GE 200D8074P037 Safety guide

GEAppliances.com
Refrigerators
Side-by-Side
200D8074P037 49-60587 02-09 JR
La section française commence à la page 38
La sección en español empieza en la página 74
Safety Instructions . . . . . . . . . . . . . . . . .2–3
Operating Instructions
Automatic Icemaker . . . . . . . . . . . . . . . . . . . .11
Care and Cleaning . . . . . . . . . . . . . . . . . . .13, 14
Crispers and Pans . . . . . . . . . . . . . . . . . . . . . . .10
Ice and Water Dispenser . . . . . . . . . . . .12, 13
Refrigerator Doors . . . . . . . . . . . . . . . . . . . . . . .9
Replacing the Light Bulbs . . . . . . . . . . . . . . .15
Shelves and Bins . . . . . . . . . . . . . . . . . . . . . . .7, 8
Temperature Controls . . . . . . . . . . . . . . . . . . . .4
TurboCool™. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Water Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . .5, 6
Installation Instructions
Installing the Refrigerator . . . . . . . . . . . .21–24
Moving the Refrigerator . . . . . . . . . . . . .17–20
Preparing to Install
the Refrigerator . . . . . . . . . . . . . . . . . . . . . . . . .16
Water Line Installation . . . . . . . . . . . . . .25–27
Troubleshooting Tips . . . . . . . . . . . .28–31
Normal Operating Sounds . . . . . . . . . . . . . . .28
Consumer Support
Consumer Support . . . . . . . . . . . . .Back Cover
Performance Data Sheet . . . . . . . . . . . .32, 33
State of California Water
Treatment Device Certificate . . . . . . . . .34, 35
Warranty (Canadian) . . . . . . . . . . . . . . . . . . . .36
Warranty (U.S.) . . . . . . . . . . . . . . . . . . . . . . . . .37
Réfrigérateurs
Côte à Côte
Refrigeradores
Lado a Lado
Models 22, 23, 25, 26, 27 and 29
Write the model and serial numbers
here:
Model # __________________________
Serial # __________________________
Find these numbers on a label inside
the refrigerator compartment at the
top on the right side.
Owner’s Manual
and Installation
Manuel d’utilisation
et d’installation
Manual del propietario
e instalación

Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions
Installation
Instructions
2
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
Use this appliance only for its intended purpose as described in this Owner’s Manual.
SAFETY PRECAUTIONS
When using electrical appliances, basic safety precautions should be followed, including the following:
■
■This refrigerator must be properly installed
and located in accordance with the Installation
Instructions before it is used.
■
■Do not allow children to climb, stand or hang
on the shelves in the refrigerator. They could
damage the refrigerator and seriously injure
themselves.
■
■Do not touch the cold surfaces in the freezer
compartment when hands are damp or wet.
Skin may stick to these extremely cold surfaces.
■
■Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
■
■In refrigerators with automatic icemakers,
avoid contact with the moving parts of the
ejector mechanism, or with the heating element
located on the bottom of the icemaker. Do
not place fingers or hands on the automatic
icemaking mechanism while the refrigerator
is plugged in.
■
■Keep fingers out of the “pinch point” areas;
clearances between the doors and between
the doors and cabinet are necessarily small.
Be careful closing doors when children are
in the area.
■
■Unplug the refrigerator before cleaning and making
repairs.
NOTE: We strongly recommend that any servicing
be performed by a qualified individual.
■
■Do not refreeze frozen foods which have
thawed completely.
NOTE: Turning the refrigerator off via the controls on
the touch panel does not shut off electrical power to
the refrigerator.

READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
Consumer SupportTroubleshooting Tips
Operating Instructions
Safety Instructions Installation
Instructions
GEAppliances.com
PROPER DISPOSAL OF THE REFRIGERATOR
Child entrapment and suffocation are not problems
of the past. Junked or abandoned refrigerators are
still dangerous…even if they will sit for “just a few
days.” If you are getting rid of your old refrigerator,
please follow the instructions below to help prevent
accidents.
Before You Throw Away Your Old
Refrigerator or Freezer:
■Take off the doors.
■Leave the shelves in place so that children may not
easily climb inside.
Refrigerants
All refrigeration products contain refrigerants, which
under federal law must be removed prior to product
disposal. If you are getting rid of an old refrigeration
product, check with the company handling the
disposal about what to do.
USE OF EXTENSION CORDS
Because of potential safety hazards under certain conditions, we strongly recommend against the use
of an extension cord.
However, if you must use an extension cord, it is absolutely necessary that it be a UL-listed (in the United States)
or a CSA-listed (in Canada), 3-wire grounding type appliance extension cord having a grounding type plug and
outlet and that the electrical rating of the cord be 15 amperes (minimum) and 120 volts.
DANGER! RISK OF CHILD ENTRAPMENT
3
WARNING!
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
For personal safety, this appliance must be properly grounded.
The power cord of this appliance is equipped
with a 3-prong (grounding) plug which mates
with a standard 3-prong (grounding) wall outlet
to minimize the possibility of electric shock hazard
from this appliance.
Have the wall outlet and circuit checked by a qualified
electrician to make sure the outlet is properly
grounded.
If the outlet is a standard 2-prong outlet, it is
your personal responsibility and obligation to
have it replaced with a properly grounded
3-prong wall outlet.
The refrigerator should always be plugged into its
own individual electrical outlet which has a voltage
rating that matches the rating plate.
This provides the best performance and also prevents
overloading house wiring circuits which could cause a
fire hazard from overheated wires.
Never unplug your refrigerator by pulling on
the power cord. Always grip plug firmly and pull
straight out from the outlet.
Repair or replace immediately all power cords that
have become frayed or otherwise damaged. Do not
use a cord that shows cracks or abrasion damage
along its length or at either end.
When moving the refrigerator away from the wall,
be careful not to roll over or damage the power cord.

The Performance Air-Flow System is designed to
maximize temperature control in the refrigerator
and freezer compartments. This unique special
feature consists of the Air Tower along the back
wall of the refrigerator and the Air Tunnel on the
bottom portion of the freezer rear wall. Placing
food in front of the louvers on these components
will not affect performance. Although the Air Tower
and the Air Tunnel can be removed, doing so will
affect temperature performance. (For removal
instructions, on-line, contact us at ge.com or
call 800.GE.CARES. In Canada, contact us at
geappliances.ca or call 1.800.561.3344.)
TurboCool rapidly cools the refrigerator
compartment in order to more quickly cool foods.
Use TurboCool when adding a large amount
of food to the refrigerator compartment, putting
away foods after they have been sitting out at
room temperature or when putting away warm
leftovers. It can also be used if the refrigerator has
been without power for an extended period.
Once activated, the compressor will turn on
immediately and the fans will cycle on and
off at high speed as needed for eight hours.
The compressor will continue to run until the
refrigerator compartment cools to approximately
34°F (1°C), then it will cycle on and off to maintain
this setting. After 8 hours, or if TurboCool is
pressed again, the refrigerator compartment
will return to the original setting.
How to Use
Press TurboCool. The TurboCool temperature
display will show Tc and the LED will be activated.
After TurboCool is complete, the TurboCool
indicator light will go out.
NOTES: The refrigerator temperature cannot be
changed during TurboCool.
The freezer temperature is not affected
during TurboCool.
When opening the refrigerator door
during TurboCool, the fans will continue
to run if they have cycled on.
About the temperature controls.
4
The temperature controls are preset in the factory at 37°F for the refrigerator compartment and 0°F for the
freezer compartment. Allow 24 hours for the temperature to stabilize to the preset recommended settings.
The temperature controls can display both the SET temperature as well as the actual temperature in the
refrigerator and freezer. The actual temperature may vary slightly from the SET temperature based on
usage and operating environment.
■On some models, setting both controls to the warmest setting until the display flashes (off) will stop
cooling in both the freezer and refrigerator compartments.
■On other models, setting either control to the warmest setting until the display flashes (off) will stop
the cooling to the freezer and refrigerator.
■NOTE: Turning the refrigerator off via the controls on the touch panel does not shut off electrical power
to the refrigerator.
NOTE: The refrigerator is shipped with protective film covering the temperature controls. If this film was
not removed during installation, remove it now.
About TurboCool.™(on some models)
How it Works
Not all features are on all models.
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions
Installation
Instructions
Performance Air Flow System

