GE SIDE-BY-SIDE REFRIRATOR 22 Operating instructions

GEAppliances.com
Refrigerators
Bottom Freezer
197D3358P002 49-60204-1 12642714SP 05-02 JR
Safety Instructions . . . . . . . . . . .2–4
Operating Instructions
Features . . . . . . . . . . . . . . . . . . . .6, 7
Ice Service . . . . . . . . . . . . . . . . . . . .8
Temperature Controls . . . . . . . . . . .5
Care and Cleaning
Cleaning . . . . . . . . . . . . . . . . . .9, 10
Light Bulbs . . . . . . . . . . . . . . . . . .10
Installation Instructions
Preparing to Install
the Refrigerator . . . . . . . . . . . .11, 12
Removal of Freezer Drawer . . .16, 17
Reversing the Door Swing . . . .12–15
Troubleshooting Tips . . . . . .18, 19
Normal Operating Sounds . . . . . .18
Consumer Support
Consumer Support . . . . .Back Cover
Warranty for Canadian
Customers . . . . . . . . . . . . . . . . . . .20
Warranty for U.S. Customers . . . . .21
Réfrigérateurs
Congélateur inférieur
Refrigeradores
Congelador inferior
Write the model and serial
numbers here:
Model #______________________
Serial # ______________________
Find these numbers on a label
on the right side, near the top of
the refrigerator compartment.
Model 22
Manuel d’utilisation
et d’installation
Owner’s Manual and
Installation Instructions
Manual del propietario
y instalación
La section française commence à la page 22
La sección en español empieza en la página 42

IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
Use this appliance only for its intended purpose as described in this Owner’s Manual.
SAFETY PRECAUTIONS
When using electrical appliances, basic safety precautions should be followed, including the following:
■
■This refrigerator must be properly installed
and located in accordance with the Installation
Instructions before it is used.
■
■Do not allow children to climb, stand or hang
on the shelves in the refrigerator. They could
damage the refrigerator and seriously injure
themselves.
■
■Do not touch the cold surfaces in the freezer
compartment when hands are damp or wet.
Skin may stick to these extremely cold surfaces.
■
■Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
■
■Keep fingers out of the “pinch point” areas;
clearances between the doors and between
the doors and cabinet are necessarily small.
Be careful closing doors when children are
in the area.
■
■In refrigerators with automatic icemakers,
avoid contact with the moving parts of the
ejector mechanism, or with the heating element
that releases the cubes. Do not place fingers or
hands on the automatic icemaking mechanism
while the refrigerator is plugged in.
■
■Unplug the refrigerator before cleaning and
making repairs.
NOTE: We strongly recommend that any servicing be
performed by a qualified individual.
■
■Turning the control to the 0 (off) position does
not remove power to the light circuit.
■
■Do not refreeze frozen foods which have
thawed completely.
Consumer Support Troubleshooting Tips Operating Instructions Safety InstructionsInstallation Instructions
2

3
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions Installation Instructions
PROPER DISPOSAL OF THE REFRIGERATOR
Child entrapment and suffocation are not problems
of the past. Junked or abandoned refrigerators are
still dangerous…even if they will sit for “just a few
days.” If you are getting rid of your old refrigerator,
please follow the instructions below to help prevent
accidents.
Before You Throw Away Your Old Refrigerator
or Freezer:
■Take off the doors.
■Leave the shelves in place so that children may
not easily climb inside.
Refrigerants
All refrigeration products contain refrigerants,
which under federal law must be removed prior
to product disposal. If you are getting rid of an
old refrigeration product, check with the
company handling the disposal about what
to do.
USE OF EXTENSION CORDS
Because of potential safety hazards under certain conditions, we strongly recommend against
the use of an extension cord.
However, if you must use an extension cord, it is absolutely necessary that it be a UL-listed (in the United
States) or a CSA certified (in Canada), 3-wire grounding type appliance extension cord having a grounding
type plug and outlet and that the electrical rating of the cord be 15 amperes (minimum) and 120 volts.
DANGER! RISK OF CHILD ENTRAPMENT
GEAppliances.com

