GECMA BCSi-1 series User manual

MANUALBCSI-1REV1.8EN.DOC 19.12.08 A.J. -1-
Operating Manual
BCSi-1 *
Barcode scanner
Doc.Nr.:60000340

MANUALBCSI-1REV1.8EN.DOC 19.12.08 A.J. -2-
List of Contents
List of Contents ..................................................................................................................2
Introduction........................................................................................................................3
BCSi-1 * models available..............................................................................................4
Technical ata ...................................................................................................................5
Certificates ..........................................................................................................................7
Connections details ..........................................................................................................8
Terminal Connections ....................................................................................................11
Available Barcode symbologys and default settings............................................12
Sample barcodes ............................................................................................................15
Programming BCSi.........................................................................................................17
Appendix A.......................................................................................................................21
ASCII Value Table ...........................................................................................................23
Barcode settings..............................................................................................................28
Safety Instructions...........................................................................................................78
General Instructions ......................................................................................................79
rawings and certifications .........................................................................................79

MANUALBCSI-1REV1.8EN.DOC 19.12.08 A.J. -3-
Introduction
The barcode scanner BCSi are designed to read all common barcodes 1D & 2D and to transmit these
barcode data to an existing ASD (application supporting device) in ha ardous or non-ha ardous areas.
The BCSi is freely positionable in front of the barcode. A interactive vibration feedback after a
successful scan is offered by the BCSi (an advantage for loud environments). There are bi-focus
positions for capturing of max. focus-decoding area. The scanner provides exceptional depth of field
on all bar code densities.
The BCSi provides built-in illumination which allows work in any ambient lighting condition — from
total darkness to bright sunlight.
A wide selection of parameters may be configured to adapt the BCSi settings for your particular
application.
The BCSi available as cable and as radio frequency version.
The cable scanner version has an intrinsically safe interface for power and data. The data transmission
is reali ed via a serial interface. The cable version is available for low-power and high-power
intrinsically safe power interfaces.
The radio frequency version has an intrinsically safe interface for charging of internal batteries in
ha ardous areas via intrinsically safe interfaces, such as for instance ExMod-1-2-3. The data
transmission is reali ed via a radio frequency interface (Bluetooth). The radio frequency version is
available with integrated 10mW and 100mW Bluetooth modules.
The radio frequency version disable the scanengine when charging is in process.
All versions of the BCSi developed for use in ha ardous areas Zone 0, Zone 20, EPL Ga and EPL Da.

MANUALBCSI-1REV1.8EN.DOC 19.12.08 A.J. -4-
BCSi-1 * models available
Various models of BCSi-1 * can be supplied:
-
--
-1 = C LP
C LPC LP
C LP : Cable barcode scanner Low Power.
Barcode scanner with cable connection and low intrinsically safe input power at the
power line. The connection interface to the other existing application supporting
devices is reali ed via serial intrinsically safe interface.
This variant is developed with internal energybuffer to provide the necessary power
for the scanner electronic (duty cycle typ. 5%). A pre-charging of typ. 16h for this
internal buffer is necessary before first operation.
C HP
C HPC HP
C HP : Cable barcode scanner High Power.
Barcode scanner with cable connection and high intrinsically safe input power at the
power line. The connection interface to the other existing application supporting
devices is via serial intrinsically safe interface.
RF 10
RF 10RF 10
RF 10 : Radio frequency scanner (Bluetooth)
Barcode scanner with data transmission by radio frequency with typ. radiated power
of 10mW.
This variant is developed with integrated Bluetooth module (Class 2) to transmit
data to other existing application supporting devices. For charging of this cordless
barcode scanner a intrinsically safe interface required (e.g. ExMod-1-2-3).
RF 100
RF 100RF 100
RF 100: Radio frequency scanner (Bluetooth)
Barcode scanner with data transmission by radio frequency with typ. radiated power
of 100mW.
This variant is developed with integrated Bluetooth module (Class 1) to transmit
data to other existing application supporting devices. For charging of this cordless
barcode scanner a intrinsically safe interface required (e.g. ExMod-1-2-3).
* : Can be any alphanumeric characters reserved for the manufacturer.
Example:
Example: Example:
Example:
BCSi
BCSiBCSi
BCSi-
--
-RF100
RF100 RF100
RF100 = Radio frequency scanner (Bluetooth) with 100mW radiated power (Class 1).
For more details please refer to the attached drawings Nr. # 30100431 and #30100432.

