GE JGBP89 User manual

Safety Instructions . . . .2–7
Operating Instructions
Aluminum Foil . . . . . . . . . . . . . . . .14
Clock and Timer . . . . . . . . . . .16, 17
Lower Oven Drawer . . . . . . . . . .32
Oven . . . . . . . . . . . . . . . . . . . . .11–34
aking and Roasting . . . . . . . .14
roiling, roiling Guide . . . . . . .15
Control Lockout . . . . . . . . . . . . .26
Convection . . . . . . . . . . . . . .20–24
Gas/Control Lockout . . . . . . . . .26
Oven Control . . . . . . . . . . . .11, 12
Power Outage . . . . . . . . . . . . . .13
Preheating . . . . . . . . . . . . . . . . .14
Probe . . . . . . . . . . . . . . . . . . . . . . .19
Sabbath Feature . . . . . . . . .27, 28
Self-Cleaning . . . . . . . . . . . .33, 34
Shelves . . . . . . . . . . . . . . . . . . . . .13
Special Features . . . . . . . . .25, 26
Thermostat Adjustment . . . . . .29
Timed aking
and Roasting . . . . . . . . . . . . . . .18
Timed Convection aking . . . .24
Surface Cooking . . . . . . . . . . .8–10
Griddle . . . . . . . . . . . . . . . . . . . . .10
Warming Drawer . . . . . . . . . .30, 31
Care and Cleaning
urner Assembly . . . . . . . . . .35, 36
urner Grates . . . . . . . . . . . . . . . .37
Control Panel and Knobs . . . . . .38
Cooktop . . . . . . . . . . . . . . . . . . . . .37
Door Removal . . . . . . . . . . . . . . . .39
Griddle . . . . . . . . . . . . . . . . . . . . . .37
Oven ottom . . . . . . . . . . . . . . . . .39
Oven Light Replacement . . . . . .40
Oven Vents . . . . . . . . . . . . . . . . . .37
Self-Cleaning . . . . . . . . . . . . .33, 34
Shelves . . . . . . . . . . . . . . . . . . . . . .40
Stainless Steel Surfaces . . . . . . .38
Drawer . . . . . . . . . . . . . . . . . . .40, 41
Installation
Instructions . . . . . . . . . .42–53
Air Adjustment . . . . . . . . . . . . . . .52
Anti-Tip Device . . . . . . . . . . . .45, 53
Assemble Surface urners . . . .50
Checking urner
Ignition . . . . . . . . . . . . . . . . . . . . . .51
Connecting the Range
to Gas . . . . . . . . . . . . . . . . . . .46–48
Dimensions and Clearances . . .44
Electrical Connections . . . . .49, 50
Leveling the Range . . . . . . . . . . .52
LP . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Troubleshooting
Tips . . . . . . . . . . . . . . . . . . . .54–57
Accessories . . . . . . . . . . . . . .61
Consumer Support
Consumer Support . . . ack Cover
Product Registration . . . . . . .59, 60
Warranty for Customers
in Canada . . . . . . . . . . . . . . . . . . .63
Warranty for Customers
in the U.S.A. . . . . . . . . . . . . . . . . .62
Ranges
183D558 P215 49-85131 05-07 JR
JGBP85
JGBP88
JGBP89
JGBP90
JGBP92
PGB900
PGB908
PGB910
PGB916
PGB918
PGB975
Owner’s Manual
& Installation
Instructions
ge.com
Self-Cleaning Gas
Write the model and serial
numbers here:
Model # ____________________
Serial #______________________
You can find them on a label
on the front of the range behind the
warming drawer or lower
oven drawer.
In Canada contact us at:
www.GE ppliances.ca

Operating Instructions Safety Instructions
Installation
Instructions
Troubleshooting Tips
Consumer Support
2
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
—WHAT TO DO IF YOU
SMELL GAS
■Do not try to light any appliance.
■ Do not touch any electrical switch;
do not use any phone in your building.
■ Immediately call your gas supplier
from a neighbor’s phone. Follow the
gas supplier’s instructions.
■ If you cannot reach your gas supplier,
call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
WARNING: If the information
in this manual is not followed e actly,
a fire or e plosion may result, causing
property damage, personal injury
or death.
WARNING!
NTI-TIP DEVICE
■ALL RANGES CAN TIP
■INJURY TO PERSONS
COULD RESULT
■INSTALL ANTI-TIP
DEVICES PACKED
WITH RANGE
■SEE INSTALLATION
INSTRUCTIONS
WARNING!
For your safety, the information in this manual must be followed to minimize the risk of fire or
explosion, electric shock, or to prevent property damage, personal injury, or loss of life.
All ranges can tip and injury could result.
To prevent accidental tipping of the range, attach it to the wall by installing the nti-Tip device supplied.
If the nti-Tip device supplied with the range does not fit this application, use the universal nti-Tip
device WB2X7909.
To check if the device is installed and engaged properly, carefully tip the range forward. The nti-Tip
device should engage and prevent the range from tipping over.
If you pull the range out from the wall for any reason, make sure the device is properly engaged
when you push the range back against the wall. If it is not, there is a possible risk of the range tipping
over and causing injury if you or a child stand, sit or lean on an open door.
Please refer to the Anti-Tip device information in this manual. Failure to take this precaution could
result in tipping of the range and injury.
NTI-TIP DEVICE
®

Consumer SupportOperating InstructionsSafety Instructions Installation
Instructions Troubleshooting Tips
3
ge.com
WARNING!
Have the installer show you the location of the range gas shut-off valve and how to shut it off if necessary.
■Have your range installed and properly
grounded by a qualified installer, in
accordance with the Installation Instructions.
Any adjustment and service should be
performed only by qualified gas range
installers or service technicians.
■Do not attempt to repair or replace any
part of your range unless it is specifically
recommended in this manual. All other service
should be referred to a qualified technician.
■Plug your range into a 120-volt grounded
outlet only. Do not remove the round
grounding prong from the plug. If in doubt
about the grounding of the home electrical
system, it is your personal responsibility and
obligation to have an ungrounded outlet
replaced with a properly grounded,
three-prong outlet in accordance with
the National Electrical Code. Do not use
an extension cord with this appliance.
S FETY PREC UTIONS
IMPORT NT S FETY NOTICE
The California Safe Drinking Water and Toxic Enforcement ct requires the Governor of California to
publish a list of substances known to the state to cause birth defects or other reproductive harm, and
requires businesses to warn customers of potential exposure to such substances.
Gas appliances can cause minor exposure to four of these substances, namely benzene, carbon
monoxide, formaldehyde and soot, caused primarily by the incomplete combustion of natural gas or
LP fuels. Properly adjusted burners, indicated by a bluish rather than a yellow flame, will minimize
incomplete combustion. Exposure to these substances can be minimized by venting with an open
window or using a ventilation fan or hood.

