GE JB670DP Manual

Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Listed by
Underwriters
Laboratories
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Specification Created 6/09 321549
KW Rating
240V 10.5
208V 7.9
Breaker Size
40 Amps†
30
25
29-7/8
A*
2-1/2
7-1/2
25-3/8
47-5/8
2-1/2
Acceptable electrical
outlet area
30_install_fse_drawer.eps
7
14-1/2
On models with baking or warming
drawers, electrical outlet must not
be in this area.
Dimension from wall to front of closed
oven door handle is 27-3/8 on models
PB910/900 and 27-3/4 on models
JBP89/84/81.
*A is 46-7/8 on models JBP89/84/81 and
46-1/2 on models JB988/968/910/900
JB670DP/TP
GE® 30" Free-Standing Electric Range
†Note: Check local codes for required breaker size.
Effective January 1, 1996, the National Electrical
Code requires that new construction (not existing)
utilize a 4-conductor connection to an electric range.
Receptacle Locations: Locally approved flexible
service cord or conduit must be used because
terminals are not accessible after range installation.
See shaded area in drawing for location of electrical
outlet box. Recommended outlet locations allow
range to be installed directly against wall.
Note: 30" ranges conform to U.L. requirements for
0" spacing from adjacent walls below countertops.
To reduce possibility of scorching walls, engineering
recommends a minimum of 1-1/2" spacing to allow
for possible extended, high-heat, no-load heating
element operation.
Installation information: Before installing, consult
installation instructions packed with product for
current dimensional data.
All 30" GE gas and electric range backguards
are 30-7/8" wide.*
Note: 30" ranges conform to U.L. requirements
for 0" spacing from adjacent walls below
countertops. To reduce possible scorching of
walls, engineering recommends a minimum of
1-1/2" spacing to allow for possible extended,
high heat, no-load heating element operation.
*Except these models: JGBS07, JGBS04, JGBP90,
all GE Profile free-standing electric and gas
ranges
Fits most countertop backsplash applications.
Consult Use & Care Manual for detailed
installation instructions.
30-7/8"

Specification Created 6/09 321549
Features and Benefits
• ConvectionBake-Thissettingisoptimalforbakingcasserolesorlasagnas,yeast
breads, pies and pizzas with no need to turn the pan
• Super-Large5.3Cu.Ft.OvenCapacity-Providesanimpressivelylargeoveninterior
to cook more dishes and large meals at once
• Self-cleanOven-Self-cleanallowsyoutospareyourselffromthetroubleandeffort
it takes to scrub the oven interior. The oven does all the work!
• 9”/12”DualElement-Twoheatingelementsinoneallowsyoutochooseeithera9”
or12”elementforyourcookware
•  T r u e T e m p ™OvenSystem-Thisfeaturehelpsensurethetemperatureyousetis
the temperature you get, with less variance, to give you the baking and broiling
performance you desire
• QuickSetIVOvenControls-Featureaneasytousedesignwhichallowsyoutoset
precise cooking temperatures
• Six-passBakeElement-Onecontinuousheatingelementdeliversevenheating,
unparalleled baking and evenly cooked food
• BigHearthWindow-Elegantshapedwindowmakesiteasytomonitortheprogress
of food
• ModelJB670DPBB-Black
• ModelJB670DPWW-White
JB670DP
BROIL SELF
CLEAN
OVEN
LIGHT
CLOCK
BAKE
OVEN
LIGHT
START
ON
CLEAR
OFF
TIME
START
TIME
JB670DP/TP
GE® 30" Free-Standing Electric Range
