GE JVM7195 User manual

I
Istall ti
structi Over the Range
Microwave Oven
JVM7195,JNM7196,DVM7195,PVM9195,
PNM9196and PVM9215
iQuestions? Call 800.GE.CARES (800.432.2737) orvisitourWebsiteat:GEAppliances.com i
BEFORE YOU BEGIN
Read these instructions completely and carefully.
•IMPORTANT -Sovethese
instructionsforlocolinspector'suse.
•IMPORTANT -Observeoll
governingcodesond ordinonces.
• Note to Installer - Be sure to leove these
instructions with the Consumer.
o
o
Note to Consumer - Keepthese instructions
for future reference.
Skill level - Installation of this appliance requires basic
mechanical end electrical skills.
Proper instollation is the responsibility of the instoller.
Product failure due to improper installation is not
covered under the Warranty.
LA SECCIUN EN ESPA()OL EMPIEZA
EN LA P.GINA 25. READ CAREFULLY.
KEEP THESE INSTRUCTIONS.
49-40702 06-13 GE

Installation
CONTENTS
General information
Instructions
[_ Recirculating .................................................19-22
Attach Mounting Plate to Wall ................19
Important SafetyInstructions ........................................3
Electrical Requirements ..................................................3
Hood Exhaust ................................................................4, 5
Damage - Shipment/Installation ..................................6
Preparation of Top Cabinet ......................19
Adapting Blower
for Recirculation ..................................20, 21
Mount the Oven...................................21, 22
Installing the Charcoal Filter....................22
Parts Included ...................................................................6
Tools You Will Need .........................................................7
Mounting Space ................................................................7
Step-by-step installation guide
Placement of Mounting Plate .................................. 8-10
Removing the Mounting Plate.............................8
Finding the Wall Studs..........................................8
Determining Wall Plate Location ........................9
Aligning the Wall Plate .......................................10
Installation Types ....................................................11-22
[_ Outside Top ....................................
Exhaust 12-14
Attach Mounting Plate to Wall .................12
Preparation of Top Cabinet.......................13
Assemble and Install Adaptor ..................13
Mount the Oven...................................13, 14
Adjust the Exhaust Adaptor ......................14
Connecting Ductwork ................................24
[_i_ Outside .................................. 15-18
Back Exhaust
Preparing Rear Wall for
Outside Back Exhaust................................25
Attach Mounting Plate to Wall .......... 15, 16
Preparation of Top Cabinet.......................16
Adapting Blower for Outside
Back Exhaust..........................................16, 17
Mount the Oven..........................................18
Before You Use Your Oven .......................................... 23

Installation Instructions
IMPORTANT SAFETY INSTRUCTIONS
A qualified electrician must perform a ground continuity
check on the wall receptacle before beginning the
installation to ensure that the outlet box is properly
grounded. If not properly grounded, or if the wall
receptacle does not meet electrical requirements noted
(under ELECTRICALREQUIREMENTS),a qualified electrician
should be employed to correct any deficiencies.
WARNING:
Riskof Electric Shock.
Can cause injury or death:
Remove house fuse or
open circuit breaker before
beginning installation to avoid
severe or fatal shock injury.
AI:lt,W_-_I_I_I I I_i _: Riskof Electric Shock.
Can cause injury or death: THISAPPLIANCEMUSTBE
PROPERLYGROUNDEDto avoid severe or fatal shock.
120 V Models
groond exi s
beforeuse
The power cord of this
appliance isequipped with
a three-prong (grounding)
plug which mates with
a standard three-prong
(grounding) wall receptacle
to minimize the possibility
of electric shock hazard
from this appliance.
Where a standard two-prong wall receptacle is
encountered, it must be replaced with a properly
grounded three-prong wall receptacle, installed by a
qualified electrician.
AWARN ING:RiskofElectricShock.
Can cause injury or death: DO NOT,under any
circumstances, cut, deform or remove any of the prongs
from the power cord. Do not usewith an extension cord.
Failure to comply may cause fire.
A,-,^, ,T,,,_t,,
_IL_f_U/I_JI_I: For personal safety, the
mounting surface must be capable of supporting the
cabinet load, in addition to the added weight of this
63-85 pound product, plus additional oven loads of up
to 50 pounds or a total weight of 113-135 pounds.
ACAUTION: Forpersonalsafety,thisproduct
cannot be installed in cabinet arrangements such as an
island or a peninsula. It must be mounted to BOTHa top
cabinet AND a wall.
CAUTION: Toavoidtheriskofpersonal
injury (back injury or other injuries due to excessive
weight of the microwave) or property damage, you will
need two people to install this microwave.
ELECTRICAL REQUIREMENTS
120 V Models
This product requires a three-prong grounded outlet.
Product rating is 120 volts AC, 60 Hertz, 15 amps,
and 1.70 kilowatts. This product must be connected
to a supply circuit of the proper voltage and frequency.
Wire size must conform to the requirements of the
National Electrical Code or the prevailing local code
for this kilowatt rating. The power supply cord and
plug should be brought to a separate lS to 20 ampere
branch circuit single grounded outlet. The outlet box
should be located in the cabinet above the oven and
away from any potential microwave ducting.The outlet
box and supply circuit should be installed by a qualified
electrician and conform to the National Electrical Code or
the prevailing local code.
3

