GE Monogram ZTD910WBWW Manual

Monogram.
™
Specification Revised 11/99
ZTD910WBWW - GE Monogram 30" Warming Drawer
For answers to your Monogram,®
GE Profile Performance Series,™
GE Profile™or GE appliance questions, call
GE Answer Center®service, 800.626.2000.
R
Listed by
Underwriters
Laboratories
26"
Including Handle
23-1/4"
30"
10-1/2"
9"
1"
Drawer
Open
27"
Warming Drawer Dimensions (in inches)
1" Min. Above Toekick or Adjust
to Oven Installation Height
28-1/2"
2" Min.
Allow 5/8"
Overlap on
All Sides
30"
10-1/2"
23-1/4"
23-1/2" Min.
Inside
Oven
Cutout
9-1/4"
2x2 or 2x4
Anti-Tip Block
Against Rear
Wall, 9" From
Floor to
Bottom of
Block
9"
Single Oven Installation (in inches)
28-1/2"
2" Min.
Allow 5/8"
Overlap on
All Sides
30"
10-1/2"
23-1/4"
23-1/2" Min.
Inside
1" Min. Above Toekick
Oven
Cutout
2x2 or 2x4
Anti-Tip Block
Against Rear
Wall, 9" From
Floor to
Bottom of
Block
9"9-1/4"
Double Oven Installation (in inches)
Important Installation Note:
Must provide anti-tip brace at the back of the cabinet and at the top of
the cutout.
Optional Accessories:
JXPN1–Optional Pan Set Accessory for Warming Drawer.
Five commercial pans with lids (4” deep)
• One large pan (14 quarts)
• Two medium pans (6 quarts each)
• Two small pans (3 quarts each)
ZXD30B–1/4” wood panel trim kit
Electrical
Outlet 16" Max.
From Left Side.
23-1/2" Min.
25" 1-1/2" Cabinet Top
36"
Countertop
Height
2" Min.*
28-1/2" 9-1/4"
Electrical Outlet 42" Max.
From Right Side.
Electrical Outlet
Flush With Side
of Cabinet 7" Max.
9"
Install
2x4 or 2x2
Anti-Tip Block
Against Rear
Cabinet Wall
9" From Floor
to Bottom
of Block 7"
Undercounter Installation (in inches)
Note: When installing warming drawer with a cooktop, allow a 2”
minimum from cooktop burner box bottom to top of cut-out.
Note: Additional clearance between cutouts may be required.
Check to be sure that oven supports above the Warming
Drawer location do not obstruct the required interior 23-1/2”
depth and 9-1/4” height.
9"
2x4 or 2x2
Runners or Solid Bottom
Install
2x4 or 2x2
Anti-Tip Block
Against Rear
Cabinet Wall
9" From Floor
to Bottom
of Block

Monogram.
™
Specification Revised 11/99
ZTD910WBWW - GE Monogram 30" Warming Drawer
Features and Benefits
• 1.92 cu. ft Capacity
• Variable Temperature Control - Proof(80) /
Low(140) / Med(170) / High(210)
• Variable Humidity Control - Crisp to Moist
• Half Rack
• "On" Signal Light
• On/Off Rocker Switch
• Removable Stainless Steel Pan
• Full Extension Ball Bearing Glides
• Hidden Controls Provide Flush
Installation Appearance
• Variable Installation Options
• Model ZTD910WBWW - White on white
• Model ZTD910BBBB - Black on black
• Model ZTD910SBSS - Stainless steel
