Gecko GALILEE CLASSIC PSC8330 User manual

GECKO® GALILEE CLASSIC PSC 8330
www.geckomusic.net
www.geckomusic.net
OWNER'S MANUAL
OWNER'S MANUAL

GECKO® SAFETY INSTRUCTIONS & SYMBOLS GUIDE
GECKO® SAFETY INSTRUCTIONS & SYMBOLS GUIDE
For your own safety and to avoid invalidation of the warranty, all text marked with these symbols should be
read carefully.
SYMBOLS:
SYMBOLS:
SAFETY INSTRUCTIONS:
SAFETY INSTRUCTIONS:
•To reduce the risk of electrical shock, do not remove covers. No user serviceable parts inside. Please
refer servicing to qualified personnel.
•To reduce the risk of electrical shock or fire, do not expose the equipment to rain or moisture.
•Do not impose unnecessary stress on your equipment (i.e. placing heavy objects on it, overscrewing its
mounting etc).
•Read and keep the instruction manuals in a safe place for future references.
•Do not attempt to clean the equipment with chemical solvents as this may damage the finish. Clean only
with dry cloth.
•Do not block any ventilation openings.
•Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus that
produce heat.
•Do not defeat the purpose of the polarized or grounding type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide
blade or the grounding prong is provided for your safety. If the provided plug does not fit into your outlet,
consult an electrician for the replacement of the obsolete outlet.
•Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
•Unplug the apparatus during lightning storms or when it is not in use for a long period of time.
NOTES
NOTES
Contain important information and useful tips on the operation of your equipment.
WARNING
WARNING
The lightning flash with arrowhead symbol within an equilateral triangle, is intended to
alert the user to the presence of uninsulated dangerous voltage within the product’s
enclosure that may be of sufficient magnitude to constitute a risk of electric shock.
CAUTIONS
CAUTIONS
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in thee
literature accompanying the appliance. Please read the manual carefully.
H
HEADPHONES EADPHONES SAFETY SAFETY WARNIN WARNING G
Contain important information and use useful tips on headphones outputs and monitoring
levels.
!

•Use only attachments / accessories specified by the manufacturer.
•Always shut down power supply when not in use to save energy and for prolonged lifespan.
•Exposure to extremely high noise levels may cause permanent hearing loss. Individuals vary
considerably in susceptibility to noise-induced hearing loss, but nearly everyone will lose some hearing if
exposed to sufficiently intense noise for a period of time. The U.S. Government’s Occupational Safety
and Health Administration (OSHA) has specified the permissible noise level exposures shown in the
following chart. According to OSHA, any exposure in excess of these permissible limits could result in
some hearing loss. To ensure against potentially dangerous exposure to high sound pressure levels, it is
recommended that all persons exposed to equipment capable of producing high sound pressure levels
use hearing protectors while the equipment is in operation. Ear plugs or protectors in the ear canals or
over the ears must be worn when operating the equipment in order to prevent permanent hearing loss if
exposure is in excess of the limits set forth here:
Duration/Day (Hours) dB, Sound Pressure Level (SPL) Descriptions
Below 90 dB Safe zone
8.00 90 Hearing damage
6.00 92
4.00 95
3.00 97
2.00 100 Serious hearing damage
1.50 102
1.00 105
0.50 110
0.25 or less 115 Human pain threshold
GECKO MUSIC GROUP
GECKO MUSIC GROUP
No. 59, 59-1, 61, 61-1, 63, 63-1, Jalan PE 3, Taman Paya Emas,
Paya Rumput, 76450 Melaka, Malaysia.
Mobile: [phone]
Email: [email protected] • Website: www.geckomusic.net

FOREWORD
FOREWORD
Dear Friends,
Thank you very much for purchasing quality products by GECKO MUSIC GROUP. I am indeed very
delighted that we have journeyed this far, setting new standards in the audio and music industry while
touching and changing lives along the way!
At GECKO MUSIC GROUP we focus on developing nothing but the best professional audio equipment and
premium grade musical instruments you ever need! It has been our philosophy all this while that good sound
reproductions can be achieved at a fraction of a premium. Our engineering team is constantly doing research
and development to meet this objective. We thank God that by HIS grace, we have succeeded in developing
the revolutionary C.R.I.S.T.A.L.® Audiophile technology that is changing the way how sound is being
encoded, reproduced and managed!
On behalf of GECKO MUSIC GROUP, I would like to pledge our continuing commitment to uphold our
traditions in serving music and audio communities around the world with more value-added highest possible
quality GECKO® professional audio equipment and premium grade musical instruments!
Once again, thank you very much for your support.
Yours truly,
Daniel Foo
Founder / Chairman
GECKO MUSIC GROUP

