GE Profile Spacemaker JVM1490 User manual

I
Ista structi kto Ove
JVM1490,JVM1790,SCAI000,SCAI001
jOuestions? Call 800-GE=CARES(800-q32=2737)or Visit our Website at: go.corn j
BEFORE YOU BEGIN
Read these instructions completely and carefully.
• IMPORTANT - S_ve_l_ese
instructions fbr local inspector's use.
•IMPORTANT - Obse,ve_,ll
governing codes and ordinances.
• Note to Installer -Be sure to leave these
instructions with the Constuner.
Note to Consumer - Keep these
instructions for filture reference.
* Skill level - Installation of this appliance requires
basic mechanical and electrical skills.
* Proper installation is the responsibility of the installer.
* Prodt_ct fhilure due to improper installation is not
covered under the Warranty.
LA SECCiON EN ESPANOL
EMPiEZA EN LA PAGiNA 25. READ CAREFU LLY. KEEP THESE iNSTRUCTiONS,

Installation instructions
CONTENTS
General information
Important Safety Instructions .................................. 3
Electrical Requirements .......................................... 3
Hood Exhaust ...................................................... 4, 5
Damage - Shipment/Installation .............................. 6
Parts Included .......................................................... 6
Tools You Will Need ................................................ 7
Mounting Space ...................................................... 7
Step-by-step installation guide
Placement of Mounting Plate ............................ 8-10
Removing the Mounting Plate ...................... 8
Finding the Wall Studs .................................. 8
Determining Wall Plate Location .................. 9
Aligning the Wall Plate ................................ 10
Installation Types .............................................. 11-22
_ Outside Top ............................
Exhaust 12-14
Attach Mounting Plate to Wall ............ 12
Preparation of Top Cabinet ................ 13
Checking for Proper Damper
Operation ............................................ 13
Mount the Oven ............................ 13, 14
Adj ust the Exhaust Adaptor ................ 14
Connecting Ductwork .......................... 14
_ Outside Back Exhaust 15-18
Preparing Rear Wall fin.
Outside Back Exhaust .......................... 15
Attach Mounting Plate to Wall ...... 15, 16
Preparation of Top Cabinet ................ 16
Adapting Blower fin Outside
Back Exhaust .................................... 16, 17
Mount the Oven .................................. 18
Recirculating ........................................ 19-22
Attach Mounting Plate to Wall ............ 19
Preparation of Top Cabinet ................ 19
Adapdng Blower
fin Recirculation .......................... 20, 21
Mount the Oven ............................ 21, 22
Installing the Charcoal Filter. ............. 22
Before You Use Your Oven .................................. 23
Seccidn en Espafiol ........................................ 25-47
2

Installation instructions
iMPORTANT SAFETY iNSTRUCTiONS
This product requires a three-prong grounded
out|et. The installer must perform a ground continuity
check on the power outlet box before beginning the
installation to instue that the out|et box is properly
grounded. If not properly grounded, or if the
outlet box does not meet electrical requirements
noted (under ELECTRICAl, REQUIREMENTS),
a qualified electrician should be employed to
correct any deficiencies.
i_1/[ CAUTION: For personal
safety, remove house fuse
i or open circuit breaker
before beginning installation
to avoid severe or fatal
shock injury.
w
CAUTION: For personal safety, the mounting surface
must be capable of supporting the cabinet load, in
addition to the added weight of this 63-85 pound
product, plus additional oven loads of up to 50 pounds
or atotal weight of 113-135 pounds.
CAUTION: For personal safety, this product cannot
be installed in cabinet arrangements such as an island or
a peninsula. It must be mounted to BOTH a top cabinet
AND a wall.
NOTE: For easier installation and personal safety, it is
recommended that two people install this product.
IMPORTANT--PLEASE READ CAREFULLY. FOR
PERSONAL SAFETY, THIS APPLIANCE MUST BE
PROPERLY GROUNDED TO AVOID SEVERE OR
FATAL SHOCK.
The power cord of this appliance is equipped with
a three-prong (grounding)
plug which mates with
a standard three-prong
(grounding) wall receptacle
to minimize the possibility
of electric shock hazard
from this appliance.
Insure proper
ground exists
before use
You should have the wall receptacle and circuit checked
by a qualified electridan to make sure the receptade is
properly grounded.
Where a standard two-prong wall receptacle is
encountered, it is very important to have it replaced
with a properly grounded three-prong wall receptacle,
installed by a qualified electrician.
DO NOT, UNDER ANY CIRCUMSTANCES, CUT,
DEFORM, OR REMOVE ANY OF THE PRONGS
FROM THE POWER CORD. DO NOT USE WITH
AN EXTENSION CORD.
ELECTRICAL
REQUIREMENTS
Product radng is 120 volts AC, 60 Hertz, 15 amps, and
1.70 ldlowatts. This product IllUSt be connected to
a supply circuit of the proper voltage and fiequenc>
Wire size must conform to the requirements of the
National Electrical Code or the prevailing local code
for this kilowatt rating. The power supply cord and
plug should be brought to a separate 15 to 20 ampere
branch circuit single grounded outlet. The outlet box
should be located in the cabinet above the oven. The
outlet box and supply circuit should be installed by
a qualified electrician and confbrm to the National
Electrical Code or the prevailing local code.
3

