GE JTP47SCSS User instructions

Specification Revised 11/00
GE Appliances
JTP47SCSS - GE 30" Double Wall Oven
21" minimum
Door Opening
Allowance
5
B
B
A
A
47
Conduit
(48" long)
Junction box
location
Cutout height
51-13/16" MIN.
51-15/16" MAX.
Recommended cutout
location 12" from the floor.
Cutout width
28-1/2'' MIN.
28-5/8'' MAX.
21
Cabinet
width
30"
C
E
D
MOST 30'' WALL CABINETS CAN BE USED WITH THIS UNIT
THE OPENING BETWEEN THE INSIDE WALLS MUST BE AT LEAST 28-1/2'' WIDE
CUTOUT DEPTH
23-1/2'' MIN.
Cabinet Installation Dimensions (in inches)
C
L
SUITABLE
BRACING
TO SUPPORT
RUNNERS
2" x 4" or
EQUIVALENT
RUNNERS
21 5/8"
OVER CENTERLINE
OF CABINET
A–Overlap of Oven Over Side Edges of Cutout 11/16-3/4""
B–Overlap of Oven at Top and Botto of Cutout 1"
Cabinet 30"
C–Overall Depth 23-1/2"
D–Overall Height 52-15/16"
E–Overall Width 30"
Oven
Note: Cabinets installed adjacent to wall ovens must have an
adhesion spec of at least 194°
*Most 30" wall cabinets can be used
with this unit.
The opening between the inside walls
must be at least 28-1/2" wide.
A = Allow minimum of 21" for clearance to
adjacent corners, drawers, walls, etc.,
when door is opened.
B = Allow 11/16" for overlap of oven
over side edges of cutout.
C = Allow 1" for overlap of oven—
top and bottom of cutout.
Installation Information: Before
installing, consult installation instructions
(Pub. No. 31-10125) packed with
product for current dimensional data.
R
Listed by
Underwriters
Laboratories
For answers to your Monogram,
®
GE Profile Performance Series,
™
GE Profile™or GE appliance questions, call
GE Answer Center®service, 800.626.2000.
KW Rating
240V 7.2
208V 5.4
Breaker Size
30 Amps†
†Note: Check local codes for required breaker size

Specification Revised 11/00
GE Appliances
JTP47SCSS - GE 30" Double Wall Oven
Features and Benefits
•TrueTemp™System
•Extra Large Capacity Self-Clean Upper Oven with Automatic Oven Door Locks
•Extra Large Capacity Self-Clean Lower Oven
•2 Oven Racks (Each Oven)
•6 Embossed Rack Positions (Each Oven)
•SmartSet Electronic Oven Controls
•Electronic Clock and Kitchen Timer
•Delay Time Bake Option with Cook and Hold
•Auto Oven Shut-Off with Override
•Variable Broil / Six-Pass Broil Element
•Extra-Large Broiler Pan with Grid
•Up-Front Oven Lights
•Frameless Glass Oven Doors with Big-View Windows
•Sure Grip Designer-Style Handle
•30" Oven Cabinet Width Required
•Model JTP47SCSS - Stainless steel
