GE 20 Operating instructions

GEAppliances.com
Refrigerators
Profile Bottom Freezer
200D9366P016 49-60603 04-09 JR
Safety Instructions . . . . . . . . . . .2, 3
perating Instructions
Additional Features . . . . . . . . . . . . . . . . .9
Automatic Icemaker . . . . . . . . . . . . . . .12
Care and Cleaning . . . . . . . . . . . . .13–14
Controls . . . . . . . . . . . . . . . . . . . . . . . . . .4–5
Crispers and ans . . . . . . . . . . . . . . . . .10
Freezer . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Replacing the Light Bulbs . . . . . . . . . .15
Shelves and Bins . . . . . . . . . . . . . . . . . .8, 9
Water Filter . . . . . . . . . . . . . . . . . . . . . . .6, 7
Installation Instructions
Installing the Refrigerator . . . . . . .17–21
Installing the Water Line . . . . . . . .30–32
reparing to Install
the Refrigerator . . . . . . . . . . . . . . . . . . . .16
Removing and Replacing
the Doors (Double Door
Refrigerator Models only) . . . . . . .27–29
Removing and Replacing the
Freezer Drawer . . . . . . . . . . . . . . . . .22, 23
Reversing the Door Swing
(Single Door Refrigerator
Models only) . . . . . . . . . . . . . . . . . . .24–26
Troubleshooting Tips . . . . . .33–37
Normal Operating Sounds . . . . . . . . . .33
Consumer Support
Consumer Support . . . . . . . .Back Cover
erformance Data Sheet . . . . . . .43, 44
Owner’s Registration
for Canadian Customers . . . . . . . .39, 40
State of California Water
Treatment Device Certificate . . . .45, 46
Warranty for Canadian
Customers . . . . . . . . . . . . . . . . . . . . . . . . .42
Warranty for U.S. Customers . . . . . . .41
Réfrigérateurs
Congélateur inférieur
Refrigeradores
Congelador inferior
Write the model and serial
numbers here:
Model # ____________________
Serial #______________________
Find these numbers on a label
on the right side, near the top of the
refrigerator compartment.
Models 20, 22 and 23
Manuel d’utilisation
et d’installation
wner’s Manual and
Installation Instructions
Manual del
propietario e
instalación
La section française commence à la page 47
La sección en español empieza en la página 89

IMP RTANT SAFETY INF RMATI N.
READ ALL INSTRUCTI NS BEF RE USING.
WARNING!
Use this appliance only for its intended purpose as described in this O ner’s Manual.
SAFETY PRECAUTIONS
When using electrical appliances, basic safety precautions should be follo ed, including the follo ing:
■
■This refrigerator must be properly installed
and located in accordance with the Installation
Instructions before it is used.
■
■Do not allow children to climb, stand or hang
on the shelves in the refrigerator. They could
damage the refrigerator and seriously injure
themselves.
■
■Do not touch the cold surfaces in the freezer
compartment when hands are damp or wet.
Skin may stick to these extremely cold surfaces.
■
■Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
■
■Keep fingers out of the “pinch point” areas;
clearances between the doors and between
the doors and cabinet are necessarily small.
Be careful closing doors when children are
in the area.
■
■In refrigerators with automatic icemakers,
avoid contact with the moving parts of the
ejector mechanism, or with the heating element
that releases the cubes. Do not place fingers or
hands on the automatic icemaking mechanism
while the refrigerator is plugged in.
■
■Unplug the refrigerator before cleaning and making
repairs.
N TE: We strongly recommend that any servicing
be performed by a qualified individual.
■
■Setting either or both controls to 0 (off) does
not remove power to the light circuit.
■
■Do not refreeze frozen foods which have
thawed completely.
PROPER DISPOSAL OF THE REFRIGERATOR
Child entrapment and suffocation are not problems of
the past. Junked or abandoned refrigerators are still
dangerous…even if they will sit for “just a few days.”
If you are getting rid of your old refrigerator, please
follow the instructions below to help prevent
accidents.
Before You Throw Away Your ld
Refrigerator or Freezer:
■Take off the doors.
■Leave the shelves in place so that children may not
easily climb inside.
Refrigerants
All refrigeration products contain refrigerants,
which under federal law must be removed prior
to product disposal. If you are getting rid of an
old refrigeration product, check with the company
handling the disposal about what to do.
USE OF EXTENSION CORDS
Because of potential safety hazards under certain conditions, e strongly recommend against
the use of an extension cord.
However, if you must use an extension cord, it is absolutely necessary that it be a UL-listed (in the United States)
or a CSA certified (in Canada), 3-wire grounding type appliance extension cord having a grounding type plug
and outlet and that the electrical rating of the cord be 15 amperes (minimum) and 120 volts.
DANGER! RISK F CHILD ENTRAPMENT
Consumer Support Troubleshooting Tips perating Instructions Safety Instructions
Installation
Instructions
2

