GE Spacemaker User manual

Spacemaker@ Dishwasher
❑
!
Safe~ instructions .........................3
❑
Operating Instructions, Tips
ApplianceRegistration..................................2
China, Crystal, Sterling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
CycleFeatures............................................4,5
CycleSelectionChart....................................5
DetergentGuide.............................................7
DispenserCups...............................................7
Drying Options ................................................4
Energy-Saving Tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Features ........................................................4, 5
Loading
.........................................................8, 9
Operatinginstructions..............................4,5
Rinse
Agent......................................................6
WaterTemperature........................................6
❑
;;? Care and Cleaning
Air Gap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
❑
●
Problem Solver .......................l 5-l7
More questions ?...call
GE Answer Center” 800.626.2000
❑
Preparation
Front Panel Change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
❑
..@
Consumer Services ...................l5
Important Phone Numbers . . . . . . . . . . . . . . . . . . . . . . . . 15
Model and Serial Numbers ..........................2
Repair Service
.................................................2
Warranty........................................BackCover
Model GSM603 ~
Winter Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
GE Appliances

HELP US HELP YOU...
Before using your
dishwasher, read this
guide carefully.
It is intended to help you
operate and maintain your new
dishwasher properly.
Keep it handy for answers to
your questions.
If you don’t understand something
If you received
a damaged dishwasher...
Immediately contact the dealer
(or builder) that sold you the
dishwasher.
Save time and money.
Before you request
service . . .
or need more help, write (include
your phone number):
Check the Problem Solver in the
back of this
guide. It lists causes
Consumer Affairs
GE Appliances of minor op;rating problems that
Appliance Park you can correct yourself.
Louisville. KY 40225
To obtain a Spanish language
Para obtener la versi6n en
version of this book, call espafiol
de este manual,
GE Answer
Center@ name a
800.626.2000 GE Answer Center,”
consumer information service.
servicio de informaci6n
para el consumidor,
telifono 800.626.2000.
Write down the model
and serial numbers.
You’ll find them on a label
fastened to the tub wall just
inside the dishwasher door.
These numbers are also on the
Consumer Product Ownership
Registration Card that came
with your dishwasher. Before
sending in this card, please write
these numbers here:
Model Number
Serial Number
Use these numbers in any
correspondence or service calls
concerning your dishwasher.
~ YOU NEED SERVICE...
To obtain service, see the Consumer Services page in NEXT, if you are still not pleased, write all the
the back of this guide. details—including your phone number—to:
We’re proud of our service and want you to be Manager, Consumer Relations
pleased. If for some reason you are not happy with the GE Appliances
service you receive, here are three steps to follow for Appliance Park
further help. Louisville, KY 40225
FIRST, contact the people who serviced your FINALLY, if your problem is still not resolved, write:
appliance. Explain why you are not pleased. In most Major Appliance Consumer Action Panel
cases, this will solve the problem. 20 North
Wacker Drive
Chicago, IL 60606
ENERGY-SAVING TWS
● Operate dishwasher only when it’s full. Let the ● Always select the cycle that uses the least amount
dishes accumulate in dishwasher. When you put in of water that will remove the soil from the load.
only a partial load, use the RINSE & HOLD cycle to (See the Operating section.)
rinse off heavy soils.
● If you don’t need your dishes right away, allow the
dishes to dry naturally over a longer period such as
overnight.
2