4
Consumer Support Troubleshooting Tips Operating Instructions Safety InstructionsInstallation Instructions
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
For personal safety, this appliance must be properly grounded.
The power cord of this appliance is equipped
with a 3-prong (grounding) plug which mates
with a standard 3-prong (grounding) wall outlet to
minimize the possibility of electric shock hazard
from this appliance.
Have the wall outlet and circuit checked by a
qualified electrician to make sure the outlet is
properly grounded.
Where a standard 2-prong wall outlet is
encountered, it is your personal responsibility and
obligation to have it replaced with a properly
grounded 3-prong wall outlet.
The refrigerator should always be plugged into its
own individual electrical outlet which has a voltage
rating that matches the rating plate.
This provides the best performance and also
prevents overloading house wiring circuits which
could cause a fire hazard from overheated wires.
Never unplug your refrigerator by pulling on the
power cord. Always grip plug firmly and pull
straight out from the outlet.
Repair or replace immediately all power cords that
have become frayed or otherwise damaged. Do not
use a cord that shows cracks or abrasion damage
along its length or at either end.
When moving the refrigerator away from the
wall, be careful not to roll over or damage the
power cord.
USE OF ADAPTER PLUGS (Adapter plugs not permitted in Canada)
Because of potential safety hazards under certain conditions, we strongly recommend against
the use of an adapter plug.
However, if you must use an adapter, where local
codes permit, a temporary connection may be made
to a properly grounded 2-prong wall outlet by use
of a UL-listed adapter available at most local
hardware stores.
The larger slot in the adapter must be aligned with
the larger slot in the wall outlet to provide proper
polarity in the connection of the power cord.
When disconnecting the power cord from the
adapter, always hold the adapter in place with one
hand while pulling the power cord plug with the
other hand. If this is not done, the adapter ground
terminal is very likely to break with repeated use.
If the adapter ground terminal breaks, DO NOT USE
the refrigerator until a proper ground has been
established.
Attaching the adapter ground terminal to a wall outlet
cover screw does not ground the appliance unless the
cover screw is metal, and not insulated, and the wall
outlet is grounded through the house wiring. You should
have the circuit checked by a qualified electrician to make
sure the outlet is properly grounded.
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS

Consumer SupportTroubleshooting TipsOperating Instructions
Safety Instructions Installation Instructions
About the controls on the refrigerator. GEAppliances.com
Control Settings
Refrigerator Control
The refrigerator control maintains the temperatures throughout the refrigerator.
Freezer Control
The freezer control maintains the temperatures throughout the freezer compartment.
Moving the freezer control to 0 (off) stops cooling in both areas—refrigerator and freezer—but does
not shut off power to the refrigerator.
Initially set the refrigerator control at 5and the freezer control at 5.
If you want colder or warmer temperatures, adjust the refrigerator temperature first. When satisfied with that
setting, adjust the freezer temperature.
Control settings will vary based on personal preferences, usage and operating conditions, and may require more
than one adjustment.
After changing the controls, allow 24 hours for the refrigerator to reach the temperature you have set.
5
4
6
5

About the refrigerator shelves and bins.
Not all features are on all models.
6
Consumer Support Troubleshooting Tips Operating Instructions Safety InstructionsInstallation Instructions
Refrigerator Door Shelf
The bottom door shelf in the refrigerator
compartment is removable for easy
cleaning.
To remove, hold both ends and pull
straight up.
Adjustable Bins on the Refrigerator Door
Adjustable bins can easily be carried from
refrigerator to work area.
To remove: Lift bin straight up, then
pull out.
To replace or relocate: Engage the bin in the
molded supports on the door, and push
down. Bin will lock in place.
Rearranging the Shelves
To remove:
Tilt the shelf up at the front.
Lift the shelf up at the back and
bring the shelf out.
To replace:
While tilting the shelf up, insert the top
hook at the back of the shelf in a slot
on the track.
Lower the front of the shelf until the
bottom of the shelf locks into place.
Shelves in the refrigerator compartment are adjustable.
Refrigerator Compartment
Spillproof Shelves (on some models)
Spillproof shelves have special edges to
help prevent spills from dripping to lower
shelves. To remove or replace the shelves,
see Rearranging the Shelves.
Slide-Out Spillproof Shelf (on some models)
The slide-out spillproof shelf allows you
to reach items stored behind others. The
special edges are designed to help prevent
spills from dripping to lower shelves.
Make sure you push the shelves all the way in
before you close the door.
Shelf Saver Rack (on some models)
Slide-out beverage rack holds twelve cans of
soda or two wine/water bottles (lengthwise).
It can be removed for cleaning.
To remove, slide the rack out to the stop
position, lift the rack up and past the stop
position and lift it out.

