GE cafe Operating instructions

GEAppliances.com
GD
N
dD
GD
t__
LL
E
0
0
0
|
m_L
I
Safety Instructions ............ 2-4
Operating Instructions
Features .......................... 5, 6
Controls .......................... 7, 8
Odor Remover ...................... 9
Dispenser .......................... 10
Hot Water ......................... 11
Water Filter ........................ 12
Fresh Food Storage Options ..... 13,14
Climate Zone & Temperature
Controlled Drawer ............... 15,16
Freezer ............................ 17
Automatic Ice maker ............... 18
Care and Cleaning ................ 19
Replacing the Lights ................ 20
Installation Instructions
Preparing to Install the
Refrigerator .................... 21, 22
Installing the Anti-Tip Bracket... 29, 30
Installing the Refrigerator ....... 23-33
Installing the Water Line ........ 34-35
Troubleshooting Tips ...... 38, 39
Normal Operating Conditions ....... 37
Service - Truth or Myth ......... 40, 41
Consumer Support
GE Brillion TM Get Connected
Starter Kit ........................ 42
Warranty for U.S.Customers ........ 43
RPWF Water Filter Cartridge Limited
Device Certificate ................. 44
Performance Data Sheet ........... 45
State of California Water Treatment
Warranty .......................... 46
Consumer Support ........ Back Cover
Write the model and serial
numbers here:
Model #
Serial #
Find these numbers on a label
on the left side, near the middle
of the refrigerator compartment,
GECareTM models
Models that stuart w/th CFE are
StandardDepth Models (SD)
Models that start w/th CYEare
CounterDepth Models (CD)
239D3389PO03 Pub No. 4,9-60678 72- 72 GE

IMPORTANT SAFETYINFORMATION.
READALL INSTRUCTIONSBEFOREUSING.
IMPORTANT SAFETY INFORMATION READ ALL INSTRUCTIONS BEFORE USING
GEApp//ances webs/te
For more information on your refrigerator_ operation, visit
........www,GEAppliances.com
1
REFRIGERATOR SAFETYINFORMATION
_This is the safety alert symbol, This symbol alerts you to potential hazards that can kill or hurt you and others, All safety
_nessages will follow the safety alert symbol and the word "DANGER", "WARNING", or "CAUTION", These words are defined as:
Indicates a hazardous situation which, if not avoided, will result in death or serious injury,
Indicates a hazardous situation which, if not avoided, could result in death or serious injury,
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury,
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of fire, explosion, electric shock, or injury when using your
refrigerator follow these basic safety precautions:
This refrigerator must be properly installed and located in
accordance with the Installation Instructions before it is
used,
Unplug the refrigerator before cleaning and making repairs,
NOTE: Repairs must be performed by a qualified Service
Professional,
, Replace all parts and panels before operating,
, Because of potential safety hazards under certain
conditions, we strongly recommend against the use of an
extension cord, However, if you must use an extension cord,
it is absolutely necessary that it be a UL-listed (in the United
States) or a CSAcertified (in Canada), 3-wire grounding type
appliance extension cord having a grounding type plug
and outlet and that the electrical rating of the cord be 15
amperes (minimum) and 120 volts,
, To prevent suffocation and entrapment hazards to children,
Remove the fresh food and freezer doors from any
refrigerator before disposing of it or discontinuing its use,
, Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance,
, Power to the refrigerator cannot be disconnected by
any setting on the control panel, refrigerator must be
unplugged to remove power,
Do not allow children to climb, stand or hang on the door
handles or the shelves in the refrigerator, They could
seriously injure themselves,
, In refrigerators with automatic ice makers, avoid contact
with the moving parts of the ejector mechanism, or with
the heating element that releases the cubes, Do not place
fingers or hands on the automatic ice making mechanism
while the refrigerator is plugged in,
, Do not clean glass shelves or covers with warm water
when they are cold, Glass shelves and covers may break if
exposed to sudden temperature changes or impact, such
as bumping or dropping, Tempered glass is designed to
shatter into many small pieces if it breaks,
, Keep fingers out of the "pinch point" areas; clearances
between the doors and between the doors and cabinet are
necessarily small, Be careful closing doors when children are
in the area,
, Do not touch the cold surfaces in the freezer compartment
when hands are damp or wet,, skin may stick to these
extremely cold surfaces,
, Do not refreeze frozen foods which have thawed completely,
, Use a sturdy glass when dispensing ice (on models with ice
dispenser)