Consumer SupportTroubleshooting TipsOperating Instructions
Safety Instructions Installation
Instructions
5
About the water filter. (on some models) GEAppliances.com
Water Filter Cartridge
The water filter cartridge is located in the back upper right
corner of the refrigerator compartment.
When to Replace the Filter on Models Without
a Replacement Indicator Light
The filter cartridge should be replaced every six months or
earlier if the flow of water to the water dispenser or icemaker
decreases.
Removing the Filter Cartridge
If you are replacing the cartridge, first remove the old one
by slowly turning it to the left. Do not pull down on the
cartridge. A small amount of water may drip down.
Installing the Filter Cartridge
If you are replacing a SmartWater cartridge with
an adapter, it must be removed before installing the
cartridge. To remove the adapter, turn it to the left
about 1/4 turn.
On models without a replacement indicator light, apply
the month and year sticker to the new cartridge to remind
you to replace the filter in six months.
Fill the replacement cartridge with water from the tap to
allow for better flow from the dispenser immediately after
installation.
Line up the arrow on the cartridge and the cartridge
holder. Place the top of the new cartridge up inside
the holder. Do not push it up into the holder.
Slowly turn it to the right until the filter cartridge stops.
DO NOT OVERTIGHTEN. As you turn the cartridge, it will
automatically raise itself into position. The cartridge will
move about 1/2 turn.
Run water from the dispenser for 3 minutes (about
1-1/2 gallons) to clear the system and prevent sputtering.
Press and hold the WATER FILTER pad (on some models)
on the dispenser for 3 seconds.
NOTE: A newly installed water filter cartridge may cause
water to spurt from the dispenser.
Filter Bypass Plug
You must use the filter bypass plug when a replacement filter
cartridge is not available. The dispenser and the icemaker will
not operate without the filter or filter bypass plug.
If you have questions—visit our Website at GEAppliances.com,
or call 1.800.GE.CARES (1.800.432.2737).
Replacement filters:
To order additional filter cartridges in the United States,
visit our Website at GEAppliances.com, or call GE Parts and
Accessories, 800.626.2002.
Filter Model MSWF
Customers in Canada should consult the yellow pages
for the nearest Mabe Service Center.
Cartridge Holder
Filter
Bypass
Plug
SmartWater
(appearance may vary)
With Adapter Without Adapter

6
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions
Installation
Instructions
About the water filter. (on some models) (cont.)
On some models
Water Filter Cartridge
The water filter cartridge is located in the back upper right
corner of the refrigerator compartment.
When to Replace the Filter on Models Without
a Replacement Indicator Light
The filter cartridge should be replaced every six months
or earlier if the flow of water to the water dispenser or
icemaker decreases.
Removing the Filter Cartridge
If you are replacing the cartridge, first remove the old
one by slowly turning it to the left. Do not pull down
on the cartridge. A small amount of water may drip down.
Installing the Filter Cartridge
If you are replacing a SmartWater cartridge with
an adapter, it must be removed before installing
the cartridge. To remove the adapter, turn it
to the left about 1/4 turn.
On models without a replacement indicator light,
apply the month and year sticker to the new cartridge
to remind you to replace the filter in six months.
Fill the replacement cartridge with water from the tap to
allow for better flow from the dispenser immediately after
installation.
Line up the arrow on the cartridge and the cartridge
holder. Place the top of the new cartridge up inside the
holder. Do not push it up into the holder.
Slowly turn it to the right until the filter cartridge stops.
DO NOT OVERTIGHTEN. As you turn the cartridge, it will
automatically raise itself into position. The cartridge will
move about 1/2 turn.
Run water from the dispenser for 3 minutes (about 1-1/2
gallons) to clear the system and prevent sputtering.
Press and hold the WATER FILTER pad (on some models)
on the dispenser for 3 seconds.
NOTE: A newly installed water filter cartridge may cause
water to spurt from the dispenser.
Filter Bypass Plug
You must use the filter bypass plug when a replacement filter
cartridge is not available. The dispenser and the icemaker will
not operate without the filter or filter bypass plug.
If you have questions—visit our Website at GEAppliances.com,
or call 1.800.GE.CARES (1.800.432.2737).
Replacement filters:
To order additional filter cartridges in the United States,
visit our Website at GEAppliances.com, or call GE Parts and
Accessories, 800.626.2002.
Filter Model MWF
Customers in Canada should consult the yellow pages
for the nearest Mabe Service Center.
(appearance may vary)
Cartridge
Holder
Filter
Bypass
Plug
SmartWater
With Adapter Without Adapter

