility in loading, the utility shelf (on some
models) may be placed in the up or down position.
The shelf may also be used to secure stemware such
as wine glasses. Because these stemware items
come in various sizes, slowly push the rack in to
ensure the items do not bump into the edges of the
dishwasher, which may cause damage to the items.
It is important to ensure that items do not protrude
through the bottom of the rack or silverware basket
(on some models) where they will block the rotation
of the middle spray arm. This could result in noise
during operation and/or poor wash performance.
Check to make sure
that no items will block
rotation of the wash
arms.
8
End Cap
Rollers
Rail
Upper Rack - 10 Place Settings - GDF510 & GDF520 Upper Rack - 10 Place Settings - GDT530, GDF540 & GDT550
Upper Rack - 12 Place Settings - GDF510 & GDF520 Upper Rack - 12 Place Settings - GDT530, GDF540 & GDT550

9
Lower Rack
The lower rack is best used for plates, saucers and
cookware items. Large items, such as broiler pans
and baking racks should go along the sides of the
rack. If necessary, oversized glasses and mugs can
be placed in the lower rack to maximize loading
flexibility. Plates, saucers and similar items should be
placed between the tines in the direction that allows
the item to remain secure in the rack.
Do not load large items where they may block the
detergent dispenser when the door is closed.
The reversible tine blocks (on some models) are
designed to allow greater flexibility in loading dishes.
The direction of the tine blocks can be changed to
match preferred loading direction. To adjust the tine
block direction, remove the clips securing the tine
blocks to the racks by pulling up on the tab, then
flex the retaining wire to unseat the tine block from
the lower rack. The tine block may be turned in the
opposite direction to reverse the loading direction.
Secure the tine block to the rack using the same
process and be sure to snap the same clips in place.
WARNING! The clips can be a
choke hazard for small children. Keep out of
reach of children.
Fold down tines (on some models) allow for greater
flexibility in loading large items. Select the position
of the fold down tine that best accommodates
your dishware items. The direction of the fold down
tines can be changed to match preferred loading
direction. To adjust the fold down tine direction,
remove the clips securing the fold down tines to the
racks by sliding the clip so that it disengages from
the rack wire. The fold down tines may be rotated
in the opposite direction to reverse the loading
direction. Secure the fold down tines to the rack
using the same clips. The clip is removed by pulling
up on the clip and separating it from the rack.
Replace the clip on the opposite side of the rack by
positioning the clip over the wire and pressing down.
It is important to ensure that items do not protrude
through the bottom of the rack or the silverware
basket where they will block the rotation of the lower
spray arm. This could result in noise during operation
and/or poor wash performance.
Clip
GEAppliances.com
Lower Rack - 10 Place Settings - GDF510 & GDF520 Lower Rack - 10 Place Settings - GDT530, GDF540 & GDT550
Lower Rack - 12 Place Settings - GDF510 & GDF520 Lower Rack - 12 Place Settings - GDT530, GDF540 & GDT550

10
Silverware Basket
Place flatware in the removable silverware and
accessory baskets (on some models). Sharp objects,
such as forks and knives, may be placed with the
handles facing up, in order to protect your hands.
For the best wash performance, place other items
such as spoons with the handles facing down. Avoid
allowing items to nest together, which may keep
them from being properly washed. When loading,
distribute items evenly in the basket.
The silverware and accessory baskets (on some
models) may also be used for small items, such as
measuring spoons, baby bottle nipples, plastic lids,
or corn cob holders. The silverware basket covers (on
some models) can be closed to contain small items.
The door mounted silverware basket (on some
models) may be positioned either on the door by
securing the basket to the door using the two
mounting bosses, or to the rack by securing the
basket to the rack using the wire loop on the front of
the lower rack to engage the tabs on the rear of the
basket.
The accessory basket (on some models) may be
positioned by placing the hooks on the back of the
basket over the top wire on the sides of the lower
rack.
The FlexBaskets (on some models) may be positioned
on the front of either the upper or lower racks.
Secure the basket to the rack using the wire loop on
the front of the upper and lower racks to engage the
tabs on the rear of the basket.
Do not load large or tall utensils where they may
block the detergent dispenser or become trapped
between the door and the gasket when the door is
closed.
Loading the silverware baskets…
Silverware
Basket
Silverware
Basket
Wire Loops
Mounting
Bosses
Silverware Basket - 10 Place Settings - GDF510 & GDF520 Silverware Basket - 10 Place Settings - GDT530, GDF540 & GDT550
Silverware Basket - 12 Place Settings - GDF510 & GDF520 Silverware Basket
- 12 Place Settings - GDT530, GDF540 & GDT550
For best dishwashing results, follow these loading guidelines. Features and appearance of racks and silverware
baskets may vary from your model.

An air gap protects your dishwasher against water
backing up into it if a drain clogs. The air gap is not
a part of the dishwasher. It is not covered by your
warranty. Not all plumbing codes require air gaps,
so you may not have one.
