GE PROFILE JTP18BABB User instructions

Specification Revised 6/99
TM
JTP18BABB - GE Profile™30" Single Wall Oven
5
24
25
Gas or electric cooktops may be installed over
this oven. See cooktop installation instructions
for cutout size. See label on top of oven for
approved cooktop models. Gas and electrical connections for
gas cooktop must be located in an
adjacent accessible location to the right.
For a 36" gas cooktop, the connections
may be made to the left.
120 Volt
Outlet
Gas
connection
Junction box
location
240/208V
36'' MIN.
4'' To 4-1/2 '' Toe kick allowable
Match toe kick height
front and two sides
22'' MIN. above
support platform
Top and/or side
fillers may be
necessary if unit
is positioned
between
existing cabinets
28-1/2'' MIN.
28-5/8'' MAX.
27-1/4'' MIN.
27-5/16'' MAX.
Cutout height
3/4'' Support
platform required
23-1/2" MIN.
Cutout depth
Allow 11/16''
overlap over side
edges of cutout
1-1/2"
Countertop
Note: Oven is rated for use only under the following cooktops:
• GE 30" and 36" electric coil and CleanDesign cooktops (Excluding Induction)
• GE 30" and 36" gas standard and sealed burner cooktops
Note: Gas or electric cooktops may be installed over this oven. See cooktop installation
instructions for cutout size. See label on back of oven for approved cooktop models.
Installation Information: Before installing, consult installation instructions [Pub. No. 31-10125]
packed with product for current dimensional data and for alternate installation options.
Undercounter Installation (in inches)
5-9/16"
Reference dim. for
MAX. support height
with typical 36" countertop
height
36" Typical
Countertop height
Power cord
Reference
5-9/16
30-7/16
Free space
1-1/2" MIN.
1-1/2" Typical countertop
Side View
22
27-5/16" MAX.
Cutout height
27-1/4" MIN.
Junction box(s) for
oven & radiant
cooktop 22" from
floor
Add suitable filler
to match adjacent
cabinets when needed
to maintain toe kick
alignment
This installation is to achieve minimum gap between bottom of countertop and control panel.
Note: For this installation, the bottom trim will not be flush with a typical 4" toe kick.
Optional Custom Installation for 30" CleanDesign
(Excluding Induction) or Sealed Burner Gas Cooktop (in inches)
Note: Cabinets installed adjacent to wall ovens must have an adhesion spec
of at least 194°
R
Listed by
Underwriters
Laboratories
For answers to your Monogram,®
GE Profile Performance Series,™
GE Profile™or GE appliance questions, call
GE Answer Center®service, 800.626.2000.

TM
JTP18BABB - GE Profile™30" Single Wall Oven
Specification Revised 6/99
Note: Oven is rated for use only under the
following cooktops:
• GE 30" and 36" electric coil and CleanDesign
cooktops (Excluding Induction)
• GE 30" and 36" gas standard and sealed
burner cooktops
Note: Gas or electric cooktops may be installed
over this oven. See cooktop installation
instructions for cutout size. See label on back
of oven for approved cooktop models.
Installation Information: Before installing,
consult installation instructions [Pub. No.
31-10125] packed with product for current
dimensional data and for alternate
installation options.
Single Oven Wall-Mount or Cabinet Installation
Dimensions (in inches)
Optional Undercounter Installation
with 36" Gas Cooktop (in inches)
Power cord
for counter unit
Junction box
for oven
Junction box in
adjacent cabinet
for counter unit
hook-up
2 (two) 90°elbows &
sufficient pipe to
connect in adjacent
cabinet
Right cabinet side
3/4" Support
Shut-off
valve
Pressure
regulator
1/2" Black
iron pipe
Union
Conduit
30" Built-in
oven
3-1/2" MIN.
Free space
4" To 4-1/2"
3-1/4
22
19-1/16" Cutout depth
Side View
Note: These ovens are not
approved for stackable or
side-by-side installations.
Most 30" Wall Cabinets can be used with this unit.
28-1/2'' MIN.
28-5/8'' MAX.
30
28-1/4
30
Recommended
cutout location
32-1/2"
from floor
21
Junction
box
location
Allow minimum of 21'' for clearance
to adjacent corners, drawers, walls, or etc.
A=Allow 1" overlap of oven over top and bottom edges of cutout.
B=Allow 11/16"-3/4" for overlap of oven over side edges of cutout.
Conduit
(48" long)
5
27-1/4'' MIN.
27-5/16'' MAX.
Cutout height
A
B
23-1/2'' MIN.
Cutout depth
22'' MIN.
Cut Opening
in Solid
Bottom
10
Note: If a solid
bottom is used
instead of the
runners, a 6" x 10"
rectangle must be
cut out of the
bottom for optimum
performance
and proper air
circulation.
6
6
(Must Support 275 lbs.)
For answers to your Monogram,®
GE Profile Performance Series,™
GE Profile™or GE appliance questions, call
GE Answer Center®service, 800.626.2000.
R
Listed by
Underwriters
Laboratories
KW Rating
240V 3.6
208V 2.7
Breaker Size
20 Amps†
†Note: Check local codes for required
breaker size

Specification Revised 6/99
TM
JTP18BABB - GE Profile™30" Single Wall Oven
Features and Benefits
•TrueTemp™ System
•Convection Oven - Convection Bake and Convection Roast
•Extra Large Capacity Self-Clean Oven with Delay Clean Option
•SmartSet Electronic Oven Controls with Digipad
•Electronic Clock and Kitchen Timer
•Automatic Meat Thermometer
•Hidden Bake Element
•3 Oven Racks (Additional Rack Kit Available at Additional Cost)
•7 Embossed Rack Positions
•Variable Broil / Six-Pass Broil Element
•Broiler Pan with Grid and Roasting Rack
•Up-Front Oven Light
•Frameless Glass Oven Door with Big-View Window
•Integrated Designer-Style Handle
•30" Oven Cabinet Width Required
•Undercounter Installation Option
•Model JTP18WAWW - White on white
•Model JTP18BABB - Black on black
•Model JTP18AAAA - Almond on almond
