GE PDF22MFSABB and Operating instructions

wvvvv.GEAppliances.com
N
©
Safety InsTtrudions ........... 9 3
Operating Instru_tions
Additional Features ............. 9
Automatic Icemaker . .......... 19
Controls .................... 4-6
Crispers and Pans ............. 10
Freezer ...................... 11
Shelves and Bins ............. 8, 9
_'ater Filter ................... 7
Care and Cleaning ........ 13-15
Installation Instructions
Installing the Refligerator . . . .17-91
Installing the _4'ater Line ..... 98-30
Preparing to Install
the Refligerator . .............. 16
Removing and Replacing the
Freezer Drawer ............ 99, 93
Reversing the Door Swing .... 24-27
Troubleshooting Tips ....... 31-35
Normal Operating Sounds ...... 31
Consumer Support
Consumer Support ..... Back (',over
Performance Data Sheet ........ 41
Product Registration ........ 37, 38
Warranty for Canadian
Customers ................... 39
_'arrantv for U.S. Customers ..... 40
Models20and22
Cong_lateur inf>rieur
R frig&ateurs
La section fran_aise commence a la page 43
Congelador inferior
Refrigeradores
La seccionen espa#olempieza en lapagina 83
Write the model and serial
numbers here:
Model #
Serial #
Find these numbex_ on a label
on the right side, near the top of
the refl'igerator compartment.
3828JL8012C 197D4618PO04 49-60355 !2-04 Jfl

IMPORTANTSAFETYINFORMATION.
READALLINSTRUCTIONSBEFOREUSING.
AWARNING!
Use this appliance only for its intended purpose as described in this Owner's Manual.
SAFETYPRECAUTIONS
When using electrical appliances, basic safety precautions should be followed, including the following:
This refl'igerat )r must be i)roi)erl ) installed
and located in accordance with the Installation
hlstrucfions before it is used.
Do not allow children to climb, stand or hang
on the shelves in the refl-Jgeratm: They could
damage the refl-Jgerator and seriously iqjm'e
themselves.
Do not touch the cold sm'fi_ces in the fl'eezer
compartment when hands are damp or wet.
Skin max stick to these extremely cold SUll'ilces.
_ Do not store or use gasoline or other flammable
wq)ors and liquids in the vicinity of this or anv
other appliance.
Keep finge_ out of the "pinch point" areas;
clearances between the doms and between
the (loo_s and cabinet are necessarily small.
Be carefld closing doms when children are
in the area.
In refl'Jgeratms Mth automatic icemake_s,
avoid contact with the moving parts of the
ejector mechanism, or with the heating element
that releases the cubes. Do not place finge_s or
hands on the automatic icemaking mechanism
while the reti-Jgerator is plugged in.
Uni)lug the reflJgerator befin'e cleaning and
making repairs.
NOTE: Westrong/}/recommendthatany servicingbe
performedbya quadded individual
Setting either or both controls to 0(off) does
not remove power to the light circuit.
Do not refl'eeze fl'ozen foods which have
thawed completely.
ADANGER!RISKOFCHILDENTRAPMENT
PROPERDISPOSALOFTHEREFRIGERATOR
Child entrapment and suffocation are not problems
of the i)ast..ltmked or abandoned reli'igeratm_ are
still dangerous...even if they will sit for 'ijust a few
days." If you are getting rid of yore" old refligeratm;
please follow the instructions below to hel I) prevent
accidents.
Before YouThrewAway YourOldRefrigerator
or Freezer:
_ke off the dome.
i.eaxe the shehes in place so that children may
not easih climb inside.
Refrigerants
All refiigeration products contain refiigerants,
which under fe(leral law must be removed prior
to product disI)osal. If you are getting rid of
an old reliigeration product, check with the
company handling the disposal about what
to do.
USEOFEXTENSIONCORDS
Because of potential safety hazards under certain conditions, we strongly recommend against
the use of an extension cord.
However, if you must use an extension cord, it is absoluteh necessary that it be a Ui_-listed (in the United
States) or a CSA certified (in Canada), B-wire ,gr°tmding, t_,l)e appliance extension cord having a gmtmding
t)pe I)hw-,and outlet and that the electrical ratim,., of the cord be 15 amperes (minimum) and 12(1xolts.