The air gap is easy to clean.
1Turn off the dishwasher and lift off the cover.
2Remove the plastic cap and clean with
a toothpick. 11
Care and cleaning. GEAppliances.com
Cleaning the Control Panel
To clean the control panel, use a lightly dampened soft
cloth. Then dry thoroughly.
Does Your Dishwasher Have an Air Gap?
If your dishwasher is left in an unheated place during
the winter, ask a service technician to:
1Cut off electrical power to the dishwasher.
Remove fuses or trip circuit breaker.
2Turn off the water supply and disconnect the
water inlet line from the water valve.
3Drain water from the water inlet line and water
valve. (Use a pan to catch the water.)
4Reconnect the water inlet line to the water valve.
Protect Against Freezing
Cleaning the Exterior Door Panel
Before cleaning the front panel, make sure you know
what type of panel you have. Refer to the last two
letters of your model number. You can locate your
model number on the left-hand tub wall just inside
the door. If your model number ends with BB, CC,
WW, SA or ES then you have a painted door panel. If
your model number ends with SS, then you have a
Stainless Steel Door panel. If your model number ends
with II, then you have an Integrated door panel.
Follow the instructions below for cleaning the door
panel for your specific model.
Painted Door Panel (model numbers ending in BB–
black, CC–bisque, WW–white, SA-silver or ES-slate)
Use a clean, soft, lightly dampened cloth, then dry
thoroughly. You may also use a good appliance wax
or polish.
Stainless Steel Door Panel (model numbers ending in
SS)
The stainless steel panels can be cleaned with
Stainless Steel Magic or a similar product using a clean,
soft cloth. Do not use appliance wax, polish, bleach or
products containing chlorine on Stainless Steel doors.
You can order Stainless Steel Magic #WX10X15
through GE Parts by calling 800.626.2002. In Canada,
call 1-800-661-1616.
Integrated Door Panel (model numbers ending in II)
This is a custom installed door panel, and you
will need to refer to the cabinet manufacturers
recommendations for proper cleaning.
Do not use scouring pads or powered cleaners
because these products can scratch the finish.
Stainless Steel Inner Door
The stainless steel used to make the dishwasher tub
and inner door provides the highest reliability available
in a GE dishwasher.
If the dishwasher tub or inner door should be
scratched or dented during normal use, they will
not rust or corrode. These surface blemishes will
not affect their function or durability.
Check the air gap any
time your dishwasher
isn’t draining well.
Air gap
Ultra-Fine Filter
To clean the Ultra-Fine Filter,
remove the bottom rack. Twist and
remove the large round filter. Rinse
filter with warm soapy water and
use a sponge to carefully remove
any stubborn particles. Scrubbing
with scouring pads or brushes can
damage the filter. Once cleaned,
replace the Ultra-Fine Filter, and
twist to lock in place.
Fine Filter
To clean the Fine Filter (mesh plate), remove the
bottom rack. Remove the Ultra-Fine Filter. Twist
each of the two retaining posts located toward the
back bottom of the tub, and remove the Fine Filter.
Rinse filter with warm soapy water. Scouring pads
or brushes can damage the filter but a soft brush or
sponge may be needed to remove stubborn soils or
calcium deposits caused by hard water. Once cleaned,
replace the Fine Filter, the Ultra-Fine Filter, and twist
the two retaining posts into place.
WARNING! The retaining posts can
be a choke hazard for small children. Keep out of
reach of children.
Retaining Posts Spray Arm
Fine
Filter Ultra-Fine
Filter
Inspect the filters periodically, every other month or so depending on usage, and clean if necessary. If there is a
decrease in wash performance or dishes feel gritty, this is also an indication the filters need to be cleaned.
Cleaning the Filters

Before you call for service…
Troubleshooting Tips
Save time and money! Review the charts on the following pages, or visit GEAppliances.com.
In Canada visit www.GEAppliances.ca. You may not need to call for service.
Problem Possible Causes What To Do
Start Status The door was opened or the   3UHVVWKHStart pad once to start the dishwasher. Press the
indicator light flashing cycle was interrupted. Start pad a second time when the dishwasher is running only if you
wish to cancel the cycle.
Dishwasher BEEPS This is a reminder that yourPress Start and close the door.
once every minute dishwasher door has been left
open during operation. It will
continue beeping until you press
Start and close the door.
Beeping at the end This is normal. The dishwasher   7RWXUQRIIWKHGRXEOHEHHSLQGLFDWRURUUHDFWLYDWHLWLILWZDVSUHYLRXVO\
of the cycle will beep twice at the end of the turned off), press the Heated Dry pad 5 times within 3 seconds.
(on some models) cycle. A triple beep will sound to indicate the end-of-cycle beep option
has been turned on or off.
Dishes and flatware Ultra fine or fine filter is clogged  6HHWKHCare and cleaning section.
not clean Low inlet water temperature  0DNHVXUHLQOHWZDWHUWHPSHUDWXUHLVFRUUHFWVHHWKH Using the dishwasher
section). Turn on the hot water faucet nearest the dishwasher, let run until
the water temperature stops rising. Then start the dishwasher and turn
off the faucet. This ensures the entering water is hot. Select Wash Temp Boost if
available.
