GE WNRD2050GWC User manual

ge.com
175D1807P590 49-90322-2 10-08 JR
Washers
WNRD2050
Owner’s Manual
Safety Information . . . . . . . . . .2, 3
Operating Instructions
Control Panel . . . . . . . . . . . . . . . . . . . . . .4
Control Settings . . . . . . . . . . . . . . . . . . .5
Loading and Using
the Washer . . . . . . . . . . . . . . . . . . . . .6, 7
Washer Features . . . . . . . . . . . . . . . . . .6
Troubleshooting Tips . . . . . .8–12
Consumer Support
Consumer Support . . . . . . .Back cover
Warranty . . . . . . . . . . . . . . . . . . . . . . . .16
Write the model and serial
numbers here:
Model # ________________
Serial # ________________
You can find them in the upper
right corner on the back of your
washer.
Laveuses
Lavadoras
Manuel d’utilisation
Manual del propietario
La section française commence à la page 17
La sección en español empieza en la página 33
P590

■Install or store where it will not be exposed to
temperatures below freezing or exposed to
the weather.
■Remove the colored protective film from the
control panel.
■Properly ground washer to conform with all
governing codes and ordinances. Follow details
in Installation Instructions.
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
2
WARNING! For your safety, the information in this manual must be followed to minimize the
risk of fire or explosion, electric shock, or to prevent property damage, personal
injury, or loss of life.
WATER HEATER SAFETY
Under certain conditions hydrogen gas may be produced in a water heater that has not been used for
two weeks or more. Hydrogen gas can be explosive under these circumstances.
If the hot water has not been used for two weeks or more, prevent the possibility of damage or injury
by turning on all hot water faucets and allowing them to run for several minutes. Do this before using
any electrical appliance which is connected to the hot water system. This simple procedure will allow
any built-up hydrogen gas to escape. Since the gas is flammable, do not smoke or use an open flame
or appliance during this process.
PROPER INSTALLATION
This washer must be properly installed and located in accordance with the Installation Instructions before
it is used. If you did not receive an Installation Instructions sheet, visit our Website at: ge.com.
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
■Keep the area underneath and around your
appliances free of combustible materials such
as lint, paper, rags, chemicals, etc.
■Close supervision is necessary if this appliance is
used by or near children. Do not allow children to
play on, with, or inside this or any other appliance.
YOUR LAUNDRY AREA

Consumer Support
Troubleshooting TipsOperating InstructionsSafety Instructions
■Never reach into washer while it is moving. Wait
until the machine has completely stopped before
opening the lid.
■Do not mix chlorine bleach with ammonia or acids
such as vinegar and/or rust remover. Mixing
different chemicals can produce a toxic gas which
may cause death.
■Do not wash or dry articles that have been cleaned
in, washed in, soaked in, or spotted with combustible
or explosive substances (such as wax, oil, paint,
gasoline, degreasers, dry-cleaning solvents, kerosene,
etc.) which may ignite or explode. Do not add these
substances to the wash water. Do not use or place
these substances around your washer or dryer
during operation.
■ The laundry process can reduce the flame
retardancy of fabrics. To avoid such a result,
carefully follow the garment manufacturer’s wash
and care instructions.
■To minimize the possibility of electric shock, unplug
this appliance from the power supply or disconnect
the washer at the household distribution panel
by removing the fuse or switching off the circuit
breaker before attempting any maintenance or
cleaning. NOTE: Pressing PAUSE or STOP/CANCEL
does NOT disconnect the appliance from the power
supply.
■Never attempt to operate this appliance if it is
damaged, malfunctioning, partially disassembled, or
has missing or broken parts, including a damaged
cord or plug.
WHEN USING THE WASHER
■Turn off water faucets to relieve pressure on hoses
and valves and to minimize leakage if a break or
rupture should occur. Check the condition of the fill
hoses; they should be replaced every 5 years.
■Before discarding a washer, or removing it from
service, remove the washer lid to prevent children
from hiding inside.
■Do not attempt to repair or replace any part of this
appliance unless specifically recommended in this
Owner’s Manual, or in published user-repair
instructions that you understand and have the
skills to carry out.
■Do not tamper with controls.
WHEN NOT IN USE
READ AND FOLLOW THIS SAFETY INFORMATION
CAREFULLY.
SAVE THESE INSTRUCTIONS
3
Use this
appliance
only for its
intended
purpose as
described
in this
Owner’s
Manual.

