GEAppliances GSD700 User manual

Dishwasher
❑
!
Safe~ instructions .........................3
❑
Operating Instructions, Tips
Appliance Registration ..................................2
China, Crystal, Sterling . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
CycleFeatures............................................4,5
Cycle Selection Chart ....................................5
DetergentGuide.............................................7
Dispenser Cups...............................................7
Drying Options ................................................4
Energy-Saving Tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..2
Features ........................................................4, 5
Loading .........................................................8, 9
Operating instructions ..............................4, 5
Rinse Agent
......................................................6
Water Temperature ........................................6
❑
<{.;: Care and Cleaning
Air Gap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
❑
●
Problem SoIver.......................l3-l5
More Questions ?...call
GE Answer Center” 800.626.2000
NPreparation
Front Panel Change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
H
o
Consumer Services ...................l5
Important Phone Numbers . . . . . . . . . . . . . . . . . . . . . . . . 15
Model and Serial Numbers ..........................2
Repair Service
.................................................2
Warranty ........................................Back Cover
~ Models GSD70~ GSD730 ~
Winter Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
GE Appliances

HELP US HELP YOU...
Before using your
dishwasher, read this
guide carefully.
It is intended to help you
operate and maintain your new
dishwasher properly.
Keep it handy for answers to
your questions.
If vou don’t understand something
If you received
a damaged dishwasher...
Immediately contact the dealer
(or builder) that sold you the
dishwasher.
Save time and money.
Before you request
service . . .
or ’need more help, write (include-
your phone number):
Check the Problem Solver in the
back of this
guide. It lists causes
Consumer Affairs
GE Appliances of minor op;rating problems that
Appliance Park you can correct yourself.
Louisville, KY 40225
To obtain a Spanish language Para
obtener la version en
version of this book, call
espafiol de este manual,
GE Answer Center
o
name a
800.626.2000 GE Answer Center,
(
’
)
consumer information service.
servicio de information
para el consumidor,
tel~fono 800.626.2000.
Write down the model
and serial numbers.
You’ll find them on a label
fastened to the tub wall just
inside the dishwasher door.
These numbers are also on the
Consumer Product Ownership
Registration Card that came
with your dishwasher. Before
sending in this card, please write
these numbers here:
Model Number
Serial Number
Use these numbers in any
correspondence or service calls
concerning your dishwasher.
~ YOU NEED SERVICE...
To obtain service, see the Consumer Services page in NEXT, if you are still not pleased, write
all the
the back of this guide. details—including your phone number—to:
We’re proud of our service and want you to be
Manager, Consumer Relations
pleased. If for some reason you are not happy with the GE Appliances
service you receive, here are three steps to follow for Appliance Park
further help.
Louisville, KY 40225
FIRST, contact the people who serviced your
FINALLY, if your problem is still not resolved, write:
appliance. Explain why you are not pleased. In most Major Appliance Consumer Action Panel
cases, this will solve the problem.
20 North Wacker Drive
Chicago, IL 60606
ENERGY-SAV~G TmS
● Operate dishwasher only when it’s full. Let the ● If you don’t need your dishes right away, allow the
dishes accumulate in dishwasher. When you put in dishes to dry naturally over a longer period such as
only a partial load, use the RINSE & HOLD cycle to
overnight.
rinse off heavy soils.
● Always select the cycle that uses the least amount
of water that will remove the soil from the load.
(See the Operating section.)