Water pressure is temporarily low 7XUQRQDIDXFHW,VZDWHUFRPLQJRXWPRUHVORZO\WKDQXVXDO",IVRZDLW
until pressure is normal before using your dishwasher.
Air gap or disposer is clogged  &OHDQWKHDLUJDSRUIOXVKWKHGLVSRVHU
Improper rack loading  0DNHVXUHODUJHGLVKZDUHGRHVQRWEORFNWKHGHWHUJHQWGLVSHQVHURUWKH
wash arms. See the Loading the dishwasher racks section.
When large utensils are placed in the silverware basket, do not mount the basket
on the door (on some models). Instead, mount basket on the lower rack.
Poor performing detergent  8VHDKLJKO\UDWHGGHWHUJHQWVXFKDVCascade Complete ®All-in-1 ActionPacs™.
Spots and filming Extremely hard water  8VHULQVHDJHQWVVXFKDV Cascade ®Rinse Aid™to remove spots
on glasses and and prevent new film buildup.
flatware If water is extremely hard, a softener may be required.
Low inlet water temperature  0DNHVXUHZDWHUWHPSHUDWXUHLVDWOHDVW)
Overloading or improper  /RDGGLVKZDVKHUDVVKRZQLQWKHLoading Place Settings section.
loading of the dishwasher
Old or damp powder detergent  0DNHVXUHGHWHUJHQWLVIUHVK
Rinse agent dispenser empty  5HILOOZLWKULQVHDJHQWVXFKDVCascade ®Rinse Aid™.
Too little or low performing  0DNHVXUH\RXXVHWKHSURSHUDPRXQWRIKLJKO\UDWHGGHWHUJHQW
detergent
12

Problem Possible Causes What To Do
Cloudiness on Combination of soft water and   7KLVLVFDOOHGHWFKLQJDQGLVSHUPDQHQW7RSUHYHQWWKLVIURPKDSSHQLQJ
glassware too much detergent use less detergent if you have soft water. Wash glassware in the shortest
cycle that will get it clean.
Low performing phosphate  6HHA white film on glassware, dishware and the interior in this
free detergent Troubleshooting section.
Water temperature entering the   7KLVFRXOGEHHWFKLQJ/RZHUWKHZDWHUKHDWHUWHPSHUDWXUH
dishwasher exceeds 150°F (66°C)
Suds in the tub Correct detergent  8VHRQO\DXWRPDWLFGLVKZDVKHUGHWHUJHQWVWRDYRLGVXGVLQJCascade®
wasn’t used Automatic Dishwashing Detergents have been approved for use in all
GE dishwashers.
   7RUHPRYHVXGVIURPWKHWXERSHQWKHGLVKZDVKHUDQGOHWVXGVGLVVLSDWH
Pump out water by pressing Start and close the door. Wait 30 seconds.
Open the door, press and hold Start for 3 seconds, and close the door.
Repeat if necessary.
Rinse agent was spilled  $OZD\VZLSHXSULQVHDJHQWVSLOOVLPPHGLDWHO\
Detergent left in Dishes are blocking the  5HSRVLWLRQWKHGLVKHVVRWKHZDWHUIURPWKHORZHUVSUD\DUPFDQIOXVK
dispenser cups detergent cup the detergent cup. See the Loading the dishwasher racks section.
Black or gray Aluminum utensils have  5HPRYHPDUNVZLWKDPLOGDEUDVLYHFOHDQHU
marks on dishes rubbed against dishes
Dishes don’t dry Low inlet water temperature  0DNHVXUHLQOHWZDWHUWHPSHUDWXUHLVDWOHDVW)
   6HOHFWHeated Dry.
   8VHWash Temp Boost option.
   6HOHFWDKLJKHUF\FOHVXFKDVWash Temp Sani ( Sanitize) or Heavy.
Rinse agent dispenser is empty  &KHFNWKHULQVHDJHQWGLVSHQVHUDQGILOODVUHTXLUHG
Control panel responded Door may not be completely   0DNHVXUHWKHGRRULVILUPO\FORVHG
to inputs but dishwasher closed
never filled with water
Water valve may be turned off  0DNHVXUHZDWHUYDOYHXVXDOO\ORFDWHGXQGHUWKHVLQNLVWXUQHGRQ
Stained tub interior Some tomato-based foods can   8VHRIWKH Steam cycle (on some models) after adding the dish to the load
cause reddish stains can decrease the level of staining.
Tea or coffee stains  5HPRYHWKHVWDLQE\KDQGXVLQJDVROXWLRQRIFXSEOHDFKDQG
3 cups warm water. NOTE: Do not use bleach on stainless steel
tub or inner door.
CAUTION!
Before cleaning interior, wait at least 20 minutes after a cycle for the
heating elements to cool down. Failure to do so can result in burns.
