Questions? Call 800.GE.CARES (800.432.2737) or Visit our Website at: ge.com
READ CAREFULLY.
KEEP THESE INSTRUCTIONS.
Installation Above the
Instr ctions Cooktop Oven
Model JVM1665
Read these instr ctions completely and caref lly.
•IMPORTANT – Save these
instructions for local inspector’s use.
•IMPORTANT –Observe all
governing codes and ordinances.
•Note to Installer –Be sure to leave these
instructions with the Consumer.
BEFORE YOU BEGIN
•Note to Cons mer – Keep these instructions
for future reference.
Skill level – Installation of this appliance requires basic
mechanical and electrical skills.
Proper installation is the responsibility of the installer.
Product failure due to improper installation is not
covered under the Warranty.
49-40584
06-08 JR

2
Recirculating ................................................ 19–22
Attach Mounting Plate to Wall ................19
Preparation of Top Cabinet ......................19
Adapting Blower for
Recirculation........................................20, 21
Mount the Oven ..................................21, 22
Installing the Charcoal Filter ....................22
Before Yo Use Yo r Oven .......................................... 23
CONTENTS
General information
Important Safety Instr ctions ...................................... 3
Electrical Req irements .................................................. 3
Hood Exha st ................................................................ 4, 5
Damage—Shipment/Installation .................................. 6
Parts Incl ded .................................................................. 6
Tools Yo Will Need.......................................................... 7
Mo nting Space ................................................................ 7
Step-by-step installation g ide
Placement of Mo nting Plate .................................. 8–10
Removing the Mounting Plate ............................ 8
Finding the Wall Studs.......................................... 8
Determining Wall Plate Location ........................ 9
Aligning the Wall Plate ...................................... 10
Installation Types .................................................... 11–22
Outside Top Exhaust .................................... 12–14
Attach Mounting Plate to Wall ................12
Preparation of Top Cabinet ......................13
Assemble and Install Adapter ..................13
Mount the Oven ..................................13, 14
Adjust the Exhaust Adapter ......................14
Connecting Ductwork................................14
Outside Back Exhaust .................................. 15–18
Preparing Rear Wall for
Outside Back Exhaust................................15
Attach Exhaust Adapter to
Oven Rear Panel ........................................15
Attach Mounting Plate to Wall ................16
Preparation of Top Cabinet ......................16
Adapting Blower for Outside
Back Exhaust..................................................17
Mount the Oven..........................................18
A
B
C
Installation Instr ctions

This product requires a three-prong grounded outlet.
The installer must perform a ground continuity check
on the power outlet box before beginning the
installation to insure that the outlet box is properly
grounded. If not properly grounded, or if the outlet
box does not meet electrical requirements noted
(under ELECTRICAL REQUIREMENTS), a qualified
electrician should be employed to correct any deficiencies.
CAUTION:
For personal safety, remove
ho se f se or open circ it
breaker before beginning
installation to avoid severe
or fatal shock inj ry.
CAUTION:For personal safety, the mo nting
s rface m st be capable of s pporting the cabinet load,
in addition to the added weight of this 63–85 po nd
prod ct, pl s additional oven loads of p to 50 po nds
or a total weight of 113–135 po nds.
CAUTION:For personal safety, this prod ct
cannot be installed in cabinet arrangements s ch as an island
or a penins la. It m st be mo nted to BOTH a top cabinet
AND a wall.
NOTE: For easier installation and personal safety,
it is recommended that two people install this prod ct.
IMPORTANT—PLEASE READ CAREFULLY.
FOR PERSONAL SAFETY, THIS APPLIANCE MUST
BE PROPERLY GROUNDED TO AVOID SEVERE
OR FATAL SHOCK.
The power cord of this
appliance is eq ipped with
a three-prong (gro nding)
pl g which mates with
a standard three-prong
(gro nding) wall receptacle
to minimize the possibility
of electric shock hazard
from this appliance.
Yo sho ld have the wall receptacle and circ it checked
by a q alified electrician to make s re the receptacle is
properly gro nded.
Where a standard two-prong wall receptacle is
enco ntered, it is very important to have it replaced
with a properly gro nded three-prong wall receptacle,
installed by a q alified electrician.
DO NOT, UNDER ANY CIRCUMSTANCES, CUT, DEFORM OR
REMOVE ANY OF THE PRONGS FROM THE POWER CORD.
DO NOT USE WITH AN EXTENSION CORD.
IMPORTANT SAFETY INSTRUCTIONS
3
ELECTRICAL
REQUIREMENTS
Product rating is 120 volts ACE, 60 Hertz, 14 amps
and 1.60 kilowatts. This product must be connected
to a supply circuit of the proper voltage and frequency.
Wire size must conform to the requirements of the National
Electrical Code or the prevailing local code for this kilowatt
rating. The power supply cord and plug should be brought
to a separate 15 to 20 ampere branch circuit single
grounded outlet. The outlet box should be located in the
cabinet above the oven. The outlet box and supply circuit
should be installed by a qualified electrician and conform
to the National Electrical Code or the prevailing local code.
Insure proper
ground exists
before use
Installation Instr ctions