www.GEAppliances.com
a, WARNING!
HOWTOCONNECTELECTRICITY
Donot, under any circumstances, cut or remove the third (ground) prong from the power cord.
For personal safety this appliance must be properly grounded.
The power cord ot this appliance is equipped
with a 3-prong (grounding) plug which mates
with a standard 3-prong (grounding) wall outlet to
minimize the possibili Fot electric shock hazard
fl'om this appliance.
Have the wall outlet and circuit checked by a
qualified electrMan to make sure the outlet is
properly grounded,
_'here a standard 2-prong wall outlet is
encountered, it is your l)e_onal responsibili_' and
obligation to have it replaced with a properly
grounded 3-prong wall outlet.
The reli-igerator should always be plugged into its
own individual electrical outlet which has a w)ltage
rating that matches the rating plate.
This provides the best pedommnce and also
prevents overloading house wiring circuits which
could cause a fire haa_rd fl'om overheated wires.
Never unplug your refrigerator by pulling on the
power cord. Mways grip plug firefly and pull
straight out from the outlet.
]),el)air or replace immediately all power cords that
have become fl'ayed or otherwise damaged. Do not
use a cord that sho_:s cracks or abrasion damage
along its length or at either end.
\4]_en moving the refrigerator away fl'om the
wall, be carefld not to roll over or damage the
power cord.
USEOFADAPTERPLUGS(Adapterpl.gsnotpermittedinCanada)
Because of potential safety hazards under certain conditions, we strongly recommend against
the use of an adapter plug.
However; if win, must use an adapte_, where local
codes pemfit, a temporary connection may be made
to a properly grounded 2-prong wall outlet by use
of a UIAisted adaptor a\_dlable at most local
hardwai'e stoi'es.
The linger slot in the adapter must be aligned Mth
the larger slot in the wall outlet to provide proper
polarity in the connection of the power cord.
When disconnecting the power cord fl'om the
a(lapte_; always hold the adapter in place with one
hand while pulling the power cord plug with the
other hand. If this is not done, the adapter ground
temfinal is ve_' likely to break with repeated use.
If the adapter ground temfinal brea!<% DO NOTUSE
the refl-igerator until a proper ground has been
established.
Attaching the adapter ground terminal to a wall outlet
cover screw does not ground the apphance unless the
cover screw is metal, andnot insulated,and the wall
outlet is grounded through the house wiring. Youshould
have the ckcuit checkedby a quafified electrician to make
sure the outlet is proper/)/grounded.
READANDFOLLOWTHISSAFETYINFORMATIONCAREFULLY.
SAVETHESEINSTRUCTIONS
3

Aboutthe controlswith
temperaturesettings.(for other models, see next page)
NOTE: Therefrigeratoris shippedwith protective film coveringthe temperaturecontrols.
If this film was not removedduringinstallation,removeit now
Thetemperature controls are preset in the factory at 37°1:for the refrigerator compartment
and O°Ffor the freezer compartment. Allow24 hours for the temperature to stabilize to the
preset recommended settings.
Thetemperature controls can display both the SET temperature as well as the actual
temperature in the refrigerator and freezer. The actual temperature may vary slightly from
the SETtemperature based on usage and operating environment.
Setting either or both controls to OFFstops cooling in both the freezer and refrigerator
compartments, but does not shut off electrical power to the refrigerator.
Changingthe Temperature
To change the temperature, press and release tile
WARMER or COLDER pad. The Sk'Tlight will con/e
oil and the display will show the set teml)erature.
To change the teml)eramre, tap either the
WARMER or COLDER pad tmfil the desired
temperature is displayed. Refl_igerator temperatures
can be ac!justed between 34°F and 47°F and the
fl'eezer teInl)eratures can be ac!justed between
-(3°F and +8°K
Once the desired temperature has been set,
the temperature display will return to the actual
refl]gei'ator and freezer teil/perattlres after 5
seconds. Several a(!iusttnents Ill}l)' be required.
Each time you at!just controls, allow 24 horns fin" the
refrigerator to reach the temperature you have set.
To turn the cooling system off, mp tile WARMER pad
fin" either the refi_igerator or the ti'eezer tmtil the
display shows OFF.Toturn the unitbackon, press the
COLDERpad for either the refl_igerator or fl'eezet:
The SETlight will illmninam on the side you
selected. Then press the COLDERpad again (on the
side where the SETlight is illuminated) and it will
go to the preset points of O°Ffiw the fl'eezer and
37°Ffi)r the reflJgeratm; Setting either or both
controls to OFFstops cooling in 1)oth the ti'eezer
and refrigerator compartments, but does not shut
off electrical power to the refl_igerat(n:
Performance Air Flow System
The Pedbmmn('e Mr How System is designed to
maximize temperatm'e control in the refl_igerator
and ti'eezer compartments. This tmique special
ti_atm'e consists of the _dr Tower along the 1)ack
wall of the refrigerator and the Air Tmmel on the
bottom portion of the fl'eezer rear wall. Placing
ti)ocl in fl'ont of the lou\'e_ on these components
will not affect perfbmmnce.
4