MANUALBCSI-1REV1.8EN.DOC 19.12.08 A.J. -5-
Technical ata
For all BCSi versions:
For all BCSi versions:For all BCSi versions:
For all BCSi versions:
Housing type: Stainless steel 1.4301 / AISI 304 (or on request)
Ingress protection: IP67
Operating temperature range: -20°C to +60°C (-4°F to 140°F), 15 to 95% rel. humidity, n. cond.
Storage temperature: -20 °C - +35°C (-4°F to 95°F), 15 to 85% rel. humidity, n. cond.
-20 °C - +60°C (-4°F to 140°F), 15 to 85% rel. humidity, n. cond.
(for one week)
Ha ardous areas: Zone 0, Zone 20, EPL Ga, EPL Da (refer certificates)
Dimensions: 220 mm x 42 mm (8,67” x 1,65”), refer attached drawings
Weight: typ. 700g (24,7 o ), depending of variant
Classification of install. and use: Mobile device, hand-held device
Data Interface: RS232, typ.settings 9600bps, 8 data, 1 stop, no parity, no flow
control
Scan engine: Bi-focus near 120mm / far 230mm (5” / 9”)
Field of view: Hori ontal: 32.2°, Vertical: 24.5°
Optical Resolution: 640 (H) x 480 (V) pixels (gray scale)
Barcode decode speed: Linear typ. 100ms or less, 2D typ. 300ms or less
Optical radiation: Aiming Element (VLD) 650 nm ± 5 nm, less than 35mW
Illumination Element (LED): 635 nm ± 20 nm, less than 35mW
Laser Classification: CDRH Class II/IEC 825 Class 1 devices
Min. Print Contrast: Min. 25% absolute dark/light reflectance measured at 650 nm
Ambient Light: Total darkness to 9,000 ft.candles (96,900Lux)
Symbologies: 1-D Symbology : All major 1D bar codes, e.g. UPC/EAN, Code
128, UCC.EAN128, RSS, Code 39, Code 93, I 2 of 5, Discrete 2
of 5, Codabar, MSI
2-D Symbology: MaxiCode, PDF417, DataMatrix, QR Code, A tec
& Composite Codes
Postal Codes: US Postnet, US Planet, UK Postal, Australian Postal,
Japan Postal
Refer chapter “Barcodesettings” for details.
Scan decode one: Typical performance @23°C (73°F) on high quality symbols in
normal room light for 1D symbology (tested with PDF417):
Near
5 mil: Code 39 - 80% MRD: 8.9 - 17.8 (cm)/ 3.5 - 7 (in)
7.5 mil: Code 39 - 80% MRD: 7 - 19.7 (cm) / 2.75 - 7.75 (in)
13 mil: UPC-A - 80% MRD: 5.7 - 22.2 (cm) / 2.25 - 8.75 (in)
20 mil: Code 39 - 80% MRD: * - 27.9 (cm) / * - 11 (in)
6.7 mil: PDF417 - 80% MRD: 9.5 - 15.2 (cm) / 3.75 - 6.0 (in)
10 mil: PDF417 - 80% MRD: 8.3 - 18.4 (cm) / 3.25 - 7.25 (in)
15 mil: PDF417 - 80% MRD: * - 19.1 (cm) / * - 7.5 (in)