4
EQUIVALENT NUMBER EQUIVALENT
DUCT PIECES LENGTH x USED = LENGTH
Roof Cap 24 Ft. x (1) = 24 Ft.
12 Ft. Straight Duct 12 Ft. x (1) = 12 Ft.
(6″Round)
Rectangular-to-Round 5 Ft. x (1) = 5 Ft.
Transition Adapter*
Equivalent lengths of duct pieces are based on actual tests and
reflect requirements for good venting performance with any vent hood. Total Length = 41 Ft.
HOOD EXHAUST
The following chart describes an example of one possible
ductwork installation.
NOTE: Read these next two pages only if yo plan to vent yo r exha st to the
o tside. If yo plan to recirc late the air back into the room, proceed to page 6.
OUTSIDE TOP EXHAUST (EXAMPLE ONLY)
NOTE: For back exhaust, care should be taken to align exhaust with space between studs, or wall should be prepared
at the time it is constructed by leaving enough space between the wall studs to accommodate exhaust.
*IMPORTANT: If a rectangular-to-round transition adapter is used, the bottom corners of the damper will have
to be cut to fit, using the tin snips, in order to allow free movement of the damper.
The following chart describes an example of one possible
ductwork installation.
Installation Instr ctions
OUTSIDE BACK EXHAUST (EXAMPLE ONLY)
EQUIVALENT NUMBER EQUIVALENT
DUCT PIECES LENGTH* x USED = LENGTH
Wall Cap 40 Ft. x (1) = 40 Ft.
3 Ft. Straight Duct 3 Ft. x (1) = 3 Ft.
(31⁄4″x 10″Rectangular)
90° Elbow 10 Ft. x (2) = 20 Ft.
Equivalent lengths of duct pieces are based on actual tests and
reflect requirements for good venting performance with any vent hood. Total Length = 63 Ft.

EQUIVALENT NUMBER EQUIVALENT
DUCT PIECES LENGTH x USED = LENGTH
Rectangular-to-Round 5 Ft. x ( ) = Ft.
Transition Adapter*
Wall Cap 40 Ft. x ( ) = Ft.
90° Elbow 10 Ft. x ( ) = Ft.
45° Elbow 5 Ft. x ( ) = Ft.
90° Elbow 25 Ft. x ( ) = Ft.
45° Elbow 5 Ft. x ( ) = Ft.
Roof Cap 24 Ft. x ( ) = Ft.
Straight Duct 6″Round or 1 Ft. x ( ) = Ft.
31⁄4″x 10″Rectangular
Total D ctwork = Ft.
Equivalent lengths of duct pieces are based on actual tests
and reflect requirements for good venting performance with
any vent hood.
* IMPORTANT:: If a rectangular-to-round transition
Adapter is used, the bottom corners of the damper
will have to be cut to fit, using the tin snips, in order
to allow free movement of the damper .
NOTE: If you need to install ducts, note that the total duct
length of 31⁄4″x 10″rectangular or 6″diameter round duct
sho ld not exceed 120 eq ivalent feet.
Outside ventilation requires a HOOD EXHAUST DUCT.
Read the following carefully.
NOTE: It is important that venting be installed using
the most direct route and with as few elbows as possible.
This ensures clear venting of exhaust and helps prevent
blockages. Also, make s re dampers swing freely
and nothing is blocking the d cts.
Exha st connection:
The hood exhaust has been designed to mate with
a standard 31⁄4″x 10″rectangular duct.
If a round duct is required, a rectangular-to-round
transition Adapter must be used. Do not se less
than a 6″diameter d ct.
Maxim m d ct length:
For satisfactory air movement, the total duct length
of 31⁄4″x 10″rectangular or 6″diameter round duct
sho ld not exceed 120 eq ivalent feet.
Elbows, transitions, wall and roof caps, etc.,
present additional resistance to airflow and are equivalent
to a section of straight duct which is longer than their
actual physical size. When calculating the total duct
length, add the equivalent lengths of all transitions and
adapters plus the length of all straight duct sections.
The chart below shows you how to calculate total
equivalent ductwork length using the approximate
feet of equivalent length of some typical ducts.
5
Installation Instr ctions