IMPORTANT SAFETYINFORMATION.
READALL INSTRUCTIONSBEFOREUSING. GEAppliances.com
INSTALLATION
'_ Explosion Hazard.
Keep flammable materials and vapors, such as gasoline, away from refrigerator.
result in fire, explosion, or death.
Failure to do so can
_1_/_ Tip Over Hazard.
Built-in style models (model PYE, CYE, and PWE) are top heavy, especially with any doors open. These
models must be secured with the anti-tip floor bracket to prevent tipping forward, which could result
in death or serious injury. Read and follow the entire installation instructions for installing the anti-tip
floor bracket packed with your refrigerator.
CONNECTING ELECTRICITY
Electrical Shock Hazard.
Plug into a grounded 3-prong outlet
Do not remove the ground prong
IDo not use an adapter
lFailure to follow these instructions can result in death, fire, or electrical shock.
Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
For personal safety, this appliance must be properly grounded.
The power cord of this appliance is equipped with a 3-prong
(grounding) plug which mates with a standard 3-prong
(grounding) wall outlet to minimize the possibility of electric
shock hazard from this appliance,
Have the wall outlet and circuit checked by a qualified
electrician to make sure the outlet is properly grounded,
Where a standard 2-prong wall outlet is encountered, it is
your personal responsibility and obligation to have it replaced
with a properly grounded 3-prong wall outlet, Do not use an
adapter,
The refrigerator should always be plugged into its own
individual electrical outlet which has a voltage rating that
matches the rating plate,
A 115 Volt AC, 60 Hz, 15- or 20-amp fused, grounded
electrical supply is required, This provides the best
performance and also prevents overloading house wiring
circuits which could cause a fire hazard from overheated
wires,
Never unplug your refrigerator by pulling on the power cord,
Always grip plug firmly and pull straight out from the outlet,
Repair or replace immediately all power cords that have
become frayed or otherwise damaged, Do not use a cord
that shows cracks or abrasion damage along its length or at
either end,
When moving the refrigerator away from the wall, be careful
not to roll over or damage the power cord,

IMPORTANT SAFETYINFORMATION.
READALL INSTRUCTIONSBEFOREUSING.
HOT WATER DISPENSER
A Scalding Hazard.
The hot water dispenser is capable of heating water to a temperature of approximately 185°F (85°C).
Water temperatures above 125°F (52°C) can cause severe burns or death from scalding. Children, the
disabled, and the elderly are at highest risk of being scalded.
Use this appliance only for its intended purpose as described in this Owner's Manual, To reduce the risk of severe burns,
scald injuries, or death when using your hot water dispenser, the instructions below must be followed:
, The water coming from the dispenser is very hot, Use
extreme caution when dispensing and drinking water, Allow
water to cool to a drinkable temperature before drinking,
, When dispensing water below 125°F, always test the
temperature of the water before drinking,
, When dispensing hot water, the container can become
very hot, Use a temperature insulating container, such
as ceramic or Styrofoam, Using container materials such
as paper or plastic may result in a burn while holding the
cup, Do not use glass containers, as thermal shock can
cause the container to break and may result in scalding or
lacerations,
, Do not permit children to use the hot water dispenser,
, The hot water dispensing knob requires both twist and
push motions in order to reduce the risk of hot water being
dispensed unintentionally or by small children, Do not
tamper with or modify the hot water dispensing knob,
, Always follow the formula manufacturer's instructions for
preparation of baby formula,
, Hold your cup or container close to the dispensing point to
minimize splashing of hot water that could contact your
hand, Do not dispense hot water into a cup resting on the
dispenser tray, as this will increase water splash,
, Do not use with water that is microbiologically unsafe or of
unknown quality,
, The hot water dispenser is designed to only dispense water,
Do not attempt to heat or dispense anything other than
water, Do not attempt to disassemble or clean the tank,
, A newly installed water filter cartridge will cause water to
spurt from the dispenser, Run 2 gallons of water through
the cold water dispenser (about 5 minutes) to remove air
from the system, Until this air is removed from the system
through the cold water dispenser, DO NOT use the hot water
dispenser as it may result in spurting of hot water and lead
to hot water scalding,
, The hot water dispensing tank is a non-pressurized tank,
with a vent on the tank and a dispenser tube outlet, Do
not modify the system, close or block the dispense tube, or
connect any other type of device to the tank or dispense
tube, Doing so may lead to rupture of the tank and hot
water scalding,
PROPER DISPOSAL OF YOUR OLD REFRIGERATOR
Suffocation and child entrapment hazard.
Remove fresh-food and freezer doors from the refrigerator, prior to disposal. Failure to do so can result
in child entrapment which can lead to death or brain damage.
IMPORTANT: Child entrapment and suffocation are not problems of the past.
,Junked or abandoned refrigerators are still dangerous even if
they will sit for 'lust a few days." If you are getting rid of your old
refrigerator, please follow the instructions below to help prevent
accidents,
Before You Throw Away Your Old Refrigerator or
Freezer:
' Take off the fresh food and freezer doors.
' Leave the shelves in place so that children may not easily
climb inside.
Refrigerants
All refrigeration products contain refrigerants, which under
federal law must be removed prior to product disposal. If you
are getting rid of an old refrigeration product, check with the
company handling the disposal about what to do.
READAND FOLLOWTHISSAFETYIAIFORMAT/ONCAREFULLX
SAVETHESEINSTRUCTIONS