About the storage drawers. GEAppliances.com
Not all features are on all models.
7
Consumer SupportTroubleshooting TipsOperating Instructions
Safety Instructions Installation Instructions
Fruit and Vegetable Drawers
Excess water that may accumulate in the
bottom of the drawers should be emptied
and the drawers wiped dry.
Adjustable Humidity Drawers
Slide the control all the way to the
HI setting to provide high humidity
recommended for most vegetables.
Slide the control all the way to the LO
setting to provide lower humidity levels
recommended for most fruits.
Snacks Drawer
The snacks drawer can be moved to the
most useful location for your family’s needs.
Drawer Removal
Drawers at the bottom of the refrigerator
compartment stop before coming all the
way out, to help prevent contents from
spilling onto the floor. Drawers can be
removed easily by tilting up slightly and
pulling past “stop” location.
To remove drawers when the refrigerator
compartment door cannot be opened all
the way, first remove food.
Remove the drawer farthest from
the door.
Remove the glass top by pushing up
from underneath and tilting it to clear
the door. Be careful when handling
the glass. We recommend wearing
protective gloves.
Remove the center rail and remove
the drawer. After cleaning, replace the
drawers in reverse order.

8
Consumer Support Troubleshooting Tips Operating Instructions Safety InstructionsInstallation Instructions
About the ice service.
Not all features are on all models.
Icemaker Accessory Kit
An icemaker accessory kit is available at
extra cost.
Check the label on the right side, near
the top of the refrigerator compartment,
for the specific icemaker kit needed for
your model.
Ice Service Compartment
The freezer has an ice service compartment
with an ice tray shelf and a pull-out ice
storage bin.
CAUTION: Make sure shelf is secure before placing
items on shelf to avoid property damage.
To install the ice tray shelf:
Slide the L-shaped opening, on the side
of the shelf, over the back screw located
on the side wall of the refrigerator.
Push the rack back until the screw is
locked into the L-shaped opening.
Lower the front of the shelf until the
front screw, located on the side wall of
the refrigerator, goes into the opening
at the front of the ice tray shelf.

Consumer SupportTroubleshooting TipsOperating Instructions
Safety Instructions Installation Instructions
Care and cleaning of the refrigerator. GEAppliances.com
9
Cleaning the Outside
The door handles and trim. Clean with a cloth
dampened with soapy water. Dry with a soft
cloth. Do not use wax on the door handles
and trim.
Keep the outside clean. Wipe with a clean
cloth lightly dampened with kitchen
appliance wax or mild liquid dish
detergent. Dry and polish with a clean,
soft cloth.
Do not wipe the refrigerator with a soiled dish
cloth or wet towel. These may leave a residue
that can erode the paint. Do not use scouring
pads, powdered cleaners, bleach or cleaners
containing bleach because these products can
scratch and weaken the paint finish.
The stainless steel panels and door handles
(on some models) can be cleaned with
a commercially available stainless steel
cleaner such as Stainless Steel Magic.™
Stainless Steel Magic is available at Ace,
True Value, Servistar, HWI and other
leading stores. It is also available through
GE Parts and Accessories, 800.626.2002,
or visit our Website, GEAppliances.com.
In Canada, call 1.888.261.3055 or visit
our Website, geappliances.ca. Order part
number WX10X15.
Do not use appliance wax or polish on the
stainless steel.
Cleaning the Inside
To help prevent odors, leave an open box of
baking soda in the refrigerator and freezer
compartments.
Unplug the refrigerator before cleaning. If this
is not practical, wring excess moisture out
of sponge or cloth when cleaning around
switches, lights or controls.
Use an appliance wax polish on the inside
surface between the doors.
Use warm water and baking soda solution—
about a tablespoon (15 ml) of baking soda
to a quart (1 liter) of water. This both cleans
and neutralizes odors. Rinse and wipe dry.
After cleaning the door gaskets, apply a
thin layer of petroleum jelly to the door
gaskets at the hinge side. This helps keep
the gaskets from sticking and bending out
of shape.
Avoid cleaning cold glass shelves with hot water
because the extreme temperature difference may
cause them to break. Handle glass shelves
carefully. Bumping tempered glass can cause
it to shatter.
Do not wash any plastic refrigerator parts in
the dishwasher.
Under the Refrigerator
For most efficient operation, keep the
area under the refrigerator clean. Remove
the base grille and sweep away or vacuum
up dust.
For best results, use a brush specially
designed for this purpose. It is available at
most appliance parts stores.
Clean the condenser coils at least
once a year.

