Geekpure RO4 Manual

Geekpure
FILTER CARTRIDGE CONFIGURATION MAY BE SUBJECT TO CHANGE.
RO4
Portable Reverse Osmosis Water Filtration System
Installation and Maintenance Manual
INSTALLERS:
1.PLEASE READ ALL INSTRUCTIONS BEFORE INSTALLING AND USING THIS SYSTEM.
2.IT IS RECOMMENDED TO WAIT UNTIL THE ENTIRE SYSTEM IS PRESSURIZED AND
RE-CHECK FOR ANY LEAKS BEFORE LEAVING INSTALLATION SITE.
3.THERE IS PROTECTION MATERIAL IN THE FILTERS, PLEASE KEEP FLUSH THE FILTERS
AT LEAST 30 MINUTES .
4.IT IS NORMAL FOR SOME BLACK CARBON FINES TO APPEAR IN THE WATER WHEN YOU
FLUSH NEW FILTERS.THE WATER PRODUCED SHOULD BE EMPTIED AND NOT USED.
5.DON'T FREEZE, ESPECIALLY RO MEMBRANE.
6.IF USING OZONE GENERATOR, PLEASE USE IT AFTER PRESSURE STORAGE TANK,
ORELSE IT WILL CAUSE EXPLOSION IF GAS FROM OZONE GENERATOR GOES INTO
PRESSURE STORAGE TANK.

How Your System Works...............................................................................
Technical Data of Membrane........................................................................
Before You Start............................................................................................
Tools Needed ...............................................................................................
System Location ..........................................................................................
Parts of the System ....................................................................................
Installation Steps ..........................................................................................
Installing the Filters .....................................................................................
Installing Tank Ball Valve ............................................................................
Installing the Faucet .................................................................................
Installing the Feed Water Diverter Valve......................................................
Installing the Waste Water Saddle ..........................................................
Installing the Unit ....................................................................................
Installing Tubing Into Fittings .................................................................
Installing Tubing Connections .................................................................
Sanitize System ............................................................................................
Flush System and Check Operation .............................................................
Filters Change Schedule...........................................................................
Spare Parts List.........................................................................................
Flow Diagrams.............................................................................................
Operation Specifications..............................................................................
Trouble Shooting..........................................................................................
Warranty........................................................................................................
1
1-2
2
3-4
4-5
6-7
7
7-8
8-9
9-10
11
11-12
12-13
13-15
15-16
16
17
17-18
18-19
20
20
21
22
Table of Contents

Geekpure RO4 Series system uses four stages of treatment to filter your water:
Stage 1 - Remove sand, dirt, sediment
Stage 2 - Remove chlorine, taste & odors, very fine particulates
Stage 3 - Reduce total dissolved minerals
Stage 4 - Polish water for refined taste
How Your System Works
Technical Data of Membrane
The system is compact and can be installed under the sink or another convenient place
close to the faucet. The closer the proximity to the faucet the better the system flow
rate.
Recommended Filter Change Schedule
Your filters require changing on a regular basis. Instructions to change them are on.
The schedule below is the minimum page 17 recommendation. Depending on your
water conditions the filters may need to be changed more often.
Disposable Filters
T33-PP
T33-CARBON
TW-1812-100G
RO5-COC10
Change Schedule
Every 6-12 months
Every 6-12 months
Every 15-24 months
Every 6-12 months
MEMBRANE
Type — TFC (Thin Film Composite)
Material — PA (Polyamide)
Charge — Negative
Configuration — Spiral-wound, Tapping
PERFORMANCE (NORMINAL)
Salt Rejection — 96%(minimum)
The stated performance is initial data taken after 30 minutes of opera-
tion based on the following conditions.
1