Quick Start Guide
• Add detergent
• Add clothes • Select wash cycle
• Check load size setting
• Close lid
• Push START
4
Your new washer offers the convenience of starting your wash loads by simply choosing a CLOTHES CARE SELECTION. Then all you
have to do is press START.
About the control panel.
Vision-Impaired Washer/Dryer Kit
For washer model WNRD2050 and dryer model DNCD450, a kit is available for the vision-impaired containing Braille overlays that fit
over the pads on the washer and dryer control panels.
Included in the kit are:
■Braille overlays for the washer and dryer control panels
■Braille Reference Keys that explain the operation of the washer and dryer
■Use and Care Audio Tape
Order publication number 14-D242, available from your GE supplier.
For best results, GE recommends use of dryer sheets to freshen clothes and reduce static cling. If you prefer to use liquid fabric softener,
please add near the end of the wash (agitate) portion of the cycle, before the water drains. The “washing” light will flash when it is time to add
fabric softener. Use of liquid fabric softener during the low-water, high-efficiency rinse can cause spotting on clothes. Rewashing will remove
these spots.

5
About the control settings.
CLOTHES CARE SELECTION
For heavily to lightly soiled cottons, household linens, work and play clothes.
For heavily to lightly soiled cottons, household linens, work and play clothes.
For non-colorfast cottons and blends, and items that are labeled cold wash by the fabric manufacturer.
For knits, wrinkle-free and permanent press items.
For lingerie and items labeled delicate with light soils. Provides periods of agitation and soak
during wash.
Spin and drain any cycle at any time.
LOAD SIZE
A LOAD SIZE setting is automatically set when the CLOTHES CARE SELECTION is chosen. The LOAD SIZE setting
can be changed by pressing the pad for the size you want.
Loosely load clothes no higher than the top row of holes in the washer basket. The water level should just cover the
clothes.
START/PAUSE
Press START to begin the cycle. Pressing START again or raising the lid will PAUSE the cycle.
■ Press twice to select the last cycle used and start the washer.
■ If the washer is running, press once to interrupt the cycle; press again to continue the cycle.
1
2
3
STOP/CANCEL
This pad should not be used to interrupt or pause a cycle.
Pressing this pad will cancel the current settings and the settings will be lost.
Estimated Time Remaining
■Displays the approximate time remaining until the end of the cycle.
■If the estimated time remaining is more than 60 minutes, “1H” will flash in the display, followed by the additional
remaining minutes. When the time remaining is less than 60 minutes, the timer will count down.
■Cycle time is affected by how long it takes the washer to fill. This depends on the water pressure in your home.
The “smart” timer “learns” the amount of time it takes to fill your washer and adjusts the total time accordingly.

Operating Instructions Safety Instructions
Consumer Support Troubleshooting Tips
6
About washer features.
The Agitator Cap
The agitator cap fits into the top of the
agitator. If it accidentally comes off, simply
put it back on.
Liquid Bleach Dispenser
The dispenser dilutes liquid chlorine bleach before it reaches into your wash load.
Check clothing care labels for special instructions.
Measure liquid bleach carefully, following instructions on the bottle.
■ Never pour undiluted liquid chlorine bleach directly onto clothes or into the wash basket.
■ Do not pour powdered bleach into bleach dispenser.
Before starting the washer, pour measured amount of bleach directly into bleach
dispenser. Avoid splashing or over-filling dispenser. If you prefer to use powdered bleach,
add it into the wash basket with your detergent.
■ Do not mix chlorine bleach with ammonia or acids such as vinegar and/or rust remover.
Mixing can produce a toxic gas which may cause death.
3
2
1
Loading and using the washer.
Always follow fabric manufacturer’s care label when laundering.
Sorting Wash Loads
Proper Use of Detergent
Using too little or too much detergent is a common
cause of laundry problems.
You can use less detergent if you have soft water,
a smaller load or a lightly soiled load.
Loading the Washer
Load dry items loosely, no higher than the top row
of holes in the washer basket. When loading wet
items, make sure you set the load/water level high
enough to allow the items to move freely. Water
level should just cover the clothes. To add items
after washer has started, lift the lid and submerge
additional items next to the agitator.
■Do not wrap long items like sheets or pants
around the agitator.
■Do not wash fabrics containing flammable
materials (waxes, cleaning fluids, etc.).
■Agitation will not start with the lid up.
Sort by color (whites, lights, colors), soil level,
fabric type (sturdy cottons, easy care, delicates)
and whether the fabric produces lint (terry cloth,
chenille) or collects lint (velveteen, corduroy).
Do not pour anything into the agitator
if the agitator cap is removed.