■Locate the range out of kitchen traffic path
and out of drafty locations to prevent poor
air circulation.
■e sure all packaging materials are removed
from the range before operating it to prevent
fire or smoke damage should the packaging
material ignite.
■e sure your range is correctly adjusted by
a qualified service technician or installer for
the type of gas (natural or LP) that is to be
used. Your range can be converted for use
with either type of gas. See the Installation
of the range section.
■WARNING: These adjustments must
be made by a qualified service technician
in accordance with the manufacturer’s
instructions and all codes and requirements
of the authority having jurisdiction. Failure
to follow these instructions could result in
serious injury or property damage. The
qualified agency performing this work
assumes responsibility for the conversion.
■After prolonged use of a range, high floor
temperatures may result and many floor
coverings will not withstand this kind of use.
Never install the range over vinyl tile or
linoleum that cannot withstand such type
of use. Never install it directly over interior
kitchen carpeting.
■Do not leave children alone or unattended
where a range is hot or in operation.
They could be seriously burned.
■Do not allow anyone to climb, stand or hang
on the oven door, lower oven drawer, warming
drawer or cooktop. They could damage the
range and even tip it over, causing severe
personal injury.
■ CAUTION: Items of interest to children
should not be stored in cabinets above a
range or on the backsplash of a range—
children climbing on the range to reach items
could be seriously injured.
■Never wear loose fitting or hanging garments
while using the appliance. e careful when
reaching for items stored in cabinets over the
range. Flammable material could be ignited
if brought in contact with flame or hot oven
surfaces and may cause severe burns.
■Do not store flammable materials in an oven,
a range drawer or near a cooktop.
■Do not store or use combustible materials,
gasoline or other flammable vapors and
liquids in the vicinity of this or any other
appliance.
■Do not let cooking grease or other flammable
materials accumulate in or near the range.
■Do not use water on grease fires. Never pick
up a flaming pan. Turn the controls off.
Smother a flaming pan on a surface burner
by covering the pan completely with
a well-fitting lid, cookie sheet or flat tray.
Use a multi-purpose dry chemical or
foam-type fire extinguisher.
■Flaming grease outside a pan can be put
out by covering it with baking soda or,
if available, by using a multi-purpose dry
chemical or foam-type fire extinguisher.
■Flame in the upper oven or lower oven drawer
can be smothered completely by closing the
oven door or drawer and turning the control
to off or by using a multi-purpose dry
chemical or foam-type fire extinguisher.
■Let the burner grates and other surfaces cool
before touching them or leaving them where
children can reach them.
■Never block the vents (air openings) of the
range. They provide the air inlet and outlet
that are necessary for the range to operate
properly with correct combustion. Air openings
are located at the rear of the cooktop, at the
top and bottom of the oven door, and at the
bottom of the range under the warming
drawer, lower oven drawer or kick panel.
■Large scratches or impacts to glass doors
can lead to broken or shattered glass.
S FETY PREC UTIONS
4
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING: NEVER use this
appliance as a space heater to heat or
warm the room. Doing so may result
in carbon monoxide poisoning and
overheating of the oven.
Operating Instructions Safety Instructions
Installation
Instructions
Troubleshooting Tips
Consumer Support

Consumer SupportOperating InstructionsSafety Instructions Installation
Instructions Troubleshooting Tips
5
ge.com
SURF CE BURNERS
Use proper pan size—avoid pans that are unstable or easily tipped. Select cookware having flat
bottoms large enough to cover burner grates. To avoid spillovers, make sure cookware is large enough
to contain the food properly. This will both save cleaning time and prevent hazardous accumulations
of food, since heavy spattering or spillovers left on range can ignite. Use pans with handles that can
be easily grasped and remain cool.
■Always use the LITE position when igniting
the top burners and make sure the burners
have ignited.
■Never leave the surface burners unattended
at high flame settings. oilovers cause smoking
and greasy spillovers that may catch on fire.
■Adjust the top burner flame size so it does
not extend beyond the edge of the cookware.
Excessive flame is hazardous.
■Use only dry pot holders— moist or damp pot
holders on hot surfaces may result in burns
from steam. Do not let pot holders come near
open flames when lifting cookware. Do not use
a towel or other bulky cloth in place of a pot
holder.
■When using glass cookware, make sure it
is designed for top-of-range cooking.
■To minimize the possibility of burns, ignition
of flammable materials and spillage, turn
cookware handles toward the side or back
of the range without extending over adjacent
burners.
■Carefully watch foods being fried at a high
flame setting.
■Always heat fat slowly, and watch as it heats.
■Do not leave any items on the cooktop. The
hot air from the vent may ignite flammable
items and will increase pressure in closed
containers, which may cause them to burst.
■If a combination of oils or fats will be used
in frying, stir together before heating or
as fats melt slowly.
■Use a deep fat thermometer whenever
possible to prevent overheating fat beyond
the smoking point.
■Use the least possible amount of fat for
effective shallow or deep-fat frying. Filling the
pan too full of fat can cause spillovers when
food is added.
■Do not flame foods on the cooktop. If you
do flame foods under the hood, turn the
fan on.
■Do not use a wok on the cooking surface
if the wok has a round metal ring that is
placed over the burner grate to support the
wok. This ring acts as a heat trap, which may
damage the burner grate and burner head.
Also, it may cause the burner to work
improperly. This may cause a carbon
monoxide level above that allowed by current
standards, resulting in a health hazard.
■Foods for frying should be as dry as possible.
Frost on frozen foods or moisture on fresh
foods can cause hot fat to bubble up and
over the sides of the pan.
■Never try to move a pan of hot fat, especially
a deep fat fryer. Wait until the fat is cool.
■Do not leave plastic items on the cooktop—
they may melt if left too close to the vent.
■Keep all plastics away from the surface
burners.
■To avoid the possibility of a burn, always be
certain that the controls for all burners are
at the OFF position and all grates are cool
before attempting to remove them.
■ If range is located near a window, do not hang
long curtains that could blow over the surface
burners and create a fire hazard.
■If you smell gas, turn off the gas to the range
and call a qualified service technician. Never
use an open flame to locate a leak.
■Always turn the surface burner controls off
before removing cookware.
■Do not lift the cooktop. Lifting the cooktop can
lead to damage and improper operation of the
range.
■When disabling Gas/Control Lockout, make
sure the surface controls are set to the OFF
position. This will preclude gas flow when the
range is turned on.
WARNING!

IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
6
■e sure to wipe off excess spillage before
self-cleaning operation.
■efore self-cleaning the oven, remove any
broiler pan, broiler grid, all cookware, probe
and any aluminum foil.
■Never place, use or self-clean the lower oven
drawer pan in the upper oven.
■Nickel oven shelves (on some models) should
be removed from the oven before beginning
the self-clean cycle.
■Gray porcelain-coated oven shelves (on some
models) may be cleaned in the oven during
the self-clean cycle.
■Clean only parts listed in this Owner’s Manual.
■Do not clean the door gasket. The door gasket
is essential for a good seal. Care should be
taken not to rub, damage or move the gasket.
■If the self-cleaning mode malfunctions,
turn the oven off and disconnect the power
supply. Have it serviced by a qualified
technician.
■Do not use oven cleaners. No commercial
oven cleaner or oven liner of any kind should
be used in or around any part of the oven.
Residue from oven cleaners will damage
the inside of the oven when the self-clean
cycle is used.
SELF-CLE NING THE UPPER OVEN
COOK ME T ND POULTRY THOROUGHLY…
Cook meat and poultry thoroughly—meat to at least an INTERN L temperature of 160°F and poultry
to at least an INTERN L temperature of 180°F. Cooking to these temperatures usually protects against
foodborne illness.
■The purpose of the warming drawer and the
WARM ZONE setting of the lower oven drawer
is to hold hot cooked foods at serving
temperature. Always start with hot food; cold
food cannot be heated or cooked in the
warming drawer or the WARM ZONE setting
of the lower oven drawer.
■Do not use the drawer to dry newspapers.
If overheated, they can catch on fire.
■Do not leave paper products, plastics, canned
food, or combustible materials in the drawer.
■Never leave jars or cans of fat drippings in or
near your drawer.
■Do not warm food in the drawer for more
than two hours.
■Never place, use or self-clean the lower oven
drawer pan in the upper oven.
■Do not touch the heating element or the
interior surface of the drawer. These
surfaces may be hot enough to burn.
REMEMBER: The inside surface of the drawer
may be hot when the drawer is opened.
■Use care when opening the drawer. Open
the drawer a crack and let hot air or steam
escape before removing or replacing food.
Hot air or steam which escapes can cause
burns to hands, face and/or eyes.
■Do not use aluminum foil to line the lower
oven drawer. Foil is an excellent heat insulator
and will trap heat beneath it. This will upset
the performance of the drawer and it could
damage the interior finish.
ELECTRIC W RMING DR WER
ND LOWER OVEN DR WER (on some models)
Operating Instructions Safety Instructions
Installation
Instructions
Troubleshooting Tips
Consumer Support

RE D ND FOLLOW THIS S FETY INFORM TION C REFULLY.
SAVE THESE INSTRUCTIONS
Consumer SupportOperating InstructionsSafety Instructions Installation
Instructions Troubleshooting Tips
7
ge.com
■Do not use the oven for a storage area.
Items stored in the oven can ignite.
■Keep the oven free from grease buildup.
■Place the oven shelves in the desired position
while the oven is cool.
■Pulling out the shelf to the stop-lock is a
convenience in lifting heavy foods. It is also
a precaution against burns from touching hot
surfaces of the door or oven walls. The lowest
position is not designed to slide.
■Do not heat unopened food containers.
Pressure could build up and the container
could burst, causing an injury.
■Do not use aluminum foil anywhere in the
oven except as described in this manual.
Misuse could result in a fire hazard or damage
to the range.
■When using cooking or roasting bags in the
oven, follow the manufacturer’s directions.
■Do not use your oven to dry newspapers.
If overheated, they can catch fire.
■Use only glass cookware that is recommended
for use in gas ovens.
■Always remove any broiler pan from range
as soon as you finish broiling. Grease left in
the pan can catch fire if oven is used without
removing the grease from the broiler pan.
■When broiling, if meat is too close to the flame,
the fat may ignite. Trim excess fat to prevent
excessive flare-ups.
■Make sure any broiler pan is in place correctly
to reduce the possibility of grease fires.
■If you should have a grease fire in a broiler
pan, press the Clear/Off pad, and keep
the oven door closed to contain fire until
it burns out.
■For safety and proper cooking performance,
always bake and broil with the oven door
closed.
■Never place, use or self-clean the lower oven
drawer pan in the upper oven.
Stand away from the range when opening the door of a hot oven. The hot air and steam that escape
can cause burns to hands, face and eyes.
UPPER OVEN
WARNING: NEVER cover any
slots, holes or passages in the oven bottom
or cover an entire rack with materials such
as aluminum foil. Doing so blocks air flow
through the oven and may cause carbon
monoxide poisoning. Aluminum foil linings
may also trap heat, causing a fire hazard.