Before You Start
Your system contains filters which must be replaced periodically for proper
operation. (Refer to Filter Change Schedule on page 17.)
Read all steps and guides carefully before installing and using your RO system.
Follow all steps exactly to correctly install.
The system is designed to be used on potable water supplies only. If water is
non-potable, additional pretreatment will be required.
Concentration — 250ppm NaCl
Pressure — 60psig
Temperature — 77°F (25°C)
Recovery —15%
pH Range — 6.5 ~ 7.0
Note:Due to different temperature, different water pressure and feed water
quality, the product water capacity and pure water quality (TDS) is different.
That is the reason why we feel lower pure water capacity in the winter, but
higher in the summer. Please refer following diagram:
OPERATING LIMITS
Max.Operating Pressure — 125psi (0.86Mpa)
Max.Feed Flow Rate — 2gpm (0.45m3/hr)
Max.Feed Water TDS — 1000 ppm (if 2000 ppm, it is available,but out of
warranty, life time will be shorter.)
Max. Operating Temperature — 110°F (45°C)
Min.Operating Temperature — 40°F(5°C)
pH -3.0 ~10.0
Chlorine Concentration — <0.1ppm
Hardness <5GPG
2

Scissors FaucetWrench for
Membrane Housing
Tools Needed
Do not use for the treatment of water that is visually contaminated(cloudy) or
has an obvious contamination source, such as contamination by raw sewage.
All plumbing should be done in accordance with local codes and requirements.
Non-Booster pump models work on inlet water pressures of 40 psi (minimum) to
100 psi (maximum).If your house water pressure is over the maximum, install a
pressure reducing valve in the water supply line to the filter system.
Do not install the system outside, or in extreme hot or cold temperatures.
Temperature of the water supply to the R/O system must be between 40-110°F
/5-45°C.Do not install on hot water.
Plastic Tube Cutter 3/8" Variable Speed Electric
Drill; 1/8",1/4",1/2" Bits
Teflon Tape
Center Punch and
Hammer Monkey Wrench Faucet Bracket
3

Tank Tank ball valve Water Pipe
RO Membrane Clip Feed Water Diverter
Valve
Drain Clamp Mounting Clamp Manual
Your RO system may be installed under the sink, in a basement, or other location
depending on available space. It is recommended the system be installed in as close a
proximity to the faucet to ensure optimal system flow rate. If you have a water
dispenser or ice maker in your fridge, your RO system can be installed to provide the
feed water for these features but you should consult your fridge owners manual for
further information.
System Location
4

Guidelines for component placement are as follows:
Faucet should be placed near the sink where drinking/cooking water is normally
required. A 2" flat surface is required to mount the faucet if an existing hole for a
second faucet is not available.The thickness of the mounting surface should not
exceed 1-1/4" on the vertical or horizontal tailpiece. Refer to Figure 1.
Storage tank may be placed where it is convenient, within ten feet of the faucet.
Under the sink or in a nearby cabinet are excellent choices. If tank is located further
than ten feet from the faucet, use 1/2" tubing to reduce pressure drop. Full tanks may
weigh more than thirty pounds, so a sturdy shelf is required.
RO unit may be mounted on either side of the sink, in a cabinet or heated basement,
with nearby access to a potable, cold line and a drain.
NOTE: All components and tubing should be located in an area not exposed to
freezing temperatures or direct sunlight.
In the cabinet On the cabinetMounted on the wall
Feed water connection is accomplished with a feed water adaptor. Locate this assembly
as close to the R/O unit as possible. Connect to a potable, cold water supply line only.
NOTE: Softened water is preferred since it will extend the life of your R/O membrane.
Drain connection is accomplished using a waste water saddle valve which is designed to
fit around a standard 1-1/2" OD drain pipe. The drain saddle valve should always be
installed above (before) the drain trap and on the vertical or horizontal tailpiece. Refer to
Figure 2.
Figure 1
5

The following components make up your Reverse Osmosis
Drinking Water System:
1. PP Sediment removes larger particles such as sand, silt, and rust.
2. Coconut Carbon removes chlorine in the feed water to protect the reverse
osmosis membrane.
3. Reverse Osmosis Membrane reduces dissolved minerals, metals and salts.
During the process, harmful compounds are separated by the membrane and
the reject water goes to waste (drain).
Parts of the System
3/8" White Tube
3/8" White Tube
Pressure Tank
Feed Water
Drain
1/4" Red Tube
1/4" White Tube
Figure 2.
Typical Installation
Faucet
12
3
4
5
7
6
8
6