3
Consumer SupportTroubleshooting Tipsperating InstructionsSafety Instructions Installation
Instructions
GEAppliances.com
WARNING!
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove the third (ground) prong from the po er cord.
For personal safety, this appliance must be properly grounded.
The power cord of this appliance is equipped
with a 3-prong (grounding) plug which mates
with a standard 3-prong (grounding) wall outlet to
minimize the possibility of electric shock hazard from
this appliance.
Have the wall outlet and circuit checked by a
qualified electrician to make sure the outlet is
properly grounded.
Where a standard 2-prong wall outlet is encountered,
it is your personal responsibility and obligation to
have it replaced with a properly grounded 3-prong
wall outlet.
The refrigerator should always be plugged into its
own individual electrical outlet which has a voltage
rating that matches the rating plate.
This provides the best performance and also prevents
overloading house wiring circuits which could cause a
fire hazard from overheated wires.
Never unplug your refrigerator by pulling on the
power cord. Always grip plug firmly and pull straight
out from the outlet.
Repair or replace immediately all power cords that
have become frayed or otherwise damaged. Do not
use a cord that shows cracks or abrasion damage
along its length or at either end.
When moving the refrigerator away from the
wall, be careful not to roll over or damage the
power cord.
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTI NS
USE OF ADAPTER PLUGS
Adapter plugs are not permitted in Canada.

4
About the controls with temperature settings.
The temperature controls are preset in the factory at 37°F for the refrigerator
compartment and 0°F for the freezer compartment. Allo 24 hours for the temperature
to stabilize to the preset recommended settings.
The temperature controls can display both the SET temperature as ell as the actual
temperature in the refrigerator and freezer. The actual temperature may vary slightly
from the SET temperature based on usage and operating environment.
Setting either or both controls to FF stops cooling in both the freezer and refrigerator
compartments, but does not shut off electrical po er to the refrigerator.
For Controls-on-the-Door Models:
To change the temperature, press and release the
WARMER or C LDER pad. The ACTUAL TEMP light
will come on and the display will show the actual
temperature. To change the temperature, tap either
the WARMER or C LDER pad until the desired
temperature is displayed.
For Controls Inside the Refrigerator:
Opening the door displays the actual temperature.
To change the temperature, press either the
WARMER or C LDER touch pads until the
desired temperature is displayed.
Once the desired temperature has been set,
the temperature display will return to the actual
refrigerator and freezer temperatures after 5 seconds.
Several adjustments may be required.
Each time you adjust controls, allow 24 hours for the
refrigerator to reach the temperature you have set.
To turn the cooling system off, tap the WARMER pad
for either the refrigerator or the freezer until the
display shows FF.To turn the unit back on, press
the C LDER pad for either the refrigerator or freezer.
Then press the C LDER pad again and it will go to
the preset points of 0°F for the freezer and 37°F for
the refrigerator. Setting either or both controls to
FF stops cooling in both the freezer and refrigerator
compartments, but does not shut off electrical power
to the refrigerator.
Changing the Temperature
N TE: The refrigerator is shipped ith protective film covering the temperature controls.
If this film as not removed during installation, remove it no .
Consumer Support Troubleshooting Tips perating Instructions Safety Instructions
Installation
Instructions
(on some models)
(on some models)

Consumer SupportTroubleshooting Tipsperating InstructionsSafety Instructions Installation
Instructions
5
About TurboCool.™(on some models) GEAppliances.com
How it Works
TurboCool rapidly cools the refrigerator
compartment in order to more quickly
cool foods. Use TurboCool when adding a
large amount of food to the refrigerator
compartment, putting away foods after they
have been sitting out at room temperature or
when putting away warm leftovers. It can
also be used if the refrigerator has been
without power for an extended period.
Once activated, the compressor will
turn on immediately and the fans will cycle
on and off at high speed as needed for eight
hours. The compressor will continue to run
until the refrigerator compartment cools to
approximately 34°F (1°C), then it will cycle on
and off to maintain this setting. After 8 hours,
or if TurboCool is pressed again, the
refrigerator compartment will return
to the original setting.
How to Use
ress TurboCool. The refrigerator
temperature display will show .
After TurboCool is complete, the
refrigerator compartment will return
to the original setting.
N TES: The refrigerator temperature cannot
be changed during TurboCool.
The freezer temperature is not
affected during TurboCool.
When opening the refrigerator
door during TurboCool, the fans
will continue to run if they have
cycled on.
About Door Alarm (on some models)
The door alarm will sound if any door is open
for more than 2 minutes. The beeping stops
when you close the door.
(on some models)
(on some models)
(on some models)
(on some models)
About Energy Saver (on some models)
This product is equipped with an Energy
Saver feature. The refrigerator is shipped with
the Energy Saver feature enabled.
Over time, moisture can form on the front
surface of the refrigerator cabinet and cause
rust. If moisture does appear on the front
surface of the refrigerator cabinet, turn off
the Energy Saver feature by pressing and
releasing the ENERGY SAVER pad on the
control panel.
(on some models)
(on some models)