About the features. GEApplia.cescom
0
0
0
O
Space-saving ice maker
Ice maker and bin are located on the door creating more usable
storage space.
Showcase LED lighting
LED lighting is positioned throughout the interior to spotlight areas
in the refrigerator. LEDs are located under the fresh food door to
light the freezer when opened.
Drop-down tray
Allows for extra door storage when you need it and tucks away
when you don't.
Full-width temperature controlled drawer
Adjustable temperature control bin that can accommodate
larger items.
Dairy bin
Separate compartment for your items,
Utility bin
A utility bin designed for flexible storage,
0 QuickSpaceTM shelf
Functions as a normal full-sized shelf when needed and easily slides
back to store tall items below.
O Spillproof shelves
Designed to capture your spills for easier clean up.
O Removable condiment bin
Separate bin designed for easy removal and storage.
Removable door bin
Can be removed for those with a wall limiting the door opening,
Climate zone bin
Separate bins for produce storage.
_ In-the-door filter
Located in the door for more available space in the fresh-food section
and easy replacement.
_I Odor filter
Removes food smells and odors.

About the features.
O
O
O
Door ice bin
1. Open left fresh food door.
2. Pull down latch to release bin door.
3. Using handhold lift ice bucket up
and out to clear Iocators in bottom of bin.
4. To replace the ice bucket, set it on the
guide brackets and push until the ice
bucket seats properly.
5. If bucket cannot be replaced, rotate the
Ice Bucket Fork 1/4 turn clockwise.
Drop down dairy bin
1. Open right fresh food door.
2. Depress both buttons on lower sides and
bin will drop down.
3. Reverse to reinstall.
Door ice/water filter
Remove filter/bypass plug
Push the indent on the cover and open filter
door. Pull up on filter/bypass plug and pull
straight out to remove.
Installing the filter cartridge
Push the indent at the bottom of the cover
and open. Lift door and align tabs on filter
to filter/holder and push filter into place.
Filter cover is designed to be
reinstalled if accidently removed
Ice bucket
Push/Pull
Swing
Do not twist
O
Water & Ice Filter (in door)
Drop tray
(tray open)

About the controls with temperature settin s. GEAppliancescom
CYE/CFE Control Style
Water
Changing the Temperature
To Change the Refrigerator Tem_re:
Access By: Temperature Button |
Activate By: Below the word "Refrigerator", use the
arrows to select the desired temperature, Press DONEwhen
finished to return to HOME screen,
To Change the Freezer Temperature:
Access By: Temperature Button |
Activate By: Below the word "Freezer", use the arrows to
select the desired temperature,
Press DONEwhen finished to return to HOME screen,
To turn OFF cooling system, access SETTINGS from the
HOME screen, Page over and tap COOLING SYSTEM ON
Press DONEto return to HOME screen,
To turn ONcooling system, access SETT/NGSfrom the HOME
screen, Page over and tap COOLING SYSTEM OFF, Press
DONE to return to HOME screen,
Turning the cooling system off stops the cooling to
refrigerator, but it does not shut off the electrical power,
NOTE: For optimal temperature performance, we recommend to avoid placing food or other items directly at the air
flow vents or the fresh food air tower, thus blocking the air flow.

