GearBest Z201YS User manual

Please read the instruction carefully before usage.
Notice:
Our products adopt gyroscope technology. It can fly in small space or outdoor.
It can meet your desire for flying if the wind is less than level 3.
Quadcopter uses 2.4Ghz frequency has a long-distance control and operated by
several persons at the same time. It has 4 CH functions such as forward,
backward, left and right sideward fly, turning left and right. It also can do some special
action like 3D rolling.
In order to operate the quadcopter easily, please read the instruction carefully before
using and retain it.

Throttle lever /
Horizontal totation
Press down for changing
low/high speed
Direction lever /
Press down enter one
key return (Auto reverse mode)
Short press: take photo
Long press: take video
(not available for the wifi version)
short press:360°flip turn
long press:headless mode
one key take-off
spinner1: Left turn Fine-tuning
spinner 5: Left Sideward
Fine-tuning
spinner 6: Right Sideward
Fine-tuning
spinner3 :Forward Fine-tuning
spinner 4 :Backward
Fine-tuning
spinner 2:
Right turn Fine-tuning
short press:one key landing
long press:emergency landing
switch:ON/OFF
electrical machine
main body
charging stock/
power switch
camera
screw blade moveable axis
1.Please put the smaller parts of quadcopter at the place where children can't touch, to avoid
accidents.
2.The quadcopter has powerful energy, at first flight, you should slowly push left lever. Avoiding
quadcopter flies rapidly to cause collisions and damage.
3.After flight, turn off the remote control first then the quadcopter
4.Do not put the battery in the high temperature, and hot place.(such as: near the fire or electric
heating device)
5.During flight, the aircraft should keep away from the user or others about 2-3 meters. Avoid
hurt them when the quadcopter lands.
6.Do not let children play alone, children should play under the guidance of adults
7.Non rechargeable batteries can not be charged. Install batteries with correct polarity and do
no mix different types of batteries.
8.When stop flying please turn off the power of transmitter and remove the batteries of quadcopter
and transmitter out
9. The power supply terminal can not be short circuit.
10.Don't look at the light directly because of radiation
Safty & Caution
Transmitter & Quadcopter Introduction
-1-

Installation and Adjustment
Insert USB port of the charging cable to any on USB port
of computer. The indicator LED on USB cable will light on
when charging, and will light off when battery fully charged.
-2-
1.5V AAA
1.5V AAA
1.5V AAA
remote control
use 1.5V *3“AAA”
Quadcopter Charging Instruction
1.Put the telephone rack
into the rack slot on back
of transmitter.
2. Press thr round button on
backside of transmitter and
pull up to take out the rack.
(see the chart)
4.You can rotate the metal
parts which on the side of
telephone rack to adjust the
angle of telephone rack,
then rotate the metal parts
clockwise to fixed it.
3.To lift and shrink the
telephone rack at right position,
and adjust it at suitable width ,
please rotate the metal parts
anticlockwise.Afcer done,please
rotate the metal parts to fix them
clockwise.

-3-
Headless Mode
★Start and setting: put the quadcopter at a horizontal
position or make it hover in the air and confirm the
front of quadcopter (blue LED light) with the transmitter
at the same direction ahead. Press the button of
headless mode (the transmitter "Di", the indicator light
keeps green),quadcopter's diagonal LED light flash. It
means start the headless mode.
★Exit the headless mode: Press the button of
headless mode(the transmitter "Di", the indicator light
is out), Quadcopter's LED lights are on which means
exit the headless mode.
★You can change the headless mode at any time even in flying

-4-
As shown in the above chart, in CF Mode (the bottom four LED lights keep flashing
quickly) No matter where the quadcopter locates(the blue light is the onward direction),
now the position of the remote controller is the rear of the quadcopter. At this time, push
the direction lever down, the aircraft will come back, and push the direction lever up,
the aircraft will fly far away.
★push the left throttle stick to the lower right,and push the right throttle srick to the
lower right, the quadcopter stop flying.(picture 1)
Emergency stop
★When the quadcopter suffers impact or external collision,quadcopter's direction will be
wrong. At this time, the quadcopter should be landed on the flat ground, to ensure the
front direction of the quadcopter(the red light is the onward direction) is consistent with
thetransmitter's. Push the left lever bottom left, and push the right lever bottom right
(two actions should be executed at the same time.) (picture 2)
Gyroscope calibration
★Before start the aircraft,turning the throttle sticks
inwards to calibration.
After finishing the calibration, turning the throttle sticks
outwards to unlock.Propellers of quadcopter turn at low
speed,Pushing the throttle sticks,quadcopter flies up at
a lower speed
Unlock
★Press the button of one key return,( the transmitter "Di"),the quadcopter will return
automatically. You can push the right lever up to correct the channel if deviation.
Press the button of one key return again( the transmitter "Di "),the quadcopter ends return
Or push the right lever up to end return
One key return
★One key take-off: After finish the unlock, push the one key take-off button
the controller sends a "tick" sound,After finishing one key return,the quadcopter hover
about 1m height
★One key landing: After the quadcopter flies, push one key landing button,
the controller sends a "tick" sound. After finishing one key landing, the quadcopter slowly
down to the ground, and stops turning.
One key take-off/landing
(picture 1)
(picture 2)