Water Filter Cartridge
The water filter cartridge is located in the
back upper right corner of the refrigerator
compartment.
When to Replace the Filter
There is a replacement indicator light for
the water filter cartridge on the temperature
display. This light will turn orange to tell you
that you need to replace the filter soon. The
filter cartridge should be replaced when the
replacement indicator light turns red or if
the flow of water to the dispenser or
icemaker decreases.
Installing the Filter Cartridge
If you are replacing the cartridge, first
remove the old one by slowly turning it
to the left. DO NOT pull down on the
cartridge. A small amount of water may
drip down.
CAUTI N: If air has been
trapped in the system, the filter cartridge may
be ejected as it is removed. Use caution hen
removing.
Remove the protective foil from the end
of the cartridge.
Fill the replacement cartridge with water
from the tap to allow for better flow from
the dispenser immediately after
installation.
Lining up the arrow on the cartridge
and the cartridge holder, slowly rotate
the cartridge clockwise until it stops.
When the cartridge is properly installed,
you will feel it “click” as it locks into place.
Do not overtighten.
Run water from the dispenser for
3 minutes (about 11⁄2gallons) to clear
the system and prevent sputtering.
See To Use the Dispenser section.
ress and hold the RESET WATER FILTER
pad for 3 seconds.
N TE: A newly-installed water filter
cartridge may cause water to spurt from
the dispenser.
Filter Bypass Plug
You must use the filter bypass plug when a
replacement filter cartridge is not available.
The icemaker will not operate without the
filter or filter bypass plug.
Replacement Filters:
To order additional filter cartridges
in the United States, visit our Website,
GEAppliances.com, or call GE Parts and
Accessories, 800.626.2002.
Filter Model MWF
Customers in Canada should consult
the yellow pages for the nearest Mabe
Service Center.
About the water filter. (on 22 and 23 models only)
Consumer Support Troubleshooting Tips perating Instructions Safety Instructions
Installation
Instructions
6
(on some models)
(on some models)
Cartridge
Holder
Cartridge
Holder

7
Consumer SupportTroubleshooting Tipsperating InstructionsSafety Instructions Installation
Instructions
Water Filter Cartridge
The water filter cartridge is located in the
back upper right corner of the refrigerator
compartment.
When to Replace the Filter
The filter cartridge should be replaced
when the flow of water to the icemaker
decreases, or every 6 months.
Installing the Filter Cartridge
If you are replacing the cartridge, first
remove the old one. Open the cartridge
cover by pressing in on the tab at the
front and pulling down.
Remove the cartridge by slowly rotating
it counterclockwise. A small amount of
water may drip down.
CAUTI N: If air has been
trapped in the system, the filter cartridge may
be ejected as it is removed. Use caution hen
removing.
Remove the protective foil from the end
of the cartridge.
Lining up the arrow on the cartridge
and the cartridge holder, slowly rotate
the cartridge clockwise until it stops.
When the cartridge is properly installed,
you will feel it “click” as it locks into place.
The grip on the end of the cartridge
should be positioned vertically.
Do not overtighten.
Close the cartridge cover.
Filter Bypass Plug
You must use the filter bypass plug when a
replacement filter cartridge is not available.
The icemaker will not operate without the
filter or filter bypass plug.
Replacement Filters:
To order additional filter cartridges
in the United States, visit our Website,
GEAppliances.com, or call GE Parts and
Accessories, 800.626.2002.
Filter Model GSWF
Customers in Canada should consult
the yellow pages for the nearest Mabe
Service Center.
About the water filter. (on 20 models only) GEAppliances.com

