GE Profile CustomStyle PSC23MGT Manual

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Dimensions and Installation Information
Overall
Dimensions
Height to top of hinge (in.) A 69-1/4
Height to top of case (in.) B 68-3/4
Case depth without door (in.) C†23-7/8
Case depth less door handle (in.) D†26-3/4
Case depth with door handle (in.) E†29-3/16
Depth with fresh food door open 90° (in.) F†45-9/16
Width (in.) G 35-3/4
Width with door open 90° inc. door handle (in.) H 41
Air
Clearances
Each side (in.) 1/8
Top (in.) 1
Back (in.) 1/2
†Water hook-up fits in back air clearance when calculating
installation depth.
If installed against a wall, allow clearance of 14-3/16" on freezer
side to remove bin.
Clearance required to remove fresh food full-size pan without
disassembling is 18-15/16".
Allow additional space for any necessary leveling adjustments.
"94 SxS Refer
A
Front View
Top View
G
D
C
F
BE
H
Dimension and installation information are shown in inches.
PSC23MGT
GE Profile CustomStyle™22.6 Cu. Ft. Side-by-Side Refrigerator with Dispenser
Specification Revised 10/06 210233
Listed by
Underwriters
Laboratories

Rough-In Dimensions and Installation Information
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Installation Tips to Maximize the Built-In Look
• All wall/floor molding should be removed prior to installation.
• Water recess on rear wall recommended to prevent water
line damage. 48" minimum length, 1/4" diameter water
line tubing recommended.
• When possible, recess both copper water line and electrical
outlet. (See local codes)
• Front and rear leveling legs are adjustable for the built-in look.
(See owner’s manual)
*The rough-in dimensions of 70-1/4”/72-1/4” are minimum and
measured from the finished floor to top of opening (or the
underside of the overhead cabinets) For Models with Trim Kit: If
frameless style cabinets are planned for above the refrigerator,
you may need to consider adding a maximum of 1/4” (70-1/2”)
to height of opening for 23 cu. ft. models and 1/8” (72-3/8”) for
25 cu. ft. models to allow additional clearance between cabinet
doors and top of refrigerator trim when cabinet doors are in
open position.
25"
Counter
Top
ElectricalWater
3/4" Airspace
(1/2" Gap + 1/4"
Wall Plates)
24"
Cabinet
25"
Counter
Top
Electrical Water
3/4" Airspace
(1/2" Gap + 1/4"
Wall Plates)
24"
Cabinet
25"
Counter
Top
ElectricalWater
Trim
3/4" Airspace
(1/2" Gap + 1/4"
Wall Plates)
24"
Cabinet
25"
Counter
Top
Electrical Water
Trim
3/4" Airspace
(1/2" Gap + 1/4"
Wall Plates)
24"
Cabinet
FOR 21 CUBIC FOOT MODELS
FOR 24 CUBIC FOOT MODELS
Fig 2A eps
8' Ceiling
13" to 14"
Cabinet
12"
Soffit
36-1/8"
24-1/2"
*The rough-in dimensions of 70-1/4"/72-1/4" are minimum and measured from
the finished floor to top of opening (or the underside of the overhead cabinets).
For Models with Trim Kit: If frameless style cabinets are planned for above the
refrigerator, you may need to consider adding a maximum of 1/4" (70-1/2") to
height of opening for 23 cu. ft. models and 1/8" (72-3/8") for 25 cu. ft. models
to allow additional clearance between cabinet doors and top of refrigerator trim
when cabinet doors are in open position.
Collar Trim In. w/ceiling
70-1/4"*
23 cu. ft. models
72-1/4"*
25 cu. ft. models
Dimension and installation information are shown in inches.
210233
Listed by
Underwriters
Laboratories
PSC23MGT
GE Profile CustomStyle™22.6 Cu. Ft. Side-by-Side Refrigerator with Dispenser
Specification Revised 10/06

PSS23MGTWW/BB/CC
PSS26MGTWW/BB/CC
PSC23MGTWW/BB/CC
PSC25MGTWW/BB
WATER
LOCK
Hold3seconds
CRUSHED
DOOR
ALARM
CUBED
LIGHT
Hold3seconds to Reset
QUICKICE
RSET
FILTER
Features and Benefits
• CustomStyle™ Configuration - Offers a built-in look without the built-in expense
• ClimateKeeper™ System - Best Temperature Management System You Can Buy!
• ExpressChill with 3 settings - Chills beverages quickly. Select 15, 30 or 45 minute with easy
one button selection
• Electronic controls with actual temperature display - Eliminates guesswork in setting
refrigerator temperatures
• Tall LightTouch! Dispenser with Child Lock - Delivers chilled water, cubed ice or crushed ice at
the slightest touch. A child lockout option keeps the dispenser off limits to little hands
• Slide ‘n Store™ Full-Extension Freezer Baskets - Extends 12” to 16” beyond the cabinet,
providing easy loading and unloading
• Quick Ice™ Option - Makes ice up to 50% faster than normal settings-ideal for entertaining
• TurboCool™ Setting - “Revs up” the refrigerator, cooling it quickly after frequent door openings
• Integrated Ice™ System - Frees up valuable freezer space. It tilts down, providing easy access
to bulk ice
• Tilt-Out Freezer Door Bins - Move forward for convenient access
• Integrated Shelf Support System - Provides strong, yet flexible support
• Model PSC23MGTWW - White on white
• Model PSC23MGTCC - Bisque on bisque
• Model PSC23MGTBB - Black on black
210233
PSC23MGT
GE Profile CustomStyle™22.6 Cu. Ft. Side-by-Side Refrigerator with Dispenser
Specification Revised 10/06