MANUALBCSI-1REV1.8EN.DOC 19.12.08 A.J. -6-
Far
5 mil: Code 39 - 80% MRD: 16.5 - 19.1 (cm) / 6.65 - 7.5 (in)
7.5 mil: Code 39 - 80% MRD: 10.8 - 25.4 (cm) / 4.25 - 10 (in)
13 mil: UPC A - 80 % MRD: 7.6 - 40.6 (cm) / 3 - 16 (in)
20 mil: Code 39 - 80% MRD: * - 51.6 (cm) / * - 21.5
10 mil: PDF417 - 80% MRD: 14.6 - 26 (cm) / 5.75 - 10.25 (in)
15 mil: PDF417 - 80% MRD: * - 51.6 (cm) / * - 21.5 (in)
MRD: min. reflectance difference
* = near distance area field of view limited
For BCSi
For BCSi For BCSi
For BCSi –
––
–C LP, BCSi
C LP, BCSi C LP, BCSi
C LP, BCSi –
––
–C HP:
C HP:C HP:
C HP:
Connection: RS232 intrinsically safe interface (interface X91)
Supply: via intrinsically safe interface (interface X91)
Length of spiralcable: typ. 0,5m / 2m (1,64ft / 6,56ft), not extended / extended. Other
lengths on request. Cable fixed mounted. Exchangeable by Gecma
only.
Note (for BCSi-C LP only): This variant is developed with internal energybuffer to provide the
necessary power for the scanner electronic (duty cycle typ. 5%). A pre
charging of typ. 16h for this internal buffer necessary before first
operation. Typ. dicharging rate when not connected is typ. 15% to
20% per month @ 20°C (68°F).
For BCSi
For BCSi For BCSi
For BCSi –
––
–RF 10, BCSi
RF 10, BCSi RF 10, BCSi
RF 10, BCSi –
––
–RF 100:
RF 100:RF 100:
RF 100:
Connection: provide wireless RS232 interface via Bluetooth 1.2 (2,4GH )
specification (transparent RS232 Interface), Class 2 for BCSi –RF
10, Class 1 for BCSi –RF 100
Supply: via internal battery (charging via interface X92)
not interchangeable.
Battery capacity: typ. >2000 scans, typ. 36h standby, typ. charging 16h (when
complete discharged), conditions @20°C (68°F), >350 cycles
(IEC61951-2). Charge battery before using.
Discharging rate: when power down and not used typ. 15% to 20% per month @
20°C (68°F)
RF distances: max. 10m for BCSi –RF 10 (open field)
max. 100m for BCSi –RF 100 (open field)
Local conditions can affect the RF distances.
Radiated power: max. 2W
Antenna: Integrated antenna
Bluetooth type setting: RS232 interface, accept bound request from remote device,
connectable, discoverable
Bluetooth PIN: 0000

MANUALBCSI-1REV1.8EN.DOC 19.12.08 A.J. -7-
Certificates
ATEX cert
ATEX certATEX cert
ATEX certification
ificationification
ification
Product
Zone 0 / EPL Ga Zone 20 / EPL Da
ATEX ignition protection Ex II 1G Ex ia op is Ga IIC
T4
Ex II 1D Ex iaD 20 T130°C
Operating/storage T° Ta: -20°C ... +60°C
(-4°F to 140°F)
Ta: -20°C ... +60°C
(-4°F to 140°F)
BCSi-1
ATEX certification TÜV 08 ATEX 7633 TÜV 08 ATEX 7633
IECEx certification
IECEx certificationIECEx certification
IECEx certification
Product
EPL Ga EPL Da
IECEx ignition protection Ex ia op is IIC T4 Ga Ex ia IIIC T130°C Da IP67
Operating/storage T° Ta: -20°C ... +60°C
(-4°F to 140°F)
Ta: -20°C ... +60°C
(-4°F to 140°F)
BCSi-1
IECEx certification IECEx TUR 09.001 IECEx TUR 09.0001
Further details and certificates can be found in the attached license.
Further details and certificates can be found in the attached license.Further details and certificates can be found in the attached license.
Further details and certificates can be found in the attached license.