About TurboCooL"M(on some models) vvww.GEAppliances.com
TurboCool
How #Works
TurboCoolrapidly cools the retiigerator
colnl)artinexlt ixl order to inore quickly
cool fi)ods. Use TurboCool when adding a
large amount of toed to the refligerator
compartment, putting away fi)o(ls after they
have been sitting out at room temperature
or when putting away wam_ leflovexs. It can
also be used if the retiigerator has been
without power for an extended period.
Once acfi\:_md, the compressor will turn on
immediately and the tm_s will cycle on and
off at high speed as needed tbr eight hom_.
The compressor will continue to rtm tmfil
the refligerator compartment cools m
approximately 34°F (l °C), then it will cycle
on and off to maintain this setting. _Mter 8
houI_, or if TurboCoolis pressed again, the
refl_gerator compartment will return to
the original setting.
How to Use
Press TurboCool,The refrigerator
temperatm'e display will show _c.
_Mter TurboCoolis complete, the
reflJgerator compartment will return
to the original setting.
NOTES:The refligerator temperatm'e
cannot be changed dining
TurboCooZ
The fl'eezer temperature is not
affected (huJng TurboCooL
_4]_en opening the refrigerator
door (lining YurboCoot the tiros
will continue to rim if they have
cycled on.
About Door Alarm (onsomemodels)
The door alam_ will sotmd if either
door is open fl)r more than 2 minutes.
The beeping stops when w)u close
the (loo_:

Aboutthe controlswith numberedsettings.
NOTE: Therefrigeratoris shippedwith protective film coveringthe temperaturecontrols.
If this film was not removedduringinstallation, removeit now
Initially, set the refrigerator control at5 and the freezer control at5 and allow24 hours
for the temperature to stabilize.
Several adjustments may be required. Adjust the controls one increment at a time, and
allow24 hours after each adjustment for the refrigerator to reach the temperature you
have set.
Setting either or both controls to 0stops cooling in both the refrigerator and freezer
compartments, but does not shut off electrical power to the refrigerator.
Performance Air Flow System
The Pe_tmmance _Mr Flow System is designed to
maximize temperattu'e control in the refl_igerator
and fl'eezer compamnents, This tmique special
teatm'e consists of the _dr Tower along the back
wall ot the refligerator and the _dr Tmmel on the
bottom portion of the fl'eezer rear wall. Placing
fi)od in fl'ont of the lou\'e_ on these components
will not affect perfi)m_ance.

Aboutthe water filter.(onsomemodels) www.GEAppliances.com
i i ii i_
J
RESETWATERFILTER
(on some models)
Water Filter Cartridge
The water filter cartridge is located in the
back Ul)l)er right corner of the refl-igerator
coiili)_l i'tlilent,
When to Replace the Filter
There is a replacement indicator
light fin" the water filter cartridge on the
temperature display This light will mrn
orange to tell you that you need to replace
the filter soon. The filter cartridge should
be replaced when the replacement
indicator light tm'ns red or if the flow
of water to the dispenser or icemaker
decreases.
Installing the Filter Cartridge
O]f yot:l are replacing the cartridge,
fi_t remove the old one. Open the
cartridge cover by pressing in on the
tnb at the ti'ont and pulling down.
O Remoxe the cartridge b) slowly rotating
it c()tmterch)ckwise. A small amotmt of
water may drip down.
ACAUTION:/fa, hasbeentra ed
in thesystem,thefi/tercartridgemaybeejectedas
it isremovecLUsecautionwhenremoving.
0 ]_,emo',e the i)rotecti',e foil from the
end of the cartridge.
IJning up the arrow on the cartridge
and the cartridge holder; slowly rotate
the cartridge clockwise tmtil it stops.
_]_en the camidge is propedy
installed, you will ti_el it "click" as it
locks into place. The blade on the end
of the cartridge should be positioned
vertically; Do not overtighten.
Close the cartridge covex;
O Rim water fl'om the dispenser fin.
3 minutes (about 11/'_)gallons) to clear
the system and prevent sputtering.
See To Use the Dispensersection.
Press and hold the RESETWATERFILTER
pad fin" 3 seconds.
NOTE°A newl_-instnlled water filter cartridge
may cause water to spurt from the dispense_:
Filter Bypass Plug
You must use the filter 1upass I)lug when a
replacement filter cartridge is not a\:filable.
The icemaker will not operate without the
filter or filter bypass plug.
Replacement Filters:
To order additional filter cartridges
in _e United States, visit our WebsRe,
www.GEAppliances.com,or call
GE Parts and Accessories, 800.626.2002.
Filter Model (;S_¥F
Customei_ in Canada should consult
the yellow pages fin" the nearest Camco
Service Center:

Abouttheshelvesandbins.
Not all features are on all models.
: o
Somemodelshavewireshelvesthat
canbeadjustedin thesamemamTe_
Rearranging the Shelves
S S Y _ "
hel;e,_ in the refi_i_e_ato_ ('()ml)artment are a(!iustable
Refrigerator Compartment
Toremove:
0Tilt the shelf up at the fi'ont.
0I,ifl the shelf ul) at the back and
bring the shelf ()tit.
Toreplace:
0_,_hile tiltino_ the shelf u ), insert the tel )
hook at theback of thelsheff in a slot
(m the track.
0 I,ower the fi'ont of the shelf until the
bottom of the shelf locks into place.
Spillproof Shelves (onsomemode/s)
Spillproof shelves have special edges to
hel I) prevent spills fl'om dripping to lower
shelves. To i'elnove oi" replace the shelves,
see Rearranging the Shelves,
Slide-Out Spillproof Shelf (onsome models)
The slide-out spillproof shelf allows you
to reach items stored behind otheis. The
spedal edges are designed to hel I) prevent
spills from dripping to lower shelves.
Toremove:
0Reinove all items from shell
0Slide the shelf ()tit until it stops.
iift the fl'ont edge of the shelf until the
central tabs are above the fl'ont bai:
0Continue pulling the shelf torward
until it can be removed.
Toreplace:
0Place the rear shelf tabs just in fi'ont of
the central notches on the shelf fl'ame,
Slide the shelf in until the central tabs
are slightly behind the fl'ont bar.
0i,ower the shelf into place until it is
horizontal and slide the shelf in.
Make surethat the shelf sits flat after reinstallation
anddoesn'tmovefreely fromside toside.
Make sureyoupush the shelvesall the way in
before youclose the door

www.GEAppliances.com
Fingerhold
tugger Adjustable Bins on the Door
A(!justable bins can easily be carried fi'om
retiJgerator to work area.
Toremove: lift bin straight up, then
pull out.
Toreplace or relocate: Engage the bin in the
molded supports of the doox; and push in.
Bin will lock in place.
]'he snugger helps prevent tipping, spilling
or sliding of small items stored on the door
shelf. (;_ip the finger hold near the rear ot
the snugger and move it to fit your needs.
Non-Adjustable Shelves on the Door
Toremove: Lilt the shelf straight up, then
ptdl out.
Toreplace: Engage the shelf in the molded
stlpports on the door and push down.
It will lock in place.
Abouttheadditional features.
Not all features are on all models.
Shelf Saver Rack (onsomemodels)
Slide-out beverage rack holds twelve cans of
soda or two wine/wamr bottles (lengthwise).
It can be removed tot cleaning.
Toremove, slide the rack out to the stop
position, lift the rack uI) and past the stop
position and lift it out.

Aboutthe crispersandpans.
Not all features are on all models.
Fruit and Vegetable Crisper
Excess water that ma) accunmlate in the
bottom of the (h'awe_ or under the (h'awe_
should be wiped dr);
Adjustable Humidity Crisper (onsomemodels)
Slide the control all the way to the Slide the control all the wax to the LOW
HIGHsetting to proxide high humidit_ .settin,,., to proxide lower humidity, lexels
recommended fi)r most xegetables, recommended fi)r most fl'uits.
Snack Pan (on some models)
This pan can be mo_ed to the most useflfl
location fin" )ore" fmnil)'s needs.
To remove, slide the pan out to the stop
position, lilt the pan u l) and past the stop
position and lift it out.
Adjustable Temperature Dell Pan (onsomemodels)
When the pan is placed in the 7th slot fl'om
the bottom of the track and the lever is set
at COLDEST, air fl'om the fl'eezer is torced
around the pan to kee I) it ve_T cold.
You can move the pan to any location if
wm don't want the extra cold storage.
The settings can be a(!justed anywhere
1)et_ven cold _ and coldest _1 _.
X,_]_en set at cold, the pan will stay at the
nom_al refligerator temperatm'e.
The coldest setting provides the coldest
storage area.
II II Crisper Removal
ToRemove:
These (h'awex_ can be removed easily 1)y
lifting up slightl)while pulling the drawer
past the stop location.
When the door cannot be fully opened,
rein(_x'e the drawer fi_rth est froln the door
first. Make sure the drawer closest to the
door is fifllv closed. There is a latch at the
fl'ont of the center slide rail. Push down on
the latch and slide the center slide rail, to
which the drawer is attached, a_v fl'om the
dora: ReInove fl_e drawer
10

Aboutthe freezer, www.GEAppliances.com
Not all features are on all models.
Appearance and features may vary
Freezer Shelves and Baskets
Depending on your model, your fi'eezer
Ill[ly feattlI'e:
O A deep fllll-width basket
A shallow fllll-width basket
0 A half:width basket
A flfll-width wire shelf
O A shelf aboxe tile ice storage bin
Appearancemayvary
Basket/Sheff Removal
Toremove the deep full-width basket on
freezer drawer models:
0 Open tile freezer drawer until it stops.
@ Tile fl'eezer basket rests on a fl'anle
inside tile fl'eezer (h'awe_; i,ift tile basket
up at tile back.
0 Lilt tile fl'ont up and lilt tile entire
basket up and out of tile (h'awe_:
Tab
Toremove the half-width basket:
0 Pull tile basket out to tile stop location.
@IJtt tile basket up at tile ti'ont to release
it from the slides.
Lift the back up and out of the slide.
When replacing the basket make sure that
tile Mre tabs and wire l/oo]_; on tile sides
of tile basket go into tile slots in tile top
of the upper basket slides.
NOTE:Mw'avsbe sure to fiflly close this
basket. You will know it is fifllv closed when
w)u teel it "click" into place.
Appearance may vary
Appearance may vary
Toremove the deep full-width baskets on
freezer door models, the shallow full-width
basket and the full-width wire shelf."
O Pull tile basket/shelf out to tile stop
location.
IJfl tile fl'ont up and oxer tile stop
location.
Lift tile basket/shelf up and out.
Toremove the shelf above the ice bin:
Pull tile shelf straight out.
11