An overall yellow or brown film can  $VSHFLDOILOWHULQWKHZDWHUVXSSO\OLQHLVWKHRQO\ZD\WRFRUUHFW
be caused by iron deposits in water this problem. Contact a water softener company.
:KLWHILOPRQLQVLGHVXUIDFH³   *(UHFRPPHQGVCascade ®Rinse Aid™to help prevent hard water
hard water minerals mineral deposits from forming.
   5XQGLVKZDVKHUZLWKFLWULFDFLGWRUHPRYHPLQHUDOGHSRVLWV&LWULFDFLG 
(Part number: WD35X151) can be ordered through GE Parts. See back
cover for ordering information.
Dishwasher won’t run Fuse is blown or circuit breaker   5HSODFHIXVHRUUHVHWFLUFXLWEUHDNHU5HPRYHDQ\RWKHUDSSOLDQFHVIURP
is tripped the circuit.
Power is turned off  ,QVRPHLQVWDOODWLRQVWKHSRZHUWRWKHGLVKZDVKHULVSURYLGHGWKURXJKD
wall switch, often located next to the disposer switch. Make sure it is on.
Control panel is locked  8QORFNFRQWUROSDQHO6HHWKHGetting started section.
13
GEAppliances.com

Problem Possible Causes What To Do
Control panel lights Time too long between  (DFKSDGPXVWEHWRXFKHGZLWKLQVHFRQGVRIWKHRWKHUV
go off when you’re touching of selected pads To relight, touch any pad again or open the door and
setting controls unlock (top control).
Water standing in Air gap is clogged  &OHDQWKHDLUJDS6HHWKHCare and cleaning section.
the bottom of the tub
Water won’t pump Drain is clogged  ,I\RXKDYHDQDLUJDSFOHDQLW6HHWKHCare and cleaning section.
out of the tub   ,IWKHGLVKZDVKHUGUDLQVLQWRDGLVSRVHUUXQGLVSRVHUFOHDU
   &KHFNWRVHHLI\RXUNLWFKHQVLQNLVGUDLQLQJZHOO,IQRW\RX
may need a plumber.
Steam This is normal  :DUPPRLVWDLUFRPHVWKURXJKWKHYHQWGXULQJGU\LQJDQGZKHQ
water is being pumped out. This is necessary for drying.
Sanitized light does The door was opened and the   'RQRWLQWHUUXSWWKHF\FOHE\RSHQLQJWKHGRRUGXULQJWKHZDVKF\FOH
not illuminate at the cycle was interrupted during
end of the cycle final rinse
The incoming water   5DLVHWKHZDWHUKHDWHUWHPSHUDWXUHWREHWZHHQ)DQG)
temperature was too low
Noise Normal operating sounds:  7KHVHDUHDOOQRUPDO1RDFWLRQLVUHTXLUHG
Detergent cup opening
Water entering dishwasher
The motor stops and starts at
various times during the cycle
Spray arms start and stop at
various times
Drain pump sounds during
pump out
Drain pump starts and stops
several times during each drain
Rattling dishes when the spray   0DNHVXUHGLVKHVDUHSURSHUO\ORDGHG6HHWKH Loading the
arm rotates dishwasher racks section.
Rattling silverware against door  7DOOXWHQVLOVPD\EHSODFHGLQWKHXSSHUUDFNWRDYRLGEXPSLQJDJDLQVW
during wash inner door during wash cycle.
A white film on This problem caused by  7RUHPRYHWKHZKLWHILOPUXQ\RXUGLVKHVWKURXJKDGLVKZDVKHUF\FOHZLWK
glassware, dishware phosphate-free dishwasher citric acid. Use a WD35X151 citric acid kit found online.
and the interior detergent Pour the citric acid in the detergent cup and close the cover. Place the filmed
but otherwise clean glassware and dishware in the dishwasher. Leave
silverware and other metal items out of the dishwasher. Turn the dishwasher
on and let it run through a complete cycle without detergent. The glassware,
dishware, and dishwasher should come out film free. Alternatively,
a vinegar rinse may be used. Pour 1 cup of vinegar into dishwasher just after
the detergent cup opens and let the dishwasher complete its cycle.
This may be repeated several times a year as needed
The use of a rinse agent such as Cascade ®Rinse Aid™may help minimize
a repeat build up of film. Also, the use of a highly rated detergent such as
Cascade Complete
®All-in-1 ActionPacs™will help prevent film build-up.
Before you call for service…
14

15
What Is Not Covered (for customers in Canada):
Service trips to your home to teach you how to use
the product.
Improper installation.
If you have an installation problem, contact your dealer
or installer. You are responsible for providing adequate
electrical, exhausting and other connecting facilities.
Failure of the product if it is abused, misused, or used for
other than the intended purpose or used commercially.
Replacement of house fuses or resetting of circuit breakers.
Damage to the product caused by accident, fire, floods
or acts of God.
Damage caused after delivery.
