GE JS750SFSS Manual

JS750SF
GE®30" Slide-In Electric Convection Range
Dimensions and Installation Information (in inches)
Listed by
Underwriters
Laboratories
Receptacle Locations: Locally approved flexible service cord or conduit must
be used because terminals are not accessible after range installation.
See
shaded area in drawing for location of electrical outlet box. Recommended
outlet locations allow range to be installed directly against rear wall.
Note: This appliance has been approved for 0” spacing to adjacent
surfaces above the cooktop. However, a 6” minimum spacing to surfaces
less than 15” above the cooktop and adjacent cabinet is recommended
to reduce exposure to steam, grease splatter and heat.
Installation Information: Before installing, consult installation insgtructions
for current dimensional data and additional requirements
Optional Kits For Slide-In
Electric Ranges
(Available At Additional Cost)
Accessory Backguards
(Attaches to the back of range
as a backguard when unit is
installed in 30" free-standing
cutout)
JXS32SS (Stainless) - 4" High
JXS32BB (Black) - 4" High
Body Sides
(Slide-in ranges are sold
without sides installed. Can
be installed on either left
or right when unit has one
exposed side [no cabinet
adjacent]. Kit contains
1 body side)
JXS77BB (Black)
Rear Filler Strip
WB07T10680 - Black Filler Strip Assembly
Optional Lower Trim Kits
(If counter height is greater
than 36.5", a lower trim kit
is recommended to extend
the useful height to 38"
maximum)
JXS56BB – Black
For answers to your Monogram® or GE®
appliance questions, visit our website at
geappliances.com or call GE Answer Center®
service, 800.626.2000.
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
320637
Specification Created 5/13
Acceptable
Electrical
Outlet Area
30" Min.
30" Min.
Shave Raised Edge To Clear
31-1/8" Wide Control Panel
Excluding Model JSS28
2-7/8"
To Front
Surface Of
Countertop
20-5/8" Door
Clearance
From Front
Surface of
Countertop
31-1/4
30
25-3/4*
Recommended
6" Min.
From Walls
23-3/16
15" Min.
4
2-1/2
30
25
9/16
7-1/2
2-1/2
Accessory
Backguard JXS32
24
36-1/4
(excluding handle) *Total depth from wall to
front of closed oven door
including handle is 28-1/2.
35-7/8"–38"
from floor to
countertop
If the countertop area is not at, excess tension may be applied to the glass cooktop, causing breakage and
voiding the warranty. Make sure the wall covering, countertop, ooring and cabinets around the range can
withstand the heat (up to 200°F) generated by the range.
A. Allow 30" minimum clearance between surface units and bottom of unprotected wood or metal cabinet, or
allow a 24" minimum when bottom of wood or metal cabinet is protected by no less than 1/4"-thick
ame-retardant millboard covered with no less than No. 28 MSG sheet metal (.015" thick), .015"-thick stainless
steel, .025" aluminum or .020" copper.
B. This appliance has been approved for 0" spacing to adjacent surfaces above the cooktop.
However, a minimum 6" spacing to surfaces less than 15" above the cooktop and adjacent cabinetry
is recommended to reduce exposure to steam, grease splatter and heat. Allow 1/4" minimum
clearance at the back wall.
To reduce the risk of burns or re when reaching over hot surface elements, cabinet storage space above the
cooktop should be avoided. If cabinet storage space is to be provided above the cooktop, the risk can be reduced
by installing a range hood that projects at least 5" beyond the front of the cabinets.
23-3/16
30
30
If you are NOT using the
Filler strip or Backguard:
If you are using the
Filler strip or Backguard:
25
Acceptable
Electrical
Outlet Area
30" Min.
30" Min.
Shave Raised Edge To Clear
31-1/8" Wide Control Panel
Excluding Model JSS28
2-7/8"
To Front
Surface Of
Countertop
20-5/8" Door
Clearance
From Front
Surface of
Countertop
31-1/4
30
25-3/4*
Recommended
6" Min.
From Walls
23-3/16
15" Min.
4
2-1/2
30
25
9/16
7-1/2
2-1/2
Accessory
Backguard JXS32
24
36-1/4
(excluding handle)
*Total depth from wall to
front of closed oven door
including handle is 28-1/2.
35-7/8"–38"
from floor to
countertop
If the countertop area is not at, excess tension may be applied to the glass cooktop, causing breakage and
voiding the warranty. Make sure the wall covering, countertop, ooring and cabinets around the range can
withstand the heat (up to 200°F) generated by the range.
A. Allow 30" minimum clearance between surface units and bottom of unprotected wood or metal cabinet, or
allow a 24" minimum when bottom of wood or metal cabinet is protected by no less than 1/4"-thick
ame-retardant millboard covered with no less than No. 28 MSG sheet metal (.015" thick), .015"-thick stainless
steel, .025" aluminum or .020" copper.
B. This appliance has been approved for 0" spacing to adjacent surfaces above the cooktop.
However, a minimum 6" spacing to surfaces less than 15" above the cooktop and adjacent cabinetry
is recommended to reduce exposure to steam, grease splatter and heat. Allow 1/4" minimum
clearance at the back wall.