A
WARN~G—When using this
appliance, always exercise basic
safety precautions, including the
following:
● Use this appliance only for its intended
purpose, as you will find described in this
Use and Care Guide.
● This dishwasher must be properly
.4,
‘Q-,”; ~
installed and located in accordance
~ ~ . . .
with the Installation Instructions
- k. ‘
before it is used. If you did not
receive an Installation Instructions sheet with your
dishwasher, you can obtain
one by calling, toll
free, the GE Answer Center$ 800.626.2000.
—This appliance must be connected to a grounded
metal, permanent wiring system; or an
equipment-grounding conductor must be run
with the circuit conductors and connected to
the equipment-grounding terminal or lead of
the appliance.
—Connect to a properly rated, protected and sized
power-supply circuit to avoid electrical overload.
● Do not store or me combustible
*
1
material% gasoline or other
-a flammable va~orsandliqtids
in the vicinity of this or any other appliance.
● Use only powder or liquid detergents or wetting
agents recommended for
use in a dishwasher.
● Do not wash plastic items unless marked
“dishwasher safe”
or the equivalent. For plastic
items not so marked,
check the manufacturer’s
recommendations.
● Load light plastic items so they will not
become dislodgd and drop to the
bottom of the
dishwasher—they might come into contact with
the heating element and be damaged.
To minimize tie possibility of injury.
● When loading items to be washed:
A. Locate sharp items’ so that they are not likely
to damage the door seal, and
B. Load sharp knives with the handles up to
reduce the tisk of cut-type injufies.
* Do not tamper with controls.
. Do not touch the heating element during or
immediately after use.
● Do not operate your dishwasher unless all enclosure
panels are properly in place.
Q Do not abuse, sit on, or stand on the door or dish
rack of the dishwasher.
● Close supervision is necessary if this appliance
is used by or near children, Do not allow children
to play inside, on or with this appliance or any
discarded appliance. Dispose of discarded
appliances and shipping or packing material
properly. Before discarding a dishwasher, remove
the door of the washing compartment.
@ Keep all washing detergents and wetting agents
out of the reach of children, preferably in a locked
cabinet. Observe
dl warnings on container labels
to avoid personal injury.
%%
● To minimize the possibility of
0“
electric shock, disconnect this
/“
appliance from the power supply
‘b~fore attempt{~g any maintenan~e. NOTE;
-
Turning the control dial to the 0~ position
does not disconnect the appliance from the
power supply. We recommend having a qualified
technician service your appliance.
A
WARNING—H~ROGEN GAS is
produced by the chemical action
within your water heater. It can
accumulate in the water heater andor
water pipes if hot water has not been used for a
period of two weeks or longer. HYDROGEN GAS
IS EXPLOSI~. To prevent the possibility of
damage or injury, if you have not used hot
water
for two weeks or more, or moved into a residence
in which the hot water system may not have been
used for some time, turn on all hot water faucets
and allow them to run for several minutes before
using any electrical appliance which is connected
to the hot water system. This will allow any
hydrogen
gas to escape. Also, since the gas is
flammable, do not smoke or use an open flame
or appliance during this process.
SAVE THESE
INSTRUCTIONS
3

HOW TO OPERATE YOUR DIS~ASHER
NOTE: If dishwasher drains into a food
waste disposal, operate the disposal until
it is empty before starting dishwasher.
Step 1.
Load your dishwasher. (See Loading section,)
Step 2.
Make sure the Cycle Indicator Dial is at the
OFF position. Add detergent to the detergent
dispenser. (See Detergent Guide.) Use a rinse aid
agent to help prevent spotting. (See How to Use a
Rinse Agent section.)
Step 3.
Latch the door.
Step 4.
Select desired wash cycle.
● POTSCRUBBER—For items such as pots, pans
and casseroles with dried-on or baked-on soils.
Everyday dishes may be included. This cycle will
get heavily soiled dishes cleaner than the normal
cycle. It will not remove burned-on foods.
● NORMAL WASH—For most loads of everyday
dishes, glasses and cookware with medium soils.
Designed to yield high performance on normal soils.
Step 5.
Select the desired Energy Options.
● HEATED DRY ON—Turns the drying heater on
for fast drying. When selected, the cycle time will
be extended for 35 minutes.
● HEATED DRY OFF—Shuts off the heating unit,
thus saving energy. Dishes air-dry naturally. It takes
longer but saves energy. You can open the door after
the motor stops to speed drying. Excellent for
overnight drying.
Step 6.
Turn the Cycle Indicator Dial to START.
● Turning the dial to START will begin the cycle
immediately. To obtain the benefits of a complete
cycle, be careful that you do not turn the dial any
farther than is necessary to start the dishwasher.
There is a time delay between start-up and water
fill so you will not hear any wash action right away.
4
\
II 1
POT- N;:~;L
HMTED ORV
SCRUBBER ON
OFF
II
Cycles Enegy Options
)
II
1
Features and appearance may va~ sljghtly.
Dial Cycles
The SHORT WASH cycle allows you to quickly
wash loads of everyday dishes with medium
soils
that have not dried on, such as loads consisting
mostly of glasses.
a. Select The NORMAL WASH cycle and any
Energy Option if desired.
b. Be sure the door is unlatched.
c. Slowly turn the Cycle Indicator Dial to
SHORT WASH.
d. Latch the door to start the cycle.
The RINSE & HOLD cycle is for rinsing partial
loads which will be washed later. Do not use
detergent.
a. Select HEATED DRY OFF.
b. Be sure the door is unlatched.
c. Slowly turn the Cycle Indicator Dial
to RINSE & HOLD.
d. Latch the door to start the cycle.
The PLATE WARMER cycle is for warming
clean dishes and serving plates for the serving of
hot foods. The cycle will take approximately 35
minutes if selected.
a. Load clean plates and dishes to be warmed.
b. Select HEATED DRY ON.
c. Be sure the door is unlatched.
d. Slowly turn the Cycle Indicator dial
to PLATE WARMER.
e. Latch the door to start the cycle.