Consumer Support Troubleshooting Tips perating Instructions Safety Instructions
Installation
Instructions
8
Rearranging the Shelves
To remove:
Remove all items from the shelf.
Tilt the shelf up at the front.
Lift the shelf up at the back and
bring the shelf out.
To replace:
While tilting the shelf up, insert the top
hook at the back of the shelf in a slot
on the track.
Lower the front of the shelf until the
bottom of the shelf locks into place.
Spillproof Shelves (on some models)
Spillproof shelves have special edges to
help prevent spills from dripping to lower
shelves. To remove or replace the shelves,
see Rearranging the Shelves.
About the shelves and bins.
Not all features are on all models.
Some models have wire shelves that can
be adjusted in the same manner.
Shelves in the refrigerator compartment are adjustable.
Refrigerator Compartment
Slide- ut Spillproof Shelf (on some models)
The slide-out spillproof shelf allows you
to reach items stored behind others. The
special edges are designed to help prevent
spills from dripping to lower shelves.
To remove:
Remove all items from shelf.
Remove the shelf from the compartment
by lifting up and out.
Remove the glass shelf from the frame
by sliding the shelf out until it stops.
ull the shelf up to release it from
the front of the frame.
Slide the shelf back to release it from
the back of the frame.
To reinstall the glass shelf, reverse these
instructions.
Make sure that the shelf sits flat after
reinstallation and doesn’t move freely from
side to side.
Make sure you push the shelves all the ay
in before you close the door.
Tuck-Away Shelf (on some models)
This shelf can retract to half its size for
storage of tall items on the shelf below.
To remove:
ull the shelf out and up.
Slide the shelf back until it stops.
To return the shelf to its original position,
pull up and forward on the shelf. ush
down slightly to lock the shelf into
position.

Non-Adjustable Bins on the Door
To remove: Lift the bin straight up, then
pull out.
To replace: Engage the bin in the molded
supports on the door and push down.
It will lock in place.
Adjustable Bins on the Door
Adjustable bins can easily be carried from
refrigerator to work area.
To remove: Lift bin straight up, then
pull out.
To replace or relocate: Slide in the bin just
above the molded door supports, and push
down. The bin will lock in place.
The snugger helps prevent tipping, spilling
or sliding of small items stored on the door
shelf. Grip the finger hold near the rear of
the snugger and move it to fit your needs.
GEAppliances.com
About the additional features.
Shelf Saver Rack (on some models)
Slide-out beverage rack holds twelve cans of
soda or two wine/water bottles (lengthwise).
It can be removed for cleaning.
To remove, slide the rack out to the stop
position, lift the rack up and past the stop
position and lift it out.
Consumer SupportTroubleshooting Tipsperating InstructionsSafety Instructions Installation
Instructions
9

10
Consumer Support Troubleshooting Tips perating Instructions Safety Instructions
Installation
Instructions
About the crispers and pans.
Not all features are on all models.
Fruit and Vegetable Crisper
Excess water that may accumulate in the
bottom of the drawers or under the drawers
should be wiped dry.
Adjustable Humidity Crisper (on some models)
Slide the control all the way to the
HIGH setting to provide high humidity
recommended for most vegetables.
Slide the control all the way to the L W
setting to provide lower humidity levels
recommended for most fruits.
Adjustable Temperature Deli Pan (on some models)
When the pan is placed in the 2nd slot from
the top of the track and the lever is set
at C LDEST, air from the freezer is forced
around the pan to keep it very cold.
You can move the pan to any location if
you don’t want the extra cold storage.
The settings can be adjusted anywhere
between cold and coldest .
When set at cold, the pan will stay at the
normal refrigerator temperature.
The coldest setting provides the coldest
storage area.
Second slot
from top

Freezer Shelves and Baskets
A shelf above the ice storage bin
A half-width basket
A shallow full-width basket
A deep full-width basket
N TE: Do not fill baskets higher than the rim
of the basket. This may cause baskets to stick
or jam when opening or closing.
Basket Removal
To remove the shallow full-width basket:
ull the basket out to the stop location.
Lift the front up and over the stop
location.
Lift the basket up and out.
To remove the deep full-width basket on
freezer drawer models:
Open the freezer drawer until it stops.
The freezer basket rests on the inside
tabs on the drawer slides.
Lift the basket so that it is out of all
6 slide bracket tabs.
Tilt the basket and lift out of the drawer.
When replacing the deep full-width basket:
Tilt the basket back and lower it down
into the drawer. Rotate the basket to a
horizontal position and press it down into
the 6 alignment tabs.
N TE: Always be sure that the basket is
seated in all 6 slide bracket tabs before sliding
back into the freezer. The basket can be
turned in either direction front to back and
installed into the freezer.
To remove the half-width basket:
ull the basket out to the stop location.
Lift the basket up at the front to release
it from the slides.
Lift the back up and out of the slide.
When replacing the basket, make sure that
the wire tabs and wire hooks on the sides
of the basket go into the slots in the top
of the upper basket slides.
N TE: Always be sure to fully close this
basket.
About the freezer. GEAppliances.com
Not all features are on all models.
Appearance and features may vary
Appearance may vary
Appearance may vary
Appearance may vary
11
Consumer SupportTroubleshooting Tipsperating InstructionsSafety Instructions Installation
Instructions