8
Throughout this manual, features and appearance may vary from your model.
How to Light a Gas Surface Burner
Make sure all the surface burners are placed
in their respective positions.
Push the control knob in and turn it to
the LITE position.
You will hear a little clicking noise—
the sound of the electric spark igniting
the burner.
Turn the knob to adjust the flame size.
If the knob stays at LITE, it will continue
to click.
When one burner is turned to LITE, all
the burners spark. Do not attempt to
disassemble or clean around any burner
while another burner is on. An electric shock
may result, which could cause you
to knock over hot cookware.
Push the control knob in and turn
it to the LITE position.
How to Select Flame Size
For safe handling of cookware, never let the
flames extend up the sides of the cookware.
Watch the flame, not the knob, as you reduce
heat. When fast heating is desired, the flame
size on a gas burner should match the
cookware you are using.
Flames larger than the bottom of the
cookware will not result in faster heating
of the cookware and could be hazardous.
Before Lighting a Gas Burner
■Make sure all burners are in place.
■Make sure all grates on the range are
properly placed before using any burner.
■If your range has the Gas/Control Lockout
feature, make sure it is disabled before
attempting to light the surface burners.
After Lighting a Gas Burner
■Do not operate the burner for an extended
period of time without cookware on the
grate. The finish on the grate may chip
without cookware to absorb the heat.
■e sure the burners and grates are cool
before you place your hand, a pot holder,
cleaning cloths or other materials on them.
Sealed Gas Burners
Your gas range cooktop has five sealed
gas burners. They offer convenience,
cleanability and flexibility to be used in
a wide range of cooking applications.
The smallest burner in the right rear position is
the simmer burner. This burner can be turned
down to LO for a very low simmer setting. It
provides precise cooking performance for
delicate foods such as sauces or foods that
require low heat for a long cooking time.
The medium (left rear) and the large
(left front) burners are the primary burners for
most cooking. These general-purpose burners
can be turned down from HI to LO to suit a
wide range of cooking needs.
The extra large burner (right front) is the
maximum output burner. Like the other four
burners, it can be turned down from HI to LO
for a wide range of cooking applications;
however, this burner is designed to quickly
bring large amounts of liquid to a boil. It has
a special POWER BOIL™setting designed to
be used with cookware 12 inches or larger
in diameter.
The center oval burner (on some models) is
for large pots/pans or for use with the griddle.
Operating Instructions Safety Instructions
Installation
Instructions
Troubleshooting Tips
Consumer Support
Using the gas surface burners.
Medium Small
Large Center (oval)
(on some
models)
Extra Large
Extra-large burner only

9
In Case of Power Failure
In case of a power failure, you can light the
gas surface burners on your range with a
match. Hold a lit match to the burner, then
push in and turn the control knob to the LITE
position. Use extreme caution when lighting
burners this way.
Surface burners in use when an electrical
power failure occurs will continue to operate
normally.
NOTE: If Gas/Control Lockout is in use at the
time of a power failure, the surface burners
cannot be lit.
Consumer Support
Operating Instructions
Safety Instructions Installation
Instructions Troubleshooting Tips
ge.com
Wok This Way
We recommend that you use a 14-inch or
smaller flat-bottomed wok. Make sure the wok
bottom sits flat on the grate. They are
available at your local retail store.
Only a flat-bottomed wok should be used.
Do not use a wok support ring. Placing the
ring over the burner or grate may cause the
burner to work improperly, resulting in carbon
monoxide levels above allowable standards.
This could be dangerous to your health.
Use a flat-bottomed wok.
Stove Top Grills
Do not use stove top grills on your sealed
gas burners. If you use the stove top grill on
the sealed gas burner, it will cause incomplete
combustion and can result in exposure to
carbon monoxide levels above allowable
current standards.
This can be hazardous to your health.
Top-of-Range Cookware
Aluminum: Medium-weight cookware is
recommended because it heats quickly
and evenly. Most foods brown evenly in an
aluminum skillet. Use saucepans with tight-
fitting lids when cooking with minimum
amounts of water.
Cast-Iron: If heated slowly, most skillets
will give satisfactory results.
Enamelware: Under some conditions,
the enamel of some cookware may melt.
Follow cookware manufacturer’s
recommendations for cooking methods.
Glass: There are two types of glass
cookware—those for oven use only and
those for top-of-range cooking (saucepans,
coffee and teapots). Glass conducts heat
very slowly.
Heatproof Glass Ceramic: Can be used for
either surface or oven cooking. It conducts
heat very slowly and cools very slowly. Check
cookware manufacturer’s directions to be
sure it can be used on gas ranges.
Stainless Steel: This metal alone has poor
heating properties and is usually combined
with copper, aluminum or other metals for
improved heat distribution. Combination
metal skillets usually work satisfactorily if
they are used with medium heat as the
manufacturer recommends.

10
Most griddled foods require cooking
on a preheated surface. Preheat griddle
according to the guide below, then switch
to the desired cook setting.
IMPORTANT NOTES:
■Avoid cooking extremely greasy foods and
be careful of grease spill-over while cooking.
■Do not use oil on the griddle for extended
lengths of time. Permanent staining and/or
craze lines on the surface could result.
■ever place or store any items on the
griddle, even when it is not in use. The
griddle can become heated when using
the surrounding burners.
■Do not overheat the griddle. Leaving the
griddle burner on at HI for an extended
amount of time without food can damage
the non-stick coating.
■Avoid using metal utensils with sharp points
or rough sharp edges which might damage
the griddle surface.
■Do not cut foods on the griddle.
Operating Instructions Safet Instructions
Installation
Instructions
Troubleshooting Tips
Consumer Support
Your non-stick coated griddle provides
an extra-large cooking surface for eats,
pancakes or other food usually prepared
in a frying pan or skillet.
NOTE: Your griddle will discolor over time
as it becomes seasoned with use.
How to Insert the Griddle
Using the griddle. (on some models)
CAUTION: Place and remove
the griddle only when all grates and
griddle are cool and all surface units are
turned OFF.
The griddle can only be used with the center
burner. To insert the griddle, re ove the
center grate and replace with the griddle.
Using the Griddle
Type of Food Preheat Cook
Conditions Setting
War ing none 3 (MED-LOW)
Tortillas
Pancakes 7 (MED-HI) 7 (MED-HI)
3 in.
Ha burgers 7 (MED-HI) 7 (MED-HI)
5 in.
Fried Eggs HI 4 (MED)
5 in.
Bacon none 5 (MED)
Breakfast HI 5 (MED)
Sausage Links 5 in.
Hot Sandwiches HI HI
(such as 4 in.
Grilled Cheese)
NOTE: Griddle settings may need to be
adjusted if the griddle is used for an
extended time.