Installation Instructions
HOOD EXHAUST
NOTE:Read these next two pages only if you plan to vent your exhaust to the outside.
If you plan to recirculate the air back into the room, proceed to page 6.
OUTSIDE TOP EXHAUST {EXAMPLE ONLY)
Thefollowing chart describes an example of one possible
ductwork installation.
DUCT PIECES
BRoof Cap
12 Ft.Straight Duct
(6" Round)
Rectangular-to-Round
Transition Adaptor*
EQUIVALENT NUMBER EQUIVALENT
LENGTH x USED = LENGTH
24 Ft. x (!)
12 Ft. x (!)
5 Ft. x (!)
Equivalent lengths of duct pieces are based on actual tests and
reflect requirements for good venting performance with any vent hood.
Total Length
24 Ft.
12 Ft.
5 Ft.
41 Ft.
*IMPORTANT:If a rectangular-to-round transition adaptor is used, the bottom corners of the damper will
have to be cut to fit, using the tin snips, in order to allow free movement of the damper.
OUTSIDE BACK EXHAUST (EXAMPLE ONLY)
The following chart describes an example of one possible
ductwork installation.
[
DUCT PIECES
DWall Cap
3 Ft.Straight Duct
31A'' x !0" Rectangular)
90° Elbow
EQUIVALENT NUMBER EQUIVALENT
LENGTH* x USED = LENGTH
40 Ft. x (!)
3 Ft. x (!)
10 Ft. x (2)
Equivalent lengths of duct pieces are based on actual tests and
reflect requirements for good venting performance with any vent hood.
Total Length
40 Ft.
3 Ft.
20 Ft.
= 63 Ft.
NOTE:For back exhaust, care should be taken to align exhaust with space between studs, or wall should be prepared
at the time it is constructed by leaving enough space between the wall studs to accommodate exhaust.
4

Installation Instructions
NOTE:If you need to install ducts, note that the total duct
length of 3¼" x 10" rectangular or 6" diameter round duct
should not exceed 140 equivalent feet.
Outside ventilation requires a HOODEXHAUSTDUCT.
Read the following carefully.
NOTE:It is important that venting be installed using
the most direct route and with as few elbows as possible.
This ensures clear venting of exhaust and helps prevent
blockages. Also, make sure dampers swing freely and
nothing is blocking the ducts.
Exhaust connection:
The hood exhaust has been designed to mate with
a standard 3½" x 10" rectangular duct.
If a round duct is required, a rectangular-to-round
transition adaptor must be used. Do not use less than
a6" diameter duct.
Maximum duct length:
For satisfactory air movement, the total duct length of
3VJ'x 10" rectangular or 6" diameter round duct should
not exceed 140 equivalent feet.
Elbows, transitions, wall and roof caps, etc.,
present additional resistance to airflow and are equivalent
to a section of straight duct which is longer than their actual
physical size.When calculating the total duct length, add the
equivalent lengths of all transitions and adaptors plus the
length of all straight duct sections. The chart below shows
you how to calculate total equivalent ductwork length using
the approximate feet of equivalent length
of some typical ducts.
EQUIVALENT NUMBER EQUIVALENT
DUCT PIECES LENGTH x USED = LENGTH
Rectangular-to-Round 5 Ft. ( ) Ft.
x
Transition Adaptor*
_ Wall Cap 40 Ft. x ( ) = Ft.
(_ 90° Elbow 10 Ft. x ( ) = Ft.
/45° Elbow 5 Ft. x ( ) = Ft.
90° Elbow 25 Ft. x ( ) = Ft.
_ /45 Elbow 5Ft. x ( ) = Ft.
Roof Cap 2/4Ft. x ( ) = Ft.
Straight Duct 6" Round or 1 Ft. x ( ) = Ft.
3¼" x 10" Rectangular
Total Ductwork = Ft.
* IMPORTANT:If a rectangular-to-round transition Equivalent lengths of duct pieces are based on actual tests and
adaptor is used, the bottom corners of the damper reflect requirements for good venting performance with any vent
will have to be cut to fit, using the tin snips, in order hood.
to allow free movement of the damper.
5