MANUALBCSI-1REV1.8EN.DOC 19.12.08 A.J. -8-
Connections details
BCSi
BCSiBCSi
BCSi-
--
-C L
C LC L
C LP:
P:P:
P:
When the distance between the supply line (X91-1) and the data lines (X91-3 and X91-4) at the
associated apparatus comply
complycomply
comply to the clearance / creepage distances and separation on the standard
IEC/EN 60079-11:
Supply voltage: X91
X91X91
X91-
--
-1
11
1, Intrinsically safe ia:
Contact 1: +Ui
Contact 2: GND
Ui ≤ 5,5 V
Ii ≤ not important
Pi ≤ 4W
Li ≤ negligible
Ci ≤ negligible
Uo ≤ negligible
Io ≤ negligible
Po ≤ negligible
Lo ≤ negligible
Co ≤ negligible
Data Lines: X91
X91X91
X91-
--
-3, X
3, X3, X
3, X91
9191
91-
--
-4
44
4, Intrinsically safe ia:
Contact 3: RXD (input)
Contact 4: TXD (output)
Ui ≤ 25 V
Ii ≤ not important
Pi ≤ not important
Li ≤ negligible
Ci ≤ negligible
Uo ≤ 5,4 V
Io ≤ 11,4 mA
Po ≤ 14,1 mW
Lo ≤ 0,3 mH
Co ≤ 65 uF
Recommended max. cable length 5m (16,4ft).
Pay attention to the values listed in corresponding standards.
This variant is developed with internal energy buffer to provide the necessary
power for the scanner electronic (duty cycle typ. 5%). A pre- charging of typ.
16h for this internal buffer necessary before first operation.

MANUALBCSI-1REV1.8EN.DOC 19.12.08 A.J. -9-
When the distance between the supply line (X91-1) and the data lines (X91-3 and X91-4) at the
associated apparatus not
not not
not comply
complycomply
comply to the clearance / creepage distances and separation on the
standard IEC/EN 60079-11:
Supply voltage / Data: X91
X91X91
X91-
--
-1, X91
1, X911, X91
1, X91-
--
-3, X91
3, X913, X91
3, X91-
--
-4
44
4, Intrinsically safe ia:
Contact 1: +Ui
Contact 2: GND
Contact 3: RXD (input)
Contact 4: TXD (output)
Ui ≤ 5,5 V
Ii ≤ not important
Pi ≤ 4W
Li ≤ negligible
Ci ≤ negligible
Uo ≤ 5,4 V
Io ≤ 11,4 mA
Po ≤ 14,1 mW
Lo ≤ 0,3 mH
Co ≤ 65 uF
Recommended max. cable length 5m (16,4ft).
Pay attention to the values listed in corresponding standards.
BCSi
BCSiBCSi
BCSi-
--
-C HP:
C HP:C HP:
C HP:
When the distance between the supply line (X91-1) and the data lines (X91-3 and X91-4) at the
associated apparatus comply
complycomply
comply to the clearance / creepage distances and separation on the standard
IEC/EN 60079-11:
Supply voltage: X91
X91X91
X91-
--
-1
11
1, Intrinsically safe ia:
Contact 1: +Ui
Contact 2: GND
Ui ≤ 5,5 V
Ii ≤ not important
Pi ≤ not important
Li ≤ negligible
Ci ≤ negligible
Uo ≤ negligible
Io ≤ negligible
Po ≤ negligible
Lo ≤ negligible
Co ≤ negligible