A
WARNING—When using this
appliance, always exercise basic
safety precautions, including the
following:
● Use this appliance only for iti intended
purpose, as you will find described in this
Use and Care Guide.
a
“This dishwasher must be properly
,Q ::’ ~
installed and located in accordance
& $ . . . with the Installation Instructions
=.
before it is used. If you did not
receive an Installation Instructions sheet with your
dishwasher, you can obtain one by calling, toll
free, the GE Answer Center~800.626.2000.
—This appliance must be connected to a grounded
metal, permanent wiring system; or an
equipment-grounding conductor must be run
with the circuit conductors and connected to
the equipment-grounding terminal or lead of
the appliance.
—Connect to a properly rated, protected and sized
power-supply circuit to avoid electrical overload.
=
● Do not store or use combustible
@
materials, gasoline or other
.. .,
flammable vapors and liquids
in the vicinity of this or any other appliance.
● Use only powder or liquid detergents or wetting
agents recommended for use in a dishwasher.
● Do not wash plastic items unless marked
“dishwasher safe” or the equivalent. For plastic
items not so marked, check the manufacturer’s
recommendations.
● Load light plastic items so they will not
become dislodged and drop to the bottom of the
dishwasher—they might come into contact with
the heating element and be damaged.
To minimize the possibility of injury.
● When loading items to be washed:
A. Locate sharp items so that they are not likely
to damage the door seal, and
B. Load sharp knives with the handles up to
reduce the risk of cut-type injuries.
● Do not tamper with controls.
● Do not touch the heating element during or
immediately after use.
● Do not operate your dishwasher unless all enclosure
panels are properly in place.
● Do not abuse, sit on, or stand on the door or dish
rack of the dishwasher.
● Close supervision is necessary if this appliance
is used by or near children. Do not allow children
to play inside, on or with this appliance or any
discarded appliance. Dispose of discarded
appliances and shipping or packing material
properly. Before discarding a dishwasher, remove
the door of the washing compartment.
● Keep all washing detergents and wetting agents
out of the reach of children, preferably in a locked
cabinet. Observe all warnings on container labels
to avoid personal injury.
*3
● To minimize the possibility of
/“
electric shock, disconnect this
/“
appliance from the power supply
before attempting any maintenance. NOTE:
Turning the control dial to the OFF position
does not disconnect the appliance from the
power supply. We recommend having a qualified
technician service your appliance.
A
WARNING—HYDROGEN GAS is
produced by the chemical action
within your water heater. It can
accumulate in the water heater andor
water pipes if hot water has not been used for a
period of two weeks or longer. HYDROGEN GAS
IS EXPLOSIVE. To prevent the possibility of
damage or injury, if you have not used hot water
for two weeks or more, or moved into a residence
in which the hot water system may not have been
used for some time, turn on all hot water faucets
and allow them to run for several minutes before
using any electrical appliance which is connected
to the hot water system. This will allow any
hydrogen gas to escape. Also, since the gas is
flammable, do not smoke or use an open flame
or appliance during this process.
SAVE THESE
INSTRUCTIONS
A
3
—

HOW TO OPERATE YOUR DISHWASHER
NOTE: The lights over the Cycle pads come ON to
indicate the cycle that has been selected. These Cycle
Indicator lights remain on while the door is latched.
If dishwasher drains into a food waste disposal,
operate the disposal until it is empty before starting
dishwasher.
step 1. Load your dishwasher. (See Loading section.)
step 2. Make sure the Cycle Indicator Dial is at
the OFF position. Add detergent to the detergent
dispenser. (See Detergent Guide.) Use a rinse aid
agent to help prevent spotting. (See How to Use
a Rinse Agent section. )
step 3. Latch the door.
step 4. Select desired wash cycle.
● POTSCRUBBER—For items such as pots, pans
and casseroles with dried-on or baked-on
soils.
Everyday dishes may be included. This cycle will
get heavily soiled dishes cleaner than the normal
cycle. It will not remove burned-on foods.
● NORMAL WASH—For most loads of everyday
dishes, glasses and cookware with medium soils.
Designed to yield high performance on normal soils.
step s. Select the desired drying option.
. HEATED DRY ON—Turns the drying heater on
for fast drying. When selected, the cycle time will
be extended for
35 minutes.
● HEATED DRY OFF—Shuts off the heating unit,
thus saving energy. Dishes air-dry naturally. It takes
longer but saves energy. You can open the door after
the motor stops to speed drying. Excellent for
overnight drying.
4
I
o
POT- NORMAL
SCRUBBER WASH
60
Cycles
)
_/
Step 6. ~rn the Cycle Indicator Dial to START.
● Turning the dial to START will begin the cycle
immediately. To obtain the benefits of a complete
cycle, be careful that you do not turn the dial any
farther than is necessary to start the dishwasher.
There is a time delay between start-up and water
fill so you will not hear any wash action right
away.
Dial Cycles
The SHORT WASH cycle allows you to quickly
wash loads of everyday dishes with medium soils
that have not dried on, such as loads consisting mostly
of glasses.
a. Select the NORMAL WASH cycle and a drying
option if desired.
b. Be sure the door is unlatched.
c.
Slowly turn the Cycle Indicator Dial to
SHORT WASH.
d. Latch the door to start the cycle.
The RINSE & HOLD cycle is for rinsing
partial loads which will be washed later. Do
not u.~e detergent.
a. Select HEATED DRY OFF.
b.
c.
d.
Be sure the door is unlatched.
Slowly turn the Cycle Indicator Dial to
RINSE & HOLD.
Latch the door to start the cycle.