Abouttheautomaticicemaker.
A newly installed refrigerator may take 12to 24 hours to begin making ice.
Power Automatic lcemaker (onsome models)
Switch ¸¸¸¸¸¸¸¸¸¸¸¸¸¸¸¸¸¸
PowerLight eeer rm
The icemaker will produce se;en cubes
per c) cle_ai)i)roxinmtel,_ 100-130 cubes
in a 94-hour i)efiod, depending (m fl'eezer
COillpai'tlllent teillpei'att/i'e, i'OOill
temperatm'e, nmnber of door openings
and other use conditions.
See below for how to access ice and reach
the power switch.
If the refl_igerator is operated before the
water cmmection is made to the icemake_;
set the power switch in the 0 (off) position.
The icemaker power light will mrn green
when the fl'eezer light switch is pressed in
or when the fl'eezer door is closed.
When the reflJgerator has been connected
to the water sui)ply, set the power switch to
the I (on) position.
Tile icemaker Mll fill Mth water when it
cools to 15°F (-10°C). A newly installed
refi_igemtor may take 12 to 24 hems to beg_n
making ice cubes.
Y)u will hear a buzzing sotmd each tilne
the icemaker fills with water;
Throw away the first ti_w batches of ice to
allow the water line to clem:
Be sm'e nothing interti_res with the sweep
of the libeler amL
_&]_en the bin fills to the level {ff the teeler
aml, the icemaker will stop producing
ice. It is nomml ti)r several cubes to be
joined together:
If ice is not used frequenfl 5 old ice cubes
will become cloud}; taste stale and shrink.
NOTE: Inhomes with lower-than-averagewater
pressure,youmayhear the icemakercycle mu/t))/e
tknes whenmaking onebatchof ice.
Toreach the power switch.
Accessing Ice and Reaching
the Power Switch
Toreach the icemaker power switch, pull the
shelf above the ice bin straight out. _Mwaxs
be sure to replace the shell
To access ice, simply pull the bin fiwward.
7-0 aCCeSS ice,
Icemaker Accessory Kit
If your refligerator did not come ah'eadv
equil)ped with an automatic icemake_;
an icemaker accessory kit is available at
exti'a cost.
Check the back of the refl_igerator for
the spedfic icemaker kit needed fi)r
VOI.II" nlodel.
i;i iiiiii!!iiiiiiiiiii!!i iii iii!i
12
To Use the Dispenser (onsomemodels)
The water dispenser is located on the left
wall inside the reii_igerator compartment.
To dispense water:
Hold the glass against the recess.
Push the water dispenser button.
Hold the glass tmderneath tile
dispenser Ira" 2-3 seconds alier
releasing the dispenser button.
Water InaV continue to dispense
alter the buttoI_ is released.
If nowaterisdispensedwhentherefwemtorisfirst
installed,theremaybeairin thewaterlinesystem.
Pressthedispenserbuttonforat/east2minutesto
removetrappedair fromthewaterfineandtoill/the
watersystem.Duringthisprocess,thedispenser
noisemaybeloudastheairispurgedfromthe
waterlinesystem.Toflushouti_npuritiesin the
waterline,throwawaythefirst6glassfulsofwater
NOTE:Toavoidwater deposits,thedispenser
shouldbe cleanedperiodicaflyby wipingwith a
cleancloth orsponge.