PART QUANTITY
Top Cabinet 1
Template
Rear Wall 1
Template
Installation 1
Instructions
Separately 1
Packed
Grease
Filter
Exhaust 1
Adapter
Damper 1
PART QUANTITY
Wood Screws 2
(1⁄4″x 2″)
Toggle Bolts (and 4
wing nuts) (1⁄4″x 3″)
Self-aligning Machine 3
Screws (1⁄4″-28 x 31⁄4″)
Nylon Grommet 2
(for metal cabinets)
Metal Screws 1 black
(1⁄8″x 1⁄2″) 2 bronze
Power Cord Strap 1
(plastic)
6
•If the nit is damaged in shipment, return
the unit to the store in which it was bought for
repair or replacement.
•If the nit is damaged by the c stomer, repair
or replacement is the responsibility of the customer.
•If the nit is damaged by the installer (if other
than the customer), repair or replacement must
be made by arrangement between customer
and installer.
DAMAGE – SHIPMENT/
INSTALLATION PARTS INCLUDED
ADDITIONAL PARTS
Installation Instr ctions
PARTS INCLUDED
You will find the installation hardware contained
in a packet with the unit. Check to make sure you
have all these parts.
NOTE: Some extra parts are included.
HARDWARE PACKET

7
TOOLS YOU WILL NEED
# 1 and #2 Phillips screwdriver Pencil
Ruler or tape measure
and straight edge Carpenter square
(optional)
Tin snips (for cutting
damper, if required)
Electric drill with 3⁄16″, 7⁄16″, 3⁄8″,
1⁄2″and 5⁄8″drill bits
Hammer (optional)
Stud finder or
Filler blocks or scrap
wood pieces, if needed
for top cabinet spacing
(used on recessed bottom
cabinet installations only)
Gloves
Saw (saber, hole or keyhole)
Level Duct and masking tape
MOUNTING SPACE
NOTES:
•The space between the cabinets must be 30″wide
and free of obstructions.
•If the space between the cabinets is greater
than 30″, a Filler Panel Kit may be used to fill
in the gap between the oven and the cabinets.
Your Owner’s Manual contains the kit number
for your model.
•This oven is for installation over ranges up to
36″wide.
•If you are going to vent your oven to the outside,
see Hood Exhaust Section for exhaust duct
preparation.
•When installing the oven beneath smooth, flat
cabinets, be caref l to follow the instr ctions
on the top cabinet template for power cord
clearance.
Backsplash
66″or more
from the floor
to the top of
the oven
30″
2″
30″
min.
16-1⁄4″
Bottom edge of
cabinet needs to
be 30″or more
from the cooking
surface
Installation Instr ctions
Scissors
(to cut template, if necessary)
Safety goggles
NOTE: Maximum cabinet depth is 13".

8
Find the studs, using one of the following methods:
A. Stud finder – a magnetic device which locates nails.
OR
B. Use a hammer to tap lightly across the mounting
surface to find a solid sound. This will indicate
a stud location.
After locating the stud(s), find the center by probing
the wall with a small nail to find the edges of the stud.
Then place a mark halfway between the edges.
The center of any adjacent studs should be 16″
or 24″from this mark.
Draw a line down the center of the studs.
THE OVEN MUST BE CONNECTED TO AT LEAST ONE
WALL STUD.
1
Remove the turntable, installation instructions,
filters, exhaust Adapter, damper, shelf and the small
hardware bag. Do not remove the Styrofoam
protecting the front of the oven.
Fold back all 4 carton flaps fully against carton
sides. Then carefully roll the oven and carton
over onto the top side. The oven should be resting
in the Styrofoam.
REMOVING THE OVEN FROM THE
CARTON/REMOVING THE MOUNTING
PLATE
FINDING THE WALL STUDS
2
PLACEMENT OF THE MOUNTING PLATE
1
Wall
Studs
Center
3
Carton
Pull the carton up and off the oven.
Open the oven door and remove any packing
material, if present, from inside the oven.
2
Styrofoam
Installation Instr ctions
3
6
Set the oven upright. Remove and properly discard
plastic bags and Styrofoam.
5
1
The mounting plate is attached to the back of the
oven. Remove the two screws holding it to the oven.
The plate will be used as the rear wall template and
for mounting the oven to the wall.
4
A.B.

