gGE Consumer Service Training
TECHNICAL SERVICE GUIDE
g
03/99
MODEL SERIES:
ZTD910_B
ZKD910_B
ELECTRIC WARMING DRAWER
gMonogram®

Warming Drawer keeps plates warm, ready and
waiting to serve that special meal.
The Hidden Temperature Control has low, medium
and high settings as well as proof — a setting that
is ideal for the dough rising process.
A convenient Half Rack provides even heat
distribution and extra room in the drawer.
GE Profile Performance Series™
JTD910SB
• Stainless steel
• 30" warming drawer
• Temperature control with Proof, Low, Medium and High settings
• Crisp/Moist humidity control
• ON/OFF switch
• “ON” indicator light
• One-half rack
• Removable stainless steel pan for easy cleaning
• Full extension ball bearing glides
JKD910SB (not shown)
• Stainless steel
• 27" warming drawer
AMERICA ISWARMING UPTOTHIS CONVENIENT NEW APPLIANCE.
The New GE Profile Performance™Warming Drawer does more than hold food at a desired temperature, it also helps in food preparation.
Once you have it, you'll never want to be without it!
Now you can fix one or more side dishes ahead of the dinner hour and slip them into the Warming Drawer one at a time. The humidity
control lets you crisp foods or keep them moist by adding water to the sealed pan.
The GE Profile Performance™Warming Drawer comes in two sizes: 27" and 30" and is available in black, white, almond and stainless steel.
It can be installed flush under a cooktop, under a wall oven, in your kitchen island or even in your bathroom to keep towels warm.
Wherever it is used, America is warming up to the convenience that will soon be considered a necessity.

GE Profile Performance Series™
JTD910WB
• White on white
• 30" warming drawer
• Temperature control with Proof,
Low, Medium and High settings
• Crisp/Moist humidity control
• ON/OFF switch
• “ON” indicator light
• One-half rack
• Removable stainless steel pan for
easy cleaning
• Full extension ball bearing glides
JTD910AB (not shown)
• Almond on almond • 30" warming drawer
JTD910BB (not shown)
• Black on black • 30" warming drawer
JKD910WB (not shown)
• White on white • 27" warming drawer
JKD910AB (not shown)
• Almond on almond • 27" warming drawer
JKD910BB (not shown)
• Black on black • 27" warming drawer
AVAILABLE MODELS/FEATURES
ËÊ
ÌÍÎÏ
Ð
Ê Moisture Selector
ËWarming Drawer Pan
ÌModel and Serial Plate
ÍTemperature Control Knob
ÎON/OFF Switch
ÏON Signal Light
ÐON Signal Light Viewer Lens
Rack
nRack will fit from front to back.
nPreheat with the rack in place.
nUsing the rack allows for double
stacking of items.
Double stacking items with
the rack in position.

Listed by
Underwriters Laboratories
R
Note: When installing warming drawer
with a cooktop, allow a 2" minimum from
cooktop burner box bottom to top of cut-out.
JTD910SB JKD910SB
JTD910WB JKD910WB
JTD910AB JKD910AB
JTD910BB JKD910BB
Features
Temperature control ll
Proof (80°F.) ll
Low (140°F.) ll
Medium (170°F.) ll
High (210°F.) ll
Humidity control Crisp/Moist Crisp/Moist
Hidden control ll
ON/OFF switch ll
“ON” indicator light ll
Half rack ll
Full extension drawer glide ll
Removable stainless steel pan ll
Appearance SS SS
WW WW
AA AA
Color appearance* BB BB
Frameless drawer front ll
Handle style Integrated Designer-Style Integrated Designer-Style
Weights & Dimensions
Interior dimensions (WxHxD in inches) 23-7/8 x 6-1/4 x 22-1/16 20-7/8 x 6-1/4 x 22-1/16
Cutout dimensions (WxHxD in inches) 28-1/2 x 9-1/4 x 23 25-1/2 x 9-1/4 x 23
Approx. shipping weight (lbs.) 65 59
Power/Ratings
KW rating @ 120V .45 .45
Amps @ 120V 15 15
Element wattage 450 450
Accessories
1/4" panel kit capability ZXD30B ZXD27B
Pan set (5 pans with lids) JXPN1 JXPN1
*SS = Stainless Steel, WW = White on white, AA = Almond on almond, BB = Black on black.
30" Warming Drawers 27" Warming Drawers
GE Profile Performance Series
™
AB
30" Models 28-1/2 30
27" Models 25-1/2 26-3/4
Dimensions (in inches)
A
9-1/4
Locate Electrical
Outlet in Adjacent
Cabinet no Further
Than 16" From
Left Side or 42"
From Right Side.
B
10-1/2
23-1/8
23-1/2" Min.
Inside
1" Min.
Above
Toekick
or Adjust
to Oven
Installation
Height
2" Min.
Between
Cutouts
Warming Drawer Dimensions (in inches)
Under Oven Installation (in inches) Undercounter Installation (in inches)
Five commercial pans with lids (4" deep)
• One large pan (14 quarts)
• Two medium pans (6 quarts each)
• Two small pans (3 quarts each)
A
9-1/4
Locate
electrical
outlet in
Adjacent
Cabinet
16" From
Left Side
or 42"
From Right
Side.
B
10-1/2
24"
Recommended
From Floor
For Under
Countertop
Installation
23-1/8
23-1/2" Min.
Inside
Electrical
Outlet 16" Max.
From Left Side.
23-1/2"
Min.
25" 1-1/2" Cabinet Top
36"
Countertop
Height
2"Min.
A9-1/4"
Electrical Outlet 42" Max.
From Right Side.
Electrical Outlet
Flush with Side
of Cabinet. 7" Max.
2x4 or 2x2
runners or Solid
Bottom
Install
2x4 or 2x2
Anti-Tip
Block 9"
From Floor
to Bottom
of Block
9
(Must Support 100 LBS.)
30" AND 27" WARMING DRAWERS
Pan Set Accessory For Warming Drawer - JXPN1