Consumer Support
Troubleshooting TipsOperating InstructionsSafety Instructions
7
Care and Cleaning of the Washer
Wash Basket: Leave the lid open after washing to
allow moisture to evaporate. If you want to clean the
basket, use a clean soft cloth dampened with liquid
detergent, then rinse. (Do not use harsh or gritty
cleaners.)
Fill Hoses: Hoses connecting washer to faucet should
be replaced every 5 years.
Exterior: Immediately wipe off any spills. Wipe with
damp cloth. Try not to hit surface with sharp objects.
Moving and Storage: Ask the service technician to
remove water from drain pump and hoses. See the
Installation Instructions packed with the product for
information on how to reinstall the shipping rod to keep
the tub stationary when moving the washer. For more
information, visit ge.com, or call 800.GE.CARES
(800.432.2737). Do not
store the washer where it will
be exposed to the weather.
Long Vacations: Be sure water supply is shut off at
faucets. Drain all water from hoses if weather will
be below freezing.
Loading and using the washer.
Always follow fabric manufacturer’s care label when laundering.

8
Before you call for service…
Troubleshooting Tips
Save time and money! Review the charts on the following
pages first and you may not need to call for service.
PERFORMANCE Possible Causes What To Do
Clothes too wet Water temp selection • Some fabrics will feel wetter when rinsed with cold water.
Colored spots Use of fabric softener • For best results, GE recommends use of dryer sheets to
freshen clothes and reduce static cling. If you prefer to use
liquid fabric softener, please add near the end of the wash
(agitate) portion of the cycle, before the water drains. The
“washing” light will flash when it is time to add fabric
softener. Use of liquid fabric softener during the low-water,
high-efficiency rinse can cause spotting on clothes.
Rewashing will remove these spots.
Dye transfer • Sort whites or lightly colored items from dark colors.
Grayed or yellowed Not enough detergent • Use more detergent (especially with larger loads). Be sure
clothes to follow detergent manufacturer’s directions.
Hard water • Use a water conditioner like Calgon brand or install
a water softener.
Water is not hot enough • Make sure water heater is delivering water at
120°F–140°F (48°C–60°C).
Washer is overloaded • Select load size to match clothes load.
Detergent is not • Add detergent as wash basket fills with water before
dissolving you load clothes.
Dye transfer • Sort clothes by color. If fabric label states wash separately,
unstable dyes may be indicated.
Lint or residue on Clothes are air or line dried • If you do not dry your clothes with a clothes dryer, your
clothes clothes may retain more lint.
Incorrect sorting • Separate lint producers from lint collectors.
Detergent not dissolving • Add detergent as wash basket fills with water, before you
load clothes.
•Try a liquid detergent.
•Use warmer water temperature.
Overloading • Load clothes no higher than the top row of holes in the
washer basket.
•Make sure load size selected matches clothes load size.
Incorrect use of fabric softener • See actions under “Colored spots.”
Pilling Result of normal wear on • While this is not caused by the washer, you can slow the
poly-cotton blends and pilling process by washing garments inside out.
fuzzy fabrics
Operating Instructions Safety Instructions
Consumer Support Troubleshooting Tips