Consumer Support
Operating Instructions
Safety Instructions Installation
Instructions Troubleshooting Tips
Bake Pad
Touch to select the bake function.
Broil Hi/Lo Pad
Touch to select the broil function.
Convection Bake Multi/1 Rack Pad
(on some models)
Touch to select baking with the convection
function.
Convection Roast Pad (on some models)
Touch to select roasting with the convection
function.
Proof Pad (on some models)
Touch to select a warm environment useful
for rising yeast-leavened products.
Start Pad
Must be touched to start any cooking or
cleaning function.
Display
Shows the time of day, oven temperature,
whether the oven is in the bake, broil or
self-cleaning mode, the times set for
the timer or automatic oven operations,
and if the range is locked.
If “F– and a number or letter” flash in the display and
the oven control signals, this indicates a function
error code. Touch the Clear/Off pad. llow the oven to
cool for one hour. Put the oven back into operation. If the
function error code repeats, disconnect the power to the
oven and call for service.
If your oven was set for a timed oven operation and a
power outage occurred, the clock and all programmed
functions must be reset.
The time of day will flash in the display when there
has been a power outage.
Self Clean Pad
Touch to select self-cleaning function. See the
Using the self-cleaning oven section.
Oven Light On/Off Pad
Touch to turn the oven light on or off.
Delay Start Pad
Use along with Cooking Time or Self Clean
pads to set the oven to start and stop
automatically at a time you set.
Cooking Time Pad
Touch and then touch the number pads to set
the amount of time you want your food to cook.
The oven will shut off when the cooking time
has run out.
Clear/Off Pad
Touch to cancel ALL oven operations except
the clock, timer and Control Lockout.
Clock Pad
Touch before setting the clock.
Number Pads
Use to set any function requiring numbers,
such as the time of day on the clock, the timer,
the oven temperature, the internal food
temperature, the start time and length of
operation for timed baking and self-cleaning.
Kitchen Timer On/Off Pad
Touch to select the timer feature.
Control Lockout (on some models)
The control lockout is 9 and 0. Touch and hold
the 9 and 0 pads at the same time for 3 seconds.
NOTE: Some models have a Control Lockout
pad.
Warming Drawer On/Off Pad (on some models)
Touch this pad and then touch number pads 1–3
to use the warming drawer. See the Using the
electric warming drawer section.
Using the oven controls.
(Throughout this manual, features and appearance may vary from your model.) ge.com
Oven Control, Clock, Timer and Features (on some models)
Features, appearance and pad locations may vary.
11

Operating Instructions
12
Safety Instructions
Installation
Instructions
Troubleshooting Tips
Consumer Support
Bake Pad
Touch to select the bake function.
Broil Hi/Lo Pad
Touch to select the broil function.
Convection Bake Multi/1 Rack Pad
(on some models)
Touch to select baking with the convection
function.
Convection Roast Pad (on some models)
Touch to select roasting with the convection
function.
Start Pad
Must be touched to start any cooking or
cleaning function.
Display
Shows the time of day, oven temperature,
whether the oven is in the bake, broil or
self-cleaning mode, the times set for
the timer or automatic oven operations,
and if the range is locked.
If “F– and a number or letter” flash in the display and
the oven control signals, this indicates a function
error code. Touch the Clear/Off pad. llow the oven to
cool for one hour. Put the oven back into operation. If the
function error code repeats, disconnect the power to the
oven and call for service.
If your oven was set for a timed oven operation and a
power outage occurred, the clock and all programmed
functions must be reset.
The time of day will flash in the display when there
has been a power outage.
Self Clean Pad
Touch to select self-cleaning function. See the
Using the self-cleaning oven section.
Oven Light On/Off Pad
Touch to turn the oven light on or off.
Delay Start Pad
Use along with Cooking Time or Self Clean
pads to set the oven to start and stop
automatically at a time you set.
Cooking Time Pad
Touch and then touch the number pads to set
the amount of time you want your food to cook.
The oven will shut off when the cooking time
has run out.
Clear/Off Pad
Touch to cancel ALL oven operations except
the clock, timer and Gas/Control Lockout or
Control Lockout (depending on model).
Clock Pad
Touch before setting the clock.
Number Pads
Use to set any function requiring numbers,
such as the time of day on the clock, the timer,
the oven temperature, the internal food
temperature, the start time and length of
operation for timed baking and self-cleaning.
Kitchen Timer On/Off Pad
Touch to select the timer feature.
Probe Pad
Touch when using the probe to cook food.
Gas/Control Lockout Pad (on some models)
Touch and hold the Gas/Control Lockout
pad for 3 seconds to lock/unlock the surface
burners, oven burners and control panel so
they cannot be activated.
Control Lockout (on some models)
The control lockout is 9 and 0. Touch and hold
the 9 and 0 pads at the same time for 3 seconds.
Warming Drawer On/Off Pad (on some models)
Touch this pad and then touch number pads 1–3
to use the warming drawer. See the Using the
electric warming drawer section.
Using the oven controls.
(Throughout this manual, features and appearance may vary from your model.)
or
Oven Control, Clock, Timer and Features (on some models)
Features, appearance and pad locations may vary.
NOTE: On models
with backlit touch pad
controls, they will
remain lit for many
minutes after they are
last touched.