10
Consumer Support Troubleshooting Tips Operating Instructions Safety InstructionsInstallation Instructions
Care and cleaning of the refrigerator.
Preparing for Vacation
For long vacations or absences, remove
food and unplug the refrigerator. Move
the freezer control to the 0 (off) position,
and clean the interior with a baking soda
solution of one tablespoon (15 ml) of
baking soda to one quart (1 liter) of
water. Leave the doors open.
Move the icemaker feeler arm (for
icemaker equipped models) to the STOP
(up) position and shut off the water supply
to the refrigerator.
If the temperature can drop below
freezing, have a qualified servicer drain
the water supply system (for icemaker
equipped models) to prevent serious
property damage due to flooding.
Preparing to Move
Secure all loose items such as grille, shelves
and drawers by taping them securely
in place to prevent damage.
Be sure the refrigerator stays in an upright
position during moving.
Light Bulb Replacement
Turning the freezer control to the 0 (off) position does not remove power to the light circuit.
Behind the Refrigerator
Be careful when moving the refrigerator
away from the wall. All types of floor
coverings can be damaged, particularly
cushioned coverings and those with
embossed surfaces.
Pull the refrigerator straight out and return
it to position by pushing it straight in.
Moving the refrigerator in a side direction
may result in damage to the floor covering
or refrigerator.
When pushing the refrigerator back, make sure
you don’t roll over the power cord or icemaker
supply line.
Refrigerator Compartment
CAUTION: Light bulbs may be hot.
Unplug the refrigerator.
The bulbs are located at the top of
the refrigerator compartment.
To remove the light shield, remove the
screw at the back. Slide the shield back
and remove it.
Replace the bulb with an appliance
bulb of the same or lower wattage.
To replace the shield, line up the tabs
on the shield with the slots in the side
of the light assembly. Slide the shield
forward until it locks in place. DO NOT
force it past the locking point, since this
could damage the shield.
Plug the refrigerator back in.
Freezer Compartment
CAUTION: Light bulbs may be hot.
Unplug the refrigerator.
The bulb is located at the top of the
freezer compartment. To remove the
shield, push in on the tabs at the back
of the shield and pull straight out.
Replace with an appliance bulb of
the same or lower wattage.
To replace the shield, insert the tabs at
the front of the shield into the slots at
the front of the light assembly. Push the
back of the shield up until the back tabs
pop into place.
Plug the refrigerator back in.

