JKP28BF/WF – GE 27" Built-In Double Oven
27" Built-In Double Oven Dimensions (in inches)
KW Rating
240V 7.1
208V 5.3
Breaker Size
240V 30 Amps
208V 30 Amps
10
Locate
junction box
for 27"models
either 5" MIN.
below cutout
floor or 44"
MIN. above
cutout floor
Allow 3/4"
for overlap
over all edges
of cutout
A
Minimum
cutout location
from floor
D
E
2" X 4" or
equiv. runners
(cutout floor) 20" MIN.
door opening
allowance
B
C
H
F
G
Conduit
49" long 20
Cabinet 27"
A – Cabinet Width Required 27" min.
B – Minimum Cabinet Depth 23-5/8"
C – Opening Width 25" min. - 25-1/4 max.
D – Opening Height 50-1/8" max.
E – Recommended Minimum
Cutout Location from Floor 13-1/4"
Oven
F –Overall Depth 23-5/8"
w/o trim 50-1/4"
G –Overall Height with trim 51"
H –Overall Width 26-5/8"
C
L
Suitable
bracing
to support
runners 18"
Over centerline
of cabinet
2" x 4" or
equivalent
runners
(Must support 275 lbs.)
Note: Cabinets installed adjacent to wall ovens must have an adhesion spec of
at least a 194°F temperature rating.
Note: If marks, blemishes or the cutout opening is visible above the installed
oven, it may be necessary to add wood shims under the runners and front trim
until the marks or openings are covered.
Specification Created 7/02
R
Listed by
Underwriters
Laboratories
For answers to your Monogram,
®GE Profile™or
GE appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center®service, 800.626.2000.
Installation Information: Before installing, consult installation
instructions packed with product for current dimensional data.
Electric wall ovens are not approved for installation with a plug and receptacle.
They must be hard wired in accordance with installation instructions.

GE Appliances
Specification Created 7/02
JKP28BF/WF –GE 27" Built-In Double Oven
Features and Benefits
•TrueTemp™System
•2 Extra-Large 3.9 cu. ft. Capacity Ovens
(Self-Clean Upper Oven)
•2 Oven Racks with 4 Embossed Positions in Each Oven
•SmartSet Electronic Oven Controls (Upper Oven)
•Six-Pass Bake Element and Interior Oven Light
•True Frameless Glass Oven Doors with Big ClearView™Windows
•Certified Sabbath Mode (Upper Oven)
•Installation Flexibility
•Model JKP28WFWW –White on white
•Model JKP28BFBB –Black on black
