Geberit AquaClean 8000plus User manual

Geberit AquaClean 8000plus
Operating
instructions

Operating instructions Geberit AquaClean 8000plus
3
For true well-being .................................................................................................. 4
Added value for health and well-being.............................................................................. 4
Easy to operate................................................................................................................ 4
Any questions about Geberit AquaClean? ........................................................................ 4
Warranty card registration ................................................................................................ 4
Environment..................................................................................................................... 4
Important notes ...................................................................................................... 5
Intended use.................................................................................................................... 5
Declaration of conformity ................................................................................................. 5
For your safety ................................................................................................................. 5
Operation......................................................................................................................... 5
Explanation of symbols .................................................................................................... 5
Geberit AquaClean 8000plus operation .................................................................. 6
Overview of controls ........................................................................................................ 6
Control panel ................................................................................................................... 6
Geberit AquaClean 8000plus remote control.................................................................... 7
Additional functions of the Geberit AquaClean 8000plus remote control........................... 8
Integrated control panel ................................................................................................. 10
Using Geberit AquaClean 8000plus ................................................................................ 11
Using the lady shower..................................................................................................... 12
What you should know ......................................................................................... 13
Spray shield ................................................................................................................... 13
Storing the remote control ............................................................................................. 13
WC seat and lid with lowering function........................................................................... 13
User-defined settings ............................................................................................ 14
Saving user profiles......................................................................................................... 14
Basic settings ................................................................................................................. 15
Restoring the factory setting ........................................................................................... 15
Care and cleaning ................................................................................................ 16
Care instructions ............................................................................................................ 16
Components.................................................................................................................. 16
Permissible cleaning agents and cleaning equipment ..................................................... 17
Non-permissible cleaning agents and cleaning equipment ............................................. 18
Tips................................................................................................................................ 19
Cleaning the WC seat, WC lid and casing ....................................................................... 20
Cleaning the hinges, the cover, the dryer arm and the spray arm .................................... 20
Cleaning the WC ceramic appliance................................................................................ 21
Troubleshooting ................................................................................................... 22
Malfunctions during operation ........................................................................................ 22
Replacing the remote control batteries ............................................................................ 24
Replacing the active carbon filter..................................................................................... 25
Refilling nozzle cleaner .................................................................................................... 26
Replacing the spray nozzle and cleaning the opening of the spray arm ........................... 27
Replacing the dryer arm and cleaning the opening of the dryer arm ................................ 28
Removing and fitting the WC seat and WC lid ................................................................. 29
Technical data ...................................................................................................... 30
End user warranty ................................................................................................ 31

Operating instructions Geberit AquaClean 8000plus
4
For true well-being
The Geberit AquaClean 8000plus is a toilet which reclaims the source of freshness
and cleanliness: water. A single water jet cleans your bottom with a pleasant and
gentle feel. Application is simple yet effective. Toilet paper, a towel or the integrated
dryer can be used for drying.
Added value for health and well-being
Additional functions like the oscillating spray, the lady shower for natural cleansing of
the sensitive female genital area, a pulsating massage spray, warm air dryer, remote
control or memory function round off this shower concept.
Easy to operate
Operation is effortless, requiring you simply to either press the clearly labelled buttons
on the side of the unit or use the remote control, via which you can also call up your
personal settings.
Any questions about Geberit AquaClean?
Our after-sales team will be happy to respond to your enquiries.
Please contact your responsible Geberit sales company.
Warranty card registration
So that we can provide you with optimum support, please take the opportunity to
register your contact details online - the process is very straightforward and takes next
to no time to complete.
• www.i-love-water.com
Environment
This product meets the requirements of the EU directive "Restriction of Hazardous
Substances" (2002/95/EC). It is largely free from hazardous substances such as lead,
mercury, cadmium and chrome VI, which are environmental pollutants.
All old Geberit AquaClean 8000plus can be returned to Geberit free of charge for
proper disposal. This arrangement applies to all EU member states as well as to
Switzerland and Norway. Equipment can be returned to the responsible Geberit sales
company (see the website of your respective country for the address).