For The Period Of: GE Will Replace:
One Year Any part of the dishwasher which fails due to a defect in materials or workmanship. During
From the date of the this limited one-year warranty, GE will also provide, free of charge, all labor and in-home
original purchase service to replace the defective part.
What GE Will Not Cover (for customers in the United States):
Service trips to your home to teach you how to use
the product.
Improper installation, delivery or maintenance.
Failure of the product if it is abused, misused, or used for
other than the intended purpose or used commercially.
Replacement of house fuses or resetting of circuit breakers.
Product not accessible to provide required service.
Damage to the product caused by accident, fire, floods
or acts of God.
Incidental or consequential damage caused by possible
defects with this appliance.
Cleaning or servicing of the air gap device in the drain line.
Damage caused after delivery, including damage from
items dropped on the door.
This warranty is extended to the original purchaser and any succeeding owner for products purchased for home use within the USA.
If the product is located in an area where service by a GE Authorized Servicer is not available, you may be responsible for a trip charge
or you may be required to bring the product to an Authorized GE Service location for service. Proof of original purchase date is needed
to obtain service under the warranty. In Alaska, the warranty excludes the cost of shipping or service calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty gives you specific legal
rights, and you may also have other rights which vary from state to state. To know what your legal rights are, consult your local or
state consumer affairs office or your state’s Attorney General.
Warrantor: General Electric Company. Louisville, KY 40225
This warranty is extended to the original purchaser and any succeeding owner for products purchased in Canada for home use within
Canada. In home warranty service will be provided in areas where it is available and deemed reasonable by Mabe to provide.
Staple your receipt here.
Proof of the original purchase
date is needed to obtain service
under the warranty.
GE Dishwasher Warranty. GEAppliances.com
All warranty service provided by our Factory Service Centers, or an
authorized Customer Care®technician. To schedule service, visit us on-line
at GEAppliances.com, or call 800.GE.CARES (800.432.2737) in the United
States. In Canada, call 1.800.561.3344. Please have serial number and
model number available when calling for service.
WARRANTOR IS NOT RESPONSIBLE FOR CONSEQUENTIAL DAMAGES.
(;&/86,212),03/,(':$55$17,(6³<RXUVROHDQGH[FOXVLYHUHPHG\LVSURGXFWUHSDLUDVSURYLGHGLQWKLV/LPLWHG
Warranty. Any implied warranties, including the implied warranties of merchantability or fitness for a particular purpose,
are limited to one year or the shortest period allowed by law.
(;&/86,212),03/,(':$55$17,(6³<RXUVROHDQGH[FOXVLYHUHPHG\LVSURGXFWUHSDLUDVSURYLGHGLQWKLV/LPLWHG
Warranty. Any implied warranties, including the implied warranties of merchantability or fitness for a particular purpose,
are limited to one year or the shortest period allowed by law.
Warrantor: MC Commercial, Burlington, ON, L7R 5B6
Servicing your appliance may require the use of the onboard data port for diagnostics. This gives a GE
Factory Service technician the ability to quickly diagnose any issues with your appliance and helps GE
improve its products by providing GE with information on your appliance. If you do not want your appliance
data to be sent to GE, please advise your technician NOT to submit the data to GE at the time of service.

16
Consumer Support.
GE Appliances Website
+DYHDTXHVWLRQRUQHHGDVVLVWDQFHZLWK\RXUDSSOLDQFH"7U\WKH*($SSOLDQFHV:HEVLWHKRXUVDGD\
any day of the year! For greater convenience and faster service, you can now download Owner’s Manuals,
order parts or even schedule service on-line.
Schedule Service
Expert GE repair service is only one step away from your door. Get on-line and schedule your service at your
convenience any day of the year! Or call 800.GE.CARES (800.432.2737) during normal business hours.
In Canada, call 800.561.3344
Real Life Design Studio In the US: GEAppliances.com
*(VXSSRUWVWKH8QLYHUVDO'HVLJQFRQFHSW³SURGXFWVVHUYLFHVDQGHQYLURQPHQWVWKDWFDQEHXVHGE\SHRSOHRI
all ages, sizes and capabilities. We recognize the need to design for a wide range of physical and mental abilities
and impairments. For details of GE’s Universal Design applications, including kitchen design ideas for people with
disabilities, check out our Website today. For the hearing impaired, please call 800.TDD.GEAC (800.833.4322).
In Canada, please write to: Director, Consumer Relations, MC Commercial
1 Factory Lane, Suite 310
Moncton, N.B. E1C 9M3
Extended Warranties
Purchase a GE extended warranty and learn about special discounts that are available while your warranty is still
in effect. You can purchase it on-line anytime, or call 800.626.2224 during normal business hours. GE Consumer
Home Services will still be there after your warranty expires. In Canada, please consult your local listings for your
extended warranty provider.