To reduce the risk of burns or re when reaching over hot surface elements, cabinet storage space above the
cooktop should be avoided. If cabinet storage space is to be provided above the cooktop, the risk can be reduced
by installing a range hood that projects at least 5" beyond the front of the cabinets.
23-3/16
30
30
If you are NOT using the
Filler strip or Backguard:
If you are using the
Filler strip or Backguard:
25
ADA qualified based
on Uniform Federal
Accessibility Standards
*
Acceptable
Electrical
Outlet Area
30" Min.
30" Min.
Shave Raised Edge To Clear
31-1/8" Wide Control Panel
Excluding Model JSS28
2-7/8"
To Front
Surface Of
Countertop
20-5/8" Door
Clearance
From Front
Surface of
Countertop
31-1/4
30
25-3/4*
Recommended
6" Min.
From Walls
23-3/16
15" Min.
4
2-1/2
30
25
9/16
7-1/2
2-1/2
Accessory
Backguard JXS32
24
36-1/4
(excluding handle) *Total depth from wall to
front of closed oven door
including handle is 28-1/2.
35-7/8"–38"
from floor to
countertop
If the countertop area is not at, excess tension may be applied to the glass cooktop, causing breakage and
voiding the warranty. Make sure the wall covering, countertop, ooring and cabinets around the range can
withstand the heat (up to 200°F) generated by the range.
A. Allow 30" minimum clearance between surface units and bottom of unprotected wood or metal cabinet, or
allow a 24" minimum when bottom of wood or metal cabinet is protected by no less than 1/4"-thick
ame-retardant millboard covered with no less than No. 28 MSG sheet metal (.015" thick), .015"-thick stainless
steel, .025" aluminum or .020" copper.
B. This appliance has been approved for 0" spacing to adjacent surfaces above the cooktop.
However, a minimum 6" spacing to surfaces less than 15" above the cooktop and adjacent cabinetry
is recommended to reduce exposure to steam, grease splatter and heat. Allow 1/4" minimum
clearance at the back wall.
To reduce the risk of burns or re when reaching over hot surface elements, cabinet storage space above the
cooktop should be avoided. If cabinet storage space is to be provided above the cooktop, the risk can be reduced
by installing a range hood that projects at least 5" beyond the front of the cabinets.
23-3/16
30
30
If you are NOT using the
Filler strip or Backguard:
If you are using the
Filler strip or Backguard:
25
Acceptable
Electrical
Outlet Area
30" Min.
30" Min.
Shave Raised Edge To Clear
31-1/8" Wide Control Panel
Excluding Model JSS28
2-7/8"
To Front
Surface Of
Countertop
20-5/8" Door
Clearance
From Front
Surface of
Countertop
31-1/4
30
25-3/4*
Recommended
6" Min.
From Walls
23-3/16
15" Min.
4
2-1/2
30
25
9/16
7-1/2
2-1/2
Accessory
Backguard JXS32
24
36-1/4
(excluding handle) *Total depth from wall to
front of closed oven door
including handle is 28-1/2.
35-7/8"–38"
from floor to
countertop
If the countertop area is not at, excess tension may be applied to the glass cooktop, causing breakage and
voiding the warranty. Make sure the wall covering, countertop, ooring and cabinets around the range can
withstand the heat (up to 200°F) generated by the range.
A. Allow 30" minimum clearance between surface units and bottom of unprotected wood or metal cabinet, or
allow a 24" minimum when bottom of wood or metal cabinet is protected by no less than 1/4"-thick
ame-retardant millboard covered with no less than No. 28 MSG sheet metal (.015" thick), .015"-thick stainless
steel, .025" aluminum or .020" copper.
B. This appliance has been approved for 0" spacing to adjacent surfaces above the cooktop.
However, a minimum 6" spacing to surfaces less than 15" above the cooktop and adjacent cabinetry
is recommended to reduce exposure to steam, grease splatter and heat. Allow 1/4" minimum
clearance at the back wall.
To reduce the risk of burns or re when reaching over hot surface elements, cabinet storage space above the
cooktop should be avoided. If cabinet storage space is to be provided above the cooktop, the risk can be reduced
by installing a range hood that projects at least 5" beyond the front of the cabinets.
23-3/16
30
30
If you are NOT using the
Filler strip or Backguard:
If you are using the
Filler strip or Backguard:
25
KW Rating
240V 13.5
208V 10.1
Breaker Size
240V 40 Amps†
208V 40 Amps†
†Note: Check local codes for required breaker size.

JS750SF
GE®30" Slide-In Electric Convection Range
320637
Specification Created 5/13
Features and Benefits
• True European Convection with Precise Air - Enjoy perfectly even results
without turning the pan
• 6"/9"/12" 3600W Power Boil - Pots and pans fit perfectly on the flexible
heating element
• Bridge Zone - Cook griddle favorites from the convenience of your range
• Fifth Element Warming Zone - Provides low heat capability for foods
• Self-Clean with Steam Clean Option - Clean your oven the way you want
• Fast Preheat - Make hot meals in a hurry with less time preheating
• Hidden Bake - Make cleanup easy by eliminating hard-to-reach areas
• Black Gloss Oven Interior - Enjoy a clean and sleek appearance
• Model JS750SFSS - Stainless steel
JS750SF