Consumer SupportTroubleshooting TipsOperating Instructions
Safety Instructions Installation Instructions
Preparing to install the refrigerator.
Read these instructions completely and carefully.
Water Supply to the Icemaker
If the refrigerator has an icemaker, it will have to be
connected to a cold water line.
A water supply kit (containing copper tubing,
shutoff valve, fittings and instructions) is available
at extra cost from your dealer or from Parts and
Accessories, 800.626.2002.
Refrigerator Location
Do not install the refrigerator where the
temperature will go below 60°F (16°C)
because it will not run often enough to
maintain proper temperatures.
Install it on a floor strong enough to support it
fully loaded.
Clearances
Allow the following clearances for ease
of installation, proper air circulation and
plumbing and electrical connections:
Sides . . . . . . . . . . . . . . . . . . . . . . . .0″(0 mm)
Top . . . . . . . . . . . . . . . . . . . . . . . . .1/2″(13 mm)
Back . . . . . . . . . . . . . . . . . . . . . . . . .1/2″(13 mm)
Door Swing at 90° angle . . . . . . . .1/4″(6 mm)
with handle, add
11⁄2″(38 mm)
Drawer Front Clearance . . . . . . . .12″(30 cm)
If the unit is to be installed into a recess where
the top of the unit is completely covered, use
dimensions from the floor to the top of the hinge
cover to verify proper clearance.
Rollers
The rollers have 3 purposes:
Rollers adjust so the door closes easily when
opened about halfway. [Front of refrigerator
should be 1/4″(6 mm) higher than the rear
of refrigerator.]
Rollers adjust so the refrigerator is firmly
positioned on the floor and does not wobble.
Rollers allow you to move the refrigerator away
from the wall for cleaning.
To adjust the rollers:
Remove the base grille.
Turn the roller adjusting
screws clockwise to
raise the refrigerator,
counterclockwise to
lower it. Use a 3/8″
socket wrench or
adjustable wrench. Set
the stabilizing brake.
See Stabilizing Brake.
Base Grille
Remove end
cap(s), then
remove the base
grille by grasping
it at the bottom
and pulling it
straight out.
To replace the base
grille, align prongs on
back of grille with slots
in cabinet and push
forward until the
grille snaps into place.
Snap the top of the
end caps on first,
then the bottom.
Roller Adjustment Screw
(3/8″hex with slot)
Roller Stabilizing
Brake 11
Base
Grille
End Cap

12
Consumer Support Troubleshooting Tips Operating Instructions Safety InstructionsInstallation Instructions
Preparing to install the refrigerator.
Read these instructions completely and carefully.
Stabilizing Brake
This refrigerator is equipped with leveling feet
which serve as a stabilizing brake. These additional
leveling feet will hold the refrigerator securely in
position during operation and cleaning.
To set the brake, first remove the end caps and
base grille. Second, adjust the rollers to the desired
position. See Rollers. Then turn both leveling feet
on each side until the feet are firmly in place
against the floor.
On models with a freezer drawer: After the brake is
securely in place, unscrew the roller adjustment
bolt counterclockwise until the weight of the
refrigerator is supported by the stabilizing brake.
This allows the weight to be positioned on the
stabilizing brake.
Replace the base grille and reinstall the end caps.
Reverse the procedure to roll the refrigerator out.
CAUTION: To avoid possible personal injury or property
damage, the leveling feet must be firmly touching
the floor.
Roller Adjustment Screw
(3/8″hex with slot)
Roller Leveling Foot
End Cap
Reversing the door swing.
Read these instructions completely and carefully.
Before You Begin
When reversing the door swing:
■Read the instructions all the way through before starting.
■Handle parts carefully to avoid scratching paint.
■Set screws down by their related parts to avoid using them in the wrong places.
■Provide a non-scratching work surface for the doors.
IMPORTANT: Once you begin, do not move the cabinet until door-swing reversal is completed.
These instructions are for changing the hinges from the right side to the left side—if you ever want to change the hinges
back to the right side, follow these same instructions and reverse all references to left and right.
Tools Required
■Phillips screwdriver
■Blade-type screwdriver or putty knife
■Masking tape
■5/16″hex head driver
■3/8″hex head driver
Removing the doors.
The doors may need to be removed to move the unit through tight spaces.
You may also want to reverse the door swing for easier access to the refrigerator.