About the controls features.
lemperatue IExpressModes ISettngs
Water
NOTE;The refrigerator is shipped with protective film covering the temperature
controls, If this film was not removed during installation, remove it now,
The temperature controls are preset in the factory at 37°F for the refrigerator compartment and O°Ffor the freezer
compartment, Allow 24 hours for the temperature to stabilize to the preset recommended settings,
The temperature controls can display both the SETtemperature as well as the actual temperature in the refrigerator and
freezer, The actual temperature may vary slightly from the SET temperature based on usage and operating environment,
Hot Water
Dispenses up to 10 ounces of filtered hot water from user
selected ranges of 90°F to 185°F,
Hot Water Knob
Illuminates to indicate hot water is ready, Dispenses with two
motions: a counter-clockwise twist and then push to dispense,
Precise Fill
Precisely dispenses filtered water in accurate measurements
in ounces, cups, quarts, or liters using paddle,
Refrigerator temp control
Adjust freezer compartment temperature,
Fresh food temp control
Adjust fresh food compartment temperature,
TurboFreeze TM setting
Activate TurboFreeze to quickly restore freezer
temperatures after frequent door openings,
TurboCool TM setting
Activate TurboCool to quickly restore fresh food temperature after
frequent door openings,
Odor Remover setting
Activate Odor Remove to remove food smells and odors.
Lock controls
Press and hold 3 seconds to lock out ice and water dispenser
and all feature and temperature buttons,
LED dispenser light
LEDlighting that can be turned on/off to light your dispenser,
Photo Upload
Insert USB memory stick to upload personal photos to the
refrigerator LCD screen, LCD will provide on screen prompts to
load and view slideshow,
Additionai Settings
• Connected Home ready
Slideshow
Reset filter
Ice maker on/off
Door alarm
Sound control
Cooling system On/OFF
Metric/English units
Additional Modes
Sabbath Mode
Press and hold lock & light simultaneously for 3 seconds to
enter/exit Sabbath mode,
Activate Sabbath Mode to turn off interior lights, tempera-
ture control and advanced features, Compressor will run on
a timed defrost when in Sabbath mode,

About Odor Remover. GEAppliances.com
Mode, press
Express Modes
on the main LCD
Using Odor Remover Mode
To access the
Odor Remover {Temperature Exp Modes.... Settings]
[lace: Odor Filter
Weter
screen, _ _
Press Odor Remover
to turn the mode On
or Off, Press Done
to return to the main
menu,
The mode will
automatically end
after 4 hours,
Express Modes
Install/Replace Odor Filter
The Odor Filter is located in the
upper left corner of the fresh food
compartment, GE recommends
replacement of the odor filter every
6 months or when odor becomes
objectionable, A reminder will
appear on the main screen after 6
months to change the filter,
Odor Filter
To Replace Filter:
Remove the cover of the odor m-_]_,
filter by sliding the front
portion towards the front of
the refrigerator,
Remove the old filter by
pulling out,
Remove the replacement
filter from the plastic, Insert
the filter into the housing by
pushing it in, The filter will
snap into place,
Replace filter cover by
sliding it on from the front, _--_
Make sure the front edge is
flush against the
refrigerator wall,
To Reset the Odor Filter Replacement reminder on the main
screen:
From the main screen on the LCD select Settings, Scroll until
Odor Filter is visible and press, This shows the current status of
the filter and how to reorder, To reset the reminder, press Reset,
Temperature I Express Hode_
Weter
System Settings
Odor Filter: Replace
To order a replacement filter, call (877]-959-8686
or order online via www.geapplianceparts.com.