4. Post-Carbon Filter is provided for a final "polish" to provide great tasting
drinking water.
5. Storage Tank (2.8 Gal) holds filtered water, ready for use.
6. Feed Water Diverter Valve is connected to the cold water line to supply water
to the RO system.
7. Faucet (Standard) used to dispense RO water when needed.
Optional air gap and designer faucets are available.
8. Waste Water Saddle is connected to the drain to remove reject water from
the RO system.
1.RO Membrane
2.Faucet
3.Feed Water Diverter Valve
4.Waste Water Saddle
5.Unit Installation
6.Tubing Connections
7.Sanitize System
8.Flush System and Check Operation
Installation Steps
Installing the Filters
Install the Membrane
Water Inlet
ORings RO Membrane
Seal Ring
Membrane
Housing
Drain Water
Outlet
Pure Water
Outlet
Housing
Connection
Housing
Cap
7

Installing Tank Ball Valve
1 Remove the tube from the fitting and twist off the housing cap with
wrench
2.
.
Push the new membrane into housing
3 Put the housing cap back and tighten it.
4.
.
you should pull out old membrane before step 2 when you replace
new membrane.(you may use pliers if necessary.)
NOTE:Please ensure the RO System to work for about 30 minutes
before drinking the purified water for washing
1 2
3 4
The RO storage tank comes with a 1/4"*3/8" tank ball valve that must be
installed.
1.Apply 5-6 wraps of teflon thread sealant tape to the male thread on the
RO storage tank.
2.Install the ball valve and tighten it.
3.Connect 3/8" white tube.
8

9
Tank Ball Valve
Open
Close
If the sink has a sprayer it may be disconnected for faucet installation.
A pipe cap or plug will be necessary to seal the sprayer connection.
The faucet should be positioned so it empties into the sink and the
spout swivels freely for convenience. If sink has a hole that can
accommodate the RO faucet, no drilling is required. Proceed with
mounting the faucet.
Installing the Faucet
NOTES:
While there is a gasket that seals against the shut off valve, it is rec-
ommended to still use teflon tape on the tank threads to insure a good
seal is achieved. It is also recommended to check for any leaks after
the system has had time to produce water and pressurize inside the
storage tank. Failure to do so could result in a leak that is not spotted
until after the installer has left the location.

10
Porcelain, Enamel, Ceramic on Metal or Cast Iron Sinks
For porcelain/enamel sinks marble or granite counter tops refer to
manufacturer/Supplier for proper drilling instructions.
1. Feed the threaded nipple through
sink or counter mounting hole and
orient the faucet as shown. From
below sink or counter, assemble
the flat washer and hex nut on
threaded nipple and tighten by
hand. After checking faucet
orientation, tighten with a wrench
until secure.
2. Install the faucet adaptor fitting
(shown below) and tighten until the
fitting bottoms out on the o-ring
inside to create the seal. Tighten
with wrench until secure.
3. Insert the 3/8“ white tube into
the quick connect fitting.
Installation procedures for stainless steel sinks
Recommended tools:
·Center punch
·Variable speed drill
·High speed drill bits
·Protective gloves & eye protectors
To make the faucet mounting hole (if sprayer or second hole is not
used), check below to make sure the drill does not interfere with
anything below the sink. Center punch a small indent at the
desired faucet location. (2”flat surface is required, not exceeding
1-1/4”in thickness). Drill the 1/8 1/2”pilot hole. Drill the ”hole for
the faucet shank to fit through. Clean up sharp edges.
Mounting the Faucet