9
Consumer Support
Troubleshooting TipsOperating InstructionsSafety Instructions
PERFORMANCE (cont.) Possible Causes What To Do
Snags, holes, tears, rips Pins, snaps, hooks, sharp • Fasten snaps, hooks, buttons and zippers.
or excessive wear buttons, belt buckles, •Remove loose items like pins, objects in pockets
zippers and sharp objects and sharp buttons.
left in pockets •Turn knits (which snag easily) inside out.
Undiluted chlorine bleach • Check bleach package instructions for proper amount.
•Never add undiluted bleach to wash or allow clothes
to come in contact with undiluted bleach.
Chemicals like hair bleach • Rinse items that may have chemicals on them before
or dye, permanent wave washing.
solution
Wrinkling Improper sorting • Avoid mixing heavy items (like work clothes) with
light items (like blouses).
•Try a fabric softener.
Overloading or • Load your washer so clothes have enough room to move
incorrect water level freely with water covering all of the clothes.
Incorrect wash and • Match Cycle selection to the type of fabric you are
dry cycles washing (especially for easy care loads).
Repeated washing in • Wash in warm or cold water.
water that is too hot
OPERATION Possible Causes What To Do
Washer pauses The DELICATES cycle was chosen • This is normal. The DELICATES cycle has a short soak
during wash cycle period.
Washer pauses during This is normal • The washer may pause during the spin cycle to remove
spin cycle soapy water more efficiently.
Washer won’t operate Washer is unplugged • Make sure cord is plugged securely into a working outlet.
Water supply is turned off • Turn both hot and cold faucets fully on.
Controls are not set properly • Check controls.
Lid is open • Close lid.
Circuit breaker/fuse is • Check house circuit breakers/fuses. Replace fuses or
tripped/blown reset breaker. Washer should have separate outlet.
Electronics need to be reset • Unplug washer, wait 2 minutes, plug back in
and press START.
START was not pressed • Press START.
Extremely low water pressure • Press START again.
Lid magnet missing • Call for service.

10
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
WATER Possible Causes What To Do
Too many suds Type of detergent • Switch to HE detergent.
Very soft water • Try less detergent.
Too much detergent • Measure your detergent carefully. Use less soap if you
have soft water, a smaller load or a lightly soiled load.
Water leaks Fill hoses or drain hose is • Make sure hose connections are tight at faucets and
improperly connected at washer.
•Make sure end of drain hose is properly connected
to washer and correctly inserted in and secured to
drain facility.
Household drain may • Check household plumbing. You may need to call a
be clogged plumber.
Constant water pressure • Tighten hoses at the faucets and turn the water off after
to the fill hoses at the each use.
water source •Check condition of the fill hoses; they should be replaced
every 5 years.
Using too much detergent • Use less detergent. Use less soap if you have soft water, a
in washer smaller load or a lightly soiled load.
Water temperature Cooler water temperatures • New laundry detergents have been formulated to work
seems incorrect provide improved energy with cooler water temperatures without affecting wash
efficiency performance.
Control is not set properly • Check cycle selection and adjust.
Water supply is turned off • Turn both hot and cold faucets fully on and make sure
or improperly connected hoses are connected to correct faucets.
Water valve screens are • Turn off the water source and remove the water connection
stopped up hoses from the upper back of the washer. Use a brush or
toothpick to clean the screens in the machine. Reconnect
the hoses and turn the water back on.
House water heater is • Make sure house water heater is delivering water
not set properly at 120°F–140°F (48°C–60°C).
All the water in your household • Wait until the water in the water heater is heated to the
water heater has been used correct temperature.
Water pumped out Lid lifted or cycle was put in • Reset cycle.
before cycle is complete pause for over 24 hours
Water won’t drain Drain hose is kinked or • Straighten drain hose and make sure washer is not sitting
improperly connected on it.
•Top of drain outlet should be less than 6 ft (1.8 m)
above floor.
Water spraying during Washer in spin cycle • Spray rinse during a spin cycle is normal.
spin cycle
Before you call for service…
Troubleshooting Tips

Consumer Support
Troubleshooting TipsOperating InstructionsSafety Instructions
11
SOUNDS Possible Causes What To Do
“Metallic clicking” Shifter mechanism is engaging or • The drive system will engage at the start of agitate and
disengaging disengage when agitate is complete. This occurs multiple
times during the wash.
Back and forth “swoosh” Electric motor reversing direction • This machine has a drive system that doesn’t use gears.
or light “clicking” sound This sound is the motor rotating back and forth to
during agitate agitate your laundry.
Quick short agitation Clothing redistribution • At the end of agitate, the motor makes short agitation
sounds at end of agitate strokes to redistribute the load.
“Click” when water stops Relay switch • The relay makes a click sound when activated. The water
filling level activates the relay and stops filling.
Motor “whining up” or Motor ramping up/down during • The motor will speed up incrementally during the spin
“coasting down” in spin spin cycle cycle. When spin is complete, it will coast until it stops.
“Humming” Water drain pump • The drain pump will make a humming sound when
pumping out water after agitation stops and continue
until spin is complete.
“Gurgling” Water drain pump • When the pump starts drawing in air, it starts to gurgle. The
washer should then begin spinning and the sound will
continue until it is done spinning.
Banging noises Washer is uneven • To level the front of the washer, adjust the front leveling
legs by rotating the individual leg in the proper direction
for up or down. To level back of washer, lift back of
machine 4″(11 cm) and set down.
Washer load is • Press PAUSE to stop the washer, open the lid and
unbalanced redistribute the load evenly. Close the lid and press START.
Shipping rod is still assembled • To remove shipping rod from washer, pull yellow tag and
in unit attached rod from the bottom right hand side of washer.
Washer is sitting too close to wall • Pull washer away from the wall; about 4″(11 cm)
(causes knocking during cycle) is needed.
WATER (cont.) Possible Causes What To Do
Washer did not fill to Extremely low water pressure • Press the START button again.
Inlet hoses are kinked • Straighten hoses.
Water valve screens are • Turn off the water source and remove the water connection
stopped up hoses from the upper back of the washer. Use a brush or
toothpick to clean the screens in the machine. Reconnect
the hoses and turn the water back on.
Water fills and drains Drain stand pipe is too low • Drain stand pipe must be above 30″.
at the same time
chosen level
(START/PAUSE lights
are flashing)