TABLE OF CONTENTS
TABLE OF CONTENTS
INTRODUCTION 1
CONTROL ELEMENTS 2
SPECIFICATIONS 5
WARRANTY 6
NOTES: Congratulations on purchasing the all new GECKO®
GALILEE CLASSIC PSC 8330 power sequencer! We recommend that
you take a moment and read through the manual as it provides
information that will assist you in using your unit to its fullest potential.
______________________________________________________________________________________
© GECKO MUSIC GROUP. All Rights Reserved.

INTRODUCTION
INTRODUCTION
The all new GECKO® GALILEE CLASSIC PSC 8330 power sequencer is specifically designed and
developed for your audio and music devices. Be it in the recording studio, at the venue, on the stage, or for
audiophile applications, the GECKO® GALILEE CLASSIC PSC 8330 maximizes the performance of your
audio and music system, making sure your system's tone quality is consistent and every nuance is being
reproduced, while protecting your system from power surge and spike, electromagnetic interference (EMI)
and electrical noise, and simplifying your system management process.
The GECKO® GALILEE CLASSIC PSC 8330 utilizes microprocessor controlled delay for precise 1.0s
interval power sequencing of its eight universal AC outlets on the rear panel, preventing AC spikes from
harming your audio and music system during system startup. To reduce the chances of mistaken identity of
the universal AC outlets by the user, the GECKO® GALILEE CLASSIC PSC 8330 front panel LINE 1 to 8
ascending order is set from left to right, identifiable with lighted green LED. Its rear panel LINE 1 to 8
universal AC outlets ascending order is also set from left to right; apart from the available clear channel
labelling.
The GECKO® Remote Switching (GRSW) function on the GECKO® GALILEE CLASSIC PSC 8330 allows
the GALILEE CLASSIC PSC 8330 to be activated and deactivated over a distant via cable trigger switching,
while the analogue voltmeter allows you to monitor your AC mains in real time.
With the GECKO® GALILEE CLASSIC PSC 8330 on-board multi-stage electromagnetic interference (EMI)
filter and High Voltage Varistor (MOV) Suppressor technology, you can be sure your audio and music system
is getting only the cleanest and safest power supply!
Complete System Summary:
* 1.5U design;
* universal AC outlets for accepting different plugs type;
* 8 individually sequenced universal AC outlets with dedicated front panel LED indicators;
* microprocessor controlled 1.0s delayed interval preventing AC spikes from harming your system;
* foolproof LINE 1 to 8 universal AC outlets (left to right) ascending order;
* surge and spike protection using High Voltage Varistor (MOV) Suppressor technology;
* electromagnetic interference (EMI) filter;
* analogue voltmeter for real time AC mains monitoring;
* GECKO® Remote Switching (GRSW) features for remote operation;
* maximum output current for each line: 13A;
* maximum total output current: 25A.
______________________________________________________________________________________
1
1
© GECKO MUSIC GROUP. All Rights Reserved.