7
Consumer SupportTroubleshooting TipsOperating Instructions
Safety Instructions Installation
Instructions
About the shelves and bins. GEAppliances.com
Refrigerator Door Bins and Freezer Door Tilt-Out Bins
Large Bins
The larger refrigerator door bins and freezer
tilt-out door bins are adjustable.
To remove: Lift the front of the bin straight
up, then lift up and out.
To replace or relocate: Engage the back side
of the bin in the molded supports of the door.
Then push down on the front of the bin. Bin
will lock in place.
Small Bins
To remove: Lift the front of the bin straight up
then out.
To replace: Position the bin above the
rectangular molded supports on the door.
Then slide the bin down onto the support
to lock it in place.
The snugger helps prevent tipping, spilling
or sliding of small items stored on the door
shelf. Place a finger on either side of the
snugger near the rear and move it back
and forth to fit your needs.
CAUTION:
On models with an
ice chute inside the
top freezer door bin,
be careful when
placing items in the
bin. Make sure that
items do not block
or fall into the ice
chute.
Not all features are on all models.
Refrigerator bin
Freezer tilt-out bin
Snugger
Freezer bin
Slide-Out Spillproof Shelf
The slide-out spillproof shelf allows you
to reach items stored behind others. The
special edges are designed to help prevent
spills from dripping to lower shelves.
To remove:
Slide the shelf out until it reaches the stop,
then press down on the tab and slide the shelf
straight out.
Press tab and pull shelf forward to
remove
To replace or relocate:
Line the shelf up with the supports and slide
it into place. The shelf can be repositioned
when the door is at 90° or more. To reposition
the shelf, slide the shelf past the stops and
angle downward. Slide shelf down to the
desired position, line up with the supports
and slide into place.
Make sure you push the shelves all the way
back in before you close the door.
Do not block

8
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions
Installation
Instructions
This rack holds up to 5 cans or one bottle
of wine.
The rack hangs from the sides
of the dairy bin.
To remove:
Empty the wine/beverage rack.
Holding the bottom of the dairy bin,
lift the front straight up, then lift up
and out.
To detach the rack from the dairy bin,
pull the rack’s side wires out of the holes
on each side of the dairy bin.
To replace:
Reattach the rack to the sides of the bin.
Engage the back side of the bin in
the molded supports on the door.
Then push down on the front of
the bin. The bin will lock into place.
About the shelves and bins. (cont.)
Not all features are on all models.
QuickSpace™Shelf (on some models)
This shelf splits in half and slides under itself
for storage of tall items on the shelf below.
This shelf can be removed and replaced
or relocated just like Slide-Out Spillproof
Shelves.
On some models, this shelf can not be used
in the lowest position.
Slide-Out Freezer Shelves
To remove, slide out to the stop position,
lift the front past the stop position, and slide
out from rib.
Make sure you push the shelves all the way
back in before you close the door.
Freezer Baskets
To remove, slide out to the stop position,
lift the front past the stop position, and
slide out.
Make sure you push the baskets all the
way back in before you close the door.
Fixed Freezer Shelves
To remove, lift the shelf up at the left side and
then bring the shelf out.
NOTE FOR DISPENSER MODELS: In order
to take full advantage of the tilt-out ice bin
(on some models), only store items on the
shelf below the ice bin that are no taller
than the lowest point on the bin.
Door Wine/Beverage Rack (on some models)
To remove, push the basket all the way to
the back of the freezer. Lift up until the back
pins are disengaged. Lift the entire basket
up and pull out.
Make sure you push the baskets all the
way back in before you close the door.

9
Consumer SupportTroubleshooting Tips
Operating Instructions
Safety Instructions Installation
Instructions
About the refrigerator doors. GEAppliances.com
Refrigerator Doors
The refrigerator doors may feel different
than the ones you are used to. The special
door opening/closing feature makes sure
the doors close all the way and are
securely sealed.
When opening and closing the door, you
will notice a stop position. If the door is
opened past this stop point, the door will
remain open to allow you to load and
unload food more easily. When the door
is only partially open, it will automatically
close.
The resistance you feel at the stop
position will be reduced as the door
is loaded with food.
When the door is only partially open,
it will automatically close.
Beyond this stop the door will
stay open.
Door Alignment
If doors are uneven, adjust the refrigerator
door.
Using a 7/16″socket wrench, turn the
door adjusting screw to the right to
raise the door; to the left, to lower it.
(A nylon plug, imbedded in the threads
of the pin, prevents the pin from
turning unless a wrench is used.)
After one or two turns of the wrench,
open and close the refrigerator door
and check the alignment at the top
of the doors.
To remove the base
grille, open the doors,
remove the screw at
each end of the base
grille and then pull
the grille straight out.
7/16″Socket Wrench
Raise

Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions
Installation
Instructions
10
About crisper removal.
Not all features are on all models.
Crisper Removal
Crispers can easily be removed by pulling the
drawer straight out and lifting the drawer up
and over the stop location.
If the door prevents you from taking out
the drawers, first try to remove the door bins.
If this does not offer enough clearance, the
refrigerator will need to be rolled forward
until the door opens enough to slide the
drawers out. In some cases, when you roll
the refrigerator out, you will need to move
the refrigerator to the left or right as you roll
it out.
About the crispers and pans.
Not all features are on all models.
Fruit and Vegetable Crispers
Excess water that may accumulate in the
bottom of the drawers should be wiped dry.
On some models, the bottom drawer has
full extension slides that allow full access
to the drawer.
Adjustable Humidity Crispers
Slide the control all the way to the HI setting
to provide high humidity recommended for
most vegetables.
Slide the control all the way to the LO
setting to provide lower humidity levels
recommended for most fruits.
HI LO
Convertible Deli Pan (on some models)
The convertible deli pan has its own cold air
duct to allow a stream of cold air from the
freezer compartment or refrigerator
compartment to flow to the pan.
The variable temperature control regulates
the air flow from the Climate Keeper Air
Tower.
Set the control to the coldest setting to store
fresh meats.
Set the control to cold to convert the pan
to normal refrigerator temperature and
provide extra vegetable storage space. The
cold air duct is turned off. Variable settings
between these extremes can be selected.
C
O
L
D
C
O
L
D
E
S
T

Consumer SupportTroubleshooting TipsOperating Instructions
Safety Instructions Installation
Instructions
11
About the automatic icemaker. GEAppliances.com
Automatic Icemaker
The icemaker will produce seven cubes
per cycle—approximately 100–130 cubes
in a 24-hour period, depending on freezer
compartment temperature, room
temperature, number of door openings
and other use conditions.
See below for how to access ice and reach
the power switch on dispenser models.
If the refrigerator is operated before the
water connection is made to the icemaker,
set the power switch in the O (off) position.
When the refrigerator has been connected to
the water supply, set the power switch to the
l (on) position.
The icemaker will fill with water when it cools
to 15°F (–10°C). A newly installed refrigerator
may take 12 to 24 hours to begin making ice
cubes.
You will hear a buzzing sound each time
the icemaker fills with water.
Throw away the first few batches of ice to
allow the water line to clear.
Be sure nothing interferes with the sweep
of the feeler arm.
When the bin fills to the level of the feeler
arm, the icemaker will stop producing ice.
It is normal for several cubes to be joined
together.
If ice is not used frequently, old ice cubes
will become cloudy, taste stale and shrink.
NOTE: In homes with lower-than-average
water pressure, you may hear the icemaker
cycle multiple times when making one batch
of ice.
A newly installed refrigerator may take 12 to 24 hours to begin making ice.
Lift the bin, then pull it
forward until the bin stops.
Icemaker
Feeler Arm
Power
Switch
Green
Power Light
Lower the bin to access ice
or reach the power switch.
NOTE: In order to take full
advantage of the tilt-out ice bin,
only store items on the shelf below
the ice bin that are no taller than
the lowest point on the bin.
Models without a shelf
above the ice bin
To access ice and reach the
icemaker power switch:
Accessing Ice and Reaching
the Power Switch on Dispenser
Models
There are two types of ice storage bins
on dispenser models. One has a shelf above
the bin, the other does not.
Special note about dispenser models
without a shelf above the ice bin:
■These models have a tilt-out ice bin.
The bin can be tilted out as shown in
the illustrations, and it will hold itself
up while you take ice out or turn the
icemaker power switch on and off.
Be sure to put the bin back in place
before closing the door.
■To restore your ice level from an empty
bucket stage, the following steps are
recommended:
12 hours after the first batch of ice
has fallen into the bin, dispense
3 to 4 cubes.
After an additional 6 hours, dispense
3 to 4 cubes again.
These steps will restore your ice level
in the shortest amount of time.
To access ice, pull the bin forward.
To reach the power switch, pull the
shelf straight out. Always be sure to
replace the shelf.
Models with a shelf
above the ice bin
Shelf
Ice Bin
Shelf
Ice Bin