OTHER Possible Causes What To Do
Labels on the exterior Occasionally the adhesive • Use a hair dryer set at the lowest heat setting, directing
of the washer will not used on the labels does the air at the label for a short amount of time. This will
peel off cleanly not release cleanly release the adhesive easily, without damaging the surface
of the washer.
Movement inside Shifting mechanism is • When the machine is manually turned off, the shifter
machine when shut off disengaging the motor will disengage the motor before completely shutting
down. If the lid is raised before the motor is disengaged,
it will resume when lid is closed.
No rinse fill This is normal • This machine uses three low-water spray rinses to remove
soap from clothes and reduce water consumption.
Operating Instructions Safety Instructions
Consumer Support Troubleshooting Tips
12
Before you call for service…
Troubleshooting Tips

Consumer Support
Troubleshooting TipsOperating InstructionsSafety Instructions
Notes.
13

Notes.
Operating Instructions Safety Instructions
Consumer Support Troubleshooting Tips
14

Consumer Support
Troubleshooting TipsOperating InstructionsSafety Instructions
Notes.
15

GE Commercial Washer Warranty.
Parts and service are available from your General Electric
Commercial Laundry distributor.
Please have serial number and model number available when
calling for service.
For The Period Of: We Will Replace:
One Year Any part of the washer which fails due to a defect in materials or workmanship. During this
From the date of the limited one-year warranty, we will also provide, free of charge, all labor and related service costs
original purchase to replace the defective part.
This warranty is extended to the original purchaser and any succeeding owner for products purchased for
commercial use within the USA. If the product is located in an area where service by a GE Authorized Servicer
is not available, you may be responsible for a trip charge or you may be required to bring the product to an
Authorized GE Service location for service. In Alaska, the warranty excludes the cost of shipping to your
place of business.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty
gives you specific legal rights, and you may also have other rights which vary from state to state. To know
what your legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor: General Electric Company. Louisville, KY 40225
What Is Not Covered (for customers in the United States):
Staple your receipt here.
Proof of the original purchase
date is needed to obtain service
under the warranty.
■Service trips to your place of business to teach you how
to use the product.
■Improper installation.
If you have an installation problem, contact your dealer or
installer. You are responsible for providing adequate
electrical, exhausting and other connecting facilities.
■Any and all implied warranties of merchantability and
fitness for a particular purpose.
■Replacement of fuses or resetting of circuit breakers
at place of business.
■Failure of the product if it is misused, or used for other
than the intended purpose.
■Damage to the product caused by accident, fire, floods
or acts of God.
■Damage to finish not reported within 48 hours following
delivery of appliance.
■Product not accessible to provide required service.
What Is Not Covered (for customers in Canada):
WARRANTOR IS NOT RESPONSIBLE FOR CONSEQUENTIAL DAMAGES.
Warrantor: MABE CANADA INC.
EXCLUSION OF IMPLIED WARRANTIES—Your sole and exclusive remedy is product repair as provided in
this Limited Warranty. Any implied warranties, including the implied warranties of merchantability or
fitness for a particular purpose, are limited to one year or the shortest period allowed by law.
This warranty is extended to the original purchaser and any succeeding owner for products purchased for home use within Canada.
In home warranty service will be provided in areas where it is available and deemed reasonable by Mabe to provide.
■Service trips to your place of business to teach you how
to use the product.
■Improper installation, delivery or maintenance.
■Failure of the product if it is abused, misused, or used
for other than the intended purpose.
■Any and all implied warranties of merchantability and
fitness for a particular purpose.
■Replacement of fuses or resetting of circuit breakers
at place of business.
■Damage to the product caused by accident, fire, floods
or acts of God.
■Incidental or consequential damage caused by possible
defects with this appliance.
■Damage caused after delivery.
■Product not accessible to provide required service.
■Defects or damage due to operation in freezing
temperatures.
■Products which are not defective or broken, or which are
working as described in the Owner’s Manual.
16
Operating Instructions Safety Instructions
Consumer Support Troubleshooting Tips