MANUALBCSI-1REV1.8EN.DOC 19.12.08 A.J. -10-
Data Lines: X91
X91X91
X91-
--
-3, X9
3, X93, X9
3, X91
11
1-
--
-4
44
4, Intrinsically safe ia:
Contact 3: RXD (input)
Contact 4: TXD (output)
Ui ≤ 25 V
Ii ≤ not important
Pi ≤ not important
Li ≤ negligible
Ci ≤ negligible
Uo ≤ 5,4 V
Io ≤ 11,4 mA
Po ≤ 14,1 mW
Lo ≤ 0,3 mH
Co ≤ 65 uF
Recommended max. cable length 5m (16,4ft).
Pay attention to the values listed in corresponding standards.
When the distance between the supply line (X91-1) and the data lines (X91-3 and X91-4) at the
associated apparatus not
not not
not comply
complycomply
comply to the clearance / creepage distances and separation on the
standard IEC/EN 60079-11:
Supply voltage / Data: X91
X91X91
X91-
--
-1, X91
1, X911, X91
1, X91-
--
-3, X91
3, X913, X91
3, X91-
--
-4
44
4, Intrinsically safe ia:
Contact 1: +Ui
Contact 2: GND
Contact 3: RXD (input)
Contact 4: TXD (output)
Ui ≤ 5,5 V
Ii ≤ not important
Pi ≤ not important
Li ≤ negligible
Ci ≤ negligible
Uo ≤ 5,4 V
Io ≤ 11,4 mA
Po ≤ 14,1 mW
Lo ≤ 0,3 mH
Co ≤ 65 uF
Recommended max. cable length 5m (16,4ft).
Pay attention to the values listed in corresponding standards.

MANUALBCSI-1REV1.8EN.DOC 19.12.08 A.J. -11-
BCSi
BCSiBCSi
BCSi-
--
-RF 10 / BCSi
RF 10 / BCSiRF 10 / BCSi
RF 10 / BCSi-
--
-RF100:
RF100:RF100:
RF100:
Charging voltage: X92
X92X92
X92, Intrinsically safe ia:
Contact inside: +Ui
Contact outside: GND
Ui ≤ 10,8 V
Ii ≤ not important
Pi ≤ not important
Li ≤ negligible
Ci ≤ negligible
Uo ≤ negligible
Io ≤ negligible
Po ≤ negligible
Lo ≤ negligible
Co ≤ negligible
Recommended max. cable length 5m (16,4ft).
Pay attention to the values listed in corresponding standards.
Terminal Connections
BCSi-C LP, BCSi-C HP:
Supply voltage / Data interface X91:
X91
Function Cable Connector
+Ui Brown 1 6
GND White 2 7
RXD (inp.) Yellow 3 2
TXT (outp.) Green 4 3
BCSi-RF 10, BCSi-RF 100:
Supply voltage interface X92:
X91
Function Connector
+Ui Contact inside
GND Contact outside
Further details can be found in attached installation plan drawings of different variants.

MANUALBCSI-1REV1.8EN.DOC 19.12.08 A.J. -12-
Available Barcode symbologys and default settings
To ensure best barcode reading results we recommend to enable the used barcode only. For flexibility we
recommend to disable as few as possible unused barcodes.
To enable or disable a barcode refer associated chapter at “Programming BCSi”.
Symbology Barcode parameter Default
UPC-A Enable
UPC-E Enable
UPC-E1 Disable
EAN-8/JAN 8 Enable
EAN-13/JAN 13 Enable
Bookland EAN Disable
Decode UPC/EAN/JAN Supplementals (2 and 5 digits) Ignore
UPC/EAN/JAN Supplemental Redundancy 10
Transmit UPC-A Check Digit Enable
Transmit UPC-E Check Digit Enable
Transmit UPC-E1 Check Digit Enable
UPC-A Preamble System Character
UPC-E Preamble System Character
UPC-E1 Preamble System Character
Convert UPC-E to A Disable
Convert UPC-E1 to A Disable
EAN-8/JAN-8 Extend Disable
UCC Coupon Extended Code Disable
UPC/EAN
Linear UPC/EAN Decode Disable
Code 128 Enable
UCC/EAN-128 Enable
Code 128
ISBT 128 Enable
Code 39 Enable
Trioptic Code 39 Disable
Convert Code 39 to Code 32 (Italian Pharmacy Code) Disable
Code 39
Code 32 Prefix Disable