On models with a freezer door: Tape the door
shut with masking tape at the upper corners.
Remove the center hinge pin with a 5/16″hex
head driver. Then remove the center hinge by
removing the three Phillips head screws.
On models with a freezer drawer: Open the
drawer and remove the hinge bracket by
removing the three Phillips head screws.
Remove the center hinge pin with a 5/16″
hex head driver.
Invert the hinge bracket and reinstall the hinge
pin in the bracket. Set the hinge bracket and
the three screws aside for reinstallation later.
Remove Freezer Door and Transfer Bottom Hinge Bracket (Freezer Door Model only)
Remove the tape from the freezer door. Tilt the
door away from the cabinet and lift it to free its
bottom socket from the hinge pin on the center
hinge bracket.
Set the door on a non-scratching surface.
Remove the bottom hinge bracket by removing
the four 3/8″hex head screws.
Remove the plug buttons on the bottom left
side of the cabinet and install them in the
vacant screw holes on the right side.
Install the bottom hinge bracket on the left
side.
Remove the hinge pin from the bottom hinge
bracket and install it in the outer hole.
Consumer SupportTroubleshooting TipsOperating Instructions
Safety Instructions Installation Instructions
13
Remove the Refrigerator Door and Top Hinge
Remove the top hinge cover by removing the
screw.
Tape the door shut with masking tape at
both upper corners.
Remove the three 5/16″hex head screws that
hold the top hinge to the cabinet.
Lift the hinge straight up to free the hinge pin
from the socket in the top of the door.
Remove the tape, tilt the door away from the
cabinet and lift it to free its bottom socket from
the hinge pin on the center hinge bracket.
Set the door on a non-scratching surface.
Before Removing the Doors
Unplug the refrigerator from its electrical
outlet.
Empty all door shelves, including the dairy
compartment.
CAUTION: Do not let either door drop to the floor. To do so
could damage the door stop.
Remove the Center Hinge Bracket
Center Right Center Hinge Pin
Plastic Washer
Bottom Right
Bottom Left

Remove the screws attaching the freezer door
handle to the left side and remove handle.
Remove the plug buttons on the right side and
install them in the vacant screw holes on the left
side.
Install the handle on the right side.
Remove the screws attaching the freezer door
stop to the bottom right side of the freezer
door.
Remove the plug buttons on the left side and
install them in the vacant screw holes on the
right side.
Install the door stop on the left side.
Rehang Freezer Door (on some models) and Install Center Hinge Bracket
On models with a freezer door: Lower the bottom
socket of the freezer door onto the bottom
hinge bracket. Shut the door and secure door
to cabinet with masking tape if needed. Insert
the center hinge pin into the hinge hole on top
of the freezer door.
Attach the center hinge bracket to the left side
loosely with the three Phillips head screws.
On models with a freezer door: Remove any
masking tape. Supporting the freezer door by
the handle, align the freezer door with the
cabinet.
Tighten the three screws.
14
Consumer Support Troubleshooting Tips Operating Instructions Safety InstructionsInstallation Instructions
Reversing the door swing.
Reverse Freezer Door Handle and Transfer Door Stop (Freezer Door Model only)
Left Side
Right Side
Door Stop
Center Left
Center Hinge Pin
Plastic Washer
Door Stop
Left Side
Right Side

Rehang Refrigerator Door and Install Top Hinge
Lower the bottom socket of the refrigerator
door onto the center hinge bracket. Shut the
door and secure door to cabinet with masking
tape if needed.
Insert the top hinge pin into the hinge hole on
top of the refrigerator door and attach the top
hinge to the cabinet loosely with the three
5/16″hex head screws.
Remove any masking tape. Supporting the
refrigerator door by the handle, align the door
with the cabinet.
Tighten the three screws.
Install the hinge cover.
Consumer SupportTroubleshooting TipsOperating Instructions
Safety Instructions Installation Instructions
15
Reverse Refrigerator Door Handle and Transfer Door Stop
Remove the screws attaching the refrigerator
door handle to the left side and remove handle.
Remove the plug buttons on the right side
and install them in the vacant screw holes on
the left side.
Install the handle on the right side.
Remove the screws attaching the refrigerator
door stop to the bottom right side of the
refrigerator door.
Remove the plug buttons on the left side and
install them in the vacant screw holes on the
right side.
Install the door stop on the left side.
Center Hinge Pin
Left Side
Door Stop
Right Side
Door Stop
Left Side
Right Side
Left Side

To remove the drawer front from the slides:
Remove the Phillips head screw on each side
of the railing. DO NOT remove the hex head
screws from the rail assemblies.
Lift up on the freezer drawer handle to separate
the drawer railings from the rail assemblies.
Set the drawer on a non-scratching surface.
16
Consumer Support Troubleshooting Tips Operating Instructions Safety InstructionsInstallation Instructions
Removal of freezer drawer.
The freezer drawer can be removed, if needed, to fit through tight areas.
Read these instructions completely and carefully.
To Remove the Freezer Drawer
To remove the baskets:
Open the freezer drawer all the way.
Slide the top basket back into the freezer.
Remove the lower basket by lifting it up at the
back, then lifting the entire basket up and out
of the railings.
To Remove the Stabilizing Brakes (if needed to fit through tight spaces)
Remove the base grille. Then remove both end
caps. Remove both stabilizing brakes with 3/8″
hex head driver. Base Grille
End Cap
Phillips
Screw
Bracket