Installing the Feed Water Diverter Valve
Installing The Waste Water Saddle
11
The feed water diverter Valve is designed for use with 3/8 to 1/2””
OD soft copper supply tubing.
Turn on water supply to pressure cold water line and check for leaks.
Turn off cold water valve from under sink or main water line valve
for whole house.
Wrap threads of Feed Water Diverter Valve with teflon tape.
Connect White Feed Water Tubing from unit to Feed Water Diverter
Valve and then connect to source water.
Prior to proceeding it is important to
inspect the condition of drain pipes to
make sure they are not thin and frail.
Waste water saddles are designed to
be installed on standard 1-1/2”OD
drain pipe.
Install waste water saddle above (and
before) the trap and on the vertical or
horizontal tailpiece.
Caution: The water supply to your unit MUST be from COLD WATER
LINE.
Connect with water system
Feed Water Diverter Valve
Connect with normal tap water
Connect with source water

Figure 3.
Installing the Unit
12
DRAIN CLAMPASSEMBLY
Drain Tubing
Compression Nut
Insert
Drain Clamp
Front Plate
M6×35 Screw
Drain Pipe
M6 Nut
Drain Clamp
Back Plate
Never install a waste water saddle close to the outlet of a garbage
disposal or plugging of the RO drain line may result . Refer to
location in Figure 3.
1. Position half of the saddle with quick connect fitting at selected
location and mark for the opening.
2. Drill 1/4”hole at mark through one side of pipe. Position both
halves of the saddle on drain pipe so quick connect opening lines
with hole.
3. Secure drain saddle clamp with bolts and nuts provided. (Do not
over tighten and make sure there is equal space between saddle
halves on each side).
When installed under a sink the unit is normally mounted to the right
or left sink cabinet sidewall. It is suggested to locate the system
where it can be easily accessed or even removed off the hanging
screws and pulled back out from the sink to change the filters.

Installing Tubing Into Fittings
13
1. Locate the unit in the desired position. Make sure it is at least 3"
off the floor. Level it and mark the location of mounting screws.
2. Install the screws. Leave 1/4" of the screw head out from the
wall.
3. Install the mounting bracket slots over the screws and hang the
unit.
NOTE: THE UNIT MUST BE INSTALLED BY HANGING THE
BRACKET ON THE WALL SO THAT THERE IS NO WEIGHT
ON THE FILTERS. THE SYSTEM IS NOT DESIGNED OR
INTENDED TO SIT ON THE FLOOR WITH THE WEIGHT
SUPPORTED BY THE REPLACEABLE FILTER CARTRIDGES.
Step 1
Step 2
Step 3
Insert the clip
Pull out the water pipe
Pull out the water clip
Press the inner claw
Pull out the water pipe
①
②
③
④
①
②
③
push the tube into the
fitting and up to the
tube stop
Pull on the tube to check that it is secure. Test the system
before use.
Cut the tube square and remove burrs
and sharp edges. Ensure that the outside
diameter is free from score marks. For
soft or thin walled plastic tubing we
recommend the use of a tube insert.
Push the tube into the fitting and up to
the tube stop
Install the water tube

14
See Figure 4 and 5. Check and cut the tubing end squarely and cleanly with utility
knife or scissors.
Make a 5/8”mark at the end of the tube so you will be able to confirm when the
tube is inserted fully into the fitting.
Remove the blue lock clip from the fitting with your nail. If the lock sleeve pops
out of the fitting when doing this, simply pop it back in.
Insert the tube into the fitting until you reach the 5/8”mark on the tube. You will
feel resistance when the tube reaches the small rubber O ring inside the fitting. You
will need to wiggle the tube and apply additional pressure to get it past this O ring
and create the seal. If the tube is not 5/8” into the fitting and past the O ring, no seal
will be created and leaking will occur.
Once the tube is fully inserted into the fitting, pop the blue lock clip back on the
fitting. This will lock the tube in place and prevent it from moving.
To connect:
1.
2.
3.
4.
5.
Installation tips for tube and quick connect fittings
Figure 4
Figure 5 Figure 6