Installation instructions
HOOD EXHAUST
NOTE: Read these next two pages only if you plan to vent your exhaust to the outside.
If you plan to redrculate the air back into the room, proceed to page 6.
OUTSIDE TOP EXHAUST (EXAMPLE ONLY}
The fbllowing chart describes an example of one possible
ductwork installation.
RoofCap
12Ft.StraightDuct
(6" Round)
Rectangular-to-Round
TransitionAdaptor*
EQUIVALENT NUMBER EQUIVALENT
IDDCI PIECES =LENGTH x USED = J LENGTH
24Ft. x (1) = 24Ft.
12Ft. x (1) = 12Ft.
5 Ft. x (1) = 5 Ft.
Equivalentlengthsof ductpiecesarebasedon actualtests and
reflectrequirementsfor goodventingperformancewith anyventhood. Total Length = 41 Ft.
*IMPORTANT: If a rectangular-to-round transition adaptor is used, the bottom corners of the damper
will have to be cut to fit, using the tin snips, in order to allow flee movement of the damper.
OUTSIDE BACK EXHAUST (EXAMPLE ONLY)
The following chart describes an example of one possible
ductwork installation.
13|lP.T PIFP.I:N EQUIVALENT I I::N_TM*
Wall Cap
3 Ft.StraightDuct
3W' x 10"Rectangular)
40 Ft.
3 Ft.
(1)
(1)
EQUIVALENT
IFN_TM
40 Ft.
3 Ft.
(_ go° Elbow 10 x (2) = 20
Ft. Ft.
Equivalent lengths of duct pieces are based on actual tests and
reflect requirements for good venting performance with any vent hood.
NOTE: For back exhaust, care should be taken to align exhaust with space bet_,veen studs, or wall should be prepared
at the time it is constructed by leaving enough space between the wall studs to accommodate exhaust.
4

Installation instructions
NOTE: If you need to install ducts, note that the total
duct length of 3¼" x 10" rectangular or 6" diameter
round duct should not exceed 140 equivalent feet.
Outside ventilation requires a HOOD EXHAUST DUCT.
Read the fbllowing careflflly:
NOTE: It is important that venting be installed using
the most direct route and with as few elbows as possible.
This ensures clear venting of exhaust and helps prevent
blockages. Also, make sure dampers swing freely and
nothing is blocMng the ducts.
Exhaust connection:
The hood exhaust has been designed to mate with
a standard 3¼" x 10" rectangular duct.
If a round duct is required, a rectangular-to-round
transition adaptor must be used. Do not use less than
a 6" diameter duct.
Maximum duct length:
For safisfhctory air movement, the total duct length of
3¼"x 10" rectangular or 6" diameter round duct should
not exceed 140 equivalent feet.
Elbows, transitions, wall and roof caps, etc.,
present additional resistance to airflow and are equivalent
to a section of straight duct which is longer than their
actual physical size. When calculating the total duct
length, add the equNa/ent lengths of all transitions and
adaptors plus the length of all straight duct sections.
The chart below shows you how to calculate total
equiwdent ducta, vork length using the approximate feet
of equivalent length of some typical ducts.
DUCT PIECES
&Rectangular-to-Round
TransitionAdaptoP
Wall Cap
90° Elbow
EQUIVALENT
LENGTH
5Ft.
40 Ft.
10 Ft.
X
NUMBER
USED
( )
( )
( )
EQUIVALENT
LENGTH
Ft.
Ft.
Ft.
45° Elbow 5Ft. x ( ) = Ft.
90° Elbow 25 Ft. x ( ) = Ft.
45° Elbow 5Ft. x () = Ft.
RoofCap 24 Ft. x () = Ft.
Straight Duct 6" Roundor 1Ft. x ( ) = Ft.
3X" x 10" Rectangular
Total Ductwork = Ft.
* IMPORTANT: If a rectangula>to-round transition
adaptor is used, the bottom corners of the damper
will ha_e to be cut to fit, using the tin snips, in
order to allow ti'ee movement of the damper.
Equivalent lengths of duct pieces are based on actual tests and
reflect requirements for good velltillg performance x_dth any
Vellt hood.
5