Consumer Support
Operating Instructions
Safety Instructions Installation
Instructions Troubleshooting Tips
13
Using the upper oven. ge.com
To avoid possible burns, place the shelves in the desired position before you turn the oven on.
Before you begin…
The shelves have stop-locks, so that when
placed correctly on the shelf supports (A
through E), they will stop before coming
completely out, and will not tilt.
When placing and removing cookware,
pull the shelf out to the bump on the shelf
support.
To remove a shelf, pull it toward you, tilt the
front end up and pull it out.
To replace, place the end of the shelf (stop-
locks) on the support, tilt up the front and
push the shelf in.
NOTE: The shelf is not designed to slide out
at the special low shelf (R) position.
The oven has 5 shelf positions.
It also has a special low shelf
position (R) for extra large items,
such as a large turkey.
Power Outage
CAUTION: Do not make any attempt to
operate the electric ignition oven during an
electrical power failure.
The oven or broiler cannot be lit during a
power failure. Gas will not flow unless the
glow bar is hot.
If the oven is in use when a power failure
occurs, the oven burner shuts off and cannot
be re-lit until power is restored. This is
because the flow of gas is automatically
stopped and will not resume when power is
restored until the glow bar has reached
operating temperature.
Upper Oven Light
Touch the Oven Light pad on the upper
control panel to turn the light on or off.
On some models, the Oven Light switch
is on the lower front control panel.
Upper Oven Vent
Your oven is vented through ducts at the rear
of the range. Do not block these ducts when
cooking in the oven—it is important that the
flow of hot air from the oven and fresh air
to the oven burner be uninterrupted. Avoid
touching the vent openings or nearby
surfaces during oven or broiler operation—
they may become hot.
■Handles of pots and pans on the cooktop
may become hot if left too close to the vent.
■Do not leave plastic or flammable items on
the cooktop—they may melt or ignite if left
too close to the vent.
■Do not leave closed containers on the
cooktop. The pressure in closed containers
may increase, which may cause them
to burst.
■Metal items will become very hot if they are
left on the cooktop, and could cause burns.
Plastic items on the cooktop may
melt if left too close to the vent.
Vent appearance and location vary.

How to Set the Upper Oven for Baking or Roasting
Your oven is not designed for open-door
cooking.
Touch the Bake pad.
Touch the number pads to set the
desired temperature.
Touch the Start pad.
The word ON and 1 ° will be displayed.
As the oven heats up, the display will show
the changing temperature. When the oven
reaches the temperature you set, a tone
will sound.
To change the oven temperature during B KE
cycle, press the Bake pad and then the
number pads to get the new temperature.
Check food for doneness at minimum
time on recipe. Cook longer if necessary.
Touch the Clear/Off pad when cooking
is complete.
Type of Food Shelf Position
Frozen pies (on cookie sheet) or C
Angel food cake, A
bundt or pound cakes
iscuits, muffins, brownies, C
cookies, cupcakes,
layer cakes, pies
Casseroles or C
Roasting R or A
Preheating and Pan Placement
Preheat the oven if the recipe calls for it.
To preheat, set the oven at the correct
temperature. Preheating is necessary when
convection baking and for good results when
baking cakes, cookies, pastry and breads.
For ovens without a preheat indicator light
or tone, preheat 10 minutes.
aking results will be better if baking pans
are centered in the oven as much as possible.
Pans should not touch each other or the walls
of the oven. If you need to use two shelves,
stagger the pans so one is not directly above
the other, and leave approximately 11⁄2″
between pans, from the front, back and sides
of the wall.
Oven Moisture
As your oven heats up, the temperature
change of the air in the oven may cause
water droplets to form on the door glass.
These droplets are harmless and will
evaporate as the oven continues to heat up.
The oven has a special low shelf (R)
position just above the oven
bottom. Use it when extra cooking
space is needed, for example,
when cooking a large turkey. The
shelf is not designed to slide out
at this position.
Operating Instructions Safety Instructions
Installation
Instructions
Troubleshooting Tips
Consumer Support
14
Using the upper oven.
If your model has a door latch, do not lock the oven door with the latch during baking or roasting.
The latch is used for self-cleaning only.
Aluminum Foil
Do not use aluminum foil on the bottom of
the oven.
Never entirely cover a shelf with aluminum
foil. This will disturb the heat circulation and
result in poor baking.
A smaller sheet of foil may be used to catch a
spillover by placing it on a lower shelf several
inches below the food.

Consumer Support
Installation
Instructions Troubleshooting Tips
Operating Instructions
Safety Instructions
15
ge.com
Broiling Guide
Quantity and/ Shelf* First Side Second Side
Food or Thickness Position Time (min.) Time (min.) Comments
Bacon 1/2 lb. C 4 3 Arrange in single layer.
(about 8 thin slices)
Ground Beef 1 lb. (4 patties) C 10 7–10 Space evenly. Up to
Well Done 1/2 to 3/4″thick 8 patties take about
the same time.
Beef Steaks
Rare†1″thick C 9 7 Steaks less than 1″thick cook
Medium 1 to 11⁄2lbs. C 12 5–6 through before browning.
Well Done C 13 8–9 Pan frying is recommended.
Slash fat.
Rare†11⁄2″thick C 10 6–7
Medium 2 to 21⁄2lbs. C 12–15 10–12
Well Done C 25 16–18
Chicken 1 whole 30–35 15–20 rush each side with melted
2 to 21⁄2lbs., butter. roil skin-side-down
split lengthwise first.
4 bone-in breasts 25–30 10–15
Lobster Tails 2–4 C 13–16 Do not Cut through back of shell.
6 to 8 oz. each turn Spread open. rush with
over. melted butter before broiling
and after half of broiling
time.
Fish Fillets 1/4 to 1/2″thick D 6 6 Handle and turn very
carefully. rush with lemon
butter before and during
cooking, if desired. Preheat
broiler to increase browning.
Ham Slices 1″thick C 8 8
(precooked)
1/2″thick D 6 6
Pork Chops 2 (1/2″thick) D 10 8 Slash fat.
Well Done 2 (1″thick) about 1 lb. D 15 8
Lamb Chops
Medium 2 (1″thick) about 10 D 8 4–7 Slash fat.
Well Done to 12 oz. D 10 10
Medium 2 (11⁄2″thick) about 1 lb. D 10 4–6
Well Done D 17 12–14
How to Set the Upper Oven for Broiling
Place the meat or fish on a broiler grid in
a broiler pan.
Follow suggested shelf positions in the
Broiling Guide.
The oven door must be closed during
broiling.
Touch the Broil Hi/Lo pad once for
Hi Broil.
To change to Lo Broil, touch the Broil
Hi/Lo pad again.
Touch the Start pad.
When broiling is finished, touch the
Clear/Off pad.
Serve the food immediately, and leave the
pan outside the oven to cool during the meal
for easiest cleaning.
Use Lo Broil to cook foods such as poultry
or thick cuts of meat thoroughly without
over-browning them.
The size, weight, thickness,
starting temperature and
your preference of doneness
will affect broiling times. This
guide is based on meats at
refrigerator temperature.
†The U.S. Department of
griculture says “Rare beef is
popular, but you should know that
cooking it to only 140°F. means
some food poisoning organisms
may survive.” (Source: Safe Food
Book, Your Kitchen Guide, USD
Rev. June 1985.)
The oven has 5 shelf positions.
*See illustration for description of shelf positions.
If your model has a door latch, do not lock the oven door with the latch during broiling.
The latch is used for self-cleaning only.
Close the door. Always broil with
the door closed.