[
\
(
RTWASH
I
!
I
PWTE WARM
I
(PRESS HEATED D
Potscrubber
\.-.....–..___. ~N=&=LDpREssHEATEDDR,oL
I
Cycle Selection Chart
Wash Cycle
Water Use Time
Gallons Minutes
Wash Cycles (approx.) (approx.) Cycle Sequence
POTSCRUBBER
10.6
72
WHWMmHB
NORMAL WASH 9.1 51
mmmmmm
SHORT WASH
7.4 43
mmmmm
RINSE & HOLD
3.0
12
mm
Drying Options:
HEATED DRY ON. Available on all wash cycles except RINSE& HOLD. Add 35 minutes to wash cycle time
HEATED DRY OFF. Drying heater is turned off. Dishes dry naturally.
5

Good Dishwashing Starts with HOT Water
To get dishes clean and dry, you need hot water. For good washing and drying,
the entering water must be at least
120°F. To prevent dish damage, inlet water should not exceed 150°F.
How to Test Water Temperature
Check your water temperature with a candy or meat Helpful hints: If outside temperatures are unusually
thermometer. Turn on the hot water faucet nearest low, or if your water travels a long distance from water
the dishwasher. Put the thermometer in a glass and heater to dishwasher, you may need to set your water
let the water run continuously into the glass until the heater’s thermostat up. If you have not used hot water
temperature stops rising. If the water temperature is for some time, the water in the pipes will be cold. Turn
below
120°F., adjust your water heater. on the hot water faucet at the sink and allow it to run
until the water is hot. Then start the dishwasher. If
you’ve recently done laundry or run hot water for
showers, give your water heater time to recover before
operating the dishwasher.
To improve washability if the water is less than
120°F.
and you cannot adjust your water heater: Select a
longer cycle and fill both detergent cups at least
half-
full with detergent.
How to Use a Rinse Agent
The rinse agent makes water flow off dishes
quicker than usual. This lessens water spotting
and makes drying faster, too.
For best dishwashing performance, use of a rinse
agent such as JET-DRY brand is recommended.
Rinse agents come in either liquid or solid form.
Your dishwasher uses the liquid form.
How to fill the rinse agent dispenser.
Unscrew the cap. Note the FULL line
y,,! , ;:=
on the tip of the cap. Add liquid rinse
agent until it just reaches the top of the ,
FULL line. Replace the cap. The
T
dispenser automatically releases the
\
Full
rinse agent into the final rinse water.
Your dishwasher’s rinse agent container holds
approximately 4fi ounces. This should last about
3 months. Fill as needed.
If you accidentally spill: Wipe up the rinse
agent with a damp cloth. Don’t leave the
spill in the
dishwasher. It can keep your detergent from working.
If you can’t find any rinse agent, write:
BENCKISER CONSUMER PRODUCTS, INC.
(“JET-DRY”)
Corporate Centre 1
55 Federal Road
P.O. Box 1991
Danbury, CT 06813-1991
6