.
RT WASH
PUTE WARM
(PRESS HEATED D
m .’”
‘.,
RlN5E&HOLD (PRESS HEATED DRY OFF)
Dial Cycles (continued)
The PLATE WARMER cycle (on some models)
is for warming clean dishes and serving plates for
the serving of hot foods. The cycle will take
approximately
35 minutes if selected.
a. Load clean plates and dishes to be warmed.
b. Select HEATED DRY ON.
c. Be sure the door is unlatched.
d. Slowly turn the Cycle Indicator dial to
PLATE WARMER.
e. Latch the door to start the cycle.
Cycle Selection Chart
Wash cycle
Water Use Time
Gall(ms Minutes
Wash Cycles
(appl”ox, ) (approx.) Cycle Sequence
POTSCRUBBER
10.6 72
mmmmmBm
NORMAL WASH
9.1
51
mmmmmm
SHORT WASH 7.4
43
mmmmm
RINSE & HOLD
3.()
J~
mm
HEATED DRY ON. Available on all wash cycles cxccpt RINSE & HOI.D. Adcl 35 minutes to WJSI1 cycle time.
HEATED DRY OFF. Drying hca[er is turned off’. Dishes dry naturally.
5

Good Dishwashing Starts with HOT Water
To get dishes clean and dry, you need hot water. For good washing and drying,
the entering water must beat least
120°F. To prevent dish damage, inlet water should not exceed 150°F.
How to Test Water Temperature
Check your water temperature with a candy or meat
Helpful hints: If outside temperatures are unusually
thermometer. Turn on the hot water faucet nearest low, or if your water travels a long distance from water
the dishwasher. Put the thermometer in a glass and heater to dishwasher, you may need to set your water
let the water run continuously into the glass until the heater’s thermostat up. If you have not used hot water
temperature stops rising. If the water temperature is for some time, the water in the pipes
will be cold. Turn
below
120°F., adjust your water heater. on the hot water
faucet at the sink and allow it to run
until the water is hot. Then start the dishwasher. If
you’ve recently done laundry or run hot water for
showers, give your water heater time to recover before
operating the dishwasher.
To improve washability if the water is less than
120°F.
and you cannot adjust your water heater: Select a
longer cycle and fill both detergent cups at least
half-
full with detergent.
How to Use a Rinse Agent
The rinse agent makes water flow off dishes
Your dishwasher’s rinse agent container holds
quicker than usual. This lessens water spotting
approximately 4fi ounces. This should last about
and makes drying faster, too.
3 months. Fill as needed.
For best
dishwashing performance, use of a rinse
agent such as JET-DRY brand is recommended.
Rinse agents come in either liquid or solid form.
Your dishwasher uses the liquid form.
How to fill the rinse agent dispenser.
Unscrew the cap.
Add liquid rinse agent
until it just reaches the
bottom of lip inside the
dispenser opening.
Q
$} : ~
Replace cap. The
dispenser automatically
&d
/’
/
releases rinse agent into
final rinse water.
If you accidentally spill: Wipe up the rinse
agent
with a damp cloth. Don’t leave the spill in the
dishwasher. It can keep your detergent from working.
If you can’t find any rinse agent, write:
BENCKISER CONSUMER PRODUCTS, INC.
(“JET-DRY”)
Corporate Centre 1
55 Federal Road
P.O. Box 1991
Danbury, CT 06813-1991
I I