The warming drawer will keep hot, cooked foods at serving te mperature. Always start with hot food.
Do not use to heat cold food other than proofing yeast dough , crisping crackers, chips or dry cereal.
Control Knob
The warming drawer controls are hidden
with the drawer shut. Open the drawer.
The controls are on the right side of the
front frame.
To use the warming drawer, press the
ON/OFF switch to the ON position.
Slide the moisture selector control to the
open or closed setting.
(See the Moisture
Selector section.)
Turn the control knob to the desired
setting.
PROOF . . . . . . . . . . . . . . . . . .75–95°F
LOW . . . . . . . . . . . . . . . . . . . .140–160°F
MED . . . . . . . . . . . . . . . . . . . .160–195°F
HIGH . . . . . . . . . . . . . . . . . . .195–230°F
PROOF
HI MED
LO
USE & CARE
ON Signal Light
The ON signal light is located below the ON/OFF
switch and glows when the ON/OFF switch is in the
ON position. It stays on until theON/OFF switch is
moved to the OFF position.
The ON signal light is visible through the light viewer
in the drawer front panel when the drawer is closed.
This is a reminder that the heat is on.
Moisture Selector
The moisture selector is located on the inside front
of the drawer.
Tokeep foods moist, slide the moisture selector
control away from the control knob. This closes the
vent and seals the moisture inside the drawer. With
the vent closed hot foods stay moist and soft.
In this setting condensation may occur around the inside edge of
the drawer.
Tokeep foods crisp slide the moisture selector control
to the right towards the control knob. This opens the
vents and allows the moisture to escape.
With the vents open, it is normal for moisture to collect on
surfaces above the warming drawer.
When using the warming drawer . . .
Do not line the warming drawer with aluminum foil.
oAllow time for the drawer to be preheated:
PROOF or LOW 15 minutes
MED 25 minutes
HIGH 35 minutes
nFood in heat-safe glass and glass ceramic
utensils may need a higher thermostat setting as
compared to food in metal utensils.
nRepeated opening of the drawer allows the hot air
to escape and the food to cool. Allow extra time for
temperature inside the drawer to stabilize after
adding items.
nWith large loads it may be necessary to use a
higher thermostat setting and cover some of the
cooked food items.
nFood should be kept hot in its cooking container
or transferred to a heat-safe serving dish.
Aluminum foil may be used to cover food.
CAUTION: Plastic containers or plastic wrap can melt if in
direct contact with the drawer or a hot utensil. If it melts onto
the drawer, it may not be removable.
nRemove serving spoons, etc., before placing
containers in warming drawer.
MOIST
CLOSED
VENT
CRISP
OPEN
VENT

L1N
HEATING
ELEMENT TEMPERATURE CONTROL
ON SIGNAL
LIGHT
ON/OFF
SWITCH
31W
WBK
RBK
W
R
Proof 75-95° F.
Low 140-160° F.
Med 160-195° F.
High 195-230° F.
Remove Warming
Drawer Pan
SERVICEABILITY
With warming pan &
drawer front removed,
remove 4 screws
which secure warming
drawer chassis to
cabinets. Pull chassis
forward to access side
panel
Remove drawer front
by lifting up on side rail
release levers. Firmly pull
the drawer front away
from the chassis.
RELEASE
LEVER
THERMOSTAT
LAMP
ON/OFF
SWITCH
HEATING
ELEMENT
LEADS
POWER
CORD
Remove right side panel
to access electrical
components & wiring
HEATING
ELEMENT
THERMO.
BULB
Note location of heating
element and thermostat
sensing bulb
To access electrical components
follow the steps listed below:
Ê
Ë
Í
Ì
Î
Î
SCHEMATIC DIAGRAM
