GE Profile JS905TKWW Manual

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
JS905TK/BK
GE Profile™ 30" Slide-In Electric Range
Specification Revised 1/08 220442
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Listed by
Underwriters
Laboratories
Dimensions and Installation Information (in inches)
28-1/4*
36
Maintain
at least 6"
from nearest
combustible
surface.
Acceptable
Electrical
Outlet Area
30" Slide-In Range
Dimensions (in inches)
45-1/8
2-1/4
5
6
4-1/2
30
30" Min.
15" Min.
6
30" Slide-in Elec. Range
Aug. 8, 2003 -km
23-3/16
30
30
If you are NOT using the
Filler strip or Backguard:
If you are using the
Filler strip or Backguard:
25
*Wall to front of
closed door handle
on model JSP34.
28" on models
JSP26/JSS26/16.
Note: Range may be placed with 0" clearance (flush) at the back wall and side walls
below countertop if the range side trims above the countertop extend beyond the cabinet
fronts at least 1/4". (Self-clean models only.) Maintain at least 6" distance from nearest
combustible surface.
30
31-1/2
28-1/4*
36
Maintain
at least 6"
from nearest
combustible
surface.
Acceptable
Electrical
Outlet Area
30" Slide-In Range
Dimensions (in inches)
45-1/8
2-1/4
5
6
4-1/2
30
30" Min.
15" Min. 6
30" Slide-in Elec. Range
Aug. 8, 2003 -km
23-3/16
30
30
If you are NOT using the
Filler strip or Backguard:
If you are using the
Filler strip or Backguard:
25
*Wall to front of
closed door handle
on model JSP34.
28" on models
JSP26/JSS26/16.
Note: Range may be placed with 0" clearance (flush) at the back wall and side walls
below countertop if the range side trims above the countertop extend beyond the cabinet
fronts at least 1/4". (Self-clean models only.) Maintain at least 6" distance from nearest
combustible surface.
30
31-1/2
Note: Cabinets installed adjacent to slide-in ranges must have an adhesion
spec of at least 194° temperature rating.
Note: 30" ranges conform to U.L. requirements for 0" spacing from adjacent
walls below countertops. To reduce possibility of scorching walls, engineering
recommends a minimum of 1-1/2" spacing to allow for possible extended,
high-heat, no-load heating element operation.
Receptacle Locations: For all 30" Slide-In Ranges locally approved flexible
service cord or conduit must be used because terminals are not accessible
after range installation. See shaded area in drawing for location of electrical
outlet box. Recommended outlet locations allow range to be installed directly against rear wall.
KW Rating
240V 11.6
208V 8.7
Breaker Size
240V 40 Amps
208V 40 Amps
Installation information: Before installing, consult installation instructions
packed with product for current dimensional data.
Acceptable
Electrical
Outlet Area
30" Min.
30" Min.
Shave Raised Edge To Clear
31-1/8" Wide Control Panel
Excluding Models JSS28 and JSP39
2-7/8"
To Front
Surface Of
Countertop
20-5/8" Door
Clearance
From Front
Surface of
Countertop
31-1/4
30
25-3/4**
Recommended
6" Min.
From Walls
23-3/16
15" Min.
A/B*
13" Max.
2-1/2
30
25
9/16
7-1/2
2-1/2
Accessory
Backguard
24
36-1/4
*JXS37 is 5-1/4" and JXS32 is 4"
(excluding handle)
**Total depth from wall to
front of closed oven door
including handle is 27-13/16.
35-7/8"–38"
from floor to
countertop
Acceptable
Electrical
Outlet Area
30" Min.
30" Min.
Shave Raised Edge To Clear
31-1/8" Wide Control Panel
Excluding Models JSS28 and JSP39
2-7/8"
To Front
Surface Of
Countertop
20-5/8" Door
Clearance
From Front
Surface of
Countertop
31-1/4
30
25-3/4**
Recommended
6" Min.
From Walls
23-3/16
15" Min.
A/B*
13" Max.