Operating instructions Geberit AquaClean 8000plus
5
Important notes
Intended use
The Geberit AquaClean 8000plus is a toilet which is also designed for cleansing the
anal area and, with the lady shower, for cleansing the vaginal area. Its use for any other
purpose is deemed improper. Geberit accepts no liability for the consequences of
improper use.
Declaration of conformity
You can obtain a copy of the declaration of conformity from your responsible Geberit
sales company.
For your safety
• In the event of evidence of damage to the Geberit AquaClean, disconnect the unit
from the mains immediately and contact Geberit Customer Service.
• If the mains connection cable is damaged, it must be replaced by a skilled person.
• Never open and repair the Geberit AquaClean yourself. Do not modify the unit or
add any additional modules. The Geberit AquaClean contains live parts. Opening
the unit exposes those present to fatal danger.
• Repairs may only be carried out by trained and authorised skilled persons using
original spare parts and accessories.
• The Geberit AquaClean must only be connected to a mains voltage conforming to
the specification plate. The specification plate is located behind the maintenance
flap. You will find more technical data in the chapter titled "Technical data".
Operation
• People who are not familiar with the Geberit AquaClean 8000plus, especially
children, must be shown how to use it.
• Everyone's temperature sensitivity is different. Please always check the dryer and
water temperature settings before using the Geberit AquaClean 8000plus.
• Operation and maintenance work may only be performed by the operator or user
as described in these operating instructions.
• The Geberit AquaClean 8000plus may only be operated with drinking water.
Explanation of symbols
DANGER
Refers to a potentially dangerous situation that may cause serious injury or
death.
Refers to important information.

Operating instructions Geberit AquaClean 8000plus
6
Geberit AquaClean 8000plus operation
Overview of controls
Control panel
1 Control panel
2 Power switch
3 Active carbon filter compartment
4 Maintenance flap
5 Serial number
6 Filling tray for nozzle cleaner
7 Cleaning instructions for end users
1
2
36
7
5
4
8 Spray arm
9Dryerarm
10 User detection
8899
1010
1Sprayintensity
2 LED displays
3 Odour extraction unit
4Drying
5 Start and stop shower
6 Remote control compartment
1
2
34
5
6

Operating instructions Geberit AquaClean 8000plus
7
Geberit AquaClean 8000plus remote control
Additional functions of the Geberit AquaClean 8000plus remote control
You can use the remote control to call up all of the additional functions or to make and
save personal settings. To activate the remote control, touch any button once. The
display appears. The display switches off automatically 10 min after use.
Display
D1 Shower water / dryer air temperature display
D2 Dryer temperature
D3 Service icon
D4 Water heater function status indicator
D5 Nozzle cleaner refill icon
D6 Filter replacement symbol
D7 Odour extraction unit
D8 Drying
D9 Spray arm position
D10 Oscillating spray
D11 Massage spray
D12 Spray intensity
D13 Error icon
D14 Activated user profile I/II/III/IIII
Buttons
1 <Shower>, start and stop
2 <Spray intensity ->, reduce
3 <Spray intensity +>, increase
4 <Odour extraction unit>
5<Drying>
6 <Oscillating spray>, start and stop
7 <Spray arm position> forwards and
backwards
8 <Service>
9 <Shower water / dryer air temperature>
10 <Water heater function>
ON/economy mode/OFF
11 <Massage spray>, start and stop
12 <User profiles I/II/III/IIII>, on and off
13 <Lady shower>
2
13
11
10
3
4
7
8
6
12
9
1
D12
D14
D11
D13
D3
D10 D9 D8
D7
D6
D5
D4
D1 D2
5
The Geberit AquaClean 8000plus with visible cistern supports three user profiles.
This version also supports a <toilet flush> button for activating the toilet flush.