Installation instructions
DAMAGE - SHIPMENT/
iNSTALLATiON
•If the unit is damaged in shipment, return the
unit to the store in which it was bought for repair
or replacement.
• If the unit is damaged by the customer, repair or
replacement is the responsibility of the customer.
• If the unit is damaged by the installer (if other
than the customer), repair or replacement must
be made by arrangement bet_,veen customer and
installer.
PARTS iNCLUDED
HARDWARE PACKET
PART QUANTITY
WoodScrews 2
(Yg'x2")
ToggleBolts(and3,,) 4
wingnuts)(1A"x
/
J
Self-aligningMachine
Screws(W'-28x 3W')
Self-aligningMachine
Screw(W'-28x 2%")
NylonGrommet
(formetalcabinets)
3
2(JVM1790only)
1(JVM1790only)
2
ExhaustAdaptor 1
Damper 1
Metal Screws 1black
(1/8"xY2") 2 bronze
PowerCordStrap 1
(plastic)
You will find the installation hardware contained in
a packet with the unit. Check to make sure you have
all these parts.
NOTE: Some extra parts are included.
PARTS iNCLUDED
ADDITIONAL PARTS
PART
I
TOPCABINET TEMPLATE
INSTALLATION
INSTRUCTIONS
TopCabinet
Template
RearWall
Template
installation
instructions
Separately
Packed
Grease
Filters
m
QUANTITY
1
6

Installation instructions
TOOLS YOU WiLL NEED
# 1 and#2 Phillipsscrewdriver
Tinsnips(forcutting
damper,if required)
Gloves
Pencil
Scissors
(tocuttemplate,if necessary)
Saw(saber,holeor keyhole)
Ruleror tapemeasure
aightedge
3 ,1 7 /z
Electricdrill with _6 ,X_ ,
_" and%" drillbits
8
Studfinder or Hammer(optional)
Carpentersquare
(optional)
Fillerblocksor scrap
woodpieces,if needed
for top cabinetspacing
(usedonrecessedbottom
cabinetinstallationsonly)
Safety goggles Level Duct and masking tape
MOUNTING SPACE
66" or more
fromthe floor
tothe top of
theoven
\
Bottomedgeof
cabinetneedsto
be30" or more
fromthe cooking
surface
Bacl<splash
NOTES:
•The space bet_,veen the cabinets must be , u wide
and f}ee of obstructions.
•If the space between the cabinets is g;eate;
than 30", a Filler Panel Kit may be used to fill
in the gap belween the oven and the cabinets.
Your Owner's Manual contains the kit numbe;
for your model.
•This oven is fbr installation over ranges up to
36" wide.
•If you are going to vent your oven to the outside,
see Hood Exhaust Section for exhaust duct
preparation.
•When installing the oven beneath smooth, fiat
cabinets, be careful to follow the instructions
on the top cabinet template for power cord
clearance.
•The depth of the opening cannot be more than
13-1/2".
7