Replace the Phillips head screw on both rail
assemblies.
Locate the slots on the inside of the rail
assemblies near the back.
Insert the hooks at the back of the railings
attached to the drawer, into the slots on the rail
assemblies.
Lower the front of the drawer, making sure the
tabs on the sides of the railing fit into the front
slots in the rail assemblies.
Replace the lower freezer basket. Make sure
the tabs on the sides of the basket fit into the
back notches in the rail assemblies and that
the lip on each side fits over the inside
section of the railings.
Consumer SupportTroubleshooting TipsOperating Instructions
Safety Instructions Installation Instructions
To Replace the Freezer Drawer
IMPORTANT: Two people may be required to complete
this procedure.
Pull out the rail assemblies to the full length on
each side of the cabinet.
Slot
Rail assembly
Slot
Tab
Hook
Phillips
Screw
Tab
Notch
Lip
17

Consumer Support Troubleshooting Tips Operating Instructions Safety InstructionsInstallation Instructions
18
Normal operating sounds.
Before you call for service…
Troubleshooting Tips
Save time and money! Review the charts on the following
pages first and you may not need to call for service.
Problem Possible Causes What To Do
Refrigerator does not Refrigerator in defrost cycle. •Wait about 30 minutes for defrost cycle to end. If lights
operate work but the unit does not restart, remove the base grille.
Locate the defrost timer mounted on the center rail and
turn the timer knob clockwise until you hear a click. The
refrigerator should begin operating.
Control in 0 (off) position. •Move the control to a temperature setting.
Refrigerator is unplugged. •Push the plug completely into the outlet.
The fuse is blown/circuit •Replace fuse or reset the breaker.
breaker is tripped.
Vibration or rattling Rollers need adjusting. •See Rollers.
(slight vibration
is normal)
Newer refrigerators sound different from older refrigerators.
Modern refrigerators have more features and use newer technology.
HUMMM...
WHOOSH...
■The new high efficiency compressor may run faster and longer
than your old refrigerator and you may hear a high-pitched
hum or pulsating sound while it is operating.
■You may hear a whooshing sound when the doors close. This is
due to pressure equalizing within the refrigerator.
■You may hear the fans spinning at high speeds. This happens
when the refrigerator is first plugged in, when the doors are
opened frequently or when a large amount of food is added to
the refrigerator or freezer compartments. The fans are helping
to maintain the correct temperatures.
■The fans change speeds in order to provide optimal cooling
and energy savings.
CLICKS, POPS,
CRACKS and SNAPS
■You may hear cracking or popping sounds when the
refrigerator is first plugged in. This happens as the refrigerator
cools to the correct temperature.
■The freezer control will click when starting or stopping the
compressor.
■Defrost timer snapping in and out of the defrost cycle.
■Expansion and contraction of cooling coils during and after
defrost can cause a cracking or popping sound.
■On models with an icemaker, after an icemaking cycle, you
may hear the ice cubes dropping into the ice bucket.
WATER SOUNDS
■The flow of refrigerant through the freezer cooling coils may
make a gurgling noise like boiling water.
■Water dropping on the defrost heater can cause a sizzling,
popping or buzzing sound during the defrost cycle.
■A water dripping noise may occur during the defrost cycle as
ice melts from the evaporator and flows into the drain pan.
■Closing the door may cause a gurgling sound due to pressure
equalization.
Do you hear what I hear? These sounds are normal.