12
Consumer Support Troubleshooting Tips perating Instructions Safety Instructions
Installation
Instructions
About the automatic icemaker.
Automatic Icemaker (on some models)
The icemaker will produce seven cubes per cycle—
approximately 100–130 cubes in a 24-hour period,
depending on freezer compartment temperature,
room temperature, number of door openings and
other use conditions.
See below for how to access ice and reach the
power switch.
If the refrigerator is operated before the water
connection is made to the icemaker, set the power
switch in the (off) position.
When the refrigerator has been connected to
the water supply, set the power switch to the l (on)
position. The icemaker power light will turn green
when the freezer light switch is pressed in or when
the freezer door is closed.
The icemaker will fill with water when it cools to
15°F (–10°C). A newly installed refrigerator may
take 12 to 24 hours to begin making ice cubes.
You will hear a buzzing sound each time
the icemaker fills with water.
Throw away the first few batches of ice to allow
the water line to clear.
Be sure nothing interferes with the sweep
of the feeler arm.
When the bin fills to the level of the feeler arm,
the icemaker will stop producing ice. It is normal
for several cubes to be joined together.
If ice is not used frequently, old ice cubes will
become cloudy, taste stale and shrink.
N TE: In homes ith lo er-than-average ater
pressure, you may hear the icemaker cycle multiple
times hen making one batch of ice.
N TE: Set the po er s itch to the (off) position
if the ater supply is shut off.
A ne ly installed refrigerator may take 12 to 24 hours to begin making ice.
cemaker
Feeler Arm
Power
Switch
Green
Power
Light
Accessing Ice and Reaching
the Power Switch
To reach the icemaker power switch, pull
the shelf above the ice bin straight out. Always
be sure to replace the shelf.
To access ice, simply pull the bin forward.
To access ice.
Shelf
ce Bin
To reach the power switch.
Shelf
ce Bin
Icemaker Accessory Kit
If your refrigerator did not come already equipped
with an automatic icemaker, an icemaker
accessory kit is available at extra cost.
Check the back of the refrigerator for the specific
icemaker kit needed for your model.
To Use the Dispenser (on some models)
ress the glass gently against the top of the
dispenser cradle.
The spill shelf is not self-draining. To reduce water
spotting, the shelf should be cleaned regularly.
If no ater is dispensed hen the refrigerator is
first installed, there may be air in the ater line
system. Press the dispenser arm for at least t o
minutes to remove trapped air from the ater line
and to fill the ater system. To flush out impurities
in the ater line, thro a ay the first six glassfuls
of ater.
Locking the Dispenser
ress the L CK pad for 3 seconds to lock
the dispenser and control panel. To unlock,
press and hold the pad again for 3 seconds.
Spill Shelf
Dispenser Cradle
To Use the Internal Water Dispenser (on some models)
The water dispenser is located on the left wall
inside the refrigerator compartment.
To dispense water:
Hold the glass against the recess.
ush the water dispenser button.
Hold the glass underneath the dispenser for
2–3 seconds after releasing the dispenser
button. Water may continue to dispense
after the button is released.
If no ater is dispensed hen the refrigerator is
first installed, there may be air in the ater line
system. Press the dispenser button for at least
2 minutes to remove trapped air from the ater line
and to fill the ater system. During this process,
the dispenser noise may be loud as the air is
purged from the ater line system. To flush out
impurities in the ater line, thro a ay the first
6 glassfuls of ater.
N TE: To avoid ater deposits, the dispenser
should be cleaned periodically by iping ith
a clean cloth or sponge.

Care and cleaning of the refrigerator. GEAppliances.com
Cleaning the utside
The door handles and trim. Clean with a
cloth dampened with soapy water. Dry with
a soft cloth. Do not use wax on the door
handles and trim.
Keep the outside clean. Wipe with
a clean cloth lightly dampened with kitchen
appliance wax or mild liquid dish detergent.
Dry and polish with a clean, soft cloth.
Do not ipe the refrigerator ith a soiled
dish cloth or et to el. These may leave
a residue that can erode the paint. Do not
use scouring pads, po dered cleaners,
bleach or cleaners containing bleach
because these products can scratch
and eaken the paint finish.
The stainless steel panels and door
handles. Stainless steel (on some models)
can be cleaned with a commercially
available stainless steel cleaner. A spray-on
stainless steel cleaner works best.
Do not use appliance wax or polish
on the stainless steel.
Silver-plated plastic parts. Wash parts with
soap or other mild detergents. Wipe clean
with a sponge, damp cloth or paper towel.
Do not scrub with steel-wool pads or other
abrasive cleaners.
Cleaning the Inside
To help prevent odors, leave an open box
of baking soda in the refrigerator and freezer
compartments.
Unplug the refrigerator before cleaning.
If this is not practical, wring excess moisture
out of sponge or cloth when cleaning around
switches, lights or controls.
Use an appliance wax polish on the inside
surface between the doors.
Use warm water and baking soda solution—
about a tablespoon (15 ml) of baking soda to
a quart (1 liter) of water. This both cleans and
neutralizes odors. Rinse and wipe dry.
After cleaning the door gaskets, apply a thin
layer of petroleum jelly to the door gaskets
at the hinge side. This helps keep the gaskets
from sticking and bending out of shape.
Avoid cleaning cold glass shelves ith hot
ater because the extreme temperature
difference may cause them to break.
Handle glass shelves carefully. Bumping
tempered glass can cause it to shatter.
Do not ash any plastic refrigerator parts
in the dish asher.
Silver-accented plastic parts. Wash parts
with soapy water. Wipe clean with a sponge,
damp cloth or paper towel.
Do not scrub with steel-wool pads or other
abrasive cleaners.
Consumer SupportTroubleshooting Tipsperating InstructionsSafety Instructions Installation
Instructions
13