MANUALBCSI-1REV1.8EN.DOC 19.12.08 A.J. -13-
Set Length(s) for Code 39 2 to 55
Code 39 Check Digit Verification Disable
Transmit Code 39 Check Digit Disable
Code 39 Full ASCII Conversion Disable
Code 93 Disable Code 93
Set Length(s) for Code 93 4 to 55
Code 11 Disable
Set Lengths for Code 11 4 to 55
Code 11 Check Digit Verification Disable
Code 11
Transmit Code 11 Check Digit(s) Disable
Interleaved 2 of 5 (ITF) Enable
Set Lengths for I 2 of 5 14
I 2 of 5 Check Digit Verification Disable
Transmit I 2 of 5 Check Digit Disable
Interleaved 2 of 5 (ITF)
Convert I 2 of 5 to EAN 13 Disable
Discrete 2 of 5 Disable
Discrete 2 of 5 (DTF)
Set Length(s) for D 2 of 5 12
Codabar Disable
Set Lengths for Codabar 5 to 55
CLSI Editing Disable
Codabar (NW - 7)
NOTIS Editing Disable
MSI Disable
Set Length(s) for MSI 4 to 55
MSI Check Digits One
Transmit MSI Check Digit Disable
MSI
MSI Check Digit Algorithm Mod 10/Mod 10
US Postnet Enable
US Planet Enable
UK Postal Enable
Transmit UK Postal Check Digit Enable
Japan Postal Enable
Postal Codes
Australian Postal Enable

MANUALBCSI-1REV1.8EN.DOC 19.12.08 A.J. -14-
Dutch Postal Enable
Transmit US Postal Check Digit Enable
RSS 14 Enable
RSS Limited Enable
RSS Expanded Enable
RSS (Red. Sp. Symb.)
Convert RSS to UPC/EAN Disable
Composite CC-C Disable
Composite CC-A/B Disable
Composite TLC-39 Disable
UPC Composite Mode Always Linked
Composite
UCC/EAN Code 128 Emulation Mode for UCC/EAN
Composite Codes Disable
PDF417 Enable
MicroPDF417 Disable
Code 128 Emulation Disable
Data Matrix Enable
Maxicode Enable
2D Symbologies
QR Code Enable
Redundancy Level 1
Security Level 0
Symbology-Specific
Security Levels
Intercharacter Gap Size Normal

MANUALBCSI-1REV1.8EN.DOC 19.12.08 A.J. -15-
Sample barcodes
EAN
EANEAN
EAN-
--
-13/JAN 13
13/JAN 1313/JAN 13
13/JAN 13
Code 128
Code 128Code 128
Code 128
Code 39
Code 39Code 39
Code 39

MANUALBCSI-1REV1.8EN.DOC 19.12.08 A.J. -16-
Data Matrix
Data MatrixData Matrix
Data Matrix
Gecma BCSi Barcode Scanner with vibration feedback
Gecma BCSi Barcode Scanner with vibration feedback available as cable and RF version
Maxicode
MaxicodeMaxicode
Maxicode
Gecma barcodescanner available as cable and RF version