How to Choose and Use the Right Detergent
Use only powder or liquid detergent specifically
made for use in dishwashers. Other types will cause
oversudsing.
How much detergent should you use? That depends.
1s your water “hard” or “soft”? With hard water, you
need extra detergent to get dishes clean. With soft water,
you need less detergent.
Your water department can tell you how hard your
water is. So
can your county extension agent or your
area’s water softener company. Just call and ask them
how many “grains” of hardness there are in your water.
Too much detergent with soft water not only wastes
money, it can be harmful.
It can cause a permanent
cloudiness of glassware, called “etching.” An outside
layer of glass is etched away! Of course, this takes some
time. But why take a chance when it’s easy to find out the
hardness of your water.
Keep your detergent fresh and dry. Under the sink
isn’t a good place to store detergent because there is too
much moisture. Don’t put powder detergent into the
dispenser until you’re ready to wash dishes, either. (It
won’t be fresh OR dry.)
If your powder detergent gets old or lumpy, throw it
away.
Old detergent often won’t dissolve. If you use a
liquid dishwasher detergent, these precautions are not
necessary because
liquid detergents don’t “lump” as
they age or come in contact with moisture.
Detergent Dispensers
You’ll find two detergent dispensers on the inside
door of your dishwasher. Two, because
some cycles use two washes.
Open
See “Detergent Usage Guide ’’below.
cup
(Be sure the CYCLE INDICATOR
DIAL is at OFF position
bejbre
adding detergent. Otherwise,
4J
%
\
the detergent cup will not
Main
close and latch properly).
cup
{
‘o> “’
Clo.~e the main cup.
NOTE: T(] open detergent cup qfter it has been .
closed, unlut(:h the door and rotate the Cycle <
Indicator Dial a full turn to the OFF position.
&
9“
When the closed cup contains soap it is
Grasp handle,
best that the door be in a partially open
rotate and
position b<fi)re rotating the Cycle
close tightly
Indicator Dial. This will help reduce the amount of
detergent and rinse aid
agent spillage into the tub.
Detergent Usage Guide (powder or liquid)
SOFT WATER (0-3 grains hardness) MEDIUM WATER (3-7 grains) HARD WATER (7- 12 grains*)
CYCLES Main Cup Open Cup
Main Cup
Open Cup
Main Cup+ Open Cup$
I I I
POTSCRUBBER Half Full : Half Fu]]
Completely
~ Half Full Completely
NORMAL WASH
~ Completely
II
Full Full
I Full
SHORT WASH Half Full None Half Full None Completely
None
Full
RINSE & HOLD
Use no detergent
Use no detergent Use no detergent
* 12 grains and up is extremely hard water. A water softener is recommended. Without it, lime
$Filled Main Cup holds 3 tablespoons:
can build up in the water valve. The water valve may stick while open
and cause flooding. Filled Open Cup holds
2 tablespoons.
How to Prepare the Dishes for Washing
If this is your first dishwasher, or if you’re replacing NOTE: You may also want to consider removing
a much older model, you may wonder how much foods such as mustard, mayonnaise, vinegar, lemon
preparation your dishes need. Actually very little, juice and other foods that can cause discoloration of
Scrape off bones, seeds, skins, toothpicks and stainless steel if allowed to remain on dishes for a
other hard solids. Remove excessive quantities
long period of time.
of oil or grease.
The POTSCRUBBER cycle can wash heavily soiled
dishes and remove dried-on and baked-on
soils from
pots, pans and casseroles. Items with burned-on
soils need extra preparation.
7

HOW TO LOAD YOUR DISHWASHER
NOTE: Do not load large platters or trays in front right corner
of lower rack. They may prevent detergent from circulating in the wash cycle.
The upper rack is best
for glasses, cups and
saucers. Cups and glasses fit best along the sides.
This is also the place for dishwasher-safe plastics.
Make sure small plastic items are lodged in tightly so
they can’t fall onto the heating unit. Arrange stemware
so that it cannot move easily. Don’t let the glasses
touch each other.
*...-
The upper rack is handy for all kinds of odd shapes. Sauce pans, mixing bowls and other items should be placed
face
do-wn. When loading dishwasher safe plastics make sure each plastic item is secured over two fingers. This
will insure good washing results.

The lower rack is best used for plates, saucers, and
cookware. Large items such as broiler pans and racks
should go in the lower rack along the edge. Load
platters, pots and bowls along the sides, in corners,
or in the back. For best washing results, all items
should be positioned with the soiled side of the dish
facing the center of the rack.
Put flatware in the removable basket with handles up
to protect your hands. Mix knives, forks and spoons
so they don’t nest together. Distribute evenly.
Small plastic items, such as measuring spoons and
lids from
small containers are not recommended for
automatic dishwashing. If placed in dishwasher, they
should
go in bottom of silverware basket with
silverware on top.
Keep center area clear in the lower rack.
The wash tower rises through the center of the lower
rack during the wash and rinse portions of the cycle.
Don’t block it or load tall things next to it. Also, be
careful not to let a ~ortion of an item such as a Dot or
dish handle
extend’through the bottom rack. T~is could
block the wash arm and cause poor washing results.
Donltletan,~
item extend
through bottom
Precaution!
Take out anything
that may fall or extend through the
bottom of the basket.
9