Parts and Accessories In the US: GEAppliances.com
Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes
(VISA, MasterCard and Discover cards are accepted). Order on-line today, 24 hours every day or by phone at
800.626.2002 during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing generally
should be referred to qualified service personnel. Caution must be exercised, since improper servicing may
cause unsafe operation.
In Canada, call 800.661.1616
Contact Us
If you are not satisfied with the service you receive from GE, contact us on our Website with all the details including
your phone number, or write to: General Manager, Customer Relations
GE Appliances, Appliance Park
Louisville, KY 40225
In Canada, please write to: Director, Consumer Relations, MC Commercial
1 Factory Lane, Suite 310
Moncton, N.B. E1C 9M3
Register Your Appliance
5HJLVWHU\RXUQHZDSSOLDQFHRQOLQH³DW\RXUFRQYHQLHQFHTimely product registration will allow for enhanced
communication and prompt service under the terms of your warranty, should the need arise. You may also
mail in the pre-printed registration card included in the packing material.
In the US: GEAppliances.com
In Canada: GEAppliances.ca
In the US: GEAppliances.com
In Canada: GEAppliances.ca
In the US: GEAppliances.com
In Canada: GEAppliances.ca
In the US: GEAppliances.com
In Canada: GEAppliances.ca
In the US: GEAppliances.com
In Canada: GEAppliances.ca

CONSIGNES DE SÉCURITÉ.. 18-19
DIRECTIVES DE FONCTIONNEMENT
Chargement et couverts de la vaisselle
.....................................................................24, 25
Chargement de panier à couverts... 26
Entretien et nettoyage........................... 27
Tableau de commande
et réglages........................................... 20–21
Utilisation du lave-vaisselle.......... 22–23
DÉPANNAGE................................... 28-30
SERVICE À LA CLIENTÈLE
Garantie........................................................ 31
Service à la clientèle................................... 32
Inscrivez ci-dessous les numéros
de modèle et de série :
N° de modèle _______________
N° de série __________________
Ils se trouvent sur la paroi de la cuve,
à l’intérieur de la porte.
17
Modèles avec commandes à l'avant
Modèles avec commandes sur le dessus

18
CONSIGNES DE SÉCURITÉ IMPORTANTES
VEUILLEZ LIRE TOUTES LES CONSIGNES AVANT D’UTILISER
/·$33$5(,/³&216(59(=&(6',5(&7,9(6
AVERTISSEMENT!
Pour votre sécurité, veuillez suivre les directives données dans le présent manuel afin de
réduire au minimum les risques d’incendie, d’explosion et de chocs électriques et prévenir tout
dommage et blessure grave ou mortelle.
SÉCURITÉ DU CHAUFFE-EAU
INSTALLATION ET ENTRETIEN
Ce lave-vaisselle doit être correctement installé, en conformitéavec les directives d’installation fournies,
avant d’être utilisé. Si vous n’avez pas reçu les directives d’installation avec votre appareil, vous pouvez vous
les procurer en visitant notre site Web à l’adresse www.electromenagersge.ca.
■Cet appareil doit être relié à un système
de câblage électrique permanent en métal, mis
à la terre. Sinon, un fil de mise à la terre pour
appareillage doit être installé et raccordé à la borne
ou au fil de mise à la terre de l’appareil.
■Un raccordement incorrect du fil de mise à la terre
peut présenter un risque d’électrocution. Consultez
un électricien ou un technicien qualifié si vous n’êtes
pas certain que l’appareil est correctement mis à la
terre.
■Veuillez vous débarrasser de la façon appropriée
de vos vieux électroménagers et des matériaux
d’emballage ou d’expédition.
■Ne tentez pas de réparer ou de remplacer une pièce
quelconque de votre lave-vaisselle, à moins que cela
ne soit spécifiquement recommandé dans le présent
manuel. Confiez toutes les autres réparations à un
technicien qualifié.
■Pour réduire au minimum les risques d’électrocution,
débranchez l’appareil de sa source d’alimentation
avant d’en effectuer l’entretien.
REMARQUE : Le fait d’arrêter le lave-vaisselle
ne coupe l’alimentation électrique de l’appareil. Nous
vous recommandons de confier la réparation
de votre électroménager à un technicien qualifié.
AVERTISSEMENT!
Dans certaines conditions, il peut se former de l’hydrogène dans un chauffe-eau qui n’a pas étéutilisépendant
deux semaines ou plus. L’HYDROGÈNE EST UN GAZ EXPLOSIF.
Si vous n’avez pas utilisé votre chauffe-eau pendant deux semaines ou plus, ouvrez tous les robinets d’eau
chaude et laissez couler l’eau pendant plusieurs minutes afin de réduire les risques de dommages matériels ou
de blessures. Prenez cette précaution avant même d’utiliser un électroménager raccordé au chauffe-eau pour
éliminer l’hydrogène qui pourrait s’y être accumuléé. Puisqu’il s’agit d’un gaz inflammable, ne fumez pas ou
n’utilisez pas une flamme nue ou un électroménager au cours de ce processus.