CONTROL ELEMENTS
CONTROL ELEMENTS
FRONT PANEL
1. METAL PUSH BUTTON SWITCH
This is the master switch for GECKO® GALILEE CLASSIC PSC 8330. Power up the GECKO® GALILEE
CLASSIC PSC 8330 by pushing in the switch. The power icon on the switch lights up (white) when the button
is in “pushed-in” position. This initiates a POWER ON sequence (LINE 1 to 8) for the rear outlets. Unpressed
the switch initiates a POWER OFF sequence (LINE 8 to 1). In POWER OFF sequence, the power icon on
the switch stays lit until all the rear outlets are completely sequenced off.
2. POWER LED INDICATOR
This POWER LED lights up red when the GECKO® GALILEE CLASSIC PSC 8330 is connected to an
external 220VAC ~ 240VAC, 50Hz/60Hz electrical supply.
3. LINE 1 TO 8 LED INDICATORS
The LINE 1 to 8 LED indicators, on the front panel, indicates the respective rear panel universal AC outlet's
power (ON/OFF) status. The LED lights up (green) when the relevant AC outlet is active (ON).
4. ANALOGUE VOLTMETER
This analogue voltmeter is for real time AC mains monitoring. It lights up blue when the GECKO® GALILEE
CLASSIC PSC 8330 is connected to an external 220VAC ~ 240VAC, 50Hz/60Hz electrical supply.
______________________________________________________________________________________
2
2
© GECKO MUSIC GROUP. All Rights Reserved.
7
5
4
7
7
7
1
2 6666 3

5. ANALOGUE VOLTMETER CALIBRATION
When needed, use this to calibrate the analogue voltmeter's reading using a reference source.
6. RUBBER FEET
Four (4) non-slip rubber feet to support and prevent the GECKO® GALILEE CLASSIC PSC 8330 from being
scratched and moved when placed on a hard surface (when the unit is not being mounted onto a standard
19” rack or flight case).
7. RACK MOUNTING HOLES
These are 1.5U rack mounting holes. Secure the GECKO® GALILEE CLASSIC PSC 8330 onto a standard
19” rack or flight case using M6 x 0.1mm screws.
REAR PANEL
8. REMOTE SWITCHING
This GECKO® Remote Switching (GRSW) allows the GECKO® GALILEE CLASSIC PSC 8330 be activated
or deactivated remotely via cable trigger switching. To use this feature, make sure the GECKO® GALILEE
CLASSIC PSC 8330 is connected to AC mains. With the PUSH BUTTON [ 1 ] depressed, plug in a wire with
its end terminated with ¼” TS connector into the GRSW ¼” TS socket. Terminate the other end of the wire
with a trigger switch type of your choice. You can now control the GECKO® GALILEE CLASSIC PSC 8330
via this cable trigger switching.
9. UNIVERSAL AC OUTLETS (LINE 1 TO 8)
These are the eight individual universal AC outlets on the rear panel. Each of these universal AC outlet is
rated with a maximum 13A output current tolerance. These universal AC outlets are compatible with 6A, 10A,
16A (Chinese Standards), 13A (UK Standards), 15A (US Standards), and G/M Connector (European
Standards).
______________________________________________________________________________________
3
3
© GECKO MUSIC GROUP. All Rights Reserved.
8
10
9

10. AC POWER CORD
This unit comes fitted with a 1.6m, unterminated three cores 60227 IEC 53 (RVV) 300/500V rated power
cord. You can terminate it with any AC plug type of your choice. Wiring color codes: green/yellow = ground;
red = live; black = neutral.
______________________________________________________________________________________
4
4
© GECKO MUSIC GROUP. All Rights Reserved.

SPECIFICATIONS
SPECIFICATIONS
Maximum Total Output Current:
25A
Maximum Output Current for Each Line:
13A
Input Voltage Range:
220VAC ~ 240VAC, 50Hz/60Hz (other voltage requirements are customizable)
Voltmeter:
Analogue Voltmeter (Blue LED Light) with calibration feature
Rear Panel AC Outlets:
LINE 1 to 8 (Left to Right): Universal AC Outlets. Compatible with 6A, 10A, 16A (Chinese Standards), 13A
(UK Standards), 15A (US Standards), and 15A (G/M Connector, European Standards) plug types.
Delay Interval:
Microprocessor Controlled Delay (1.0s)
Switch:
Metal Push Button ON/OFF Switch with White LED Light
Front Panel Indicators:
LINE 1 to 8 (Left to Right): Green LED
POWER: Red LED
Protections:
Spike Protection: Line to Neutral, Neutral to Ground, Line to Ground
Electromagnetic Interference (EMI) Filter: 20dB at 200kHz, rising to >40dB, 1Hz ~ 100MHz
Surge & Transient Protection: High Voltage Varistor (MOV) Suppressor
Remote Switching:
GECKO® Remote Switching (GRSW) via ¼” TS Socket (1)
Physical Properties:
Enclosure: Steel with Brushed Aluminium Faceplate
Color: Metallic Grey (Enclosure) / Silver (Brushed Aluminium Faceplate) / Black (Metal Push Button Switch)
Power Cord: 3 Cores 60227 IEC 53 (RVV) 300V/500V 10mm²; (L) 1.6m; unterminated
Net Weight: 3.80Kg
Dimension: (H) 65mm (w/o Rubber Feet); 75mm (w Rubber Feet) x (W) 483mm x (D) 274mm
Specifications subject to change without prior notice. Manufactured under ISO9000 certified management
system.
______________________________________________________________________________________
5
5
© GECKO MUSIC GROUP. All Rights Reserved.