About the dispenser.
k4
Water & Ice Dispenser
(See about the controls with
Temperature settings & about the
Control features)
_--(Dispenser
Tray
If no water is dispensed when the refrigerator is first installed,
there may be air in the water line system. Pressthe dispenser
paddle for at least five minutes to remove trapped air from the
water line and to fill the water system. To flush out impurities in
the water line, throw away the first six full glasses of water.
Hazard
, Never put fingers or any other object into ice crusher
discharge opening. Doing so can result in contacting the ice
crushing blades and lead to serious injury or amputation
, Use a sturdy glass when dispensing ice. A delicate glass may
break and result in personal injury.
Toremove Dispenser Tray
Pull Dispenser Tray out until it stops.
_ Locate tab in the center on the bottom and push in.
_ Pull Dispenser Tray assembly out.
_ Lift metal Dispenser Tray out at center notch to clean.
Toreinstall Dispenser Tray
_ Place the Dispenser Tray cover on top of catch tray and
position under the two plastic retainers on either side.
_ Center Dispenser tray, and align with center guides.
_ Push in until it firmly in place.
Important Facts About Your Dispenser
_ Do not add ice from trays or bags to the door ice maker
bucket. It may not crush or dispense.
_ Avoid overfilling glass with ice and use of narrow glasses.
Backed-up ice can jam the chute or cause the door in the
chute to freeze shut. If ice is blocking the chute remove the ice
bucket, poke it through with a wooden spoon.
_ Beverages and foods should not be quick-chilled in the
door ice maker bin. Cans, bottles or food packages in the
storage drawer may cause the ice maker or auger tojam.
_ To keep dispensed ice from missing the glass, put the glass
close to, but not touching, the dispenser opening.
_ Some crushed ice may be dispensed even though you
selected CUBED ICE.This happens occasionally when a few
cubes accidentally get directed to the crusher.
_ After crushed ice is dispensed, some water may drip from the
chute.
_ Sometimes a small mound of snow will form on the door in the
ice chute. This condition is normal and usually occurs when you
have dispensed crushed ice repeatedly. The snow will eventually
evaporate.
10

About Hot Water. GEAppliances.com
To Use Hot Water Dispenser
• Press HOTWATER button.
• Select desired water temperature on the LCDscreen (90, 150,
170, 185, or Custom).
• When hot water is ready (indicated on the screen and by a
beeping sound) hold container with left hand centered in the
recess under the spout,
• To dispense water, rotate the hot water knob counterclockwise
and then push it in,The knob must be held in during dispense,
Important Facts about HOTWATEl?
• _ Scalding Hazard.
Thewater coming from the dispenserisvery hot and can cause
scaldsor burns.Readall warnings prior to use.(Seepage 4.)
• Alwaysusea container that issuitable for hot liquids(ceramic,
styrofoam, etc.)
• Themaximum singlehotwater dispenseamount is10 oz.
Additional hotwater can be dispensedbyrestartingthe hot
water feature through the LCDscreen.
• HOTWATERworks bestwith householdwater pressureof40 to
1O0psi.
• HOTWATERwill time out ifunusedand may require a short
reheattime.
11