9
DETERMINING WALL PLATE LOCATION UNDER YOUR CABINET
C.
Your cabinets may have decorative trim that interferes
with the oven installation. Remove the decorative trim
to install the oven properly and to make it level.
THE OVEN MUST BE LEVEL.
Use a level to make sure the cabinet bottom is level.
If the cabinets have a front overhang only, with no
back or side frame, install the mounting plate down
the same distance as the front overhang depth.
This will keep the oven level.
Measure the inside depth of the front overhang.
Draw a horizontal line on the back wall an equal
distance below the cabinet bottom as the inside
depth of the front overhang.
For this type of installation with front overhang only,
align the mounting tabs with this horizontal line, not
touching the cabinet bottom as described in Step D.
Plate position – beneath flat bottom
cabinet
Plate position – beneath recessed bottom
cabinet with front overhang
Mounting Plate Tabs
Touching the Cabinet
Bottom
Mounting Plate with
Tabs Below Cabinet
Bottom the Same
Distance as the Front
Overhang Depth
At least 30″, up to 36″
Plate position – beneath framed recessed
cabinet bottom
Mounting Plate Tabs
Touching the Back
Frame
Installation Instr ctions
30″to Cooktop
30″to Cooktop
1
2
3

10
ALIGNING THE WALL PLATE
Draw a vertical line on the wall at the center of the 30″
wide space.
Use the mounting plate as the template for the rear
wall. Place the mounting plate on the wall, making
sure that the tabs are to ching the bottom of the
cabinet or the level line drawn in Step C for cabinets
with front overhang. Line p the notch and center line
on the mo nting plate to the center line on the wall.
While holding the mounting plate with one hand,
draw circles on the wall at holes A, B, C and D (see
illustration above/actual plate marked with arrows).
Fo r holes m st be sed for mo nting.
NOTE: Holes C and D are inside area E. If neither C nor D
is in a stud, find a stud somewhere in area E and draw a
fifth circle to line up with the stud. It is important to use
at least one wood screw mounted firmly in a st d
to support the weight of the oven.
Set the mo nting plate aside.
Drill holes on the circles. If there is a stud, drill a 3⁄16″hole
for wood screws. For holes that don’t line up with a stud,
drill a 5⁄8″hole for toggle bolts.
NOTE: DO NOT MOUNT THE PLATE AT THIS TIME.
2
3
4
Draw a Vertical
Line on Wall
from Center of
Top Cabinet
Area E
Hole A
Hole B
Hole D
Hole C
D.
Installation Instr ctions
CAUTION: Wear gloves to
avoid cutting fingers on
sharp edges.
1
NOTE: Appearance and
shape of the mounting
plate may vary from your
model.

A
INSTALLATION TYPES (Choose A, B or C)
This oven is designed for adaptation to the following three
types of ventilation:
A. O tside Top Exha st (Vertical D ct)
B. O tside Back Exha st (Horizontal D ct)
C. Recirc lating (Non-Vented D ctless)
NOTE: This oven is shipped assembled for Outside Top
Exhaust (except for non-vented models). Select the type
of ventilation required for your installation and proceed
to that section.
OUTSIDE TOP EXHAUST
(VERTICAL DUCT) OUTSIDE BACK EXHAUST
(HORIZONTAL DUCT)
RECIRCULATING
(NON-VENTED DUCTLESS)
See page 12 See page 15
See page 19
On models shipped for
non-vented exhaust, a
disposable charcoal filter is
included with the oven and
needs to be installed to help
remove smoke and odors.
On models shipped for outside
top exhaust, a Charcoal Filter
Accessory Kit is required for the
non-vented exhaust. (See your
Owner’s Manual for the kit
number.)
Installation Instr ctions
2
B
C
11