12
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions
Installation
Instructions
About the ice and water dispenser. (on some models)
To Use the Dispenser
Select CUBED ICE , CRUSHED ICE
or WATER .
Press the glass gently against the top of the
dispenser cradle.
The spill shelf is not self-draining. To reduce
water spotting, the shelf and its grille should
be cleaned regularly.
If no water is dispensed when the
refrigerator is first installed, there may
be air in the water line system. Press the
dispenser arm for at least two minutes to
remove trapped air from the water line
and to fill the water system. To flush out
impurities in the water line, throw away
the first six glassfuls of water.
CAUTION: Never put fingers or any other
objects into the ice crusher discharge
opening.
Locking the Dispenser
Press the Lock Controls
pad for 3 seconds to lock
the dispenser and control
panel. To unlock, press
and hold the pad again
for 3 seconds.
Dispenser Light
This pad turns the night
light in the dispenser on
and off. The light also
comes on when the
dispenser cradle is
pressed. If this light burns
out, it should be replaced
with a 6 watt 12V
maximum bulb.
Door Alarm (on some models)
To set the alarm,
press this pad until the
indicator light comes on.
This alarm will sound if
either door is open for
more than 3 minutes.
The light goes out and
the beeping stops when
you close the door.
Spill Shelf
Important Facts About Your Dispenser
■Do not add ice from trays or bags to
the storage drawer. It may not crush or
dispense well.
■Avoid overfilling glass with ice and use
of narrow glasses. Backed-up ice can jam
the chute or cause the door in the chute to
freeze shut. If ice is blocking the chute, poke
it through with a wooden spoon.
■Beverages and foods should not be
quick-chilled in the ice storage drawer.
Cans, bottles or food packages in the
storage drawer may cause the icemaker
or auger to jam.
■To keep dispensed ice from missing
the glass, put the glass close to, but not
touching, the dispenser opening.
■Some crushed ice may be dispensed
even though you selected CUBED ICE. This
happens occasionally when a few cubes
accidentally get directed to the crusher.
■After crushed ice is dispensed, some water
may drip from the chute.
■Sometimes a small mound of snow will
form on the door in the ice chute. This
condition is normal and usually occurs
when you have dispensed crushed ice
repeatedly. The snow will eventually
evaporate.

Consumer SupportTroubleshooting TipsOperating Instructions
Safety Instructions Installation
Instructions
Care and cleaning of the refrigerator.
Cleaning the Outside
The dispenser drip area (on some models),
beneath the grille, should be wiped dry. Water
left in this area may leave deposits. Remove
the deposits by adding undiluted vinegar to
the well. Soak until the deposits disappear
or become loose enough to rinse away.
The dispenser cradle (on some models).
Before cleaning, lock the dispenser by
pressing and holding the Lock Controls pad
for 3 seconds. Clean with warm water and
baking soda solution – about a tablespoon
(15 ml) of baking soda to a quart (1 liter)
of water. Rinse thoroughly and wipe dry.
The door handles and trim. Clean with
a cloth dampened with soapy water.
Dry with a soft cloth.
Keep the outside clean. Wipe with a
clean cloth lightly dampened with kitchen
appliance wax or mild liquid dish detergent.
Dry and polish with a clean, soft cloth.
Do not wipe the refrigerator with a soiled
dish cloth or wet towel. These may leave
a residue that can erode the paint. Do not
use scouring pads, powdered cleaners,
bleach or cleaners containing bleach
because these products can scratch
and weaken the paint finish.
Cleaning the Inside
To help prevent odors, leave an open box
of baking soda in the fresh food and freezer
compartments.
Unplug the refrigerator before cleaning.
If this is not practical, wring excess moisture
out of sponge or cloth when cleaning around
switches, lights or controls.
Use warm water and baking soda solution –
about a tablespoon (15 ml) of baking soda to
a quart (1 liter) of water. This both cleans and
neutralizes odors. Rinse and wipe dry.
Use of any cleaning solution other than
that which is recommended, especially
those that contain petroleum distillates,
can crack or damage the interior of the
refrigerator.
Avoid cleaning cold glass shelves with hot
water because the extreme temperature
difference may cause them to break.
Handle glass shelves carefully. Bumping
tempered glass can cause it to shatter.
Do not wash any plastic refrigerator
parts in the dishwasher.
Dispenser drip area
GEAppliances.com
Lift the bin, then pull it
forward until the bin stops.
Lift and pull forward again
to remove the bin.
Models without a shelf
above the ice bin
To remove:
Models with a shelf
above the ice bin
To remove:
Removing and Replacing the Ice
Storage Bin on Dispenser Models
There are two types of ice storage bins on
dispenser models. One has a shelf above
the bin, the other does not.
Always set the icemaker power switch to the
O (off) position before removing the ice bin.
When replacing either type of ice bin:
Always be sure to press it firmly into place.
If it does not go all the way back, remove it
and rotate the drive mechanism 1/4 turn.
Then push the bin back again.
Pull the bin straight out, then lift
past the stop position.
Rotate
Drive
Mechanism
13

