GE JBP89DM Manual

Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Listed by
Underwriters
Laboratories
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Specification Revised 10/08 321578
KW Rating
240V 14.2
208V 10.7
Breaker Size
40 Amps†
30
25
29-7/8
A*
2-1/2
7-1/2
25-3/8
47-5/8
2-1/2
Acceptable electrical
outlet area
30_install_fse_drawer.eps
7
14-1/2
On models with baking or warming
drawers, electrical outlet must not
be in this area.
Dimension from wall to front of closed
oven door handle is 27-3/8 on models
JB988/968/910/900 and 27-3/4 on models
JBP89/84/81.
*A is 46-7/8 on models JBP89/84/81 and
46-1/2 on models JB988/968/910/900
JBP89DM
GE® 30" Free-Standing Double Oven Range
†Note: Check local codes for required breaker size.
Effective January 1, 1996, the National Electrical
Code requires that new construction (not existing)
utilize a 4-conductor connection to an electric range.
Receptacle Locations: Locally approved flexible
service cord or conduit must be used because
terminals are not accessible after range installation.
See shaded area in drawing for location of electrical
outlet box. Recommended outlet locations allow
range to be installed directly against wall.
Note: 30" ranges conform to U.L. requirements for
0" spacing from adjacent walls below countertops.
To reduce possibility of scorching walls, engineering
recommends a minimum of 1-1/2" spacing to allow
for possible extended, high-heat, no-load heating
element operation.
Installation information: Before installing, consult
installation instructions packed with product for
current dimensional data.
All 30" GE gas and electric range backguards
are 30-7/8" wide.*
Note: 30" ranges conform to U.L. requirements
for 0" spacing from adjacent walls below
countertops. To reduce possible scorching of
walls, engineering recommends a minimum of
1-1/2" spacing to allow for possible extended,
high heat, no-load heating element operation.
*Except these models: JGBS07, JGBS04, JGBP90,
all GE Profile free-standing electric and gas
ranges
Fits most countertop backsplash applications.
Consult Use & Care Manual for detailed
installation instructions.
30-7/8"

Specification Revised 10/08 321578
Features and Benefits
• Self-Clean Oven - Conveniently cleans the oven cavity without the need for scrubbing
• Super-Large 5.3 Cu. Ft. Oven Capacity - Provides an impressively large oven interior
to cook more dishes and large meals at once
• Hidden Bake Oven Interior - Hides previously exposed bottom element to deliver a
clean interior appearance
• Self-Clean Heavy-Duty Oven Racks - Double coated porcelain-enameled racks no
longer require hand cleaning
• Lower Oven - Offers an additional 1.2 cu. ft. of capacity for convenient baking from
140 degrees to 450 degrees
• 12"/9"/6" Tri-Ring Element - Provides three cooking areas in one for the ultimate in
cooking versatility
• Bridge Element - Combines three cooktop elements into one large cooking area,
ideal for oversized cooking pans
• Warming Zone - Provides low heat capability for foods, making meal
coordination simple
• QuickSet IV Oven Controls - Feature an easy to use design which allows you to set
precise cooking temperatures
• Big Hearth Window - Features an enhanced shape to add an elegant appearance
and make viewing trouble-free
• Model JBP89DMBB - Black on black (black glass door and black patterned cooktop)
JBP89TM/DM
BROILSELF
CLEAN
OVEN
LIGHT
CLOCK
OVENCONTROLSTrueTemp
ON
TEMP
NORMAL
HILOOFF
KITCHEN
TIMER
ONOFF
BAKESTART
ON
CLEAR
OFF
TIMECONTROLS
COOKING
TIME
ONOFF
AUTOMATICOVEN
START
TIME
ONOFF
SMALL
BURNER
LARGE
BURNER
FRONT
BURNER
BRIDGE
BURNER
LOWEROVEN
HEATING
WM
200
250
300350400
450
WARMINGZONE
MED
JBP89DM
GE® 30" Free-Standing Double Oven Range