Mesures de sécurité . . . . . . . . . . . . .18, 19
Directives de fonctionnement
Chargement et utilisation
de la laveuse . . . . . . . . . . . . . . . . . . . . . . .22, 23
Le tableau de commande . . . . . . . . . . . . . . . . .20
Les caractéristiques . . . . . . . . . . . . . . . . . . . . . . .22
Les réglages de commande . . . . . . . . . . . . . . .21
Conseils de dépannage . . . . . . . . .24 28
Soutien au consommateur
Garantie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Soutien au consommateur . . . . . . . . . . . . . . . .32
Inscrivez ici le numéro de
modèle et le numéro de série :
Modèle #__________________
Série #____________________
Vous pouvez les apercevoir dans le
coin supérieur droit à l’arrière de
votre laveuse.
Soutien au consommateurConseils de dépannageFonctionnementMesures de sécurité
17

18
■ Installez ou placez votre laveuse dans un endroit où
elle n’est pas exposée à des températures inférieures
à zéro degré centigrade ou à du mauvais temps.
■ Retirez la pellicule de protection du tableau
de commande.
■Mettez la laveuse à la terre conformément à tous
les codes et règlements en vigueur. Consultez les
Directives d’installation.
MESURES DE SÉCURITÉ IMPORTANTES.
LISEZ D’ABORD TOUTES LES DIRECTIVES.
AVERTISSEMENT! Pour votre sécurité, suivez les directives fournies dans le présent
manuel afin de minimiser les risques d’incendie, d’explosion et de
chocs électriques et prévenir des dégâts matériels et des blessures
graves ou mortelles.
SÉCURITÉ DU CHAUFFE-EAU
Dans certaines circonstances, de l’hydrogène peut se former dans le chauffe-eau s’il n’a pas été
utilisé pendant deux semaines ou plus. L’hydrogène peut être explosif dans ces conditions.
Si l’eau chaude n’a pas été utilisée depuis deux semaines ou plus, réduisez les risques de dommages ou
de blessures en ouvrant tous les robinets d’eau chaude et en laissant couler l’eau pendant plusieurs minutes
avant d’utiliser un appareil électrique raccordé au système d’eau chaude. L’hydrogène sera ainsi libéré dans
l’atmosphère. Comme c’est un gaz inflammable, ne fumez pas ou n’utilisez pas une flamme nue ou un appareil
ménager ou cours de ce processus.
UNE INSTALLATION ADÉQUATE
Avant d’utiliser votre laveuse, assurez-vous qu’elle a été adéquatement installée, conformément
aux Directives d’installation. Si vous n’avez pas reçu de Directives d’installation avec votre
laveuse, appelez sans frais au 1.800.561.3344.
AUTOUR DE VOTRE LAVEUSE
■Évitez toute accumulation de matériaux
combustibles (charpie, papiers, chiffons,
produits chimiques, etc.) à proximité de vos
électroménagers.
■Il faut exercer une étroite surveillance lorsque
l’appareil fonctionne en présence d’enfants. Ne
les laissez pas jouer sur, avec ou à l’intérieur de
cet appareil ni aucun autre électroménager.
Fonctionnement Mesures de sécurité
Soutien au consommateur Conseils de dépannage