How to Choose and Use the Right Detergent
Use only powder or liquid detergent specifically
made for use
in dishwashers. Other types will cause
oversudsing.
How much detergent should you use? That depends.
Is your water “hard” or “soft”? With hard water, you
need extra detergent to get dishes clean. With soft water,
you need less detergent.
Your water department can tell you how hard your
water is. So
can your county extension agent or your
area’s water softener company. Just call and ask them
how many “grains” of hardness there are in your water.
Too much detergent with soft water not only wastes
money, it can be harmful. It can cause a permanent
cloudiness of glassware, called “etching.” An outside
layer of glass is etched away! Of course, this takes some
time. But why take a chance when it’s easy to find out the
hardness of your water.
Keep your detergent fresh and dry. Under the sink
isn’t a good place to store detergent because there is too
much moisture. Don’t put powder detergent into the
dispenser until you’re ready to wash dishes, either. (It
won’t be fresh OR dry.)
If your powder detergent gets old or lumpy, throw it
away.
Old detergent often won’t dissolve. If you use a
liquid dishwasher detergent, these precautions are not
necessary because liquid detergents don’t “lump” as
they age or come in contact with moisture.
Detergent Dispensers
You’ll find two detergent dispensers on the inside Close
the main CUP.
/
NOTE: To open detergent cup after it has been
closed, unlatch the door and rotate the Cycle ~-
Indicator Dial afill turn to the OFF position.
@
When the closed cup contains soap it is
Grasp handle,
best that the door be in a partially open
rotate and
position before rotating the Cycle
close tightly
Indicator Dial. This will help reduce the amount of
detergent and rinse aid agent spillage into the tub.
Detergent Usage Guide (powder or liquid)
I
SO~ WATER (0-3 grains hardness) I MEDIUM WATER (3-7 grains)
HARD WATER (7-12 grains*)
I
I
CYCLES
Main Cup Open Cup Main Cup Open Cup
Main Cup~
Open Cup$
POTSCRUBBER
I Half Full ~ Half Full ] Completely ~ Half Full
I Completely ~ Completely
NORMAL WASH Full Full Full
SHORT WASH
Half Full None
Half Full None
Completely None
Full
I
I I
RINSE & HOLD
Use no detergent Use no detergent Use no detergent
*12 grains and up is extremely hard water. A water softener is recommended. Without it, lime
~Filled Main Cup holds 3 tablespoons;
can build up in the water valve. The water
valve may stick while open and cause flooding. Filled Open Cup
holds 2 tablespoons.
How to Prepare the Dishes for Washing
If this is your first dishwasher, or if you’re NOTE: You may also want to consider removing
replacing a much older model, you may wonder foods such as mustard, mayonnaise, vinegar, lemon
how much preparation your dishes need. Actually juice and other foods that can cause discoloration of
very little. Scrape off bones, seeds, skins, toothpicks stainless steel if allowed to remain on dishes for a
and other hard solids. Remove excessive quantities long period of
time.
of oil or grease.
The POTSCRUBBER cycle can wash heavily soiled
dishes and remove dried-on and baked-on soils from
pots, pans and casseroles. Items with burned-on
soils need extra preparation.
7

HOW TO LOAD Y
‘o UR DISHWASHER
NOTE: Do not load large platters or trays in front right
of lower rack. They may prevent detergent from
circulai
cor
Ling
ner
in the wash cycle.
This is a random mixed load, the most common type WATCH OUT FOR THIS.
you will have.
The washer tower rises through the center of the
Make sure dishes are properly loaded to insure that bottom rack during the wash and rinse portions of
water can reach the soiled surfaces. The wash arm in the cycle. Don’t block it or load tall things next to it.
the bottom sprays water up. The tower that rises in Also, be careful not to let a portion of an item such
the center sends water out over the dishes to wash the as a pot or dish handle extend through the bottom
items in the upper rack. A spray arm in the top washes rack. This could block the wash arm and cause poor
down also. Make sure to place tall items to the outside
washing results.
so the upper wash arm is not blocked.
HOW TO LOAD THE TOP RACK
Place tall glasses, mugs, tumblers and stemware in
the deep front section. The shallow rear section is
ideal for cooking and serving utensils. Make sure
that all items–front and rear sections–do not extend
above the side wires of the rack. Arrange stemware
so that it cannot move easily. Don’t let the glasses
touch each other.
This rack is ideal for dishwasher-safe Plastics. Load
small shallow items in the rear section-; larger, deeper
bowls in front section. If loading plastic tumblers in
deep front section, be sure that each plastic tumbler
is secured over two fingers.
8

HOW TO LOAD T~ BOTTOM WCK
Fit plates and saucers between the pins. Load platters,
pots and bowls along the sides, in corners or in the back.
Pots, pans, casseroles, salad bowls, mixing bowls and
lids must be loaded in the bottom rack facing down.
Put flatware in the removable basket with handles up to
protect your hands. Mix knives, forks and spoons so they
don’t nest together. Distribute evenly. Small plastic items,
such as measuring spoons and lids from small containers,
are not recommended for automatic
dishwashing. If
placed in the dishwasher, they should go in the bottom
of silverware basket with silverware on top.
botiom. -
Precaution!
Take out anything that may fall or extend through the
bottom of the basket.
9