Careand cleaning oftherefrigerator, vvww.GEAppliances.com
Cleaning the Outside
The doorhandles and trim. Clean with a cloth
daml)ened with soapy water: Dry with a sott
cloth. Do not use wax on the door handles
and trim.
Keep the outside clean. _A]l)e Mth a clean
cloth lightly dampened Mth kitchen
appliance wax or mild liqlfid dish
detergent. D_3' and polish with a clean,
soft cloth.
Do not wipe the refngerator with a soiled dish
cloth or wet towel Thesemay leave a residue
that can erode the pa/n_ Do not usescouring
pads,powdered cleaners, bleach or cleaners
contein/ng bleach because these products can
scratch and weaken the paint finish.
The stainless steel panels and doorhandles.
Stainless steel (on some models) can be
cleaned with a commerdallv available
stainless steel cleanex: A spray-on stainless
steel cleaner works best.
Do not use appliance wax or polish
on the stainless steel,
Cleaning the Inside
Tohelp prevent odors, leave an open be× _:,t
baking soda in the reflJgerator and fi'eezer
COIIII)_I I'[ll/ents.
Unplug the refrigerator before cleaning. If this
is not practical, wring excess moisture ()tit
of sponge or cloth when cleaning arotmd
switches, lights or controls.
Lrse an appliance wax polish on the inside
sml'hce between the do(n_.
Use warn/ water and baking soda solution--
about a tnblesl)oon (15 ml) of baking soda
to a quart (l liter) oI water: This both cleans
and neutralizes odo_. Rinse and wipe (h_'.
_Mter cleaning the door gaskets, apply a
thin layer of petrolemnjelly to the door
gaskets at the hinge side. This helps kee I)
the gaskets ti'om sticking and bending out
of shape.
Avoid cleaning cold glass shelves with hot water
because the extreme temperature difference may
cause them to break. Handle glass shelves
carefull_z Bumping tempered g/ass can cause
it to shatter
Donot washanyplasticrefrigeratorpartsin
thedishwasher
/3

Careand cleaning oftherefrigerator.
Behind the Refrigerator
Be caretul when moving the refl_igerator
away fl'om the wall. MI types of floor
coverings can be (lamaged, particularly
cushioned coverings and those with
embossed stiFf,ices.
Pull the retiigerator straight out and return
it m position by pushing it straight in.
Moving the refligerator in a side direction
may result in damage to the floor covering
or reffigeratoi:
When pushing the refrigerator back, make sure
you don't rofl over the power cord or icemaker
supply line {onsome models).
Preparing for Vacation
For long \;l(-ations or absen(-es_ i'eillOVe
food and unplug the reli_igerattn: Move
the ti'eezer control to the 0 (0f0 position,
and clean the inmrior with a baking soda
solution of one tablespoon (l 5 ml) _ff
baking soda to one qtlart (1 liter) of wami:
i,eave the clom_ open.
Set the icemaker power switch to the 0(off)
position and shut off the water supply to
the reffigeratm:
If tile temperature can drop below
freezing, have a qualified servicer drain the
water supply system (oil some models) to
prevent serious propel F dmnage due to
flooding.
Preparing to Move
Secm'e all loose items such as base grille,
shelves and drawei_ by taping them
seetlrely in place to prevent danmge.
_]_en using a hand truck to move tile
refl_igeratoi; do not rest the flxmt or back
of the reti_igerator against the hand truck.
This could danmge the reti_igeratm: Handle
only ti'om the sides ot the reti_igeratm:
Besurethere{ngerator staysin anupwht
positionduringmowbg
14

Replacingthe lightbulbs, vvvvw.GEAppliances.com
Turning the control to the 0(off) position does not remove power to the light circuit.
Refrigerator Lights
CAUTION:ah,b./bsmaybeho_
0 Unplug the refl_geratoi:
@ Tile bulbs are located at tile top of tile
refl_gerator compartment behind tile
controls. To remoxe the light shield,
,grasI ) the shield at the back and pull
out to release the tabs at the back.
_]_ Rotate tile shield down and then
fin'ward to release the tabs at the fl'ont
of the shield.
_Mter replacing with an appliance bulb
of the same or lower wattage, replace
the shield.
0 Plug tile refl_igerator back in.
Appearance may vary
Freezer Light
P' CAUTION:L,_h,b.lbsma_beho_
Unplug tile reti_igerato_:
0 Tile bulb is located at tile top of tile
freezer inside a light shield. To relnove
the shield, grasp the shield at the back
and pull out to release tile tabs at tile
back.
Rotate tile shield down and then
forward to release the tabs at the fl'ont
of the shield.
@ _Mter replacing with an appliance bull)
of the same or lower wattage, replace
the shield.
0 Plug tile refl_igerator back in.
15