Place the mounting plate against the wall
and insert the toggle wings into the holes
in the wall to mount the plate.
NOTE: Before tightening toggle bolts and wood screw,
make sure the tabs on the mounting plate touch
the bottom of the cabinet when pushed flush against
the wall and that the plate is properly centered under
the cabinet.
CAUTION: Be careful to avoid pinching fingers between
the back of the mounting plate and the wall.
Tighten all bolts. Pull the plate away from the wall
to help tighten the bolts.
3
A
4
ATTACH THE MOUNTING PLATE
TO THE WALL
A1.
12
OUTSIDE TOP EXHAUST (Vertical D ct)
Attach the plate to the wall using toggle bolts.
At least one wood screw must be used to attach
the plate to a wall stud.
Remove the toggle wings from the bolts.
Insert the bolts into the mounting plate
through the holes designated to go into drywall
and reattach the toggle wings to 3⁄4″onto each bolt.
1
INSTALLATION OVERVIEW
A1. Attach Mounting Plate to Wall
A2. Prepare Top Cabinet
A3. Install Adapter
A4. Mount Oven
A5. Adjust Exhaust Adapter
A6. Connect Ductwork
Wall
Mounting
Plate
Spacing for Toggles
More Than Wall
Thickness
Bolt End
Toggle
Bolt
Toggle Wings
To se toggle bolts:
Installation Instr ctions
2

13
2Rotate front of oven
up against cabinet
bottom.
1
MOUNT THE OVEN
A4.
ASSEMBLE AND INSTALL
ADAPTER
A3.
USE TOP CABINET TEMPLATE FOR
PREPARATION OF TOP CABINET
You need to drill holes for the top support screws,
a hole large enough for the power cord to fit through,
and a cutout large enough for the exhaust adapter.
A2.
FOR EASIER INSTALLATION AND PERSONAL SAFETY, WE
RECOMMEND THAT TWO PEOPLE INSTALL THIS OVEN.
IMPORTANT: Do not grip or se handle
d ring installation.
NOTE: If your cabinet is metal, use the nylon
grommet around the power cord hole to prevent
cutting of the cord.
NOTE: We recommend using filler blocks if the
cabinet front hangs below the cabinet bottom shelf.
IMPORTANT: If filler blocks are not sed,
case damage may occ r from over
tightening screws.
NOTE: When mounting
the oven, thread power cord
through hole in bottom
of top cabinet. Keep it tight
throughout Steps 1–3.
Do not pinch cord or lift
oven by pulling cord. Lift oven, tilt it
forward and hook
slots at back bottom
edge onto two lower
tabs of mounting
plate.
Damper
Back of
Oven
•Read the instructions on the top cabinet template.
•Tape it underneath the top cabinet.
•Drill the holes, following the instructions
on the top cabinet template.
CAUTION: Wear safety goggles when drilling holes
in the cabinet bottom.
Installation Instr ctions
Place the oven in its upright position, with the top
of the unit facing up.
NOTE: Make s re the blower fan blades are visible
and are pointing p.
Insert the tabs on each side of the damper
into the holes at the inside rear of the adapter.
Attach the exhaust adapter to the blower plate
with the two bronze metal screws provided.
Make s re that the damper pivots easily before
mo nting oven.
You will need to make adjustments to assure
proper alignment with your house exhaust duct
after the oven is installed.
Exhaust
Adapter
1
2
Blower Plate
3
NOTE: On some models, the exhaust adapter and damper
assembly may already be assembled to the oven.

Attach the oven to the top cabinet by inserting
3 self-aligning screws through outer top cabinet
holes. Turn two full turns on each screw. Be s re
to keep power cord tight. Be caref l not to pinch
the cord, especially when mo nting fl sh to
bottom of cabinet.
3
14
5
4
Cabinet Front
Cabinet Bottom Shelf
Tighten the three screws to the top of the oven
completely. (While tightening screws, hold the oven
in place against the wall and the top cabinet.)
Filler Block
Oven Top
Equivalent
to Depth
of Cabinet
Recess
Install grease filters. See the Owner’s Manual
packed with the oven.
Installation Instr ctions
ADJUST THE EXHAUST ADAPTER
A5.
Open the top cabinet and adjust the exhaust adapter
to connect to the house duct.
CONNECTING DUCTWORK
1
2
Extend the house duct down to connect
to the exhaust adapter.
Seal exhaust duct joints using duct tape.
A6.
House Duct
Self-Aligning Screw
MOUNT THE OVEN (contin ed)
A4.
Back of
Oven
Damper