WHAT YOU CAN USUALLY WASH SAFELY
IN YOUR DISHWASHER.
usually
SafeMaterial
Aluminum
Exceptions (not safe)
Some colored anodized
aluminum can fade.
Special Instructions
Some darkening or spotting possible. Remove by
scouring with soap-filled steel wool pads.
YES
Chinti
Stoneware
YES Antique, metal-trimmed,
hand-painted or over-the-glaze
patterns fade. Gold leaf
will discolor.
If in doubt, check with the manufacturer. Or test wash
one piece daily for at least a month. Compare with the
rest of the set.
Crystal
YES
Antique, metal-trimmed or
hand-painted patterns fade.
Gold leaf will discolor.
Load securely to prevent movement. Check your
manufacturer’s instructions for your crystal.
Non-dishwasher
items—such
as electronic
air cleaner
filters, furnace
filters, paint
brushes. etc.
NO
YES
Do not wash in dishwasher. Damage to dishwasher
and discoloration or staining of dishwasher may result.
Glass
Iron
Iron will rust. NO
Pewter
NO
Pewter tarnishes.
Plastics
Stainless
steel
YES
If it doesn’t say DISHWASHER SAFE. test one piece in
the top rack before dishwashing an entire set.
Rinse if not washing immediately. Salty or acid foods
can stain if left on.
YES
Sterling Silver
and Silver
plate
YES Don’t put in same silverware
basket with stainless steel.
Contact between metals can
damage silver.
Don’t wash copper utensils in
the same load. Silver may get a
brown film.
Adhesive used to attach some
hollow-handle knives can loosen.
Rinse if
not washing immediately. Salty or acid foods can
stain if left on. Dry detergent can cause difficult-to-remove
black spots. Place in
back section of silverware basket to avoid
exposure to detergent from the detergent cup.
Non-stick
coatings
Tin
YES
After washing, wipe the non-stick coating area with
vegetable oil to
kee~ it from losing its non-stick quality.
NO Tin can rust.
Wood NO
Wood can warp, crack or lose
its finish with any type of washing.
Forget a dish? Here’s when you can add it.
Add dishes any time during the RINSE & HOLD
cycle. With other wash cycles, you can add dishes
at any time BEFORE the main detergent wash portion
of the cycle.
However, opening the door during any cycle
lessens cleaning power. So try to load everything
at the beginning.
Here’s how to add a forgotten dish:
1. Push the door latch to the left. Washing will stop.
2.
Wait a few seconds until the water calms. Then
open the door. WARNING: Hot vapor may rise
from opened door.
3. Add dishes you’
ve forgotten.
4. Close the door and push the latch to the far right.
When the door is locked, washing will continue.
10

USER MAINTENANCE INSTRUCTIONS
Clean the control panel with a lightly dampened Appliance Polish
Wax & Cleaner (Cat. No.
cloth. Dry thoroughly. Do
not use abrasives or
WR97X02 16) is available from GE Service and
sharp (~bjects on the panel. They can damage it.
Parts Centers.
Clean the outside with a good appliance polish The inside usually takes care of itself.
If it should
wax. The outside cabinet finish is durable, but it ever need cleaning, use
a mild cleansing powder.
can scr~tch. So use no scouring pads, or harsh or
Scouring pads and harsh cleaners can mar the finish.
gritty cleaners.
Not Using Your Dishwasher in Winter? Protect Against Freezing.
If your dishwasher is left in an
unheated place during the winter,
usk a service technician to:
● Cut off electrical power to the
dishwasher.
Rcmove fuses or trip
circuit breaker.
● Turn oft the water supply.
I
● Disconnect the water inlet I ine
t’rom the water valve.
Pump Cover Screws
Built-in Dishwashers Often Use an Air Gap. Keep It Clean.
An air gap is a plumbing device.
It protects your dishwasher against
water
bdcking up into it if u drain
clogs. The air gap is not a part of
the dishwasher. And you may not
even htive one. Not a] 1 p]umbing
codes require uir gaps.
● Drain water from the inlet I i ne
and water valve. (Use a pan to
catch the water. )
● Reconnect the water inlet I i ne to
the water valve.
● Remove the plastic pump cover
in the tub bottom” and use a
sponge to soak up water in
the rubber
hoot.
If you have an air gap, check it at
least once a month.
IT IS NOT
PART OF YOUR DISHWASHER.
IT IS NOT COVERED IN YOUR
WARRANTY.
The air gap is easy to clean.
With
most types, first turn oft the
dishwasher, then lift off the chrome
cover. Then unscrew the plastic cap
and check for any buildup
of grit.
A toothpick” makes cleaning easy.
Check the air gap any time your
dishwasher isn’t draining well.
11