Installation Instructions
DAMAGE- SHIPMENT/
INSTALLATION
• If the unit is damaged in shipment, return
the unit to the store in which it was bought for
repair or replacement.
• If the unit is damaged by the customer, repair or
replacement is the responsibility of the customer.
• If the unit is damaged by the installer (if other than
the customer), repair or replacement must
be made by arrangement between customer
and installer.
PARTS INCLUDED
HARDWARE PACKET
PART
Wood Screws
(¼" x 2")
Toggle Bolts (and
wing nuts)(¼" x 3")
Self-aligning Machine
Screw (¼"-28 x 2%')
Nylon Grommet
(for metal cabinets)
QUANTITY
2
You will find the installation hardware contained
in a packet with the unit. Check to make sure you
have all these parts.
NOTE:Some extra parts are included.
PARTS INCLUDED
ADDITIONAL PARTS
PART
TOPCABINETTEMPLATE
I_"_=_i_I
REAR W_LL_EMPLAmD
INSTAU_ATION
INSTRUCTIONS
Top Cabinet
Template
RearWall
Template
Installation
Instructions
Separately
Packed
Grease
Filters
Exhaust
Adoptor with
Damper
Charcoal
Filter
m
QUANTITY
i
i
i
6

Installation Instructions
TOOLS YOU WILL NEED
# i and #2 Phillips Pencil
screwdriver
Tinsnips(forcutting
damper,if required)
Gloves
Safetygoggles
Ruleror tape
measureand
ht edge
Scissors(tocut
template, if necessary)
Saw(saber,holeor keyhole)
Electric drill with VX', V_G",
W' and s/8"drill bits
0
Studfinder
OF I
Hammer(optional)
Level
Carpentersquare
(optional)
¢5b
Fillerblocksor scrap
wood pieces,if needed
for top cabinet spacing
(usedon recessedbottom
cabinet installationsonly)
Ductand masking
tape
MOUNTING SPACE
66" or
morefrom
the floorto
the top of
the oven
..........Bottom edge of
cabinet needs to
be 30" or more
from the cooking
surface
Backsplash
NOTES:
• The space between the cabinets must be 30" wide
and free of obstructions.
• If the space between the cabinets is greater than
30", a Filler Panel Kit may be used to fill in the gap
between the oven and the cabinets. Your Owner's
Manual contains the kit number for your model.
• This oven is for installation over ranges up to
36" wide.
• If you are going to vent your oven to the outside,
see Hood Exhaust Section for exhaust duct
preparation.
• When installing the oven beneath smooth, flat
cabinets, be careful to follow the instructions
on the top cabinet template for power cord
clearance.
• Maximum cabinet depth above and beside the unit
is 13".
. Formodels with top venting holes: Do not allow
cabinetry or other objects to block the airflow of the
vent.
. The product should not be installed over any
cooktop or range with a combined BTUgreater
than 66,000 BTU.