About the GE® RPWF water filter cartridge.
Water Filter Cartridge
The water filter cartridge islocated in one of the following places:
Bottom-freezer (BF)refrigerators:
- Inthe water filter compartment on the right side wall of the
left-hand fresh food door.
- Inthe fresh food interior on the left side wall, near the top.
When to replace the filter cartridge
The filter cartridge should be replaced every six months or earlier
if the flow of water to the dispenser or icemaker decreases.
Touch Screen Models: A filter status message will appear on the
screen when the water filter needs to be replaced. The filter status
message must be reset manually.
The "Water Filter: Replace" status message can be reset by
entering the Settings menu from the home screen. Then, select
the Water Filter menu and press the RESETbutton. This will reset
the filter status.
Non-touch Screen Models: A filter indicator light (ormessage)
will illuminate on the screen when the water filter needs to be
replaced. This light must be reset by pressing and holding the
Reset Filter button for three seconds.
The filter cartridge has a maximum life of six months and
should be replaced when indicated by the filter indicator on the
refrigerator, or sooner if asignificant reduction in flow occurs.
Removing the filter cartridge
Toreplace the filter, first remove the old cartridge by opening
the filter door and pulling on the bottom of the cartridge to allow
it to swing outward. When the cartridge can no longer swing,
gently pull to unseat it from the cartridge holder. DO NOT TWIST
CARTIDGE.A small amount of water may drip out.
Installing the Filter Cartridge
1.Align top of filter with cartridge holder and push until cartridge
is fully seated.
2.While continuing to ensure cartridge
is fully seated in the holder, gently
swing the filter inward until it is in a
vertical position. Iffilter will not swing
easily, check to ensure filter is properly
aligned and fully seated within the
cartridge holder.
3. Run 2 gallons of water through the cold
water dispenser {about 5 minutes) to
remove air from the system. Anew_
installed filter cartridge will cause
water to spurt from the dispenser. Use
a large pitcher or sports bottle to catch
the water spray. DO NOTuse the hot
water dispenser or hands-free auto-fill
(some models) until all air is removed
from the system.
pu_sh/Pull
4. Reset Filter Status message
Touch Screen Models: Access RESETbutton through the Water
Filter menu.
Non-touch Screen Models: Press and hold the Reset Filter button
for three seconds.
Z_ WARNING Using the hot water dispenser prior to purging air
from the system may result in spurting of hot water and lead
to hot water scalding. Follow the instructions above to purge all air
from the system through the cold water dispenser prior to using the
hot water dispenser.
Note: It isnormal for water to appear discolored during the initial
system flush. Water color will return to normal after first few minutes
of dispensing.
Filter Bypass Plug
To reduce the risk of property damage due to water leakage, you
MUST use the filter bypass plug when a replacement filter cartridge
is not available. The dispenser and icemaker will not operate without
either the filter or bypass plug installed. The bypass plug is installed
in the same way as afilter cartridge.
Z_ WARNING
To reduce the risk associated with choking, do not altow cMMren under 3 years of age to have access to
smart parts during the installation of this product. The disposable filter cartridge should be replaced every
6 months at the rated capacity, or sooner if a noticeable reduction in flow rate occurs.
For the maximum benefit of your filtration system, GE recommends the use of GE-branded filters only. Using GE-branded filters in GE
and Hotpoint ®refrigerators provides optimal performance and reliability. GEfilters meet rigorous industry NSF standards for safety
and quality that are important for products that are filtering your water. GE has not qualified non-GE-branded filters for use in GEand
Hotpoint refrigerators and there is no assurance that non-GE-branded filters meet GE's standards for quality, performance and reliability.
If you have questions, or to order additional filter cartridges, visit our website at www.geapplianceparts.com or call
GE Parts and Accessories, 800.626.2002.
Customers in Canada should consult the yellow pages for the nearest Camco Service Center.
GE
Appliances
Appliance Park
Louisville, KY40225
geappiianceparts.com
12
RPWF
© 2012 General Electric Company PC71879
Refer to 239D4126P002 Pub# 31-45497

About the fresh food storage options. GEApplia.cescom
Rearranging the Shelves
Shelves in the refrigerator compartment are adjustable,
To remove:
0 Remove all items from the shelf,
Tilt the shelf up at the front,
Lift the shelf up at the back and bring the
shelf out,
_j_
To replace:
While tilting the shelf up, insert the top hook
atthe back of the shelf in a slot on the
track,
Lower the front of the shelf until the bottom
of the shelf locks into place,
Spillproof Shelves
Spillproof shelves have special edges to help
prevent spills from dripping to lower shelves,
Quick Space Sheff
This shelf splits in half and slides under itself for
storage of tall items on the shelf below,
This shelf can be removed and replaced or
relocated (just like spillproof shelves),
NOTE: The back half of the Quick Space Shelf is
not adjustable,
13