Installation
Instructions Refrigerator
Models 20 and 22
I Questions? Call 800.GE.CARES (800.432.2737) or Visit our Website at: www.GEAppliances.com
In Canada, call 1.800.361.3400 or Visit our Website at: www.geappliances.ca I
BEFORE YOU BEGIN
Read these instructions completely
and carefully.
• IMPORTANT - Savethese
instructions for local inspector's use.
• IMPORTANT - Observeall
governing codes and ordinances.
•Note to Installer -Be sure to leave these
instructions with the Consumer.
•Note to Consumer - Keep these
instructions for future reference.
•Skill level - Installation of this appliance
requires basic mechanical skills.
• Completion time -Refrigerator Installation
20 minutes
Water Line Installation
30 minutes
• Proper installation is the responsibility of
the installer.
•Product failure due to improper installation
is not covered under the Warranty.
PREPARATION
MOVING THE REFRIGERATOR INDOORS
If the refrigerator will not fit through a doorway,
the refrigerator door and freezer drawer or door
(depending on model) can be removed.
• To remove the refrigerator door, see Step 1
in the Reversing the Door Swing section.
• To remove the freezer drawer, see the
Removing the Freezer Drawer section.
• To remove the freezer door, see Steps 2
and 3 in the Reversing the Door Swing
section.
PREPARATION (cont.)
WATER SUPPLY TO THE ICEMAKER AND
DISPENSER (ON SOME MODELS)
If the refrigerator has an icemaker, it will have
to be connected to a cold water line. AGE water
supply kit (containing tubing, shutoff valve,
fittings and instructions) is available at extra
cost from your dealer, by visiting our Website
at www.GEAppliances.com (in Canada at
www.geappliances.ca) or from Parts and
Accessories, 800.626.2002 (In Canada
1.888.261.3055).
TOOLS YOU MAY NEED
Adjustable Wrench 3/8" and 10 mm Socket
Drivers
1/4" Outer Diameter
Compression Nut
and Ferrule (sleeve)
(icemaker models only)
3/32" Allen wrench
supplied for use on
Stainless steel
refrigerator handles
(on some models)
Phillips Head Screwdriver
l
1/4" Allen wrench supplied
for changing handle
fasteners location
(on some models)
16

Installation Instructions
INSTALLING THE REFRIGERATOR
REFRIGERATOR LOCATION
• Do not install the refrigerator where the
temperature will go below 60°F (16°C) because it
will not run often enough to maintain proper
temperatures.
• Do not install the refrigerator where the
temperature will go above IO0°F (37°C) because it
will not perform properly.
•Install it on a floor strong enough to support it fully
loaded.
CLEARANCES
Allow the following clearances for ease of installation,
proper air circulation and plumbing and electrical
connections.
Sides 1/8" (4 mm)
Top 1" (25 mm)
Back 1" (25 mm)
REMOVE TOP CAP (onsomemodels)
•IMPORTANT NOTE: This refrigerator is34-1/2" deep.
Doors and passageways leading to the installation
location must be at least 36"wide in order to
leave the doors and handles attached to the
refrigerator while transporting it into the installation
location. If passageways are lessthan 36", the
refrigerator doors and handles can easily be scratched
and damaged. The top cap and doors can be removed
to allow the refrigerator to be safely moved indoors.
Start with Step A.
•If it isnot necessary to remove doors, skip Step A.
Leave tape and all packaging on doors until the
refrigerator is in the final location.
•SKID REMOVAL: lilt refrigerator to each side to
remove skid.
•NOTE: Use a padded hand truck to move this
refrigerator. Place the refrigerator on the hand
truck with a side against the truck. We strongly
recommend that TWO PEOPLE move and complete
this installation.
[] Locate and remove the two Phillips head screws
on the top of the refrigerator. Remove the two
screws on each side at the rear of the top cap.
Lift off and remove top cap.
[] Remove the fresh-food door. Refer to Steps 1
through 3 of "Reversing the Door Swing" section.
[] Remove the bottom freezer drawer. Refer to
"Removing Freezer Drawer" section.
[] Move refrigerator to the installation location.
REMOVE TOP CAP (cont.)(onsomemodels)
REINSTALL DOORS, DRAWERS AND TOP CAP
[] Carefully lower the door onto the center hinge.
Reinstall top hinge. NOTE: Ensure the door is
properly aligned to the case top to avoid
readjustment of the door during top cap
reinstallation.
[] Place cap over the top of the refrigerator. Reinstall
the original screws in the top and back of the cap.
[] Reinstall the bottom freezer drawer. Refer to
"Replacing the Freezer Drawer" section.
A,
[] CONNECTING THE REFRIGERATOR
TO THE HOUSE WATER LINE
(icemaker and dispenser models)
A cold water supply is required for automatic
icemaker operation. If there is not a cold water
supply, you will need to provide one. See
Installing the Water Line section.
NOTES:
• Before making the connection to the
refrigerator, be sure the refrigerator power cord
is not plugged into the wall outlet.
• If your refrigerator does not have a water filter,
we recommend installing one if your water
supply has sand or particles that could clog the
screen of the refrigerator's water valve. Install it
in the water line near the refrigerator. If using
GE SmartConnect TM Refrigerator Tubing Kit, you
will need an additional tube (WXO8XIO002) to
connect the filter. Do not cut plastic tube to
install filter.
17