GECKO
GECKO® ® TERMS OF WARRANTY TERMS OF WARRANTY
WARRANTY:
GECKO MUSIC GROUP warrants its GECKO® products for a period of three (3) years from the original date
of purchase, in accordance to the warranty regulations described below.
WHAT IS COVERED:
During the applicable warranty period, GECKO MUSIC GROUP warrants the product against defects in
materials and workmanship and against malfunctions. GECKO MUSIC GROUP will remedy all such defects
and malfunctions without charge for parts or labour if the warranty applies. In the case that other parts are
used which constitutes an improvement, GECKO MUSIC GROUP may, at its discretion, charge the customer
for the additional cost of these parts. Final determination of warranty coverage lies solely with GECKO
MUSIC GROUP.
WHAT IS NOT COVERED:
1. If the product needs to be modified or adapted in order to comply with applicable technical or safety
standards on a national or local level, in any country which is not the country where the product was
originally developed and manufactured, this modification/adaptation shall not be considered a defect in
material or workmanship.
2. Normal wear and tear, in particular, of faders, cross faders, potentiometers, keys/buttons, valves,
guitar/bass strings, machine heads, pick-up covers, vinyl covers, illuminants, and similar parts are not
covered by this warranty.
3. Improper handling, neglect or failure to operate the unit in compliance with the instructions given in the
user or service manuals.
4. Connection or operation of the unit in any way that does not comply with the technical or safety
regulations applicable in the country where the product is used.
5. Damages/defects caused by force of nature or any other condition that is beyond the control of GECKO
MUSIC GROUP.
6. Any repair or opening of the unit carried out by unauthorized personnel (user included) will void the
warranty.
7. Modification or removal of serial numbers.
OBTAINING WARRANTY SERVICE:
To return a GECKO® product for warranty service, first fill out the Online Technical Report on
www.geckomusic.net and submit for an authorization/service number. Write the authorization/service
number so that it is prominently displayed on the outside of the shipping carton. Any products received
without an authorization/service number that is clearly visible upon arrival at the factory will be refused.
Enclose proof of the original delivery date or a copy of the original sales receipt/invoice. Enclose a
description of the suspected defect or malfunction and the condition, if any, which caused the problem.
Return the product to GECKO MUSIC GROUP.
WARRANTY SHIPPING:
You are responsible for prepaying shipping costs F.O.B. GECKO MUSIC GROUP, Melaka, Malaysia.
Shipped product(s) must be properly packaged. Use original shipping cartons and packing materials where
possible. GECKO MUSIC GROUP is not responsible for damages resulting from inadequate and or improper
packing. Products received with damages due to improper packaging will be deemed out of warranty.
______________________________________________________________________________________
6
6
© GECKO MUSIC GROUP. All Rights Reserved.

Products which do not meet the terms of this warranty will be repaired exclusively at the buyer’s expense.
GECKO MUSIC GROUP will inform the buyer of such circumstance. If the buyer fails to submit a written
repair order within six (6) weeks after notification, GECKO MUSIC GROUP will return the unit C.O.D. with a
separate invoice for freight and packing. Such costs will also be invoiced separately when the buyer has sent
in a written repair order.
WARRANTY RIGHTS:
This warranty is exclusive and extended to the original buyer and is not transferable to anyone who may
subsequently purchase this product. No other person (apart from authorized GECKO® Stores) shall be
entitled to give any warranty promise on behalf of GECKO MUSIC GROUP.
______________________________________________________________________________________
7
7
© GECKO MUSIC GROUP. All Rights Reserved.