W~T YOU CAN USUALLY WASH SAFELY
IN YOUR
DIS~ASHER.
Material
Aluminum
Chind
Stoneware
Crystal
Non-dishwasher
items—such
as electronic
air cleaner
filters, furnace
filters, paint
brushes, etc.
Glass
kon
Pewter
Plastics
Stainless steel
Sterling Silver
and Silver plate
Usually
Safe
YES
YES
YES
NO
YES
NO
NO
YES
YES
YES
Non-stick ~ YES
coatings
I
Exceptions (not safe)
Some colored anodized
aluminum can fade.
Antique, metal-trimmed,
hand-painted or over-the-glaze
patterns fade. Gold leaf
will discolor.
Antique, metal-trimmed or
hand-painted patterns fade.
Gold leaf will discolor.
Iron will rust.
Pewter tarnishes,
Don’t put in same silverware
basket with stainless steel.
Contact between metals can
damage silyer.
Don’t wash copper utensils in
the same load.
Silver may get a
brown film.
Adhesive used to attach some
hollow-handle knives can loosen.
Tin can rust.
Wood can warp, crack or lose
its finish with any type of washing.
Forget a dish? Here’s when you can add it.
Add dishes any time during the RINSE & HOLD
cycle. With other wash cycles, you can add dishes
at any time BEFORE the main detergent wash portion
of the cycle.
However, opening the door during any cycle
lessens cleaning power. So try to load everything
at the beginning.
Special Instructions
Some darkening or spotting possible. Remove by
scouring with soap-filled steel wool Pads.
‘~ in doubt, check with the manufacturer. Or test wash
one piece daily for at least a monk. Compare with the
rest of the set.
bad securely to prevent movement. Check your
manufacturer’s instructions
for your crystal.
Do not wash
in dishwasher. Damage to dishwasher
and discoloration or staining of dishwasher may result.
If it doesn’t say DIS~ASHER SA~, test one piwe in
the top rack before dishwashing an entire set.
Rinse if not washing immediately. Salty or acid finds
can stain if left on.
Rinse if not washing imrndiately.
Sahy or acid foods can
stain if left on.
Dry detergent can cause difficult-to-remove
black spots.
Place in back section of silverware basket to avoid
exposure to detergent from the detergent cup.
Afier washing, wipe the non-stick coating area with
vegetable oil to keep it from losing its non-stick quality.
Here’s how to add a forgotten dish:
1. Push the door latch to the left. Washing will stop.
2. Wait a few seconds until the water calms. Then
open the door. WARNING: Hot vapor may rise
from opened door.
3. Add dishes you’ve forgotten.
4. Close the door and push the latch to the far right.
When the door is locked, washing will continue.
10

USER MAINTENANCE INSTRUCTIONS
Clean the control panel with a lightly dampened
Appliance Polish Wax & Cleaner (Cat. No.
cloth. Dry thoroughly. Do not use abrasives or WR97X0216) is available from GE Service and
sharp objects on the panel. They can damage it.
Parts Centers.
Clean the outside with a good appliance polish The inside usually takes care of ihelf. If it should
wax. The outside cabinet finish is durable, but it ever need cleaning, use a mild cleansing powder.
can scratch. So use no scouring pads, or harsh or Scouring pads and harsh cleaners can mar the finish.
gritty cleaners.
Not Using Your Dishwasher in
If your dishwasher is left in an
unheated place during the winter,
ask a service technician to:
● Cut off electrical power to the
dishwasher. Remove fuses or trip
circuit breaker.
● Turn off the water supply.
● Disconnect the water inlet line
from the water valve.
Winter? Protect Against Freezing.
Pump Cover Screws
● Drain water from the inlet line
A
and water valve. (Use a pan to
catch the water.) -
● Reconnect the water inlet line to
the water valve.
● Remove the plastic pump cover
in the tub bottom and use a
sponge to soak up water in
the rubber boot.
Built-in Dishwashers Often Use an Air Gap. Keep It Clean.
An air gap is a plumbing device.
It protects your dishwasher against
water backing up into it if a drain
clogs. The air gap is not a part of
the dishwasher. And you may not
even have one. Not all plumbing
codes require air gaps.
Check the air gap any time your
dishwasher isn’t draining well.
If you have an air gap, check it at
least once a month. IT IS NOT
PART OF YOUR DISHWASHER.
IT IS NOT COVERED IN YOUR
WARRANTY.
The air gap is easy to clean.
With most types, first turn off the
dishwasher, then lift off the chrome
cover. Then unscrew the plastic cap
and check for any buildup of grit.
A toothpick makes cleaning easy.
11