HOW TO CHANGE COLOR PANELS
If you are redecorating, you can change your dishwasher’s front panels to
match or blend with your new colors by flipping them over. Each side of
each panel is
a different color. You may also paint a panel with a color of
your
own choice.
How to Change the Door Panel:
1. Take out trim screws on either side of the
dishwasher door. Remove the side trim.
2. Slide the door panel out.
(Careful—edges may be sharp.)
3. Turn the door panel around and put the color you
want in front.
4. Replace the door panel, side trim and screws.
NOTE: Do not operate
dishwasher while changing
panels or when lower access
panel is removed.
How to Change the Lower Panel:
“L-
Attachment Screws
1. Remove the panel attachment screws.
2. Remove the entire access assembly by lifting it up
and over the retaining tabs.
3. Take out the top trim screws and remove the
top trim.
4. Slide the color panel(s) up and out and put the color
you want in front.
5. Replace the top trim and screws.
6. Replace the entire access assembly by hanging
it back on the retaining tabs. Hold the access
assembly in place and replace attachment screws.
Wood Panel fiim Kits (Available for both models)
color Panels (For model GSD700 only)
Wood panel trim kits, contain trim and
If you have redecorated, and the color panels in
instructions for adding a decorative wood door your dishwasher do not blend with your new color
panel and lower access panel no thicker than l/4° scheme you may order one additional color panel
to match kitchen cabinets. without charge.
Specify the trim color of your choice from the Specify the color panel you would like from the
following options: following options:
GPF40BC (Chrome Trim and Screws) GPF24 White/Almond
GPF40BK (Black Trim)
GPF26 HarvestiBlack
GPF40WH (White Trim) Order a Trim Kit or a Color Panel from:
The kit is available for $5.00 (shipping and handling). GE Appliances
Make check payable to the General Electric Co. c/o
Dri-View Manufacturing
4706 Allmond Ave.
12
Louisville, KY 40209

PROBLEM
DISHWASHER
WON’T RUN
UNUSUAL NOISE
DISHES DON’T DRY
UNCLEAN DISHES
AND FLATWARE
DETERGENT LE~
IN DISPENSER CUPS
DETERGENT CUP
LID WON’T LATCH
A~ER ADDING
DETERGENT
YELLOW OR
BROWN FILM
CYCLE AND OPTION
INDICATOR LIGHTS
STAY ON WHEN
CYCLE IS COMPLETEE
POSSIBI,E CAUSE
A fuse in your home
may be blown, or the circuit breaker tripped. Replace fuse or
reset circuit breaker. Remove
any other appliances from the circuit.
Utensils
may not be secure on rack pins, or something small may have dropped from
the
rack. Water is causing utensils to rattle. Make sure everything is securely placed
in dishwasher.
Make sure inlet water temperature is correct. (See How to Test Water Temperature
section).
Unload the bottom rack first. Water from dishes in the top rack may be spilling into
the bottom rack.
Check for improper loading. Dishes shouldn’t nest together. Avoid overloading.
Check the rinse agent dispenser to see that it’s not empty.
Check inlet water temperature. It should be at least 120°F. (To test, see How to Test
Water Temperature section).
Water pressure may be temporarily low. Turn on a faucet. Is water coming out slower
than usual?
If so, wait until pressure is normal before using your dishwasher.
Plugged
air gap. (See Care and Cleaning section).
Improper rack loading. (See
Lotiding section).
Choose another cycle to
give you longer washing time.
Water may not be reaching the detergent cups. Move dishes that
may be blocking
detergent cup.
The dispenser cover may not be opening or may be blocked by improperly loaded
items. If you used a
powder detergent, open the cup and remove any caked-on
detergent. If the cup still doesn’t open automatically,
call for service.
Detergent may be old.
If the powder detergent is hard or caked in the box, throw it
away. The detergent
may not be working well. Try another brand.
Cycle Indicator Dial must
be OFF for cup lid to close and latch properly. If you
unlatch the door
and open it to dry your dishes, the Cycle Indicator Dial does
not advance by itself.
Tea or coffee can stain cups. Remove the stain by hand, using a solution of l/2 cup
bleach and
3 cups warm water.
An overall yellow or brown film on dishes or glassware can be caused by iron
deposits in water. A special
filter in the water supply line is the only way to correct
this problem. Your water softener company can tell you about the filter.
Yellow film on sterling silver results when you wash copper utensils in the same load.
Silver polish will usually remove this stain.
This is normal. Unlatch the door to turn off the lights.