Attach the exhaust adapter to the oven rear panel
by sliding it into the guides at the top center
of the back of the oven.
OUTSIDE BACK EXHAUST (Horizontal D ct)
PREPARING THE REAR WALL
FOR OUTSIDE BACK EXHAUST
B1.
INSTALLATION OVERVIEW
B1. Prepare Rear Wall
B2. Attach Exhaust Adapter
to Wall Plate
B3. Attach Mounting Plate
to Wall
B4. Prepare Top Cabinet
B5. Adjust Blower
B6. Mount the Oven
Installation Instr ctions
B
Read the instructions on the REAR WALL TEMPLATE.
Tape it to the rear wall, lining up with the holes
previously drilled for holes A and B in the wall plate.
Cut the opening, following the instructions of the REAR
WALL TEMPLATE.
15
3
2
1
Unscrew and remove the exhaust adapter assembly
from the top of the oven.
1
2
Exhaust Adapter Damper
(hinge side up)
Locking
Tabs
Guide
ATTACH THE EXHAUST ADAPTER
TO THE OVEN REAR PANEL
B2.
Guide
Push in securely until it is in the lower locking tabs.
Take care to assure the damper hinge is installed so
that it is at the top and that the damper swings freely.
You need to cut an opening in the rear wall for outside
exhaust.
Exhaust
Adapter

16
USE TOP CABINET TEMPLATE FOR
PREPARATION OF TOP CABINET
B4.
•Read the instructions on the TOP CABINET TEMPLATE.
•Tape it underneath the top cabinet.
•Drill the holes, following the instructions on the TOP
CABINET TEMPLATE.
CAUTION: Wear safety goggles when drilling holes
in the cabinet bottom.
Wall
Mounting
Plate
Spacing for Toggles More
Than Wall Thickness
Toggle
Bolt
Toggle Wings
To se toggle bolts:
Bolt End
Installation Instr ctions
You need to drill holes for the top support screws
and a hole large enough for the power cord to fit through.
Place the mounting plate against the wall and insert
the toggle wings into the holes in the wall
to mount the plate.
NOTE: Before tightening toggle bolts and wood
screw, make sure the tabs on the mounting plate touch
the bottom of the cabinet when pushed flush against
the wall and that the plate is properly centered under
the cabinet.
CAUTION: Be careful to avoid pinching fingers between
the back of the mounting plate and the wall.
Tighten all bolts. Pull the plate away from the wall
to help tighten the bolts.
3
4
ATTACH THE MOUNTING PLATE
TO THE WALL
B3.
Attach the plate to the wall using toggle bolts. At least
one wood screw must be used to attach the plate to
a wall stud.
Remove the toggle wings from the bolts.
Insert the bolts into the mounting plate through
the holes designated to go into drywall and reattach
the toggle wings to 3⁄4″onto each bolt.
1
2

Place the blower unit back into the opening.
Roll the blower unit 90° so that fan blade
openings are facing out the back of the oven.
4
BEFORE: Fan Blade
Openings Facing Up
AFTER: Fan
Blade Openings
Facing Back
2
1Remove the two screws that hold the blower plate
and remove the screw holding the blower motor to
the oven. Slide blower plate from under its retaining
flange.
ADAPTING BLOWER FOR
OUTSIDE BACK EXHAUST
B5.
17
Carefully pull out the blower unit. The wires
will extend far enough to allow you to adjust
the blower unit.
Blower Plate
Blower Plate
Replace the blower plate in the same position
as before and replace the screws for the blower
plate and blower motor.
Before Rolling After Rolling
Back of Oven
Back of
Oven
Back of
Oven
CAUTION: Do not p ll or stretch the blower nit
wiring. Make s re the wires are not pinched.
NOTE: The blower nit exha st openings sho ld
match exha st openings on rear of oven.
Installation Instr ctions
Retaining
Flange
Blower Plate Screws
Back
of Oven
3Rotate blower unit counterclockwise 180°.
Before Rotation After Rotation
Back of
Oven Back of
Oven
5
6
Blower Motor Screw