14
Consumer Support Troubleshooting Tips perating Instructions Safety Instructions
Installation
Instructions
For long vacations or absences, remove
food and unplug the refrigerator. Clean the
interior with a baking soda solution of one
tablespoon (15 ml) of baking soda to one
quart (1 liter) of water. Leave the doors open.
Set the icemaker power switch to the (off)
position and shut off the water supply to
the refrigerator.
If the temperature can drop below freezing,
have a qualified servicer drain the water
supply system (on some models) to prevent
serious property damage due to flooding.
Care and cleaning of the refrigerator. (cont.)
Behind the Refrigerator
Be careful when moving the refrigerator
away from the wall. All types of floor
coverings can be damaged, particularly
cushioned coverings and those with
embossed surfaces.
Raise the leveling legs located at the bottom
front of the refrigerator.
ull the refrigerator straight out and return it
to position by pushing it straight in. Moving
the refrigerator in a side direction may
result in damage to the floor covering
or refrigerator.
Lower the leveling legs until they touch
the floor.
When pushing the refrigerator back, make
sure you don’t roll over the po er cord or
icemaker supply line (on some models).
Preparing for Vacation
Preparing to Move
Secure all loose items such as base grille,
shelves and drawers by taping them
securely in place to prevent damage.
When using a hand truck to move the
refrigerator, do not rest the front or back
of the refrigerator against the hand truck.
This could damage the refrigerator. Handle
only from the sides of the refrigerator.
Be sure the refrigerator stays in an upright
position during moving.

Refrigerator Lights
CAUTI N: Light bulbs may
be hot.
Unplug the refrigerator.
To remove the light shield, grasp the
shield at the back and pull out to release
the tabs at the back.
Rotate the shield down and then forward
to release the tabs at the front of the
shield.
After replacing with an appliance bulb
of the same or lower wattage, replace
the shield.
lug the refrigerator back in.
N TE: Appliance bulbs may be ordered from
GE arts and Accessories, 800.626.2002.
Freezer Light
Replacing the light bulbs. GEAppliances.com
Turning the control to the 0 (off) position does not remove po er to the light circuit.
CAUTI N: Light bulbs may
be hot.
Unplug the refrigerator.
Remove the freezer basket for access.
The bulb is located at the rear of the
freezer inside a light shield.
To remove, grasp the shield at the top
and pull out to release the tabs at the
bottom.
After replacing with an appliance bulb
of the same or lower wattage, replace
the shield and freezer basket.
lug the refrigerator back in.
Middle Lights
CAUTI N: Light bulbs may
be hot.
Unplug the refrigerator.
The bulbs are located behind the crisper
drawers. To remove the drawers, lift up
slightly while pulling the drawer past the
stop location.
Replace the bulbs with appliance bulbs
of the same or lower wattage.
Replace crisper drawers by sliding them
gently back onto the tracks while lifting
up slightly.
lug the refrigerator back in.
Lights are behind
crisper drawers
Light Bulbs
Appearance may vary
Consumer SupportTroubleshooting Tipsperating InstructionsSafety Instructions Installation
Instructions
15

