Specification Revised 11/99
TNX22PACWW - GE Profile Performance™21.9 Cu. Ft. CustomStyle™No-Frost Top-Freezer Refrigerator
Case Dimensions (in inches/cm.)
69-7/8
68-3/4
CU
®
Manufacturer Certified to
ASSOCIATION OF HOME
APPLIANCE MANUFACTURERS
ANSI/AHAN HRF-1-1979
VOLUME and
SHELF AREA
R
Total volume and shelf
area are calculated by the
Association of Home
Appliance Manufacturers’
standards.
Listed by
Underwriters
Laboratories
For answers to your Monogram,®
GE Profile Performance Series,™
GE Profile™or GE appliance questions, call
GE Answer Center®service, 800.626.2000.
35-3/4
28-5/8
23-3/4
61
26-3/4
36-1/4
25"
Counter
Top
ElectricalWater
3/4" Airspace
(1/2" Gap + 1/4"
Wall Plates)
24-1/2"* Side panels
24"
Cabinet
8' Ceiling
13" to 14"
Cabinet
12"
Soffit
70-1/4"*
36"
24"
Standard, New Construction and Replacement Installation
Rough-In Dimensions (in inches/cm.)
• All wall/floor moulding should be removed prior to installation.
• Water recess on rear wall recommended to prevent water line damage. 48" minimum length 1/4"
diameter water line tubing recommended.
• When possible, recess both copper water line and electrical outlet. (See local codes)
• Front and rear leveling legs are adjustable for the built-in look. (See owner’s manual)
Installation Tips to Maximize the Built-In Look
Handle Side Clearance
–At least 2" (51 mm) on the handle side for fingertip clearances.
Top and Bottom Clearance
–At least 3/16" (4.75 mm) at the top and bottom edges to allow for trim flange.
Hinge Side Clearance
–The installation of 3/4" (19 mm) thick side panels requires less clearance because the space
between the door and adjacent countertop is wider.
• To avoid door contact to countertop consider:
–Miter the corner of the adjacent countertops 45°, or
–pull the refrigerator forward enough to avoid contact.
IMPORTANT: Before finalizing specifications for your GE Profile Performance™
CustomStyle™ Refrigerator, Please NOTE:
• A minimum of 36" is required for refrigerator installation
• Be sure to allow for 1/2" or 3/4" side panels in addition to the 36" minimum
Top View
Front View

Specification Revised 11/99
TNX22PACWW - GE Profile Performance™21.9 Cu. Ft. CustomStyle™No-Frost Top-Freezer Refrigerator
Features and Benefits
• 21.9 cu ft Capacity (Fresh Food 15.4 cu ft / Freezer 6.5 cu ft)
• Equipped for Optional Automatic Icemaker
• 2 Adjustable Humidity Window Vegetable/Fruit Crispers
• Adjustable Temperature Meat Pan
• Slide-Out, Spill-Proof Crisper Cover
• 4 Adjustable Glass Fresh Food Cabinet Shelves (3 Slide Out, 3 Spill Proof)
• 3 Adjustable Modular Door Bins with Gallon Storage
• 1 Fixed Fresh Food Door Shelf
• Quick Space™Shelf
• Quick Store™Bin
• Beverage Rack
• Slide-Out, Slide-Over Pans
• Modular Dairy Compartment with Glass Butter Dish
• Snugger™Clips
• 2 Adjustable Wire Everwhite Freezer Compartment Shelves
• 3 Freezer Door Bins (2 Adjustable; 1 Fixed with Gallon Storage)
• 4 Ice 'N Easy Trays with Ice Storage Bin
• Interior Freezer Light
• Dual Upfront Temperature Controls
• Bright Fresh Food Upfront Lighting
• Color-Matched Premium Deluxe Door Handles
• Model TNX22PACWW - White on white
• Model TNX22PACBB - Black on black
• Model TNX22PACCC - Bisque