MANUALBCSI-1REV1.8EN.DOC 19.12.08 A.J. -17-
Programming BCSi
Presettings done by Gecma Components GmbH (indicated by “*”).
Presettings done by Gecma Components GmbH (indicated by “*”).Presettings done by Gecma Components GmbH (indicated by “*”).
Presettings done by Gecma Components GmbH (indicated by “*”).
Don’t scale or modify the barcodes.
Don’t scale or modify the barcodes.Don’t scale or modify the barcodes.
Don’t scale or modify the barcodes.
We recommend to program “Set Default Parameter” only.
We recommend to program “Set Default Parameter” only. We recommend to program “Set Default Parameter” only.
We recommend to program “Set Default Parameter” only.
Changes/adjustments are under owner’s responsibility.
Changes/adjustments are under owner’s responsibility.Changes/adjustments are under owner’s responsibility.
Changes/adjustments are under owner’s responsibility.
Set Default Parameter
Set Default ParameterSet Default Parameter
Set Default Parameter
Scan this bar code to return all parameters to the default values
Set all default
Focus Mode
Focus ModeFocus Mode
Focus Mode
Select the Focus Mode to control the working range of the BCSi. If Far Focus
Far FocusFar Focus
Far Focus is selected, the BCSi is optimi ed to
read at its far position. With Near Focus
Near FocusNear Focus
Near Focus, the BCSi is optimi ed to read at its near position. Smart Focus
Smart FocusSmart Focus
Smart Focus toggles the
focus position after every frame.
* Far Focus
Near Focus
Smart Focus

MANUALBCSI-1REV1.8EN.DOC 19.12.08 A.J. -18-
Decoding Illumination
Decoding IlluminationDecoding Illumination
Decoding Illumination
Selecting Enable Illumination causes the decoder to flash illumination on every image capture to aid decoding.
Select Disable Illumination to prevent the decoder from using decoding illumination.
Enabling illumination usually results in superior images. The effectiveness of the illumination decreases as the
distance to the target increases.
* Enable Decoding Illumination
Disable Decoding Illunmination
Decode Aiming Pattern
Decode Aiming PatternDecode Aiming Pattern
Decode Aiming Pattern
This parameter only applies when in Decode Mode. Select Enable Decode A
Enable Decode AEnable Decode A
Enable Decode Aiming Pattern
iming Patterniming Pattern
iming Pattern to project the aiming
pattern during bar code capture, or Disable Decode Aiming Pattern
Disable Decode Aiming PatternDisable Decode Aiming Pattern
Disable Decode Aiming Pattern to turn the aiming pattern off.
* Enable Decode Aiming Pattern
Disable Decode Aiming Pattern

MANUALBCSI-1REV1.8EN.DOC 19.12.08 A.J. -19-
Prefix/Suffix Values
Prefix/Suffix ValuesPrefix/Suffix Values
Prefix/Suffix Values
A prefix and/or one or two suffixes can be appended to scan data for use in data editing. To set a value for a prefix
or suffix, scan a prefix or suffix bar code below, then scan a four-digit number (i.e., four bar codes from Appendix A
Appendix AAppendix A
Appendix A,
Numeric Bar Codes) that corresponds to that value. See Table “ASCII Value Table
ASCII Value TableASCII Value Table
ASCII Value Table” for the four-digit codes. To
correct an error or change a selection, scan Cancel from Appendix A.
To use Prefix/Suffix values, first set the Scan Data Transmission Format below.
Scan Prefeix
Scan Suffix 1
Scan Suffix 2
Scan Data Transmission Format
Scan Data Transmission FormatScan Data Transmission Format
Scan Data Transmission Format
To change the scan data format, scan one of the following eight bar codes corresponding to the desired format.
If using this parameter do not
do notdo not
do not use ADF rules to set the prefix/suffix. To set values for the prefix and/or suffix, see
Prefix/Suffix Values above.
* Data As Is
<DATA> <SUFFIX 1>

MANUALBCSI-1REV1.8EN.DOC 19.12.08 A.J. -20-
<DATA> <SUFFIX 2>
<DATA> <SUFFIX 1> <SUFFIX 2>
<PREFIX> <DATA>
<PREFIX> <DATA> <SUFFIX 1>
<PREFIX> <DATA> <SUFFIX 2>
<PREFIX> <DATA> <SUFFIX 1> <SUFFIX 2>