2-1/2
30
25
9/16
7-1/2
2-1/2
Accessory
Backguard
24
36-1/4
*JXS37 is 5-1/4" and JXS32 is 4"
(excluding handle)
**Total depth from wall to
front of closed oven door
including handle is 27-13/16.
35-7/8"–38"
from floor to
countertop
Acceptable
Electrical
Outlet Area
30" Min.
30" Min.
Shave Raised Edge To Clear
31-1/8" Wide Control Panel
Excluding Models JSS28 and JSP39
2-7/8"
To Front
Surface Of
Countertop
20-5/8" Door
Clearance
From Front
Surface of
Countertop
31-1/4
30
25-3/4**
Recommended
6" Min.
From Walls
23-3/16
15" Min.
A/B*
13" Max.
2-1/2
30
25
9/16
7-1/2
2-1/2
Accessory
Backguard
24
36-1/4
*JXS37 is 5-1/4" and JXS32 is 4"
(excluding handle)
**Total depth from wall to
front of closed oven door
including handle is 27-13/16.
35-7/8"–38"
from floor to
countertop
Optional Kits For Slide-In
Electric Ranges
(Available At Additional Cost)
Accessory Backguards
(Attaches to the back of range
as a backguard when unit is
installed in 30" free-standing
cutout)
JXS32SS (Stainless) - 4" High
JXS32WW (White) - 4" High
JXS32CC (Bisque) - 4" High
JXS32BB (Black) - 4" High
JXS37WW (White) - 5-1/4" High
JXS37CC (Bisque) - 5-1/4" High
JXS37BB (Black) - 5-1/4" High
Body Sides
(Slide-in ranges are sold
without sides installed. Can
be installed on either left
or right when unit has one
exposed side [no cabinet
adjacent]. Kit contains
1 body side)
JXS77WW (White)
JXS77CC (Bisque)
JXS77BB (Black)
Vertical Side Trim Kits
(If cabinet cutout width is
more than 30", a vertical
side trim kit may be used to
close the gap between the
range and cabinet)
JXS86WW (White)
JXS86CC (Bisque)
JXS86BB (Black)
Optional Lower Trim Kits
(If counter height is greater
than 36.5", a lower trim kit
is recommended to extend
the useful height to 38"
maximum)
JXS56WW – White
JXS56CC – Bisque
JXS56BB – Black
Optional Top Filler Kits
JXS66WW – White
JXS66CC – Bisque
JXS66BB – Black

JS905TK/BK
GE Profile™ 30" Slide-In Electric Range
Features and Benefits
• Self-Clean Oven - Conveniently cleans the oven cavity without the need
for scrubbing
• Dual Size Ribbon Element - Offers a convenient choice of using a 6” or 9” heating
element, depending on the size of the pan
• Bridge Element - Combines three cooktop elements into one large cooking area,
ideal for oversized cooking pans
•
Warming Zone - Provides low heat capability for foods, making meal coordination simple
• TrueTemp™System - Delivers even heat distribution and maximum oven control
• Ribbon Heating Elements - Provide powerful heat beneath a smooth glass surface
to ensure even heat and fast warm-up times
• Electronic Oven Controls - One-touch electronic pads are easy-to-use and allow for
simple oven operation
• Ceramic Glass Cooktop - A smooth cooktop surface makes cleaning quick and easy
• Warm Mode - Help keep just-cooked foods warm and at the ideal serving temperature
• Proof Mode - Specialized mode allows dough to rise quickly and efficiently
• Two Oven Racks - Feature a durable construction to help accommodate any size
or type of cookware
• Big ClearView™Window - An extra large clear window makes monitoring the
progress of food easy
• Model JS905TKWW - True white (white door and true white cooktop)
• Model JS905BKBB - Black on black (black door and black patterned cooktop)
Specification Revised 1/08 220442
I
H
8
6
4
2
L
O
L
O
2
4
6
8
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
I
H
8
6
4
2
L
O
2
4
6
8
JS905TK/BK