Operating instructions Geberit AquaClean 8000plus
8
<Lady shower>
The low spray intensity has a pleasant and gentle feel whilst cleaning.
Press the button: The spray arm moves into position and the shower
procedure starts. The shower stops after 20 s. You can stop the
shower before this by pressing the <shower> button.
<Toilet flush>
Press the button: Triggers a full flush
(Geberit AquaClean 8000plus with visible cistern).
<User profile>
Press the button: The user profile is activated with its saved settings.
<Massage spray>
The pulsating massage spray is pleasant and relaxing.
Press the button: The massage spray is activated. The function can be
activated before or during the shower procedure.
Press the button again: The massage spray is deactivated.
<Spray arm position>
To suit your sitting position, the spray arm can be moved forwards or
backwards through 7 positions in accordance with the directions
shown on the arrow button.
Press the button: Sets the position of the spray arm.
<Oscillating spray>
The oscillating spray intensifies cleaning efficiency.
Press the button: The oscillating spray is activated. The function can be
activated before or during the shower procedure.
The spray arm moves back and forth.
Press the button again: The oscillating spray stops.
<Water heater function>
Press the button:
• : Heating element is switched on. The water temperature is preset
to 37 °C
• : Economy mode (factory setting). In economy mode, the heating
element only switches on if user detection is activated. The warm-up
time is 3 to 4 minutes.
• : Heating element is switched off.
<Shower water temperature>
Sets the required shower water temperature.
Press the button: Increase or reduce temperature.
<Dryer air temperature>
Sets the required dryer air temperature.
Prerequisite: Select the drying function.
Press the button: Increase or reduce temperature.

Operating instructions Geberit AquaClean 8000plus
9
<Service>
To deactivate the spray functionality for manual cleaning or for
changing the spray nozzle or dryer nozzle.
Press the button: The spray arm / dryer arm extends but is not in
operation.
See chapter "Troubleshooting" for more information.
Geberit AquaClean 8000plus for concealed cisterns:
• Press the actuator button on the actuator plate on the wall (large actuator button
for full flush, small actuator button for partial flush)
Geberit AquaClean 8000plus with visible cistern:
• Press the actuator button on the cistern (large actuator button for full flush, both
actuator buttons for partial flush) or
• Press the <toilet flush> button on the remote control (full flush)

Operating instructions Geberit AquaClean 8000plus
10
Integrated control panel
<Shower>, starting and stopping
Press the button: The spray arm moves into position and the
shower procedure starts. The shower automatically stops
after 20 s.
You can stop the shower before this by pressing the
<shower> button.
Press the button again: The shower stops.
<Spray intensity>
Adjust the sliding button during the shower procedure to
change the spray intensity of the anal shower or the lady
shower.
There are 7 spray intensity levels to choose from.
<Odour extraction unit>
Prerequisite: Odour extraction unit is switched on.
The odour extraction unit starts as soon as someone sits
down on the toilet.
Press the button: The odour extraction unit stops.
Press the button again: The odour extraction unit starts.
<Drying>
Prerequisite: Drying is activated.
Drying starts after the shower procedure and stops as soon
as you stand up. You can interrupt drying before this by
pressing the <drying> button.
Press the button: Drying stops.
Press the button again: Drying starts.
Blue LED Meaning
Lights up Heating element is switched on. In economy mode (factory
setting), the heating element only switches on if user
detection is activated. The warm-up time is 3 to 4 minutes.
Does not light up Heating element is switched off
Red LED Meaning
Lights up Replace active carbon filter or refill nozzle cleaner
Flashing Error message (see "Troubleshooting")

