Dimensions and Clearances (in inches)
For answers to your Monogram,
®GE Profile™or
GE®appliance questions, visit our website at
GEAppliances.com or call GE Answer Center®
service, 800.626.2000.
Listed by
Underwriters
Laboratories
Professional ranges offer a number of choices in size and cooktop
configurations.
All Professional Ranges are factory set for natural or liquid propane
gas. The correct model should be ordered for the installation situation.
36" Natural Gas Model
ZDP36N6HSS–6 gas burners
36" Liquid Propane Gas Model
ZDP36L6HSS–6 gas burners
Note: Conversion kits (WB49X10132, Natural to LP and WB49X10133,
LP to Natural) are available if the wrong gas type was ordered. High
Altitude kit, WB49X10130 (for Natural and LP gas models), is also
available. The kits must be installed by a qualified service technician
at additional cost.
Installation Information
Before installing, consult installation instructions packed with product
or online at Monogram.com for current dimensional data.
A 36" or 42" wide professional vent hood with a minimum 600 CFM
is recommended for installation over this range.
Advance Planning
Refer to dimensional drawings for appropriate placement and
necessary clearances when planning the installation.
• Cabinetry cannot be installed directly above the range.
• Working areas adjacent to the range should have 18" minimum
clearance between countertop and cabinet bottom.
• Clearance between range and side wall or combustible material
must be at least 12" on each side.
If the range is installed in an island
• Allow 12" minimum clearance at the back to combustible materials.
• The vent hood blower should provide at least 600 CFM and up to
1200 CFM.
• Installation must conform with local codes. In the absence of local
codes, the range must comply with the National Fuel Gas Code,
ANSI Z223.1-1990.
Clearances between range and side wall or combustible material must
be at least 12" on each side.
22"
1-1/2"
35-1/4"
to
36-3/4"
28-1/4" 35-7/8"
Optional
Backsplash
12"
Specification Revised 3/08
130546
ZDP36N6HSS (Natural Gas)
ZDP36L6HSS (Liquid Propane) – GE Monogram 36" Dual Fuel Professional Range
with 6 Burners

Electrical Requirements
Ranges must be supplied with 208/240V, 60Hz, and connected to
an individual, properly grounded branch circuit protected by a circuit
breaker or time-delay fuse. Install a 30-amp circuit for 36" ranges. The
receptacle must be a NEMA 14-50R device to accept the four-prong
plug on the range.
Specification Revised 3/08
130546
For answers to your Monogram,
®GE Profile™or
GE®appliance questions, visit our website at
GEAppliances.com or call GE Answer Center®
service, 800.626.2000.
Listed by
Underwriters
Laboratories
Gas Supply
• Natural gas models are designed to operate at 5" water column
pressure. A regulator is required at the natural gas source to
provide maximum of 7" water pressure to the range regulator.
• The liquid propane models are designed to operate at 10" water
column pressure. A regulator is required at the LP source to provide
maximum of 14" water pressure to the range regulator.
4" 4" 4"
12" 12"
Gas
Supply
36"
1-1/2"
4"
Electric
Supply
Locate gas and
electric as shown
Optional Backsplash Accessories
The range requires a 12" minimum clearance to a vertical combustible
surface at the rear. A backsplash is required for installations with
less than 12" clearance. The following backsplash accessories are
available, or a custom, non-combustible backsplash can be used.
Backsplashes: Order one with a 36"-wide range
ZX12B36HSS–12" backsplash
ZX22B36HSS–22" backsplash with warming shelf
Backsplash with Warming Shelf
All Monogram Professional Wall-Mounted Hoods feature infrared
warming lights. The 22"-high warming shelf is a perfect complement
when installed with the tapered or straight-sided hoods.
If you choose to install this range with a Restaurant-Style
Professional Hood (ZV36RSFSS), no additional accessories are
required. These hoods are shipped with a stainless steel
backsplash and warming shelf.
Side View with a Backsplash
Backguard
36" Min.
to
Combustibles
0" Clearance
12" Min. to Combustibles or
0" Min. to Combustibles
with 12" or 22" Backsplash
ZDP36N6HSS (Natural Gas)
ZDP36L6HSS (Liquid Propane) – GE Monogram 36" Dual Fuel Professional Range
with 6 Burners

Features and Benefits
• Sophisticated styling – Designed with chamfered edges and
die cast knobs, Monogram stainless steel ranges offer the
bold appearance and high-performance cooking capabilities
of commercial appliances
• Sealed, dual-flame stacked burners – Each gas burner uses two
separate flames to give you a range of precise temperature
options, from an ultra-low 140 degree simmer to a powerful
17,000 BTU setting. The burners are sealed to the recessed
cooktop surface for easy cleaning
• Exclusive reversible grates – Sectioned, dishwasher-safe grates
provide two cooking surfaces for unprecedented versatility in
gas cooking
• Oven (4.6 cu. ft., 27" wide) – The large, self-cleaning convection
oven offers two multi-pass broil and bake elements for even
browning and backing, with no hot or cold spots
• Self-clean oven racks – Porcelain-coated racks are designed to be
left in the oven during the self-clean cycle for effortless cleaning
• Halogen lighting – Illuminates your culinary work in progress
• Model ZDP36N6HSS – Natural Gas, 6 burners
• Model ZDP36L6HSS – Liquid Propane, 6 burners
ZDP36N6HSS
OFFBAKECONVBROILCLEAN
HEA
TINGDOOR LOCKED
OVEN
LIGHT
Specification Revised 3/08
130546
ZDP36N6HSS (Natural Gas)
ZDP36L6HSS (Liquid Propane) – GE Monogram 36" Dual Fuel Professional Range
with 6 Burners