Installation instructions
[- PLACEMENT OF THE MOUNTING PLATE
A--71 EMOVING THE OVEN FROM
THE CARTON/REMOVING THE
MOUNTING PLATE
[] Open top of box and remove Styrofoam pack
containing installation instructions, filters, exhaust
adaptor, damper, and the small hardware bag.
[]Locate cut line at the bottom of the box and
carefully cut along the indicated dotted line.
Then pull the carton up and off the unit.
[]Remove the the front
St'_7I'O f}jaill protecting
of the oven. Open the oven door and remove
any contents f}om inside.
[_ Using a portion of the carton or other material
to protect the outer casing flom damage, stand
the oven on its side so the control panel is nearest
to the ground.
]The mounting plate is attached to the back
of the oven. Remove the two screws holding
the plate to the oven. The plate will serve
as the rear wall template and provide the support
to mount the oven to the wall.
]Once the plate has been removed, set the oven
upright. Remove and properly discard the plastic
bags and Styrofbam.
[_ Check that all adhesive has been
to enstlie tape
removed flom exhaust adapters, grease filters, and
the power supply cord.
ControlPanelSide "" [ ................". -- MountingPlate
IB,---1FINDING THE WALL STUDS
l i i
Wall
Studs
i
Centeri_i
[_ Find the studs, using one of the fbllowing
methods:
A. Stud finder--a magnetic device which
locates nails. OR
g. Use a hammer to mp lighdy across the
mounting surf_ce to find a solid sound.
This will indicate a stud location.
[_ After locating the stud(s), find the center by
probing the wall with a small nail to find the
edges of the stud. Then place a mark halfk,vW
between the edges. The center of any adjacent
studs should be 16" or 24 " f]om this mark.
[_ Draw line down the center of the studs.
a
THE OVEN MUST BE CONNECTED TO AT LEAST
ONE WALL STUD.
8

Installation instructions
DETERMiNiNG WALL PLATE LOCATION UNDER YOUR CABINET
Plate position -beneath flat bottom
cabinet Plate position - beneath framed recessed
cabinet bottom
MountingPlateTabs
ig the CabinetBottom
':o
o,
MountingPlateTabs
Touchingthe Back
Frame
II1 30"to Cool<top
Plate position -beneath recessed bottom
cabinet with front overhang
MountingPlatewith
TabsBelowCabinet
Bottomthe Same
Distanceasthe Front
OverhangDepth
"-..
L
III
30" to Cool<top
Your cabinets may have decorative trim that interferes
with the oven installation. Remove the decorative trhn
to install the oven properly and to make it level.
THE OVEN MUST BE LEVEL.
Use a level to make sure the cabinet bottom is level.
If the cabinets have a front overhang only, with no
back or side fiame, install the mounting plate down
the same distance as the front overhang depth. This
will
%
%
keep the oven level.
Measme the inside depth of the flont overhang.
Draw a horizontal line on the back wall an equal
distance below the cabinet bottom as the inside
depth of the fiont overhang.
For this t),pe of installation with fiont overhang only;
align the mounting robs with this horizontal line, not
touching the cabinet bottom as described in Step D.
9

Installation instructions
ALiGNiNG THE WALL PLATE
HoleA
HoleD
CAUTION: Wear gloves
to avoid cutdng fingers on
sharp edges.
I
I
I
I
I DrawaVertical
i_ LineonWall
from Centerof
TopCabinet
I
I
I
I
j
0 0 0 b
0 0
00 0 0 0 0 0 0 0 0 0 0 0
0 010 0 0 0 0 0 0 0
I nn
I
0
HoleD
[]Draw a vertical line on the wall at the center of die
30" wide space.
[_] Use the mounting plato as the template for the rear
wall. Place the mounting plato on the wall, maMng
sure that the robs are touching the bottom of the
cabinet or the level line drawn in Step C for cabinets
with front overhang. Line up the notch and center line
on the mounting plate to the center line on the wall.
[] While holding the mounting plate with one hand,
draw circles on the wall at holes A, B, C and D (see
illustration above/actual plate marked with arrows).
Four holes must be used for mounting.
NOTE: Holes C and D are inside area E. If neither
C nor D is in a stud, find a stud somewhere in area E
and draw a fifth circle to line up with the stud. It is
important to use at least one wood screw mounted
firmly in a stud to support the weight of the oven.
Set the mounting plate aside.
Drill holes on the circles. If there is a stud, drill a NJ'
hole for wood screws. For holes that don't line up with
a stud, drill a %" hole for toggle bolts.
NOTE: DO NOT MOUNT THE PLATE AT THIS TIME.
10