THE PROBLEM SOLmR
(continued)
PROBLEM
SPOTS AND
FILMING ON
GLASSES AND
FLATWARE
CLOUDINESS ON
GLASSWARE
CHIPPING OF CHINA
POSSIBLE CAUSE
Spotting can be caused by all these things:
● Extremely hard water. (See How to Choose and Use Detergent section).
● Low inlet water temperature. (See How to Test Water Temperature section).
. Overloading the dishwasher.
● Improper loading. (See Loading section).
● Old or damp powder detergent.
● Phosphate level in detergent too low. (See How to Choose and Use
Detergent section).
● Rinse agent dispenser empty. (See How to Use a Rinse Agent section).
● Too little detergent. (See How to Choose and Use Detergent section).
Local water conditions and personal preferences vary. Try several brands of
detergents to
find one that gives the best results for you. A liquid dishwasher
detergent may help reduce filming.
To remove stubborn spots and film from glassware:
1. Remove all metal utensils from the dishwasher.
2. Do not add detergent.
3. Select POTSCRUBBER cycle.
4. Start the dishwasher and allow to run for 18 to 22 minutes. The dishwasher will
now be in the main wash.
5. Then open the door and pour 2 cups (500 ml) of white vinegar into the bottom of
the dishwasher.
6. Close the door and allow to complete the cycle.
If vinegar rinse doesn’t work: Repeat as above, except use 1/4 cup (60 ml) of citric
acid crystals instead of vinegar. (Most drugstores carry citric acid crystals. If yours
doesn’t, call GE Factory Service).
Using a vinegar or citric acid crystal rinse more than twice a month? Consider a home
water softener.
If vinegar or citric acid crystal rinse doesn’t work, the cloudiness is “etching.”
The film cannot be removed.
It can be prevented: Use less detergent if you have soft water. Wash glassware in
the shortest cycle that
will get them clean.
Water temperature entering dishwasher exceeds
150°F,
Rough handling can cause chipping. Load with care. Make sure glassware and china
are secure and can’t jar loose. (See Loading section). Make sure
tdl glasses and
stemware will clear the top of the tub when you push the rack into the dishwasher.
Always use the top rack for delicate items.
14

PROBLEM POSSIBLE CAUSE
BLACK OR GRAY Aluminum utensils often leave marks when they rub against dishes. Remove marks
MARKS ON DISHES with a mild abrasive cleanser.
SMALL AMOUNT OF
WATER STANDING
IN THE BOTTOM
OF THE TUB
Water around the outlet on the tub bottom at the back of the tub is normal. It is clean
water. It’s there to keep the water seal lubricated.
WATER WON’T PUMP
If the entire bottom of the tub has water, you may have a drain problem. Clean the air
OUT OF THE TUB gap, if you have one. (See Care and Cleaning section).
I
Check the kitchen sink. Is it draining well? You may need a plumber.
I
If dishwasher drains into disposer, run disposer to clear. Be sure disposer is not
clogged.
SUDS IN THE TUB Sudsing detergents are not meant for dishwashers. USE ONLY AUTOMATIC
DISHWASHER DETERGENTS TO AVOID
SUDSING.
To remove suds from the tub: Open the dishwasher. Let suds evaporate. Add
1 gallon of cold water to the tub. Close and latch the dishwasher. Pump out water
by slowly turning the control dial until a drain period is reached.
I Repeat if necessary.
DISHWASHER Suds can cause unit to overflow. That’s why it’s so important to use a detergent that’s
LEAKS
designed for automatic dishwashers.
Spilling the rinse agent can cause foam during washing. This can lead to overflowing.
Wipe up accidental spill of rinse agent with a damp cloth.
I
MOTOR HUMS Dishwasher has not been used on a regular basis.
STAINING OF
TUB INTERIOR
If you do not use your dishwasher often, set it to fill and pump out once every week.
This will help keep the sed moist, and the garbage disposer clear.
Some detergents contain colorant (pigment or dyes) that will discolor the tub
interior with extended use. Check the detergent cup for signs of any discoloration.
If cup is discolored, change to detergent without any colorant.
SOUNDS YOU
WILL HEAR
You’ll hear occasional clicking sounds. These are normal.
● Soft food disposal shredding action.
● Drain valve opening to pump water out.
● Timer control as cycle progresses.
● Detergent cup opening.
During the drying period:
● The motor stops,
VAPOR AT
T= VENT
Water vapor comes through the vent by the door latch during drying and when
water is being pumped out.
If you need more help... call, toll free:
GE Answer
Center@
800.626.2000
consumer information service
15