-5-
Wifi FPV Instruction
Flying Preparation
We suggest the beginner to practice within 10 meters.
After you are skillful, you can play in far distance.
According to you mobile phone systems, scanning OR code to download the APP.
Open Setting. Find the unlocked WIFI of quadcopter,and connect it.
Start the APP to enter startup interface,turn on height-locating mode and click "START"
to enter control interface.Viedo display means successful connection.
1: Unfold the quadcopter.
Clockwise rotate the four wings of
quadcopter in turn, stretch the quadcopter
to the flying condition.
(as pictures showed on the right)
2.Syncing the quadcopter
Turning on the quadcopter, keep it in a horizontal position.
Then turn on the transmitter, the bottom four LED lights flash quickly.
Push the throttle lever to the highest position ,then pull it back to the lowest position,
there will be one clear sound from the transmitter, it shows the binding finished.
3.Calibration
Pushing the left lever to bottom left, and push the right lever to bottom right (Two
actions should be executed at the same time.)The bottom four LED lights flash quickly ,
then become bright , it means the calibration succeeded.
Note: Before flying, the quadcopter needs to be calibrated.
5. Low power warning
When the quadcopter is in the low power status, the bottom four LED lights keep
flashing slowly. Quadcopter should be stopped flying and be charged.
APP(IOS) APP(Android)
4.Unlock
Pushing the left lever to bottom left, and push the right lever to bottom Left (Two actions
should be executed at the same time.)The quadcopter move slowly , it means the
calibration succeeded.

-5-
-6-
Instruction
Push the throttle
lever up or down,
the quadcopter
flies upward or
downward.
Push the throttle lever
left or right, the
quadcopter turns left
or right.
Push the direction lever
up or down, the quadcopter
flies forward or backward.
Push the direction lever
left or right, the quadcopter
flies left side or right side.
Hold the direction
lever and push forward
the quadcopter does
360°forward rolling
action.

-7-
Hold the
direction lever and
push backward, the
quadcopter does 360°
backward rolling
action.
Hold the
direction lever and
push left, the
quadcopter does 360°
rolling action left side.
Hold the
direction lever and
push right, the
quadcopter does 360°
rolling action right
side.

-8-
Attention
Special Note
Notes of Using the Lithium Battery
★Keep a suitable distance from the quadcopter fo r safety.
★Do not look straightly to the lights, they will be laser radiation.
★If the transmitter or quadcopter is lack of power, the control distance and height of flying will
be affected.
★If the quadcopter is broken, please repair it in time. Do not play quadcopter when
propellers are damaged.
★Please put out the batteries to avoid battery leakage when do not be used for a long time.
★Do not let the quadcopter crash at a high altitude, because tit will be damaged and the
lifetime will be shorter.
★There is certain risk exiting when using the lithium battery as it may cause would to your body
or cause substantial loss to your property. Please not that the user should take all the
responsibility by its own. Manufacturer and sales agent won’t take any responsibility on the boy
injury or property loss as we can not monitor or control the user’s behavior during the process of
using the battery (for example: charging, discharging or storage of the battery, etc.)
★ If there is any battery leakage happened, please try to avoid the leakage fluid being contacted
with the skin or eyes. In case that it has reached the skin, please rinse it with soap and clear
water. In the case it has reached the eyes, please rinse it with massive cold water and go see
the doctor immediately.
★ If the charger appears suspicious smell, noise or smoke, please unplug it from the power socket
immediately.
★ Please strictly follow the following requirement. Otherwise it may cause fire disaster, electric
shock or explosion.
Push the throttle lever slowly, then use the spinner action to
control when the quadcopter spinning or deviating
in the sky.
When the quadcopter fly within 30 cm between the ground or the ceiling,
the quadcopter becomes unstable because of blades swirl, this is
"Ground effect". Lower weight,bigger ground cffcct.
Note:
Charging
★ Original special-purposed charge should be required when charging the battery. Damaged
charger or any other chargers are highly forbidden to be used.
★ Please do not charge the batteries that is swollen, leakage or damaged.
★ Please do not overcharge the battery. When batteries are full charged, please unplug the
charger and finish charging.
★ Please do not charge on the flammable or combustible surface (such as carpet, wooden floor,
solid wooden furniture, etc) or on the electric-conductive surface. You are required to watch
carefully the battery and the surface where you need to charge. Please do not re-charge this
battery so as to avoid overheating.

-9-
Use and store
★The charging temperature of the battery should be between 0-40 Celsius degree.
★Wrapping the broken or damaged battery by plastic is highly forbidden.
★When starting this equipment, please do not load or remove the battery.
★Please do not over pose the battery and avoid excessive physical collision.
★Using the battery that is swollen, leakage, broken or even sending out smell is highly forbidden.
★Children are forbidden to touch the battery.
★Please do not throw the battery into the fire. Try to avoid the battery being contacted with the
liquid. This equipment is forbidden to be put in the rain. Not does it to be placed in the moisten
area. Please do not put the batter into the microwave or pressure tank.
★Please do not disassemble, drill or transform or cut the battery as the battery or charge can not
sustain the heavy object. Striking the battery is highly forbidden.
★Please do not use any solvents, industrial-purposed alcohol in any other flammable solvents to
clean the charge.
★In order to prevent from being short-circuited, please avoid being contacted by the electrolyte
substance in the battery as electrolyte substance and electrolyte steam dose great harm to the
human body.
★Please store this equipment under the normal room temperature. Please do not put this
equipment under extreme temperature. Try it avoid storing or on the place where temperature
has substantial change.
★Please do not place this product near the hear source.
★Please remove the batteries if you do not use it.
★Please be familiar with the method that the local trash is centralized and disposed.
Recycle
★Please do not treat this equipment as the daily trash. Battery that is damaged or can not be
used should be put into the special-purposed container.
★This equipment is composed of electronic component and battery. Regarding the electronic
trash, please dispose in accordance with special regulation.
★Please be familiar with the way the local trash is centralized and disposed.
★ Please do not charge immediately when the product is just finished using or the battery is still
hot enough.