Not all features are on all models.
To Set the Clock
The clock must be set to the correct time of
day for the automatic oven timing functions
to work properly. The time of day cannot be
changed during a timed baking or self-
cleaning cycle.
Touch the Clock pad.
Touch the number pads.
Touch the number pads the same way you
read them. For example, to set 12:34, touch
the number pads 1, 2, 3 and 4in that order.
If number pads are not touched within one
minute after you touch the Clock pad, the
display reverts to the original setting. If this
happens, touch the Clock pad and reenter
the time of day.
Touch the Start pad until the time of
day shows in the display. This enters
the time and starts the clock.
To check the time of day when the display
is showing other information, simply touch
the Clock pad. The time of day shows until
another pad is touched.
To Set the Timer
The timer does not control oven operations.
The maximum setting on the timer is 9 hours
and 59 minutes.
Touch the Kitchen Timer On/Off pad.
Touch the number pads until the
amount of time you want shows in the
display. The maximum time that can be
entered in minutes is 59. Times more
than 59 minutes should be changed to
hours and minutes. For example, to
enter 90 minutes as 1 hour 30 minutes,
touch 1, 3 and in that order.
If you make a mistake, press the Kitchen
Timer On/Off pad and begin again.
Touch the Start pad. After pressing the
Start pad, Set disappears; this tells you
the time is counting down, although the
display does not change until one
minute has passed.
When the timer reaches : , the control
will beep 3 times followed by one beep
every 6 seconds until the Kitchen Timer
On/Off pad is touched.
The 6 second tone can be canceled by
following the steps in the Special features
of your oven control section under Tones
at the End of a Timed Cycle.
Using the clock and timer.
Operating Instructions Safety Instructions
Installation
Instructions
Troubleshooting Tips
Consumer Support
16
Make sure the clock is set to the
correct time of day.
The timer is a minute timer only.
The Clear/Off pad does not affect
the timer.

Power Outage
If a flashing time is in the display, you have
experienced a power failure. Reset the clock.
Touch the Clock pad once to reset. Enter
the correct time of day by touching the
appropriate number pads. Touch the Start
pad.
17
Consumer Support
Installation
Instructions Troubleshooting Tips
Operating Instructions
Safety Instructions
To Reset the Timer
If the display is still showing the time
remaining, you may change it by touching
the Kitchen Timer On/Off pad, then touch
the number pads until the time you want
appears in the display.
If the remaining time is not in the display
(clock, delay start or cooking time are in the
display), recall the remaining time by
touching the Kitchen Timer On/Off pad and
then touching the number pads to enter the
new time you want.
To Cancel the Timer
Touch the Kitchen Timer On/Off pad twice.
ge.com

Operating Instructions Safety Instructions
Installation
Instructions
Troubleshooting Tips
Consumer Support
18
Using the timed baking and roasting features. (upper oven only)
If your model has a door latch, do not lock the oven door with the latch during timed cooking. The latch is used for
self-cleaning only.
NOTE: Foods that spoil easily—such as milk, eggs, fish, stuffings, poultry and pork—should not be allowed to sit for
more than 1 hour before or after cooking. Room temperature promotes the growth of harmful bacteria. Be sure that
the oven light is off because heat from the bulb will speed harmful bacteria growth.
How to Set an Immediate Start and Automatic Stop
The upper oven will turn on immediately and cook
for a selected length of time. t the end of the
cooking time, the oven will turn off automatically.
Touch the Bake pad.
Touch the number pads to set the desired
oven temperature.
Touch the Cooking Time pad.
NOTE: If your recipe requires preheating, you may
need to add additional time to the length of the
cooking time.
Touch the number pads to set the desired
length of cooking time. The minimum
cooking time you can set is 1 minute.
The oven temperature that you set and the
cooking time that you entered will be in the
display.
Touch the Start pad.
The oven will turn ON, and the display will show
the cooking time countdown and the changing
temperature starting at 100°F. (The temperature
display will start to change once the oven
temperature reaches 100°F.) When the oven
reaches the temperature you set, 3 beeps will
sound.
The oven will continue to cook for the set amount
of time, then turn off automatically, unless the
Cook and Hold feature was set. See the Special
features of your oven control section.
After the oven turns off, the end-of-cycle tone will
sound.
Touch the Clear/Off pad to clear the display
if necessary. Remove the food from the
oven. Remember, even though the oven
turns off automatically, food left in the oven
will continue cooking after the oven turns off.
How to Set a Delayed Start and Automatic Stop
The upper oven will turn on at the time of day you
set, cook for a specific length of time and then turn
off automatically.
Make sure the clock shows the correct time of day.
Touch the Bake pad.
Touch the number pads to set the desired
oven temperature.
Touch the Cooking Time pad.
NOTE: If your recipe requires preheating, you may
need to add additional time to the length of the
cooking time.
Touch the number pads to set the desired
length of cooking time. The minimum
cooking time you can set is 1 minute.
The oven temperature that you set and the
cooking time that you entered will be in the
display.
Touch the Delay Start pad.
Touch the number pads to set the time of
day you want the oven to turn on and start
cooking.
Touch the Start pad.
NOTE: n attention tone will sound if you are using
timed baking and do not touch the Start pad.
NOTE: If you would like to check the times you
have set, touch the Delay Start pad to check the
start time you have set or touch the Cooking Time
pad to check the length of cooking time you have
set.
When the oven turns ON at the time of day
you set, the display will show the cooking time
countdown and the changing temperature
starting at 100°F. (The temperature display
will start to change once the oven temperature
reaches 100°F.) When the oven reaches the
temperature you set, beeps will sound.
The oven will continue to cook for the set amount
of time, then turn off automatically, unless the
Cook and Hold feature was set. See the Special
features of your oven control section.
After the oven turns off, the end-of-cycle tone
will sound.
Touch the Clear/Off pad to clear the display
if necessary. Remove the food from the
oven. Remember, even though the oven
turns off automatically, food left in the oven
will continue cooking after the oven turns off.