Installation Instructions
INSTALLING THE REFRIGERATOR (cont,)
[] CONNECTING THE REFRIGERATOR
TO THE HOUSE WATER LINE
(cont.)
[] If you are using copper tubing, place a
compression nut and ferrule (sleeve) onto
the end of the tubing coming from the
house cold water supply.
If you are using the GE SmartConnect TM
tubing, the nuts are already assembled to
the tubing.
[] If you are using copper tubing, insert
the end of the tubing into the refrigerator
connection, at the back of the refrigerator,
as far as possible. While holding the
tubing, tighten the fitting.
If you are using GE SmartConnect TM
tubing, insert the molded end of the
tubing into the refrigerator connection,
at the back of the refrigerator, and tighten
the compression nut until it is hand tight.
Then tighten one additional turn with a
wrench. Overtightening may cause leaks.
[] Fasten the tubing into the clamp provided
to hold it in position. You may need to pry
open the clamp.
One of the illustrations below will look like
the connection on your refrigerator.
Icemaker-Ready models
1/4" -- Tubing
Copper Clamp
Tubing
1/4"
Compression
Nut
(sleeve)
SmartConnect T"
Tubing gerator
Connection
Icemaker-lnstalled Models
Refrigerator Ferrule
Connection 1/4" Tubing
[] TURN ON THE WATER SUPPLY
(icemaker and dispenser models)
Turn the water on at the shutoff valve
(house water supply) and check for
any leaks.
[] PLUG IN THE REFRIGERATOR
On models with an icemaker, before
plugging in the refrigerator, make sure
the icemaker power switch is set to the
O (off) position.
%
%
See the grounding information attached
to the power cord.
[] PUT THE REFRIGERATOR
IN PLACE
Move the refrigerator to its final location.
18

Installation Instructions
[] REMOVE THE FRESH FOOD
DOOR HANDLE
(For placement in the installation
location or reversal of the handles -
on some models)
Stainless steel (on some models):
O REMOVING
THE DOOR
HANDLE: Loosen
the set screws
with the 3/32"
Allen wrench
and remove
the handle.
OREVERSING THE
DOOR HANDLE:
•Remove the
handle mounting
fasteners with a
1/4" Allen
wrench and
transfer the
O_adge
lug
utton
J
.Mounting
Fasteners
(appearance may vary)
handle mounting fasteners to the right side.
* Remove and transfer the plug button and
logo badge to the left side of the fresh food
door. NOTE: Use a flat plastic edge to prevent
damaging the door. Remove any adhesive on
the door with a mild detergent. Remove the
paper covering on the adhesive backing on
the logo badge prior to carefully attaching the
badge to the door.
Plastic handle (on some models):
REMOVING
THE DOOR
HANDLE: Slide
the handle up
on the handle
mounting
fasteners and
remove the
handle.
OREVERSING THE
DOOR HANDLE:
.Remove the
handle Button
mounting Mounting Fasteners
fasteners with a
3/8" or 10 mm (appearancemay vary)
socket wrench and transfer the handle
mounting fasteners to the right side.
.Remove and transfer the plug button and
logo badge to the left side of the fresh food
door. NOTE: Use a flat plastic edge to prevent
damaging the door. Remove any adhesive on
the door with a mild detergent. Remove the
paper covering on the adhesive backing on
the logo badge prior to carefully attaching the
badge to the door.
After removing the handle: Move the small plug
button from the top right side of the door top and
insert it into the hole on the opposite side.
(appearance may vary)
[] REMOVE THE FREEZER DOOR
HANDLE
Stainless steel handle:
O Loosen the set screws located on the underside
of the handle with the 3/32" Allen wrench and
remove the handle.
NOTE: If the handle mounting fasteners need to
be tightened or removed use a 1/4" Allen wrench.
Plastic handle:
Q Slide the handle to the right on the handle
mounting fasteners and remove the handle.
NOTE: If the handle mounting fasteners need to
be tightened or removed use a 3/8" or 10 mm
socket wrench.
Mounting
fasteners
(appearance may vary) Slots on back
of handle
19

Installation Instructions
INSTALLING THE REFRIGERATOR (cont.)
[] ATTACH THE FRESH FOOD
DOOR HANDLE
Stainless steel handle:
Attach the handle
to the handle
mounting
fasteners and
tighten the set
screws with a
3/32" Allen
wrench. Mounting
Fasteners
Plug
(appearance may vary)
Plastic handle:
O Attach the handle to the handle mounting
fasteners by aligning the slots with the handle
mounting fasteners.
0Slide it down until it is firmly locked into
position.
Mounting
fasteners Slots on back of
handle
(appearance may vary)
[] ATTACH THE FREEZER DOOR
HANDLE
Stainless steel handle:
Q Attach the handle to the mounting fasteners
and tighten the set screws on the bottom of
the handle with a 3/32" Allen wrench.
(appearance may vary)
Plastic handle:
Q Attach the handle to the mounting fasteners by
aligning the slots with the mounting fasteners.
OSlide it to the left until it is firmly locked into
position.
NOTE: A properly locked handle will be centered
on the freezer.
Mounting
fasteners
Slots on back
(appearance may vary) of handle
20
