For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
340104
Specification Revised 8/07
Listed by
Underwriters
Laboratories
JVM1851BH/CH/SH/WH
GE Spacemaker® Over-the-Range Microwave Oven with Recirculating Venting
Note: Requires 120V grounded outlet. Electrical receptacle
must be located in cabinet above Spacemaker microwave oven.
No additional wiring, venting or cabinet rebuilding necessary
in many cases. Complete detailed, easy-to-follow installation
instructions and convenient full-size templates are packed with
the Spacemaker microwave oven.
Important Information: When installing the Spacemaker
microwave oven over a range, allow minimum of 2" from bottom
of Spacemaker microwave oven to top of range backguard to
allow for removal of light covers.
Installation Information: This information is not intended to
be used for installing unit described. Before installing, consult
installation instructions packed with product/kit for current
dimensional data.
66" MIN.
Mounting
height
from
floor
30"
MIN.
width
required Exhaust outlet
connects to
3-1/4" X 10" duct
16-13/32
(rear)
105°
Door open
15-1/4
24-1/2
16
29-7/8
Minimum distance from
door hinge side to adjacent
wall should equal 1/2-inch.
(without
obstruction)
13"
MAX.
12"
MIN.
Dimensions (in inches)
Over-the-Range Microwave Oven
Dimensions and Installation Information (in inches)

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
340104
Specification Revised 8/07
Listed by
Underwriters
Laboratories
JVM1851BH/CH/SH/WH
GE Spacemaker® Over-the-Range Microwave Oven with Recirculating Venting
Hood Exhaust Duct: Outside ventilation requires a HOOD EXHAUSTDUCT. Read the
following carefully.
Exhaust Connection: The hood exhaust has been designed to mate with a standard
3-1/4" x 10" rectangular duct. If a round duct is required, a rectangular-to-round transition
adaptor must be used. Do not use less than a 6" diameter duct
Rear Exhaust: If a rear or horizontal exhaust is to be used, care should be taken to
align exhaust with space between studs, or wall should be prepared at the time it is
constructed by leaving enough space between the wall studs to accommodate exhaust.
Maximum Duct Length: For satisfactory air movement, the total duct length of
3-1/4" x 10" rectangular or 6" diameter round duct should not exceed 120 equivalent feet.
Elbows, Transitions, Wall and Roof Caps, etc., present additional resistance to airflow
and are equivalent to a section of straight duct which is longer than their actual physical
size. When calculating the total duct length, add the equivalent length of all transitions
and adaptors plus the lengths of all straight duct sections. The chart below shows the
approximate feet of equivalent length of some typical ducts.
Duct Equivalent Feet
A. Rectangular-To-round 5 ft.
Transition Adaptor
B. Wall Cap 40 ft.
C. 90° Elbow 10 ft.
D. 45° Elbow 5 ft.
E. 90° Elbow 25 ft.
F. 45° Elbow 5 ft.
G. Roof Cap 24 ft.
Optional Accessories (Available at additional cost)
Filler Panel Kits
JX52WH–White
JX52BL–Black
When replacing a 36" or
42" range hood, this kit fills
in the additional width to
provide a custom built-in
appearance. For installation
between cabinets only; not
for end-of-cabinet installation.
Each kit contains two 3"-wide
filler panels.
Filter Kits
JX81B–Recirculating
Charcoal Filter Kit
To be used when
the Spacemaker
microwave oven
cannot be vented to
the outside.
Dimensions and Installation Information (in inches)

340104
Specification Revised 8/07
Listed by
Underwriters
Laboratories
JVM1851BH/CH/SH/WH
GE Spacemaker® Over-the-Range Microwave Oven with Recirculating Venting
JVM1850/1851WH/CH/BH
ONE TOUCH SENSOR
BEVERAGE
VEGETABLES
POPCORN REHEAT
POTATO
ADD
30 SEC.
POWER
LEVEL
123
456
789
0
EXPRESS COOKEXPRESS COOKEXPRESS COOK
EXPRESS COOKEXPRESS COOKEXPRESS COOK
TIME
COOK
AUTO/TIME
DEFROST
1 lb QUICK
DEFROST
CLEAR
OFF
START
PAUSE
CLOCK
AM/FM
DELAY
START
VENT FAN
BOOST
SURFACE
LIGHT
VENT FAN
OPTIONS
HELP
TIMER
TURNTABLE REMEMBER
Spacemaker XL1800
Features and Benefits
• 1.8 Cu. Ft. Capacity - 1100 Watts (IEC-705 test procedure)
• Circuwave™1100 Cooking System - Patented system
provides more ower for faster more even cooking results
• Sensor Cooking Controls - Automatically adjust the time and
power for perfect cooking results
• Convenience Cooking Controls - Allows cooking and
reheating at the touch of a button
• 1-lb Quick Defrost- Evenly defrosts a pound of meat, poultry
or fish in a fraction of the usual time, withough precooking or
turning the food
• 14-1/4" Recessed Turntable - Large enough to handle 5-qt
casserole dishes and can easily be removed for cleaning
• Three-speed, 300-CFM Vortex Venting System with
Recirculating Exhaust Fan - Quickly removes smoke and
steam from the cooktop
• Model JVM1851WH – White on white
• Model JVM1851BH – Black on black
• Model JVM1851CH – Bisque on bisque
• Model JVM1851SH – Stainless steel