HOW TO CHANGE COLOR PANELS
If you are redecorating, you can change your dishwasher’s front panel to
match or blend with your new colors by flipping it over. Each side of each
panel is a different color. You may also paint a panel with a color of your
own choice.
How to Change the Door Panel:
1. Take out trim screws on either side of the
dishwasher door. Remove the side trim.
2. Slide the door panel out.
(Careful-edges may be sharp.)
3. Turn the door panel around and put the color you
want in front.
4. Replace the door panel, side trim and screws.
NOTE: Do not operate
dishwasher while changing
panels or when lower access
panel is removed.
How to Change the Lower Panel:
,Retaining
“L-
Bottom Panel Attachment Screws
1. Remove the bottom panel attachment screws.
2. On models without top mounting screws, remove
the entire access assembly by lifting it up and over
the retaining tabs.
3. On models with top mounting screws, remove
the screws.
4. Take out the top trim screws and remove the
top trim.
5. Slide the color panel(s) up and out and put the
color you want in front.
6. Replace the top trim and screws.
7. Replace the entire access assembly by reversing
the steps.
Wood Panel fiim Kifi
Color Panel
Wood panel trim kits, contain trim and
instructions for adding a decorative wood door
panel and lower access panel no thicker than 1/4”
to match kitchen cabinets.
Specify the trim color of your
choice from the following options:
GPF40BC (Chrome Trim and Screws)
GPF40BK (Black Trim)
GPF40WH (White Trim)
The kit is available for $5.00 (shipping and handling).
Make check payable to the General Electric Co.
If you have redecorated, and the color panels in
your dishwasher do not blend with your new color
scheme you may order one additional color panel
without charge.
Specify the color panel GPF26 HarvestiBlack.
Order a Wim Kit or a Color Panel from:
GE Appliances
c/o
Dri-View Manufacturing
4706 Allmond Ave.
Louisville, KY 40209
12

PROBLEM
DISHWAS~R
,W,ON’T RUN
UNUSUAL NOISE
DiSHES DON’T’DRY
UNCLEAN DISHES
AND ~ATWARE
DETERGENT LE~
IN DISPENSER CUPS
DETERGENT CUP
LD WON’T LATCH
~R ADDING
DETERGENT
YELLOW OR
BROWN F~M
POSSIBLE CAUSE
A fuse
in your home maybe blown, or the circuit breker tripped. Replace fuse or
reset circuit breaker. Remove any other
appEances from the circuit.
Utensils
may not be secure on rack pins, or somqthing small may have dropped from
the rack. Water is causing utensils to rattle. Make sure
everyting is securely placed
in dishwasher.
Make sure inlet water temperature is correct. [See How to Test Water
Temperature section).
Unload the bottom rack frost. Water from dishes in the top rack maybe spilling into
the bottom rack.
Check for improper loading. Dishes shouldn’t nest together. Avoid overloading.
Check
the rinse agent dispenser to see that it’s not empty.
Check inlet water temperature. It should be at least 120°F. (To test, see How to Test
Water Temperature section).
Water pressure may be temporarily low. Turn on a faucet. Is water coming out slower
than usual? If so, wait until pressure is normal before using your dishwasher.
Plugged air gap. (See Care and Cleaning section).
Improper rack loading. (See Loading section).
Choose another cycle to give you longer washing time.
Water may not be reaching the detergent cups, Move’dishes that maybe blocking
detergent
cup.
The dispenser cover may not be opening or may b,bloekd by improperly loaded
items. If you used a powder detergent, open the cup and remove any caked-on
detergent. If the cup still doesn’t open automatically, cdl for service.
Detergent may be old. If the powder detergent is hard or caked in the box, throw it
away. The detergent may not be working well. Try another brmd.
Cycle Indicator Dial must be OFF for cup lid to close and latch properly. If you
unlatch the door and open it to dry your dishes, the Cycle Indicator Dial does
not advance by itself.
Tea or coffee can stain cups. Remove the stain by hand, using a solution of 1/2 cup
bleach and 3 cups warm water.
An overall yellow or brown film on dishes or glassware can be caused by iron
deposits in water.
A special filter in the water supply line is the only way to correct
this
problem. Your water softener company can tell yau about the filter.
Yellow fik on sterIing silver results when you wash copper utensfis in the same load.
Silver polish will usually remove this stiin.
(continued next page)
13