■N’utilisez cet appareil que pour l’usage pour lequel
il a été conçu, comme expliqué dans le présent
manuel.
■Ne faite pas fonctionner le lave-vaisselle si tous
les panneaux de la carrosserie n’ont pas été
correctement réinstallés.
■
Ne rangez ni n'utilisez des matières combustibles, y
compris de l'essence ou d'autres liquides ou vapeurs
inflammables, à proximité de cet appareil ou de tout autre.
■N’utilisez pas le lave-vaisselle de façon abusive,
et ne vous assoyez pas ou ne montez pas sur
la porte ou les paniers de l’appareil.
■Ne modifiez pas le fonctionnement des commandes.
■Ne lavez pas les articles en plastique à moins qu’ils
ne portent la mention « Lavable au lave-vaisselle »
ou l’équivalent. Si certains articles en plastique
ne portent pas cette mention, reportez-vous aux
recommandations du fabricant.
AVERTISSEMENT! Lors du fonctionnement de votre lave-vaisselle, prenez les
précautions de base, notamment les suivantes :
AVERTISSEMENT!
APPROPRIÉS

CONSIGNES DE SÉCURITÉ IMPORTANTES
VEUILLEZ LIRE TOUTES LES CONSIGNES AVANT D’UTILISER
/·$33$5(,/³&216(59(=&(6',5(&7,9(6 www.electromenagersge.ca
■Pendant ou après le cycle de lavage, le contenu
peut s'avérer très chaud au toucher. Manipulez-le
avec soin.
■L’utilisation d’un détergent non
conçu pour les lave-vaisselles peut
provoquer la formation de mousse.
■Articles autres que la vaisselle : ne lavez pas
dans le lave-vaisselle des articles comme des
filtres de purificateur d’air, des filtres de systèmes
de chauffage ou des pinceaux. Vous pourriez
endommager le lave-vaisselle et provoquer une
décoloration ou des taches dans l’appareil.
■Une surveillance attentive est nécessaire lorsque cet
appareil est utilisé par ou près des enfants.
■ Placez les articles légers en plastique de manière
qu’ils ne se déplacent pas ou ne tombent pas au fond
GHO·DSSDUHLO³LOVSRXUUDLHQWHQWUHUHQFRQWDFWDYHF
l’élément chauffant, ce qui pourrait les endommager.
■Placez les articles coupants de manière à ce qu’ils
n’endommagent pas le joint d’étanchéité de la porte.
■Placez dans le panie r à couverts les couteaux
tranchants le manche vers le haut afin de réduire
les risques de coupures.
■
Ne laissez pas les enfants jouer à proximité du lave-
vaisselle lorsque vous ouvrez ou fermez la porte afin
d’éviter que leurs petits doigts se coincent dans la porte.
■Ne touchez pas à l’élément chauffant pendant ou
immédiatement après le fonctionnement de l’appareil.
ATTENTION : Pour éviter les blessures mineures ou les dommages matériels
ATTENTION : EXIGENCES ÉLECTRIQUES
■ Cet appareil électroménager doit être alimenté par
du courant de 120V, 60 Hz, et branchéà un circuit de
dérivation bien mis à la terre, protégé par un fusible à
retardement ou un disjoncteur de 15 ou 20 ampéres.
■Si l’alimentation électrique fournie ne remplit
pas les caractéristiques ci-dessus, nous
vousrecommandons de faire installer par un
électricien qualifié une bonne prise.
■Le circuit de votre lave-vaisselle ne doit être
utilisépar aucun autre appareil électroménager
quandle lave-vaisselle fonctionne, car le lave-
vaissellenécessite toute la capacité du circuit.
■Si la prise murale dans laquelle vous branchez
le cordon d’alimentation de votre lave-vaisselle
est contrôlé par un interrupteur, mettez
cetinterrupteur en position ON (marche).
ÉLIMINATION APPROPRIÉE DU LAVE-VAISSELLE
AVERTISSEMENT! RISQUE DE SUFFOCATION POUR
UN ENFANT COINCÉ À L’INT RIEUR DE L’APPAREIL
VEUILLEZ LIRE ET SUIVRE À LA LETTRE CES CONSIGNES DE SÉCURITÉ.
CONSERVEZ CES DIRECTIVES
Ne laissez pas les enfants jouer avec le lave-vaisselle, ou à l’intérieur de celui-ci ou de tout
autre électroménager mis aux rebuts.
Les lave-vaisselle jetés ou abandonnés sont dangereux… même si vous ne les laissez
là que pour quelques jours. Si vous voulez jeter votre vieux lave-vaisselle, veuillez
suivre les directives ci-dessous pour éviter les accidents.
Avant de jeter votre vieux lave-vaisselle :
■Enlevez la porte du compartiment de lavage ou enlevez le verrou en ôtant les deux
vis du récepteur de verrou à l'intérieur de la cuve (tel qu'illustré).
NOTICE
■ Si votre lave-vaisselle est branché sur un circuit relié
à un interrupteur mural, assurez-vous d’actionner
celui-ci avant d’utiliser votre appareil.