14
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions
Installation
Instructions
For long vacations or absences, remove
food and unplug the refrigerator. Clean the
interior with a baking soda solution of one
tablespoon (15 ml) of baking soda to one
quart (1 liter) of water. Leave the doors open.
Set the icemaker power switch to the
O (off) position and shut off the water
supply to the refrigerator.
If the temperature can drop below freezing,
have a qualified servicer drain the water
supply system (on some models) to prevent
serious property damage due to flooding.
Care and cleaning of the refrigerator. (cont.)
Behind the Refrigerator
Be careful when moving the refrigerator
away from the wall. All types of floor
coverings can be damaged, particularly
cushioned coverings and those with
embossed surfaces.
Pull the refrigerator straight out and
return it to position by pushing it straight
in. Moving the refrigerator in a side direction
may result in damage to the floor covering
or refrigerator.
When pushing the refrigerator back, make
sure you don’t roll over the power cord or
icemaker supply line (on some models).
Preparing for Vacation
Preparing to Move
Secure all loose items such as shelves and
drawers by taping them securely in place
to prevent damage.
When using a hand truck to move the
refrigerator, do not rest the front or back
of the refrigerator against the hand truck.
This could damage the refrigerator. Handle
only from the sides of the refrigerator.
Be sure the refrigerator stays in an upright
position during moving.

15
Replacing the light bulbs. GEAppliances.com
NOTE: Turning the refrigerator off via the controls on the touch panel does not shut off electrical power to
the refrigerator.
Refrigerator Compartment—Upper Light
Unplug the refrigerator.
The bulbs are located at the top of
the compartment, inside the light shield.
On some models, a screw at the front of
the light shield will have to be removed.
On other models, the screw is located
in the pocket located at the back of
the shield.
To remove the light shield, on some
models, press in on the tabs on the sides
of the shield and slide forward and out.
On other models, just slide the shield
forward and out.
After replacing the bulb with an appliance
bulb of the same or lower wattage,
replace the light shield and screw. When
replacing the light shield, make sure that
the tabs at the back of the shield fit into
the slots at the back of the light shield
housing.
Plug the refrigerator back in.
Refrigerator Compartment—Lower Light
This light is located above the top drawer.
Unplug the refrigerator.
Lift the light shield up and pull it out.
After replacing the bulb with an appliance
bulb of the same or lower wattage,
replace the shield.
Plug the refrigerator back in.
Freezer Compartment
Unplug the refrigerator.
Remove the shelf just above the light
shield. (The shelf will be easier to remove
if it is emptied first.) Remove the screw at
the top of the light shield.
To remove the light shield, press in on the
sides, and lift up and out.
Replace the bulb with an appliance
bulb of the same or lower wattage,
and reinstall the light shield. When
reinstalling the light shield, make sure
the top tabs snap securely into place.
Replace the screw.
Reinstall the shelf and plug the
refrigerator back in.
Dispenser
Unplug the refrigerator.
The bulb is located on the dispenser
under the control panel. Remove the light
bulb by turning it counterclockwise.
Replace the bulb with a bulb
of the same size and wattage.
Plug the refrigerator back in.
Tabs
Your light shield will look like one
of the following:
Pocket
OR
Refrigerator Compartment (on some models)
There is an LED lighting display in the top
of the refrigerator compartment on some
models. If this assembly needs to be
replaced, call GE Service at 1.800.432.2737
in the United States or 1.800.561.3344
in Canada.
LED
Lighting
Display
Consumer SupportTroubleshooting Tips
Operating Instructions
Safety Instructions Installation
Instructions

16
BEFORE YOU BEGIN
Read these instructions completely
and carefully.
•IMPORTANT —Save these instructions
for local inspector’s use.
•IMPORTANT —Observe all governing
codes and ordinances.
• Note to Installer – Be sure to leave these
instructions with the Consumer.
• Note to Consumer – Keep these instructions
for future reference.
• Skill level – Installation of this appliance requires
basic mechanical skills.
• Completion time – Refrigerator Installation
30 minutes
Water Line Installation
30 minutes
•Proper installation is the responsibility of
the installer.
•Product failure due to improper installation is not
covered under the Warranty.
If the refrigerator has already been installed,
remove the base grille (see Step 2 in Moving
the Refrigerator), then skip to Step 5 in Installing
the Refrigerator.
Questions? Call 800.GE.CARES (800.432.2737) or Visit our Website at: GEAppliances.com
In Canada, call 1.800.561.3344 or Visit our Website at: www.GEAppliances.ca
Installation Refrigerator
Instructions Models 22, 23, 25, 26, 27 and 29
If the refrigerator has an icemaker, it will have
to be connected to a cold water line. A GE water
supply kit (containing tubing, shutoff valve,
fittings and instructions) is available at extra
cost from your dealer, by visiting our Website
at GEAppliances.com (in Canada at
www.GEAppliances.ca) or from Parts and
Accessories, 800.626.2002 (in Canada
1.888.261.3055).
PREPARATION
WATER SUPPLY TO THE ICEMAKER
TOOLS YOU WILL NEED
Phillips-Head Screwdriver
3/8″and 5/16″Socket 1/2″and 7/16″Wrench
Plastic Putty Knife