Operating instructions Geberit AquaClean 8000plus
11
Using Geberit AquaClean 8000plus
Shower concept:
• The spray nozzle is automatically cleaned with fresh water before and after each
shower procedure.
• The rinsing chamber and spray nozzle are also cleaned after each shower
procedure with a cleaning agent and then cleaned with fresh water.
You control the intensity and aim of the water jet.
The shower spray gradually cools down continuously during the shower procedure.
Prerequisites
Odour extraction unit and drying are activated.
Thanks to the user detection, the shower procedure can only be activated once
someone sits down on the toilet. The Geberit AquaClean 8000plus can be used as a
normal toilet at any time.
1 Sit down on the toilet.
Result
The odour extraction unit starts automatically, ensuring that you do not leave any
unpleasant odours behind. It stops as soon as you stand up.
2 Press the <shower> button.
Result
The shower starts and stops after 20 s.
You can interrupt the shower procedure before this by pressing the <shower>
button.
The warm air dryer starts automatically at the end of the shower procedure. It stops
as soon as you stand up or press the <drying> button.
3 Press the <toilet flush> button.

Operating instructions Geberit AquaClean 8000plus
12
Using the lady shower
You control the intensity and aim of the water jet.
The shower spray gradually cools down continuously during the shower procedure.
1 Press the <lady shower> button.
Result
The lady shower starts and stops after 20 s.
You can stop the shower before this by pressing the <shower> button.
The warm air dryer starts automatically at the end of the shower procedure. It stops
as soon as you stand up or press the <drying> button.
2 Press the <toilet flush> button.

Operating instructions Geberit AquaClean 8000plus
13
What you should know
Spray shield
The spray shield can be used to test the performance of the Geberit AquaClean
8000plus without anyone sitting on the toilet. You have to cover the user detection and
can use the remote control to test all functions.
Storing the remote control
WC seat and lid with lowering function
1 Spray shield
2Userdetection
2
1
The remote control can be stored in the remote
control compartment or in a separate wall-
mounted holder.
Dampers cushion the WC seat and lid noiselessly
and slow down closing. The seat and lid open
just like any normal WC seat and lid.
Do not press the WC seat and lid down with your hand. This will damage the
dampers.

Operating instructions Geberit AquaClean 8000plus
14
User-defined settings
Saving user profiles
Every user responds differently. That is why it is possible to personalise the following
functions:
•Sprayintensity
• Water temperature
• Spray arm position
• Odour extraction unit on and off
• Drying on and off
• Dryer temperature
• Massage spray on and off
• Oscillating spray on and off
Simply use the memory function to avoid having to make your settings from scratch
every time. Personal settings for the Geberit AquaClean 8000plus can be saved in a
user profile.
The Geberit AquaClean 8000plus with cistern supports three user profiles.
The Geberit AquaClean 8000plus for concealed cisterns supports four user profiles.
All of the settings can also be changed and saved when the user detection is inactive,
i.e. when no-one is sitting on the toilet.
1 Touch any function once to activate the remote control.
2 Set the desired values on the remote control.
3 Press and hold down the <user profile> button for 2 s.
Result
A signal sounds.
The settings are saved in the corresponding user profile.

Operating instructions Geberit AquaClean 8000plus
15
Basic settings
The following settings can be changed:
•Sprayintensity
• Water temperature
• Spray arm position
• Dryer temperature
• Massage spray on and off
• Oscillating spray on and off
1 Touch any function once to activate the remote control.
2 Set the desired values on the remote control.
3 Press and hold down buttons <I> and <II> simultaneously for 2 s.
Result
A signal sounds.
The changes to the basic settings are saved.
Restoring the factory setting
`Press and hold down the <service> and <water heater function> buttons on the
remote control simultaneously for 2 s.
Result
A signal sounds.
All factory settings are restored.