NOTES
16

NOTES
17

NOTES
18

Wdll Be There
With the purchase of your new GE appliance, receive the assurance that if you ever need
information or
assis~nce from GE, we’ll be there. All you have to do is call—toll-free!
lwHome Repair Service
80MEXARES(8DM32-2737)
AGE consumer service professional will provide expert repair service, sched-
uled
at a time that’s convenient for you. Many (1E (;onsumer Service company-
operat.ed locations offer you service today or tomorrow, or at your {convenience
(7:00 a.m. to 7:00 p.m. weekdays, 9:()() a.m. to 2:00 p.m. Saturdays). our f’actory-
trained technicians know your appliance inside and oLIt-so most repairs can bc
handled in just 1 visit.
GEAnswer Cente~
Whatever your question about any GE rnqjor appliance, {lkl Answer (;entere
information service is available to help. Your call—and your qLlestion- will bc
answered promptly and courteously. And you can call any time. (JE; Answer
Center@ service is open 24 hours a day, 7 days a week.
I mT
. .
I
kr Customers With Special Needs...
Upon request, C;E will provide (lonsL]mers with impaired hearing or speech who have
Braille controls
for a variety of (;E
access 10 a rDD or a conventional teletypewriter may
appliances, and a brochLlre to call
800-TDD-(lEJA(;” (800-833-4322) to request infi~rma-
assist in planning a barrier-free tion or service.
kitchen
for persons with limited
mobility. To obtain these items,
free of charge, call 800.626.2000.
Service Contracts
80M262224
You can have the secure feeling that (JE (;ousumer Service will still be there
after your warranty expires. Purchase a
(JE contract while your warranty is still
in effect and you’ll receive a substantial discount. With
a rnulLiple-yeal” conLracL,
you’re assured of future service at today’s prices.
Parts andAccessories
80M2&2002
Individuti quafified to service their OM appliances User maintenance instructions contained in
tiis boo~et
can have needed parts or accessories sent directly to cover procedures intended to be performed by any user.
their home. The
C,EI parts sys[em provides a(ress to over Other servicing
gener~yshotid be referred to qutified
47,000 parts... and all (1E Genuine Renewal Parts are
service personnel. Caution must be exercised, since
fully warranted. VISA, Master(;ard and Discover (ards improper servicing may cause unsafe operation.
are accepted.

YOUR GE DISHWASHER WITH
Staple sales slip or cancelled check
PERMATUF(R) INTERIOR
here. Proof of original purchase date
WARRANTY
is needed to obtain service
under warranty.
WHAT IS COVERED
FULL ONE-YEAR WARRANTY
For one year from date of original
purchase, we will provide, free of
charge, parts and sewice labor in
your home to repair or replace any
part of the dishwasher that fails
because of a manufacturing defect.
FULL TEN-YEAR WARRANTY
For ten years from date of original
purchase, we will provide, free of
charge, parts and semice labor in
your home to repair or replace
the
PermaTuf tub or door /iner if it
fails to contain water because of
a manufacturing defect such as
cracking, chipping, peeling
or rusting.
LIMITED SECOND-YEAR
WARRANTY
For the second year from date of
original purchase, we will provide,
free of charge, replacement parts for
anypati of the Water Distribution
System
(as illustrated below) that
fails because of a manufacturing
defect. Associated inlet and drain
plumbing parts are not covered by
this warranty. You pay for the
service trip to your home and
service labor charges.
1
Power Shower ’’arm_
3 Piece Power TowerrM
Wash arm
‘Spray arm)-- -~:$nectlon
t
Boot -
d
i
Hose
assembly
If
J
● Motor
Pum~
Soft Food Disposer
Water Distribution System
This warranty is extended to
the original purchaser and any
succeeding owner for products
purchased for ordinary home use in
the 48 mainland states, Hawaii and
Washington,
D.C. In Alaska the
warranty is the same except that it is
LIMITED because you must pay to
ship the product to the service shop
or for the service technician’s travel
costs to your home.
All warranty service will be
provided by our Factory Service
Centers or by our authorized
Customer
Care’’” sewicers during
normal working hours.
Should your appliance need
sewice, during warranty period or
beyond, call 800-GE-CARES
(800-432-2737).
WHAT IS NOT COVERED
● Service trips to your home to teach adequate electrical, plumbing, and
you how to use the product.
other connecting facilities.
Read your Use and Care material.
● Replacement of house fuses or
If you then have any questions
resetting of circuit breakers.
about operating the product, please
● Cleaning or sewicing of air gap
contact your dealer or our
Consumer Affairs office at the device in drain line.
address below, or call, toll free:
● Failure of the product if it is used for
GE Answer Center” other than its intended purpose or
800.626.2000
used commercially.
consumer information service
● Damage to product caused by
● Improper installation, accident, fire, floods or acts of God.
,,
If you have an installation problem,
WARRANTOR IS NOT RESPONSIBLE
contact Vour dealer or installer. You
FOR CONSEQUENTIAL DAMAGES.
are responsible for providing
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion
may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
To know what your legal rights are in your state, consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor: General Electric Company
If further help is needed concerning this warranty, write:
Manager—Consumer Affairs, GE Appliances, Louisville, KY 40225
Th;s book is pr;nted on recycled pape~
1
Part No. 165D3080P299
GSD70U
Pub No. 49-5607 GSD730
6-93 CG
Printed in Louisville,KY