Attach the oven to the top cabinet by inserting
3 self-aligning screws through outer top cabinet
holes. Turn two full turns on each screw. Be s re
to keep power cord tight. Be caref l not to pinch
the cord, especially when mo nting fl sh
to bottom of cabinet.
18
Installation Instr ctions
2Rotate front of oven up
against cabinet bottom.
1
MOUNT THE OVEN
B6.
FOR EASIER INSTALLATION AND PERSONAL SAFETY, WE
RECOMMEND THAT TWO PEOPLE INSTALL THIS OVEN.
IMPORTANT: Do not grip or se handle
d ring installation.
NOTE: If your cabinet is metal, use the nylon grommet
around the power cord hole to prevent cutting
of the cord.
NOTE: We recommend using filler blocks if the
cabinet front hangs below the cabinet bottom shelf.
IMPORTANT: If filler blocks are not sed,
case damage may occ r from over
tightening screws.
NOTE: When mounting
the oven, thread power
cord through hole in
bottom of top cabinet.
Keep it tight throughout
Steps 1–3. Do not pinch
cord or lift oven by
pulling cord. Lift oven, tilt it
forward and hook
slots at back bottom
edge onto two lower
tabs of mounting plate.
5
4
Cabinet Front
Cabinet Bottom Shelf
Tighten the three screws to the top
of the oven completely. (While tightening
screws, hold the oven in place against the wall
and the top cabinet.)
Filler Block
Oven Top
Equivalent
to Depth
of Cabinet
Recess
Install grease filters. See the Owner’s Manual
packed with the oven.
Self-Aligning Screw
3

USE TOP CABINET TEMPLATE FOR
PREPARATION OF TOP CABINET
C2.
19
RECIRCULATING (Non-Vented D ctless)
INSTALLATION OVERVIEW
C1. Attach Mounting Plate to Wall
C2. Prepare Top Cabinet
C3. Adjust Blower
C4. Mount the Oven
C5. Install Charcoal Filter
•Read the instructions on the TOP CABINET TEMPLATE.
•Tape it underneath the top cabinet.
•Drill the holes, following the instructions on the TOP
CABINET template.
CAUTION: Wear safety goggles when drilling holes
in the cabinet bottom.
Installation Instr ctions
You need to drill holes for the top support screws and
a hole large enough for the power cord to fit through.
C
Place the mounting plate against the wall
and insert the toggle wings into the holes in the wall
to mount the plate.
NOTE: Before tightening toggle bolts and wood
screw, make sure the tabs on the mounting plate touch
the bottom of the cabinet when pushed flush against
the wall and that the plate is properly centered under
the cabinet.
CAUTION: Be careful to avoid pinching fingers between
the back of the mounting plate and the wall.
Tighten all bolts. Pull the plate away from the wall
to help tighten the bolts.
4
3
ATTACH THE MOUNTING PLATE
TO THE WALL
C1.
Attach the plate to the wall using toggle bolts. At least
one wood screw must be used to attach the plate to
a wall stud.
Remove the toggle wings from the bolts.
Insert the bolts into the mounting plate through
the holes designated to go into drywall and
reattach the toggle wings to 3⁄4″onto each bolt.
1
Wall
Mounting
Plate
Spacing for Toggles
More Than Wall
Thickness
Bolt End
Toggle
Bolt
Toggle Wings
To se toggle bolts:
2

AFTER: Fan Blade
Openings Facing
Forward
3
2
4
ADAPTING BLOWER
FOR RECIRCULATION
C3.
20
NOTE: The exhaust Adapter with damper is not
needed for recirculating models. You may want
to save them for possible future use.
Carefully pull out the blower unit. The wires
will extend far enough to allow you to adjust
the blower unit.
Roll the blower unit 90° so that fan blade openings
are facing toward the front of the oven.
Roll
Slide the blower plate from under its retaining
flange and lift it off.
Remove and save screws that hold blower plate
and blower unit to the oven.
Installation Instr ctions
BEFORE: Fan Blade
Openings Facing Up
1
Blower Plate
Retaining
Flange
Blower Plate
Back of Oven
Blower Plate Screws
Blower Motor Screw