T~ PROBLEM SOL~R
(continued)
PROBLEM
SPOTS AND
FILMING ON
GLASSES AND
~ATWARE
CLOUDINESS ON
GLASSWARE
CH~PING OF CH~A
POSSIBLE CAUSE
Spotting can be caused by
dl these things:
● Extremely hard water. (See How to Choose and Use Detergent section).
● Low inlet water temperature. (See How to Test Water Temperature section),
● Overloading the dishwasher.
● Improper loading. (See Loading section).
● Old or damp powder detergent.
● Phosphate level in detergent too low. (See How to Choose and Use
Detergent section).
● Rinse agent dispenser empty. (See How to Use a Rinse Agent section).
● Too fittle detergent. (See How to Choose and Use Detergent section).
Local water conditions and personal preferences vary. Try several brands of
detergents to
find one that gives the best results for you. A liquid dishwasher
detergent may
help reduce filming.
To remove stubborn spots and film from glassware:
1. Remove dl metal utensils from the dishwasher.
2. Do not add detergent.
3.
Select POTSCRUBBER cycle.
4. Start the dishwasher and allow to mn for 18 to 22 minutes. The dishwasher will
now be in the main wash.
5. Then open the door and pour 2 cups (500 ml) of white vinegar into the bottom of
the dishwasher.
6. Close the door and allow to complete the cycle.
If vinegar rinse doesn’t work: Repeat as above, except use 1/4 cup (60 ml) of citric
acid crystals instead of vinegar. (Most drugstores carry citric acid crystals. If yours
doesn’t,
cdl GE Factory Service).
Using a vinegar or citric acid crystil rinse more than twice a
month? Consider a home
water softener.
If vinegar or citric acid crystal rinse doesn’t work, the cloudiness is “etching.”
The
ftim cannot be removed.
It can be prevented: Use less detergent if you have soft water. Wash glasswme in
the shortest cycle that
win get them clean.
Water temperature entering dishwasher exceeds 150°F.
Rough handling can cause chipping. Load with care. Make sure glassware and china
are secure and can’t jar loose. (See Loading section). Make sure Ml glasses and
stemware will
clear the top of the tub when you push the rack into the dishwasher.
Always use the top rack for delicate items.
14

PROBLEM
BLACK OR
GRAY
MARKS ON DISHES
SMALL AMOUNT OF
WATER
STANDWG
IN THE BOTTOM
OF THE TUB
WATER WON’T PUMP
OUT OF THE TUB
SUDS IN THE TUB
DISHWASHER
LEAKS
MOTOR HUMS
STAIN~G OF
TUB INTERIOR
SOUNDS YOU
~L HEAR
VAPOR AT
THE VENT
POSSIBLE CAUSE
Aluminum utensils often leave marks when they rub against dishes. Remove marks
with a mild abrasive cleanser.
Water around the outlet on the tub bottom at the back of the tub is normal, It is clean
water.
It?s thereto keep the water seal lubricated.
If the entire bottom of the tub has water, you may have a drain problem. Clean the air
gap, if you have one. (See Care and
Clearting section).
Check the kitchen sink. Is
it draining well? You may need a plumber.
If dishwasher drains into disposer, run disposer to
clear. Be sure disposer is not
cIogged.
Sudsing detergents are not meant for dishwashers. USE ONLY AUTOMATIC
DISHWASHER DETERGENTS TO AVOID SUDSING.
To remove suds from the tub: Open the dishwasher.
bt suds evaporate. Add
1 gallon of cold water to the tub. Close and latch the dishwasher. Pump out water
by slowly turning the control dial until a drain
period is reached.
Repeat if necessary.
Suds can cause unit to ovefiow.
That’s why it’s so important to use a detergent that’s
designed for automatic dishwashers.
Spilling the rinse agent can cause foam during washing. This can lead to overflowing.
Wipe up
accidenti spill of rinse agent with a damp cloth.
Dishwasher has not been used on a regular basis,
If you do not use your dishwasher often, set it to fill and pump out once every week.
This will help keep the
sed moist, and the garbage disposer clear.
Some detergents contain colorant (pigment or
dyes) that will discolor the tub
interior with extended use. Check the detergent cup for signs of any discoloration.
If
cup is discolored, change to dstergent without any colorant.
You’ll hear occasional clicking sounds. These are normal.
● Sofi food disposal shredding action.
● Drain valve opening to pump water out.
Q Timer control as cycle progresses.
● Detergent cup opening.
During
the drying period:
Q The motor stops.
Water vapor comes through the vent by the door latch during drying and when
water is being pumped out.
If you need more help. ..call, toll free:
GE Answer
Center@
800.626.2000
consumer information service
15

