GE GTR12GBEWW Assembly instructions

Black
Yellow
GTR12GBEWW/GTR12SBESS
谭艳荣
2013.3.23
杨垒
2013.3.23
能效标识
157g铜版纸双面覆膜
设 计
DESIGN
校 对
CO.BY
图号/物料编码 PART NO.
标准化
STANDARD
图纸名称 PART NAME
业务
seller
图样标记
REL
版本号
REV.NO.
重量(g)
WEIGHT
比例
scale
材料 MATERIAL
0 1:1
批 准
AUTHORIZE
共1页
TOTAL SHEETS
第1页
NO. OF SHEETS
美的冰箱事业部
MIDEA REFRIGERATION DI VISION
(UL-BCD326W )
$
$41 $44
孔φ2MM，并系上黄绳，黄绳长为25CM左右
技术要求
1、成品尺寸为138 X188 m m；
2、印刷颜色按资料，印刷图案轮廓清晰，
无毛边，不能有印刷缺陷；
3、切边过渡要圆滑，贴纸应平整、牢固，
边角不能有翘起和不贴现象；
4、须送一个样确认后，方可批量生产。
188mm
138mm
408
43
kWh
U.S.Government Federal law prohibits removal of this label before consumer purchase.
General Electric
Models:GTR12GBE****
GTR12SBE****
Capacity:11.6 Cubic Feet
Cost Range of Similar Models
Estimated Yearly Operating Cost
Estimated Yearly Electricity Use
Your cost will depend on your utility rates and use.
For more information,visit www.ftc.gov/appliances.
Estimated operating cost based on a 2007 national average electricity cost of
10.65 cents per kWh.
Cost range based only on models of similar capacity with automatic defrost,
top-mounted freezer, and without through-the-door ice.
Refrigerator-Freezer
Automatic Defrost
Top-Mounted Freezer
Without Through-the-Door Ice
MARKER 变更内容 修改日期 签名
1
2
50200601B617
