Gearhead KB5000WDR User manual

120944-109128
Rev.061017
WirelessDesktop&OpticalMouse
Model: KB5000WDR
User’sManual

2
User’sRecord:
Toprovide qualitycustomer serviceandtechnicalsupport, itissuggested thatyoukeepthe
followinginformationaswell as your storereceiptandthis user’smanual.
DateofPurchase:
__________________________________
ModelNumber:
__________________________________
SerialNumber:
__________________________________
ProductRevNumber(locatedbelowtheUPConthepackage):
__________________________________

3
PackageContents:
YournewWireless Desktopwill ship withthefollowingitems.
§Wireless Desktop&OpticalMouse
§WiredReceiverwithDualPS/2 Connectors
§Detachable Palmrest
§6AAA Ni-MHRechargeable Batteries
§User’sManual
§Warranty Information
SystemRequirements:
Pleasebesure thatyoumeetall ofthesystemrequirementsbelowtoavoiddifficultiesduringinstallation.
§IBMPCsor100%Compatibles
§Windows®ME, 2000, XP
§2Available PS/2 Ports
SystemSpecifications:
YournewWireless Desktopcomplieswiththefollowingspecifications.
§PS/2 Interface

4
Installation:
NOTE: The picturesshown in theUser’sManualarefordemonstrationpurposesonly.Yourcomputerorproductmay lookslightly different.
1. Turnoffyourcomputer.
2. PlugyourReceiverintothe appropriate PS/2Ports onyourcomputer.
3. Turnonyourcomputer.
4. YourcomputerwilldetectyourReceiver,andthenecessary driverswill be installedautomatically.

5
BatteryInstallation:
Toinstall batteriesintoyourMouse, pleasefollowthe instructionsbelow:
a. Removethe BatteryCompartmentCover fromthe bottom ofyourMouse.
b. Install twoofthe enclosed AAA Ni-MHRechargeableBatteries into the BatteryCompartment followingthe battery
orientationguideprintedinsidethe compartment.
c. Replacethe BatteryCompartmentCover backonto yourMouseuntil itsecurely locks.
d. YourMousewill establishaconnectionwiththereceiverautomatically.Ifaconnectionisnot established,proceedtothe
EstablishaConnection sectionofthismanual.

6
Toinstall batteriesintoyourKeyboard,pleasefollowthe instructionsbelow:
1. Removethe BatteryCompartmentCover fromthe bottom ofyourKeyboard.
2. Install twoofthe enclosed AAA Ni-MHRechargeableBatteries into the BatteryCompartment followingthe battery
orientationguideprintedinsidethe compartment.
3. Replacethe BatteryCompartmentCover backonto yourKeyboarduntil itsecurely locks.
4. Yourkeyboardwill establishaconnectionwiththereceiverautomatically.Yourkeyboardandmousearenowready to
be used.Formoreinformationaboutyourspecialfunctionkeyspleasesee the Special FunctionKeys Section ofthe manual. Ifa
connectionisnot automatically established,proceedto the EstablishaConnection sectionofthismanual.

7
EstablishaConnection:
Press the ConnectButton onyourWireless Receiverfor6seconds,the AutoSyncfunctionofyourreceiverwillbe activatedandwill begin
searchingforyourKeyboardandMouse, anautomatic connectionwillbe establishedbetween yourreceiver,mouseandkeyboard.Ifthisdoes
not occurpleasefollowtheinstructionsbelow.
Toestablishadedicatedconnectionbetween yourWiredReceiver,Keyboard,Mouse, andcomputerpleasefollowthe instructionsbelow:
Note: Anautomatic connectionmay fail iftherearemorethanone KB5000WDRWireless Desktopsoperatingwithin acloseproximity.The
followinginstructionsareforadedicatedconnection:
1. Press the ConnectButton onyourWireless Receiver,andthen press the ConnectButton onthe bottom ofyourKeyboard.

8
2. Press the ConnectButton onyourWireless Receiver,andthen press the ConnectButton onthe bottom ofyourMouse.
3. YourKeyboardandMousearenowready tobe used.

9
WiredReceiverLEDIndicators:
TherearefourLEDIndicatorsonyourWiredReceiver,pleasesee the chartbelowforadescriptionofeach(startingfromlefttoright):
LEDIndicator Status Description
Signal LED(Green/Red) Green Solid If thegreen LEDissolid,yourcomputerispoweredonandyourWired
Receiverisconnected.
RedBlinkingRapidlyIf theredLEDblinksrapidly,yourWiredReceiverisscanningforaconnection
to yourkeyboardand/ormouse.
RedBlinking If theredLEDblinks,yourWiredReceiverhasestablishedaconnectiontoyour
keyboardand/ormouse.
RedBlinkingSlowlyIf theredLEDflashes,yourkeyboardand/ormouseisactive.
NumLockLED(Red) RedSolid If theredLEDissolid,numberlockisenabled.
CapsLockLED(Red) RedSolid If theredLEDissolid,capslockisenabled.
ChargeLED(Red) Off If theLEDisoff,nobatteriesareinstalledin yourWiredReceiver,orthe
batteriesinstalledarefully charged.
RedSolid If theLEDissolidred,yourWiredReceiverischargingthe installedbatteries.

10
Recharging YourNi-MHBatteries:
TorechargeyourNi-MHBatteriesusingyourWiredReceiver,pleasefollowthe instructionsbelow:
1. Make sureyourcomputeristurnedonandyourWiredReceiverisconnectedtoyourcomputer.
2. Press down andthen slideoff the BatteryCompartmentCover fromyour WiredReceiver.
3. PlacetwoNi-MHBatteriesinto the BatteryCompartment followingthe batteryorientationguideprintedinsidethe compartment.
4. Replacethe BatteryCompartmentCover backonto your WiredReceiver.
5. The ChargeLED willturnsolidredandthe installedbatterieswill begin charging.
6. When the LEDindicatorturnsoff,the batteriesarefully charged.