About the fresh food storage options.
I_ i
Non-AdJustable Dairy Bin
To remove: Lift the dairy bin straight up,
then pull out, To replace: Engage the bin in the molded door supports and push down, The bin will lock in
place, See page 33,
i
J
Adjustable Bins on the Door
Adjustable bins can easily be carried from
refrigerator to work area,
To remove: Lift bin straight up, then pull out,
To replace or relocate: Slide in the binjust
above the molded door supports, and push
down, The bin will lock in place (see page 33),
Drop down tray
(tray open)
1, Open right fresh food
door
2, Depress both buttons
on lower sides of bin
and bin will drop down,
3, Reverse to reinstall,
Non-Adjustable Bins on the Door
To remove: Lift the bin straight up, then pull
out,
To replace: Engage the bin in the molded
supports on the door and push down,
It will lock in place,
The ice maker door bins are not
interchangeable, note the location upon
removal and replace the bin in its proper
location,
14

About the climate zone and temperature
controlled drawer. GEAppliances.com
ClimateZone
Keep fruits and vegetables organized in
separate compartments for easy access,
Excess water that may accumulate in the
bottom of the drawers or under the drawers
should be wiped dry,
Temperature Controlled Drawer
The Temperature Controlled Drawer is a
full-width drawer with adjustable temperature
control, This drawer can be used for large
miscellaneous items,
To change setting, press select button,
Note: when fresh food temperature is set to 40 ° or
higher, temperature controlled drawer can only be
set to citrus, HEAT
32°
BEVERAGE
-I
134 °
l
m
m
l
L
PRODUCE CHEESE CITRUS
36° 38° 4O°
Laceration Hazard.
"3I
m
Do not store glass bottles at this setting. If I
they are frozen, they can break and result
in personal injury. J
15

About the climate zone and temperature controlled drawer.
Toremove:
0 Pull the drawer out to the stop position,
0 Lift the front of the drawer up and out,
How to Remove and Replace the Adjustable Deli/Produce Drawer
Toreplace:
Pull left and right slides until fully extended,
Place drawer back in first and rotate drawer
front down to seat on slide,
0 Push the drawer in to closed position,
How to Remove and Replace Drawer Divider
Toremove: To replace:
Pull the drawer out to the stop position, Reverse steps 1 and 2 to replace drawer
divider,
Slide pan divider to right to release it from
pan,
16

About the freezer. GEAppliancescom
Freezer Basket and Drawer
0 Basket,
Drawer
Utility Bin
Non-Adjustable Bin in the Freezer
Toremove: push in plastic tab on either left or
right side
Toreplace: slide bin into location until it
locks into place,
Basket Removal
Toremove, CFE only:
Open freezer door to the stop position,
Remove freezer door bin by pushing
plastic tab on either left or right side to
release bin hinge pin,
Remove freezer basket by lifting up the
rear of the basket and moving basket
rearward until the front of the basket
can be rotated upward and out,
Lift it out to remove,
Toremove, CYEonly:
Open fresh food doors,
Open freezer doorto the stop position,
Remove freezer basket by lifting up the
rear of the basket and rotate it
upward,
Lift it out to remove,
Toreplace:
Reversestep 1thru 4 to replace,
17

About the automatic ice maker.
A newly installed refrigerator may take 12 to 24 hours to begin making ice.
Automatic Ice maker (on some models)
lcemaker The ice maker will produce seven cubes
per cycle approximately 100-130 cubes
in a 24-hour period, depending on freezer
compartment temperature, room temperature,
number of door openings and other use
conditions.
FeelerArm The ice maker will fill with water when it cools to
15°F (-10°C). A newly installed refrigerator may
take 12 to 24 hours to begin making ice cubes.
Ifthe refrigerator is operated before the water
line connection is made to the unit or if the
water supply to an operating refrigerator is
turned off, make sure that the ice maker is
turned off. Once the water has been connected
to the refrigerator, the ice maker may be turned
on. See the table below for details.
You may hear a buzzing sound each time the
ice maker fills with water.
Throw away the first few batches of ice to allow
the water line to clear.
Be sure nothing interferes with the sweep of the
feeler arm.
When the bin fills to the level of the feeler
arm, the ice maker will stop producing ice. It is
normal for several cubes to bejoined together.
If ice is not used frequently, old ice cubes will
become cloudy, taste stale and shrink.
NOTE: In homes with lower-than-average water
pressure, you may hear the ice maker cycle
multiple times when making one batch of ice.
To minimize the risk of personal injury, avoid contact with the moving parts of the ejector
mechanism, or with the heating element that releases the cubes. Do not place fingers or
hands on the automatic ice making mechanism while the refrigerator is plugged in.
l Cafe. Control Style
How to Turn the ice Maker On/Off
CYE/CFE Use the settings menu on the touchscreen
Ice Box
Lift and pull
Ice Bucket and Dispenser
. Open the ice box door on inside of the left
door.
. Pull up and out on on the ice bucket in
the left hand door to remove it from the
compartment.
. To replace the ice bucket, set it on the
guide brackets and push until the ice
bucket seats properly.
. If bucket cannot be replaced, rotate the ice
bucket fork 1/4 turn clockwise.
Extra Ice Storage
There is additional ice storage in the freezer compartment drawer.
, Open the freezer drawer.
, The ice bucket is located on the left side below the mullion.
o Pull the ice bucket forward.
18