Instollotion Instructions
-IPLACEMENT OF THE MOUNTING PLATE
REMOVING THE OVEN FROM
THE CARTON/REMOVING
THE MOUNTING PLATE
%
[]
Remove the box containing the installation
instructions, filters, exhaust adaptor, damper
and the small hardware bag. Do not remove
the foam packing protecting the front of the oven.
Fold back all 4 carton flaps fully against carton sides.
Then carefully roll the oven and carton over onto
the top side. The oven should be resting in the foam
packing.
Foam
packing
%
%
%
%
Pullthe carton up and off the oven.
The mounting plate is attached to the back of the
oven. Remove the two screws holding it to the oven.
The plate will be used as the rear wall template and
for mounting the oven to the wall.
Setthe oven upright. Remove and properly discard
plastic bags and foam packing.
Open the oven door and remove the foam pack
from inside the oven. Remove the tape covering the
turntable hub.
FINDING THE WALL STUDS
Cente_
Wall
Studs
[_ Findthe studs, using one of the following methods:
A. Stud finder - a magnetic device which locates nails.
OR
B. Use a hammer to tap lightly across the mounting
surface to find a solid sound. This will indicate
a stud location.
[_ After locating the stud(s),find the center by probing
the wall with a small nail to find the edges of the stud.
Then place a mark halfway between the edges.
The center of any adjacent studs should be 16" or 24"
from this mark.
[_ Draw a line down the center of the studs.
IMPORTANT: The microwave must be connected to at
least one wall stud.
8

Installation Instructions
[_ DETERMINING WALL PLATE LOCATION UNDER YOUR CABINET
Plate position - beneath flat bottom
cabinet Plate position - beneath framed recessed
cabinet bottom
o
MountingPlateTabs
Touching theCabinet
:.Bottom
At least 30", up to 36"
Mounting Plate Tabs
Touching the Back
Frame
II "30" to Cooktop
i ,, I
Plate position - beneath recessed bottom
cabinet with front overhang
0
0
C
MountingPlate
with TabsBelow
CabinetBottom
the SameDistance
asthe Front
'....Overhang Depth
..
..-.. l
;0" to CooktopI
Your cabinets may have decorative trim that interferes
with the oven installation. Remove the decorative trim
to instGIIthe oven properly and to make it level.
THE OVEN MUSTBE LEVEL.
Use a level to make sure the cabinet bottom is level.
If the cabinets have a front overhang only, with no back
or side frame, install the mounting plate down the same
distance as the front overhang depth. This will keep
the oven level.
[_ Measure the inside depth of the front overhang.
[_ Draw a horizontal line on the back wall an equal
distance below the cabinet bottom asthe insidedepth
of the front overhang.
[_ For this type of installation with front overhang only,
align the mounting tabs with this horizontal line,not
touching the cabinet bottom as described in Step D.
9

Installation Instructions
_ ALIGNING THE WALL PLATE
Hole Draw a
Vertical Line
b---- on Wall from
Center of Top
Cabinet
Hole C
ACAUTION'.
Wear gloves to avoid cutting
fingers on sharp edges.
I
Iolo
4T
I
AreaE J
I
[_ Draw a vertical line on the wall at the center of the 30"
wide space.
[_ Usethe mounting plate as the template for the rear wall.
Placethe mounting plate on the wall, making sure that
the tabs are touching the bottom of the cabinet or
the level line drawn in Step Cfor cabinets with front
overhang. Line up the notch and center line on
the mounting plate to the center line on the wall.
[_ While holding the mounting plate with one hand, draw
circles on the wall at holesA,B,Cand D(seeillustration
above/actual plate marked with arrows). Four holes
must be used for mounting.
NOTE:HolesCand D are inside area E.If neither C nor D
isin a stud, find a stud somewhere in area Eand draw a
fifth circle to line up with the stud. It is important to use
at least one wood screw mounted firmly in a stud
to support the weight of the oven.
Set the mounting plate aside.
WARNING:Riskofelectricshock.Cancause
injury or death. Take care to not drill into electrical wiring
inside walls or cabinets.
[_ Drill holeson the circles. If there is a stud, drill a sad'hole
for wood screws. Forholes that don't line up with a stud,
drill a %" hole for toggle bolts.
NOTE:DONOTMOUNTTHEPLATEATTHISTIME.
10