17
Installation Instructions
LOADING THE RERIGERATOR
ONTO A HAND TRUCK
Leave all tape and door pads on doors until
the refrigerator is in its final location.
To move the refrigerator, use a padded hand
truck. Center the refrigerator on the hand truck
and secure the strap around the refrigerator.
DO NOT OVERTIGHTEN THE STRAP.
1
REMOVE THE BASE GRILLE
Remove the grille by removing the two Phillips
head screws.
2
If the refrigerator must go through
any entrance that is less than 38″wide,
the doors must be removed. Proceed to
Step 3.
DO NOT remove the handles.
If all entrances are more than 38″wide,
skip to Installing the Refrigerator.
DISCONNECT THE WATER COUPLING
(on some models)
If the refrigerator has a water dispenser,
there is a water line from the cabinet into
the bottom hinge on the freezer door that
must be disconnected.
To disconnect, push in on the white collar
of the coupling and pull out the tubing.
3
White collar
Bottom
freezer
hinge
MOVING THE REFRIGERATOR

18
Installation Instructions
DISCONNECT THE POWER COUPLING
(on some models)
If the refrigerator has a water dispenser,
there is a power line (harness) from the cabinet
into the bottom hinge on the freezer door that
must be disconnected.
To disconnect, pull apart at the coupling.
4
Bottom
freezer
hinge
DISCONNECT THE ELECTRICAL
CONNECTORS (on some models)
If the refrigerator has a refreshment center,
there are electrical connectors (harnesses)
from the cabinet into the bottom hinge on the
refrigerator door that must be disconnected.
To disconnect, pull apart each connector.
5
Bottom
refrigerator
hinge
CLOSE THE FREEZER AND
REFRIGERATOR DOORS
6
REMOVE THE FREEZER DOOR
Remove the freezer door top hinge cover by
either squeezing it and pulling it up or by
prying it off with a plastic putty knife.
Remove the two 5/16″hex head screws, then
lift the hinge straight up to free the hinge pin.
Open the freezer door to 90.°
7
A
C
B
5/16″Hex Head
90°
MOVING THE REFRIGERATOR (CONT.)

19
Installation Instructions
REMOVE THE FREEZER DOOR (cont.)
As one person slowly lifts the freezer door up
and off the bottom hinge, the second person
should carefully guide the water line and power
line (harness) through the bottom hinge.
Set the door on a non-scratching surface with
the inside up.
7
D
E
90°
REMOVE THE REFRIGERATOR DOOR
Remove the refrigerator door top hinge cover
by either squeezing it and pulling it up or by
prying it off with a plastic putty knife.
8
A
REMOVE THE REFRIGERATOR DOOR
(cont.)
Remove the two 5/16″hex head screws, then
lift the hinge straight up to free the hinge pin.
Open the refrigerator door to 90.°
8
B
C
5/16″Hex Head
90°

20
Installation Instructions
REMOVE THE REFRIGERATOR DOOR
(cont.)
Lift the refrigerator door up and off the bottom
hinge.
If the refrigerator has a refreshment center,
one person should slowly lift the door up and
off the bottom hinge and the second person
should carefully guide the electrical lines
(harnesses) through the bottom hinge.
Set the door on a non-scratching surface with
the inside up.
8
D
E
90°
REPLACING THE DOORS
To replace the doors, simply reverse steps 3
through 8.
However, please note the following:
• When lowering the doors onto the bottom
hinges, make sure the second person
carefully guides the tube and harnesses
through the holes in the hinges.
• When connecting the water line, make sure
you insert the tubing all the way to the mark.
• Do not pinch the tubing and harnesses when
placing the doors on the bottom hinges.
• When connecting the power line and the
electrical lines (refreshment center models
only), be sure that the connectors are seated
together fully.
9
Mark
Refreshment Center Models only
MOVING THE REFRIGERATOR (CONT.)
