GE QuickClean JBS03M Manual

†Note: Check local codes for required breaker size.
Effective January 1, 1996, the National Electrical Code requires
that new construction (not existing) utilize a 4-conductor
connection to an electric range.
Receptacle Locations: Locally approved flexible service cord
or conduit must be used because terminals are not accessible
after range installation. See shaded area in drawing for location
of electrical outlet box. Recommended outlet locations allow
range to be installed directly against wall.
Note: 30" ranges conform to U.L. requirements for 0" spacing
from adjacent walls below countertops. To reduce possibility
of scorching walls, engineering recommends a minimum of
1-1/2" spacing to allow for possible extended, high-heat,
no-load heating element operation.
Installation information: Before installing, consult installation
instructions packed with product for current dimensional data.
Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Listed by
Underwriters
Laboratories
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Specification Created 5/07 322035
KW Rating
240V 11.5
208V 8.6
Breaker Size
40 Amps†
CENTER LINE
2-1/4
7-1/2
7-1/2
7
5
2-1/4
3-1/2
REAR
WALL
26-1/4*
46-1/4
46-1/4
*Dimension from wall to front
of closed door handle is 28-3/4".
29-7/8
*Dimension from wall to front of closed door handle is 27-3/4".
CENTER LINE
2-1/4
7-1/2
7-1/2
7
5
2-1/4
3-1/2
REAR
WALL
26-1/4*
46-1/4
46-1/4
*Dimension from wall to front
of closed door handle is 28-3/4".
29-7/8
JBS03M
GE®30" Free-Standing QuickClean™Electric Range

Features and Benefits
• Super-Large Oven Capacity - Provides an impressively large oven interior
for cooking more dishes and large meals at one time
• Coil Heating Elements - Provides consistent and even heat on the cooktop with
a plug-in element that is removable for easy cleaning
• Dual Element Bake - Alternates the upper broiling element and the lower baking
element for even heating and optimal baking results
• Frameless Glass Oven Door - Offers an easy-to-clean and stylish design that blends
seamlessly into existing cabinetry
• CleanWell™ Cooktop System - Ensures spills are properly contained, while providing
convenient cleaning access
• Chrome Drip Bowls - Contain minor spills and are removable for easy cleaning
• Six Rack Positions - Provides flexibility and allows consumers to make the most
of available oven capacity
• Porcelain Upswept Cooktop - Features raised edges to help contain spills
and make clean-up easy
• Removable Full Width Storage Drawer - This convenient drawer can be used
for storing cookware or kitchen accessories
• 1 Oven Rack with 6 Embossed Rack Positions
• Model JBS03MWH – White (white door and blackcontrol panel/white cooktop)
JBS03M
Specification Created 5/07 322035
JBS03M
GE®30" Free-Standing QuickClean™Electric Range