Installation Refrigerator
Instructions Models 20, 22 and 23
Questions? Call 00.GE.CARES ( 00.432.2737) or visit our Website at: GEAppliances.com
In Canada, call 1. 00.561.3344 or visit our Website at: www.GEAppliances.ca
BEFORE YOU BEGIN
Read these instructions completely and carefully.
•IMPORTANT —Save these instructions
for local inspector’s use.
•IMPORTANT —Observe all governing
codes and ordinances.
• Note to Installer – Be sure to leave these
instructions with the Consumer.
• Note to Consumer – Keep these instructions for
future reference.
• Skill level – Installation of this appliance requires
basic mechanical skills.
• Completion time – Refrigerator Installation
20 minutes
Water Line Installation
30 minutes
•roper installation is the responsibility of the
installer.
•roduct failure due to improper installation is not
covered under the Warranty.
PREPARATION
MOVING THE REFRIGERATOR INDOORS
If the refrigerator will not fit through a doorway,
the refrigerator door and freezer drawer can be
removed.
•To remove the refrigerator door, see Step 1 in
the Reversing the Door S ing section.
•To remove the freezer drawer, see the Removing
the Freezer Dra er section.
WATER SUPPLY TO THE ICEMAKER AND DISPENSER
(ON SOME MODELS)
If the refrigerator has an icemaker, it will have to be
connected to a cold water line. A GE water supply kit
(containing tubing, shutoff valve, fittings and
instructions) is available at extra cost from your dealer,
by visiting our Website at GEAppliances.com (in
Canada at www.GEAppliances.ca) or from arts and
Accessories, 800.626.2002 (In Canada .888.261.3055).
TOOLS YOU MAY NEED
Adjustable Wrench
1/4″Outer Diameter
Compression Nut
and Ferrule (sleeve)
(icemaker models only)
hillips Head Screwdriver
16
3/8″and 5/16″Socket
Ratchet/Driver
3/32″, 1/8″and 3/16″Allen
wrenches
encil
1/8″Drill Bit and
Electric or Hand Drill
Tape measure
1/4″Nut Driver
Wire Cutters Level

Installation Instructions
INSTALLING THE REFRIGERATOR
REFRIGERATOR LOCATION
•Do not install the refrigerator where the temperature
will go below 60°F (16°C) because it will not run often
enough to maintain proper temperatures.
•Do not install the refrigerator where the temperature
will go above 100°F (37°C) because it will not perform
properly.
•Install it on a floor strong enough to support it fully
loaded.
CLEARANCES
Allow the following clearances for ease of installation,
proper air circulation and plumbing and electrical
connections.
Standard Depth
Models
Sides 1/8″(3 mm)
Top 1″(25 mm)
Back 1″(25 mm)
CONNECTING THE REFRIGERATOR
TO THE HOUSE WATER LINE
(icemaker and dispenser models)
A cold water supply is required for automatic
icemaker operation. If there is not a cold water
supply, you will need to provide one. See Installing
the Water Line section.
NOTES:
•Before making the connection to the refrigerator,
be sure the refrigerator power cord is not plugged
into the wall outlet.
•If your refrigerator does not have a water filter, we
recommend installing one if your water supply has
sand or particles that could clog the screen of the
refrigerator’s water valve. Install it in the water line
near the refrigerator. If using GE SmartConnect™
Refrigerator Tubing Kit, you will need an additional
tube (WX08X10002) to connect the filter. Do not cut
plastic tube to install filter.
1
REMOVE TOP CAP (on some models)
•IMPORTANT NOTE: This refrigerator is 34-1/2″deep.
Doors and passageways leading to the installation
location must be at least 36″wide in order to leave
the doors and handles attached to the refrigerator
while transporting it into the installation location.
If passageways are less than 36″, the refrigerator
doors and handles can easily be scratched and
damaged. The top cap and doors can be removed
to allow the refrigerator to be safely moved indoors.
Start with Step A.
•If it is not necessary to remove doors, skip Step A.
Leave tape and all packaging on doors until the
refrigerator is in the final location.
•SKID REMOVAL: Tilt refrigerator to each side to
remove skid.
•NOTE: Use a padded hand truck to move this
refrigerator. Place the refrigerator on the hand truck
with a side against the truck. We strongly recommend
that TWO PEOPLE move and complete this installation.
Locate and remove the two hillips head screws on
the top of the refrigerator. Remove the two screws
on each side at the rear of the top cap. Lift off and
remove top cap.
Remove the fresh-food door. Refer to Steps 1 through
3 of “Reversing the Door Swing” section.
Remove the bottom freezer drawer. Refer to
“Removing Freezer Drawer” section.
Move refrigerator to the installation location.
A
B
C
D
17
REMOVE TOP CAP (cont.) (on some models)
REINSTALL DOORS, DRAWERS AND TOP CAP
Carefully lower the door onto the center hinge.
Reinstall top hinge. NOTE: Ensure the door is properly
aligned to the case top to avoid readjustment of the
door during top cap reinstallation.
lace cap over the top of the refrigerator. Reinstall
the original screws in the top and back of the cap.
Reinstall the bottom freezer drawer. Refer to
“Replacing the Freezer Drawer” section.
E
F
G
A
Top Hinge B