19
Consumer SupportTroubleshooting TipsOperating Instructions
Safety Instructions Installation Instructions
GEAppliances.com
Problem Possible Causes What To Do
Motor operates for Normal when refrigerator •Wait 24 hours for the refrigerator to completely
long periods or cycles is first plugged in. cool down.
on and off frequently. Often occurs when large •This is normal.
(Modern refrigerators amounts of food are
with more storage placed in refrigerator.
space and a larger
Door left open. •Check to see if package is holding door open.
freezer require more
Hot weather or frequent •This is normal.
operating time. They
door openings.
start and stop often
Temperature control •See About the controls.
to maintain even
set at the coldest setting.
Grille and condenser need •See Care and cleaning.
cleaning.
Refrigerator or freezer Temperature controls not set •See About the controls.
compartment too warm cold enough.
Warm weather or frequent •Set the temperature control one step colder.
door openings. See About the controls.
Door left open. •Check to see if package is holding door open.
Frost or ice crystals Door left open. •Check to see if package is holding door open.
on frozen food Too frequent or too long
(frost within package door openings.
is normal)
Ice cubes have Food transmitting odor/taste •Wrap foods well.
odor/taste to ice cubes.
Interior of refrigerator •See Care and cleaning.
needs cleaning.
Slow ice cube freezing Door left open. •Check to see if package is holding door open.
Freezer control not set •See About the controls.
cold enough.
Refrigerator has odor Foods transmitting •Foods with strong odors should be tightly wrapped.
odor to refrigerator. •Keep an open box of baking soda in the refrigerator;
replace every three months.
Interior needs cleaning. •See Care and cleaning.
Moisture forms on Not unusual during •Wipe surface dry and reset the refrigerator control
outside of refrigerator periods of high humidity. one setting colder.
Moisture collects inside Too frequent or too
(in humid weather, air long door openings.
carries moisture into
refrigerator when doors
are opened)
Door/drawer does not Rollers need adjusting. •See Preparing to Install the Refrigerator.
close by itself
Freezer door/drawer This is normal if, after popping •This indicates that there is a good seal on the freezer
pops open when open, the freezer door/drawer door/drawer. If the freezer door/drawer does not
refrigerator door closed on its own. automatically close after popping open, then see the
is closed Problem: Door/drawer does not close by itself, above.
temperatures.)

CUSTOMER WARRANTY
(for customers in Canada)
Your refrigerator is warranted to be free of defects in material and workmanship.
What is covered How Long Warranted Parts Labour
(From Date of Sale) Repair or Replace
at Camco’s Option
Compressor Ten (10) Years Ten (10) Years Five (5) Years
Sealed System (including Five (5) Years Five (5) Years Five (5) Years
evaporator, condenser
tubing and refrigerant)
All Other Parts One (1) Year One (1) Year One (1) Year
TERMS AND CONDITIONS:
1. This warranty applies only for single
family domestic use in Canada when the
Refrigerator has been properly installed
according to the instructions supplied by
Camco and is connected to an adequate
and proper utility service.
Damage due to abuse, accident,
commercial use, and alteration or
defacing of the serial plate cancels all
obligations of this warranty.
Service during this warranty period must
be performed by an Authorized Camco
Service Agent.
2. Neither Camco nor the Dealer is liable for
any claims or damages resulting from
failure of the Refrigerator or from service
delays beyond their reasonable control.
3.
To obtain warranty service, purchaser
must present the original Bill of Sale.
Components repaired or replaced are
warranted through the remainder of the
original warranty period only.
4. This warranty is in addition to any
statutory warranty.
WHAT IS NOT COVERED:
• Service trips to your home to teach you
how to use the product.
• Damage to finish after delivery.
• Improper installation—proper installation
includes adequate air circulation to the
refrigeration system, adequate electrical,
plumbing and other connecting facilities.
• Replacement of house fuses or resetting
of circuit breakers.
• Replacement of light bulbs.
• Damage to product caused by accident,
fire, floods or acts of God.
• Loss of food due to spoilage.
• Proper use and care of product as listed
in the owner’s manual, proper setting of
controls.
• WARRANTOR IS NOT RESPONSIBLE
FOR CONSEQUENTIAL DAMAGES.
IMPORTANT
Keep this warranty and your bill of sale as proof of original purchase and purchase date.
Camco Service is available coast to coast.
If further help is needed concerning this
warranty, contact:
Manager, Consumer Relations
Camco Inc., Consumer Service
1 Factory Lane
Suite 310
Moncton, New Brunswick E1C 9M3
20
Staple your receipt here.
Proof of the original purchase
date is needed to obtain service
under the warranty.