Care and cleaning of the refrigerator.
Cleaning the Outside
The stainless steel panels, door handles and trim.
Do not use appliance wax, polish, bleach, or other products
containing chlorine on stainless steel,
Stainless steel can be cleaned with a commercially available
stainless steel cleaner, A spray-on stainless steel cleaner
works best,
GEAppliances.com
Silver-accented plastic parts.
Wash parts with soap or other mild detergents, Wipe clean with
a sponge, damp cloth or paper towel,
Do not use scouring pads, powdered cleaners, bleach or
cleaners containing bleach because these products can
scratch and weaken the paint finish,
Should spill tray need cleaning use lime remover.
Cleaning the Inside
Unplug the refrigerator before cleaning.
If this is not practical, wring excess moisture out of sponge or
cloth when cleaning around switches, lights or controls,
Use an appliance wax polish on the inside surface between
the doors,
Use warm water and baking soda solution-about (_
tablespoon (15 ml) of baking soda to a quart (1 liter) of water,
This both cleans and neutralizes odors, Rinse and wipe dry,
Do not clean glass shelves or covers
with warm water when they are cold, Glass shelves and
covers may break if exposed to sudden temperature
changes or impact such as bumping or dropping,
Tempered glass is designed to shatter into many small
pieces if it breaks.
Behind the Refrigerator
Be careful when moving the refrigerator away from the wall, All
types of floor coverings can be damaged, particularly cushioned
coverings and those with embossed surfaces,
Raise the leveling legs located at the bottom front of the
refrigerator,
Pull the refrigerator straight out and return it to position by
pushing it straight in, Moving the refrigerator in a side direction
may result in damage to the floor covering or refrigerator,
Lower the leveling legs until they touch the floor,
When pushing the refrigerator back, make sure you don't
rofl over the power cord or water supply line.
Preparing for Vacation
For long vacations or absences, remove food and unplug the
refrigerator, Clean the interior with a baking soda solution of
one tablespoon (15 ml) of baking soda to one quart (1liter) of
water, Leave the doors open,
LCD Models: turn refrigerator off at control (pg 7),
If the temperature can drop below freezing, have a qualified
service technician drain the water supply system to prevent
serious property damage due to flooding,
1) Turn refrigerator off (pg, 7) or unplug the refrigerator,
3) Turn water supply off
If you cut the water supply off, turn offthe ice maker (pg. 18).
Upon returning from vacation:
1) Replace the water filter,
2) Run 2 gallons of water through the cold water dispenser
(about 5 minutes) to flush the system,
3) Dispense 185°F hot water 3 times (10 oz, each) to flush the
system,
2) Empty ice bucket
Preparing to Move
Secure all loose items such as shelves and drawers by taping
them securely in place to prevent damage,
When using a hand truck to move the refrigerator, do not rest
the front or back of the refrigerator against the hand truck, This
could damage the refrigerator,
Handle only from the sides of the refrigerator,
Be sure the refrigerator stays in an upright position during
moving,
19

Replacing the lights
Refrigerator Lights (LEDs)
There is LEDlighting in fresh food
compartment and on the bottom of
the fresh food doors to light the freezer
compartment,
An authorized technician will need to
replace the LED light,
If this assembly needs to be replaced, call
GE Service at 1,800,432,2737
in the United States or 1,800,561,3344
in Canada,
2O