INSTALLING THE REFRIGERATOR (cont.)
CONNECTING THE REFRIGERATOR TO
THE HOUSE WATER LINE
(cont.)
If you are using copper tubing, place a
compression nut and ferrule (sleeve) onto the
end of the tubing coming from the house cold
water supply.
If you are using the GE SmartConnect™
tubing, the nuts are already assembled to
the tubing.
If you are using copper tubing, insert
the end of the tubing into the refrigerator
connection, at the back of the refrigerator,
as far as possible. While holding the tubing,
tighten the fitting.
If you are using GE SmartConnect™tubing,
insert the molded end of the tubing into the
refrigerator connection, at the back of the
refrigerator, and tighten the compression
nut until it is hand tight. Then tighten one
additional turn with a wrench. Overtightening
may cause leaks.
Fasten the tubing into the clamp provided to
hold it in position. You may need to pry open
the clamp.
One of the illustrations below will look like
the connection on your refrigerator.
Icemaker-Ready models
Icemaker-Installed Models
1
Installation Instructions
1
A
B
C
1/4″Tubing
Tubing Clamp
1/4″
Compression
Nut
Ferrule
(sleeve)
SmartConnect™
Tubing
Refrigerator
Connection
TURN ON THE WATER SUPPLY
(icemaker and dispenser models)
Turn the water on at the shutoff valve (house
water supply) and check for any leaks.
2
PLUG IN THE REFRIGERATOR
On models with an icemaker, before plugging in
the refrigerator, make sure the icemaker power
switch is set to the O (off) position.
See the grounding information attached to the
power cord.
3
PUT THE REFRIGERATOR IN PLACE
Move the refrigerator to its final location.
4
1/4″Copper
Tubing
1/4″
Compression
Nut
Ferrule
(sleeve)
SmartConnect™
Tubing
Refrigerator
Connection
Tubing
Clamp LEVEL THE REFRIGERATOR
Adjustable legs at the front corners of the
refrigerator should be set so the refrigerator is
firmly positioned on the floor, and the front is
raised just enough that the door closes easily
when opened about halfway.
To adjust the leveling legs, turn the legs
clockwise to raise the refrigerator,
counterclockwise to lower it.
5

Installation Instructions
REMOVE THE FRESH FOOD
DOOR HANDLE
(For placement in the installation location
or reversal of the handles – on some
models)
Stainless steel (on
some models):
REMOVING
THE DOOR
HANDLE: Loosen
the set screws
with the 3/32″
Allen wrench
and remove
the handle.
NOTE: For
Double Door
models follow
the same
procedure on
the opposite door.
Plastic handle
(on some models):
REMOVING THE DOOR HANDLE: Depress the
tab on the underside of the handle and slide
the handle up and off of the mounting
fasteners.
REVERSING THE
DOOR HANDLE
(on some
models):
•Remove
the handle
mounting
fasteners with
a 3/16″Allen
wrench and
transfer
the handle
mounting
fasteners to
the right side.
•Remove the logo badge.
•Remove and transfer the plug button to
the left side of the fresh food door. NOTE:
Use a flat plastic edge to prevent damaging
the door. Remove any adhesive on the door
with a mild detergent. Remove the paper
covering on the adhesive backing on
the logo badge prior to carefully attaching
the badge to the door.
A
A
6
A
B
A
B
Mounting
Fasteners
Mounting
Fasteners
Badge
Badge
(appearance may vary)
(appearance may vary)
REMOVE THE FREEZER DOOR HANDLE
Stainless steel and plastic handles:
Loosen the set screws located on the
underside of the handle with the 1/8″Allen
wrench and remove the handle.
NOTE: If the handle mounting fasteners need
to be tightened or removed, use a 3/16″Allen
wrench.
A
7
A
19

INSTALLING THE REFRIGERATOR (cont.)
ATTACH THE FREEZER DOOR HANDLE
Stainless steel and plastic handles:
Attach the handle firmly to the mounting
fasteners and tighten the set screws on
the bottom of the handle with a 1/8″Allen
wrench.
A
Installation Instructions
20
ATTACH THE FRESH FOOD
DOOR HANDLE
Stainless steel handle:
Attach the
handle to the
handle mounting
fasteners and
tighten the set
screws with a
3/32″Allen
wrench.
NOTE: For
Double Door
models follow
the same
procedure on the
opposite door.
Plastic handle:
Attach the handle to the handle mounting
fasteners by aligning the slots with the
handle mounting fasteners.
Slide it down until it is firmly locked into
position.
A
A
A
Mounting
Fasteners
(appearance may vary)
(appearance may vary)
Mounting
fasteners
Slots on back of
handle
A
A
9
A
(appearance may vary)