NOTES
16

NOTES
17

NOTES
18

Wdll Be There
With the purchase ofyour new GE appliance, receive the assurance that if you ever need
,-
infomation or assistance from GE, we’ll be there. All you have to do is call—toll-free!
In-Home Repair Service
80WE4ARES(80M32-2737)
AGE consumer service professional will provide expert repair service, sched-
uled at
a time that’s c(>nvenient f’(~r yc)u. Many GF. CJonsumer Service company-
operated locations
offer you ser}ice today or tomorrow) or al your convenience
(7:00 a.m. to 7:00 p.m. }\eekdays, !):()() a.m. to 2:00 p.m. Saturdays). ou~- fact.ory-
trained technicians know your appliance inside and out-so most repairs can be
handled in just
one visil.
GEAnswer Center@
80~62E2000
Whatever your question about any GE major arpliance, GE ,4nswer (lent.er@
information service is available to help. Your call-and your question-w 7ill be
answered promptly and courteously. And you can call any time.
C,E Answer
Center@ service is open 24 hours a day, 7 days a week.
sEmloNA.A
,....-.,”” ”..s,.., .!,.”... . . . .
.,.” .”.........,”.......,,. ~.,. ,.,.
kr Customers With Special Needs...
80~62E2000
Upon request., GE will provide Gonsumers with imraired hearing or speech who have
13raille controls for a variety of’GE access to a TDIJ or a conventional teletypewriter may
arpl iances, and a brochure to call 800-TDD-GEA(; (800-833-4322) to requesL inforn~a-
assist in rlanning a barrier-free tion or service.
kitchen
for persons with limited
mobilit). ‘1’() obtain these items,
free
of charge, call 800.626.2000.
Service Contracts
80@626-2224
You can have the secure feeling that GE [;onsurner Service will still be there
after your warranty expires. Purchase a GE contract while your warranty is still
in effect and
yoLI’11 receive a substantial discount. With a multiple-year contract,
you’re assured of
f’uture service at today’s prices.
Pads andAccessories
80@626-2002
Individuds qualified to service their om appliances User maintenance instructions contained in this
bootiet
can have needed parts 01- accessories sent directly to cover procedures intended to be performed by any user.
their home. The GE parts sys(em provides access to over Other servicing
gener~y shotid be referred to qualified
47,000 parts.. and all GE G:nuine Renewal I’arts are
service personnel. Caution must be exercised, since
fully warranted. VISA, Master(.~ard and Disco\el cards improper servicing may cause unsafe operation.
are accepted.

1
I
YOUR GE DISHWASHER WITH
Staple sales slip or cancelled check
PERMATU~ INTERIOR
here. Proof of original purchase date
WARRANTY
is needed to obtain service
under warranty.
J
WHAT IS COVERED
FULL ONE-YEAR WARRANTY
For one year from date of original
purchase, we will provide, free of
charge, parts and sewice labor in
your home to repair or replace
any
part of
the dishwasher that fails
because of a manufacturing defect.
FULL TEN-YEAR WARRANTY
For ten years from date of original
purchase, we will provide, free of
charge, parts and service labor in
your home to repair or replace
the
PermaTu~ tub or door liner if it
fails to contain water because of
a manufacturing defect such as
cracking, chipping, peeling
or rusting.
LIMITED SECOND-YEAR
WARRANTY
For the second year from date of
original purchase, we will provide,
free of charge, replacement parts for
any pati of the Water Distribution
System
(as illustrated below) that
fails because of a manufacturing
defect. Associated inlet and drain
plumbing parts are not covered by
this warranty. You pay for the
sewice trip to your home and
service labor charges.
Power
Showefiarm-1
Wash arm
(spray arm)
Boot
ti
i
– Hose
Hub
*
connection
E
assembly
Motor
Pump
Soft Food Disposer
Water Distribution System
This warranty is extended to
the original purchaser and any
succeeding owner for products
purchased for
ordina~ home use in
the 48 mainland states, Hawaii and
Washington, D.C. In Alaska the
warranty is the same except that it is
LIMITED because you must pay to
ship the product to the service shop
or for the
sewice technician’s travel
costs to your home.
All warranty service will be
provided by our Factory Sewice
Centers or by our authorized
Customer
Care@ servicers during
normal working hours.
Should your appliance need
service, during warranty period or
beyond, call 800-GE-CARES
(800-432-2737).
WHAT IS NOT COVERED
● Service trips to your home to teach adequate electrical, plumbing, and
you how to use the product.
other connecting facilities.
Read your Use and Care material.
If you then have any questions
about operating the product, please
contact your dealer or our
Consumer Affairs office at the
address below, or call, toll free:
GE Answer Center”
800.626.2000
consumer information service
● Improper installation.
If you have an installation problem,
contact your dealer or installer. You
are responsible for providing
. Replacement of house fuses or
resetting of circuit breakers.
● Cleaning or servicing of air gap
device in drain line.
● Failure of the product if it is used for
other than its intended purpose or
usedcommercially.
● Damage to product caused by
accident, fire, floods or acts of God.
WARRANTOR IS NOT RESPONSIBLE
FOR CONSEQUENTIAL DAMAGES.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion
maynot applyto you.This warrantygives you specific legal rights, and you may also have other rights which vay from state to state.
To know what your legal rights are in your state, consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor: General Electric Company
If further help is needed concerning this warranty, write:
Manager—Consumer Affairs, GE Appliances, Louisville, KY 40225
Jis book is printed on recycled paper.
Part No. 165 D3080P300
Pub
No. 49-5608
GSM
12-93 CG
Printed in Louisville
