GE JDP39DN Manual

All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Listed by
Underwriters
Laboratories
JDP39DN
GE®30" Drop-In Electric Range with Self-Cleaning Oven
Dimensions and Installation Information
Note: Cabinets installed adjacent to drop-in
ranges must have an adhesion spec of at
least 194°.
Important
30” Drop-In Ranges are designed to hang from
the countertop. It does not rest on the floor.
For installation alternatives, refer to installation
instructions packed with product.
Note: 30” Drop-In Electric Ranges conform to
U.L. requirements for 3” minimum spacing between
range and side walls above countertop.
Installation Information: Before installing,
consult installation instructions packed with
product for current dimensional data.
Dimension and installation information are shown in inches.
Acceptable Electrical Outlet
Area Also In Adjacent
Cabinet Or Under Floor
Conduit is 40" long
30" Min.
30" Min.
15" Min.
6" Min.
from walls
7-1/2
2-7/8"
To Front Surface
of Countertop
30
36
27-1/2 25
23-3/16
If necessary,
build upsides
to 1-1/4" thick
to provide
countertop
support
27
20-5/8" Door
Clearance
From Front
Surface of
Countertop
24
31-1/4
30
A/B*
Accessory
Backguard
26-1/2** *JXS37 is 5-1/4" and JXS32 is 4"
(excluding handle)
**Total depth from wall to
front of closed oven door
including handle is 29-1/2.
Acceptable Electrical Outlet
Area Also In Adjacent
Cabinet Or Under Floor
Conduit is 40" long
30" Min.
30" Min.
15" Min.
6" Min.
from walls
7-1/2
2-7/8"
To Front Surface
of Countertop
30
36
27-1/2 25
23-3/16
If necessary,
build upsides
to 1-1/4" thick
to provide
countertop
support
27
20-5/8" Door
Clearance
From Front
Surface of
Countertop
24
31-1/4
30
A/B*
Accessory
Backguard
26-1/2** *JXS37 is 5-1/4" and JXS32 is 4"
(excluding handle)
**Total depth from wall to
front of closed oven door
including handle is 29-1/2.
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
geappliances.com or call GE Answer Center®service,
800.626.2000.
Specification Revised 3/10
320827
KW Rating
240V 10.8
208V 8.1

JDP39DN
GE®30" Drop-In Electric Range with Self-Cleaning Oven
Specification Revised 3/10
320827
JDP39DNWWCCBB
Features and Benefits
• Self-CleanOven-Convenientlycleanstheovencavitywithoutneedofscrubbing
•ElectronicControls-Provideasmootheasy-to-use,easy-to-cleansurface
•CoilHeatingElements-Providesconsistentandevenheatonthecooktopwithaplug-
in element that is removable for easy cleaning
•BigHearthWindow-Featuresanenhancedshapetoaddanelegantappearanceand
make viewing trouble-free
•Lift-UpPorcelainCooktop-Makesspillsandmessesunderthecooktopeasily
accessible and within reach
•ChromeDripBowls-Containminorspillsandareremovableforeasycleaning
•FramelessGlassOvenDoor-Offersaneasy-to-cleanandstylishdesignthatblends
seamlessly into existing cabinetry
•DualElementBake-Alternatestheupperbroilingelementandthelowerbaking
element for even heating and optimal baking results
•AudiblePreheatSignal-Featuresanaudiblesignalthatactivateswhentheovenhas
reached the desired cooking temperature
•TwoOvenRacks-Featureadurableconstructiontohelpaccommodateanysizeor
type of cookware
• ModelJDP39DNWW-Whiteonwhite(Whitedoorandwhitecooktop)
• ModelJDP39DNCC-Bisqueonbisque(Bisquedoorandbisquecooktop)
• ModelJDP39DNBB-Blackonblack(Blackdoorandblackcooktop)