Consumer Support
Installation
Instructions Troubleshooting Tips
Operating Instructions
Safety Instructions
If your model has a door latch, do not lock the oven door with the latch while cooking with the probe. The latch is used
for self-cleaning only.
For many foods, especially roasts and poultry, internal food temperature is the best test for doneness. The
temperature probe takes the guesswork out of cooking foods to the exact doneness you want.
Use of probes other than the one provided
with this product may result in damage to
the probe.
Use the handles of the probe and plug when
inserting and removing them from the food
and outlet.
■ To avoid damaging your probe, do not use
tongs to pull on the cable when removing it.
■ To avoid breaking the probe, make sure food
is completely defrosted before inserting.
■ To prevent possible burns, do not unplug the
probe from the outlet until the oven has cooled.
■ Never leave your probe inside the oven
during a self-cleaning cycle.
■ Do not store the probe in the oven.
The temperature probe has a
skewer-like probe at one end and
a plug at the other end that goes
into the outlet in the oven.
After preparing the meat and placing it on
a trivet or on a broiler pan grid, follow these
directions for proper probe placement.
Insert the probe completely into the meat.
It should not touch the bone, fat or gristle.
For roasts with no bone, insert the probe into
the meatiest part of the roast. For bone-in
ham or lamb, insert the probe into the center
of the lowest large muscle.
Insert the probe into the center of dishes such
as meat loaf or casseroles.
Insert the probe into the meatiest part of the
inner thigh from below and parallel to the leg
of a whole turkey.
How to Set the Upper Oven For Cooking When Using the Probe
Insert the probe into the food.
Plug the probe into the outlet in the
oven. Make sure it’s pushed all the
way in. Close the oven door.
Touch the Probe pad.
Touch the number pads to set
the desired internal food or meat
temperature between 100°F and 200°F.
Touch the Bake pad.
Touch the number pads to set the
desired oven temperature.
Touch the Start pad.
The display will flash if the probe is inserted
into the outlet and you have not set a probe
temperature and touched the Start pad.
The display will show LO until the internal
temperature of the food reaches 100°F; then
the changing internal temperature will be
shown.
When the internal temperature of the
food reaches the number you have set,
the probe and the oven turn off and the
oven control signals. To stop the signal,
touch the Clear/Off pad. Use hot pads to
remove the probe from the food. Do not
use tongs to pull on it—they might
damage it.
To change the oven temperature during
probe cooking, touch the Bake pad and then
the number pads to set the new temperature.
■If the probe is removed from the food before
the final temperature is reached, a tone will
sound and the display will flash until the
probe is removed from the oven.
■You can use the timer even though you
cannot use timed oven operations while
using the probe.
Plug
Probe
Cable
Handles
Using the probe. (on some models) ge.com
19

Operating Instructions Safety Instructions
Installation
Instructions
Troubleshooting Tips
Consumer Support
20
Using the convection oven. (on some models)
If your model has a door latch, do not lock the oven door with the latch during convection cooking. The latch is used
for self-cleaning only.
The convection oven fan shuts off when the oven door is opened. DO NOT leave the door open for long periods of time
while using convection cooking.
To help you understand the difference
between convection bake and roast and
traditional bake and roast, here are some
general guidelines.
Convection Bake
■Preheat the oven. See the Using the Oven–
Preheating and Pan Placement section.
■Ideal for foods cooked on multiple shelves.
■Good for large quantities of baked foods.
■Good results with cookies, biscuits,
brownies, cupcakes, cream puffs, sweet
rolls, angel food cake and bread.
The convection fan circulates the heated
air evenly over and around the food.
Convection Roast
■Good for large tender cuts of meat,
uncovered.
The convection fan circulates the heated air
evenly over and around the food. Meat and
poultry are browned on all sides as if they
were cooked on a rotisserie. Heated air will
be circulated over, under and around the
food being roasted. The heated air seals in
juices quickly for a moist and tender product
while, at the same time, creating a rich
golden brown exterior.
Roasts or poultry should be cooked on shelf
position ( ).
When you are convection roasting, it is
important that you use a broiler pan and grid
for best convection roasting results. The pan
is used to catch grease spills and the grid is
used to prevent grease spatters.
■Place the shelf in shelf position ( ).
In a convection oven, a fan
circulates hot air over, under and
around the food. This circulating
hot air is evenly distributed
throughout the oven cavity. s a
result, foods are evenly cooked and
browned—often in less time than
with regular heat.
Auto Recipe™Conversion
You can use your favorite recipes in the
convection oven.
When using CONVECTION B KE,
the oven will automatically convert the
oven temperature from regular baking
to Convection Bake temperatures.
Using the number pads, enter
the temperature recommended
in the recipe.
Touch the Start pad.
The display will show the temperature
you entered from your recipe. The
oven will automatically convert it to
the convection cooking temperature.
Touch the Clear/Off pad when baking
is finished.
■ Use pan size recommended in the recipe.
■ Some package instructions for frozen
casseroles, main dishes or baked goods
have been developed using commercial
convection ovens. For best results in this
oven, preheat the oven and use the
temperature, for regular baking, on the
package.