■Si vous fermez l’interrupteur mural entre les
cycles de lavage, attendez de 5 à 10 secondes
après avoir ramené l’interrupteur à ON (Marche)
avant d’appuyer sur la touche Start (Marche) pour
permettre aux commandes de se réinitialiser.
■ N’utilisez que les détergents et agents de rinçage
liquides, en poudre ou en tablette ou les Cascade
Complete®All-in-1 ActionPacs™recommandés pour les
lave-vaisselle et gardez-les hors de la portée des enfants.
Les détergents pour lave-vaisselle Cascade Complete®
All-in-1 ActionPacs™et les agents de rinçage Cascade®
Rinse Aid™ sont approuvés avec les lave-vaisselle GE.
19

20
Pour démarrer!
Les caractéristiques et l'apparence des appareils varieront tout au long de ce manuel.
Charger le lave-vaisselle
Pour de meilleurs résultats de lavage, suivez les directives de chargement des paniers dans la section Chargement des paniers du lave-
vaisselle. Aucun pré-rinçage des dépôts alimentaires normaux n'est nécessaire. Enlevez les dépôts durs, notamment les os, les cure-dents,
la peau et les graines. Enlevez les légumes-feuilles, les parties non comestibles de la viande et les quantités excédentaires de graisse ou
d'huile. Enlevez les dépôts alimentaires acides qui peuvent décolorer l'acier inoxydable.
Ajouter le détergent
Ajoutez la quantité de détergent requise dans le distributeur à détergent. Utilisez un détergent du type Cascade Complete All-in-1 ActionPacs™.
Consultez la rubrique Distributeur de détergent dans la section Utilisation du lave-vaisselle.
Ajouter le produit de rinçage
Ajoutez le produit de rinçage dans le distributeur. Consultez la section Utilisation d’un produit de rinçage comme Cascade® Rinse Aid™ dans la
section Utilisation du lave-vaisselle.
Sélectionner le cycle
Appuyez sur la touche Select Cycle pour choisir le cycle de lavage désiré. Le voyant vis-à-vis de la touche Select Cycle s'allumera pour indiquer le
cycle qui a été choisi.
Le cycle peut être sélectionné même si la porte est ouverte. Le cycle ne démarrera qu'une fois la porte fermée et la commande Start sélectionnée.
AutoSense (certains modèles) Ce cycle détecte automatiquement le degré de saleté et règle le cycle de lavage en conséquence.
Heavy Ce cycle est destiné à la vaisselle et batterie de cuisine très sale, avec dépôts alimentaires séchés
ou cuits. Ce cycle convient aussi à la vaisselle de tous les jours.
Normal Normal Ce cycle est conçu pour la saleté normale de tous les jours et pour économiser l'eau et l'énergie.
REMARQUE : Le cycle Normal a servi à évaluer l'efficacité énergétique de ce lave-vaisselle.
Light Ce cycle est conçu pour la vaisselle de saleté légère à moyenne. Il convient à la porcelaine et au cristal.
Rinse Pour le rinçage de charges partielles qui seront lavées plus tard. N'utilisez pas de détergent. Le détergent n'est
(certains modèles) pas distribué pendant le cycle de rinçage.
Sélectionner les options
Le voyant vis-à-vis la touche sélectionnée S'ALLUMERA pour indiquer l'option qui a été sélectionnée.
Wash Temp Cette option augmente la température pour faciliter le lavage de la vaisselle très sale et elle peut allonger la durée totale
Boost du cycle. L'option peut être activée ou désactivée pendant le cycle de lavage.
(certains modèles)
Wash Temp Cette option augmente la température de l'eau lors du rinçage final afin de désinfecter la vaisselle.
Sani La durée du cycle variera selon la température de l'eau d'admission.
(certains modèles) REMARQUE : Cette option est contrôlée en fonction de critères de désinfection. Si le cycle est interrompu pendant
ou après l'étape du lavage principal, ou si la température de l'eau d'admission est si basse qu'un lavage adéquat
ne peut être obtenu, il se peut que les critères de désinfection ne soient pas atteints. Dans ce cas, le voyant
Sanitized ne s'allumera pas à la fin du cycle. L'utilisation de cette option modifiera le cycle pour satisfaire
à la Section 6 de la norme NSF 184 relative au délogement de la saleté et à l'efficacité de la désinfection.
REMARQUE : Les lave-vaisselle domestiques homologués NSF ne sont pas destinés aux établissements
alimentaires du commerce.
Heated Dry Désactive l'option de séchage avec chaleur. La vaisselle sèche naturellement à l'air et l'énergie est économisée.
Off Ouvrez la porte du lave-vaisselle pour accélérer le séchage.
Heated Dry Allume l'élément chauffant afin d'accélérer le séchage. Ce cycle prolongera le cycle de lavage de 30 minutes.
On NE PAS utiliser avec le cycle Rinse seulement.
1
2
3
4
5