Operating instructions Geberit AquaClean 8000plus
16
Care and cleaning
Geberit AquaClean 8000plus is a high-quality, easy-care product.
The WC ceramic appliance has a special coating. This coating draws water drops
together to form spheres which drip away very effectively. Residue such as limescale
and dirt is taken up by the water drops and simply flushed away with them. This effect
is very environmentally-friendly, as aggressive WC cleaning agents are no longer
required. The WC seat and lid are easy to clean and, if necessary, to remove. Similarly,
the spray nozzle can easily be replaced if it becomes blocked with limescale or
clogged with dirt.
Care instructions
As a general rule, water, a mild washing-up liquid that is kind to the skin and a not
scratching sponge or a soft cloth will suffice for regular cleaning. Take action to
prevent the build-up of limescale deposits. When you have finished cleaning, wipe
away any remaining drops of water on the cover with a soft cloth (do not use a
cleaning agent when doing this).
Components
To meet demands for design and performance, the Geberit AquaClean 8000plus
comprises a number of different components. Therefore, we ask that you follow the
cleaning instructions below, as the warranty does not cover surface damage and
material damage caused by improper use.
Aggressive cleaning agents can damage the material surface. Therefore, we ask that
you follow the care and cleaning instructions below.
1 WC seat and WC lid
2 Hinges, cover, dryer arm and spray arm
3 WC ceramic appliance
4Casing
1
2
3
4

Operating instructions Geberit AquaClean 8000plus
17
Permissible cleaning agents and cleaning equipment
Cleaning agents
Cleaning agents are permitted to have a low acid content; e.g. they may
contain citric acid.
Cleaning agents should ideally be diluted with water.
Cleaning agents must be fluid.
Cleaning agents must be dermatologically tested.
The use of foaming cleaning agents is permitted.
Cleaning equipment
Sponge, eraser
Cloth, shammy leather
Toilet brush

Operating instructions Geberit AquaClean 8000plus
18
Non-permissible cleaning agents and cleaning equipment
Cleaning agents
The use of powdery cleaning agents, such as scouring powder or
scouring agent, is not permitted.
The use of corrosive cleaning agents, such as concentrated drain
cleaners, is not permitted.
The use of cleaning agents which may irritate the eyes or the skin is not
permitted.
The use of cleaning agents with a high chlorine concentration is not
permitted.
The use of abrasive cleaning agents such as sand or scouring liquid is
not permitted.
Xi
Cleaning equipment
Scratching sponge
Steel wool, steel cleaner, scrubbing sponge

Operating instructions Geberit AquaClean 8000plus
19
Tips
Problem Fault clearance
Urine scale deposits on the WC
ceramic appliance
To clean, apply a mild bathroom cleaner (4 ≤pH value ≤9)
and leave to work for 30 minutes, then rinse with water.
Cleaning gels and foam cleaners are particularly good for
this type of cleaning, as they stick to sloping surfaces.
Rusty water residue on the WC
ceramic appliance
Will not damage the coating on the WC ceramic
appliance. To clean, apply a mild bathroom cleaner
(4 ≤pH value ≤9) and leave to work for 30 minutes, then
rinse with water.
Use of disinfectants Apply disinfectant with a soft cloth and wipe the
components clean. Test the disinfectant for suitability.
Limescale deposits on the WC
ceramic appliance
To clean, apply a mild bathroom cleaner (4 ≤pH value ≤9)
and leave to work for 30 minutes, then rinse with water.
Limescale deposits on the cover Apply a mild bathroom cleaner with a soft cloth and wipe
the chrome cover clean. Then rinse with water and dry the
cover.
Spray nozzle blocked with limescale
or clogged by foreign bodies in the
water
To clean the spray nozzle, submerge it in standard
limescale remover for a few hours.

Operating instructions Geberit AquaClean 8000plus
20
Cleaning the WC seat, WC lid and casing
Do not use scratching sponges or scouring agents for cleaning. We also advise
against the use of cleaners containing solvent or acid, limescale removers, vinegar
and cleaning agents containing acetic acid. They corrode the surface and can lead to
discolouration.
1 Wipe the components with a soft cloth and a mild washing-up liquid which is kind to
the skin.
2 Dry the components with a soft cloth.
Cleaning the hinges, the cover, the dryer arm and the spray arm
Do not use scratching sponges or scouring agents for cleaning. We also advise
against the use of cleaners containing solvent or acid, limescale removers, vinegar
and cleaning agents containing acetic acid. They corrode the surface.
1 Wipe the components with a soft cloth and a mild washing-up liquid which is kind to
the skin.
2 Dry the components with a soft cloth.