19
N’utilisez
cet appareil
que pour
l’usage
auquel il
est destiné,
comme
expliqué
dans le
présent
manuel.
LORSQUE VOUS UTILISEZ LA LAVEUSE
■Ne mettez jamais la main dans la laveuse pendant
qu’elle fonctionne. Attendez que l’appareil se soit
complètement arrêté avant d’ouvrir le couvercle.
■
Ne mélangez pas de javellisant avec de
l’ammoniaque ou des acides (vinaigres ou décapant
pour la rouille). Ce mélange peut produire un gaz
toxique et mortel.
■Ne lavez pas et ne séchez pas des articles qui
ont été lavés ou trempés dans des produits
combustibles ou explosifs
(cire, huile, peinture,
essence, dégraissants, solvants de nettoyage à sec,
kérosène, etc.). Ces substances émettent des
vapeurs qui peuvent prendre feu ou exploser. Ne
versez pas ces substances dans l’eau de lavage.
N’utilisez pas ces substances à proximité de votre
laveuse ou sécheuse pendant qu’elle fonctionne.
■La lessive peut atténuer les propriétés
ignifugeantes des tissus. Pour éviter cette situation,
suivez les directives données par le fabricant
du vêtement.
■Pour réduire les risques de chocs électriques,
débranchez toujours l’appareil ou débranchez la
laveuse au panneau de distribution en enlevant
le fusible ou en déclenchant le disjoncteur avant
de la réparer ou de la nettoyer. NOTE : Enfoncer
PAUSE ou STOP/CANCEL (Arrêter/Annuler) ne met
PAS l’appareil hors tension.
■N’essayez jamais de faire fonctionner l’appareil
s’il est endommagé, défectueux, partiellement
démonté, si des pièces sont manquantes ou
défectueuses ou si le cordon d’alimentation
ou la fiche est endommagé.
LORSQUE LA LAVEUSE N’EST PAS UTILISÉE
■Fermez les robinets d’eau et diminuez la pression
sur les tuyaux et les mécanismes de distribution
d’eau pour minimiser la fuite s’il se produit une
rupture ou une cassure. Vérifiez l’état des tuyaux
d’alimentation d’eau. GE conseille de changer les
boyaux tous les 5 ans.
■ Avant de jeter ou d’entreposer une laveuse, enlevez
le couvercle de l’appareil afin d’empêcher les
enfants de se cacher à l’intérieur.
■Ne réparez et ne remplacez aucune pièce de cet
appareil, à moins que cela soit spécifiquement
recommandé dans le présent manuel ou dans des
directives de réparation que vous comprenez et
que vous êtes en mesure de suivre.
■Ne trafiquez pas les commandes de l’appareil.
VEUILLEZ LIRE ET SUIVRE ATTENTIVEMENT CES MESURES
DE SÉCURITÉ.
CONSERVEZ CES DIRECTIVES
Soutien au consommateur
Conseils de dépannageFonctionnementMesures de sécurité

Guide de démarrage rapide
• Ajoute le détersif
• Ajoutez les vêtements • Choisissez le cycle de lavage
• Vérifiez le réglage de charge
• Fermez le couvercle
• Appuyez sur START
(Marche)
20
Votre nouvelle laveuse vous offre la possibilité de démarrer un lavage simplement en choisissant CLOTHES CARE SELECTION
(Sélection du soin des vêtements). Tout ce que vous avez à faire ensuite est d'appuyer sur START (Marche).
Le tableau de commande.
Trousse laveuse/sécheuse pour personnes ayant une déficience visuelle
Une trousse destinée aux personnes ayant une déficience visuelle est disponible pour les modèles de laveuse WNRD2050 et de
sécheuse DNCD450; elle contient des décalques en Braille qui s’appliquent sur les touches des panneaux de commande de la laveuse
et de la sécheuse.
La trousse comprend :
■des décalques en Braille qui s’appliquent sur les panneaux de commande de laveuse ou sécheuse
■des touches de référence en Braille qui expliquent le fonctionnement de la laveuse ou sécheuse
■une bande audio qui traite de l’utilisation et de l’entretien
Commandez la publication numéro 14-D242, disponible auprès de votre détaillant GE.
Pour les meilleurs résultats, GE recommande d’utiliser des feuilles d’assouplisseur pour sécheuse afin de rafraîchir les vêtements et réduire
l’adhésion statique. Si vous préférez un assouplisseur liquide, veuillez l’ajouter vers la fin du cycle de lavage (agiter), avant l’évacuation de
l’eau. Le voyant « washing » (lavage) clignotera au moment d’ajouter l’assouplisseur. L’utilisation d’un assouplisseur liquide lors d’un rinçage
haute efficacité à faible volume d’eau peut tacher les vêtements. Les taches disparaîtront au prochain lavage.