Installing Tubing Connections
15
See Figures 6. Remove the blue lock clip from the fitting.
With the blue lock clip removed, use your thumb and index finger to hold down the
lock sleeve. This will release the metal teeth holding the tube in place. While holding
the lock sleeve down with that hand, use your other hand to remove the tube from
the fitting.
To disconnect:
1.
2.
1.Please cut the wound tube.it is very important.and keep the section part is smooth
and straight.
2.The tube must be inserted deeply.or else,it may leaking in the future,even it works
well recently.
3.Tube must be keep straight as possible, if bend or pulled over, it may leaking in the
future.
4.If leaking from o ring part,Please clean the oring surfaces and ensure o ring is put
and seat in the right position and smooth.You may lubricate some food grade silicone
gel for o ring.
5.If leaking from thread screw part please wrap more and proper quantity seal tape.
6.For quick change fittings, please remember to lock it by blue clips.
Very important keys for tube and fitting connection:
3/8" White Tube
3/8" White Tube
Pressure Tank
Feed Water
Drain
1/4" Red Tube
1/4" White Tube
Faucet
12
3
4
5
7
68

Sanitize System
16
With all components in place, complete final tubing connections using
these guidelines:
·Tubing should follow contour of the cabinets
·Cut tubing to desired length using square cuts and proper cutting
device
·Make no sharp bends
·keep tubing from the post-filter to the faucet as short as practical
for good flow.
·Leave enough tubing that the system can easily be pulled out from
the cabinet for easy filter changes.
1. Connect 3/8" white tube from faucet to RO unit.
2. Connect 3/8" white tube from tank to RO unit.
3. Connect 1/4" white tube from supply valve to RO unit.
4. Connect 1/4" red tube from drain valve to RO unit.
5. Check all connections to be sure they are secure.
6. Turn on feed water diverter valve and check for leaks.(turn off and
correct leaks if leaks occur).
Procedure (Standard Faucet)
Sanitize the System (Recommended)
Sanitizing is recommended every 2 years after installation of the Reverse
Osmosis system. It’s also recommended after servicing inner parts. It is
important that the person installing or servicing the system have clean
hands while handling inner parts of the system.
Note: The bleach must be removed from the system before drinking
the water. See Flush System instructions on the next page.
1. Turn off the water supply to the RO system and close the ball valve on
the storage tank.
2. Open the RO faucet.
3. Use an eyedropper (not included) and common household bleach
(5.25%).
4. Add 3 ml. of bleach into open end of 3/8" tube connected to tank.
Handle bleach according to bleach manufacturer’s recommendations.
5. Connect tubing back to tank ball valve.
6. Sanitizing the system will be completed during the Flush System and
Check Operation steps on the following page.

Flush System and Check Operation
Filter Change Schedule
17
1. Check all connections to be sure they are secure.
2. Turn on feed water valve and check for leaks. (turn off and correct
leaks if leaks occur).
3. Close faucet and wait 5 minutes to see if leaks result. (turn off and
correct leaks if leaks occur).
Start-up
1. Open faucet handle and allow tank to completely drain. Do not use
this water. (When tank is empty, faucet will steadily drip. This is the
rate the R/O system processes water).
2. Close faucet and reinspect system for leaks.
3. Allow system to process water for approximately 1~2 hours, at
which point tank will be practically full.
4. Open faucet again and allow tank to empty for a second time. Do
not use this water.
5. Wait another 1~2 hours to allow tank to re-fill.
Flush System and Check Operation
Recommended Filter Change Schedule
The following periodic maintenance is recommended so your system
will provide years of trouble-free service:
Your system contains a R/O (reverse osmosis) membrane which
should also be replaced periodically for proper operation. The R/O
membrane may require changing more frequently depending on the
source water conditions.
Disposable Filters
T33-PP
T33-CARBON
TW-1812-100G
RO5-COC10
Change Schedule
Every 6-12 months
Every 6-12 months
Every 15-24 months
Every 6-12 months

Spare Parts List
18
1
2
23
3 22
4
5
6
7
8
818 18
12
9 10
7
14 21131920
1716 1511
Change Filter Cartridges
1-3. Same as Change Membrane Procedure
4. Apply 5-6 wraps of teflon thread sealant tape to the male thread of quick fittings.
5. Install the quick fittings to new filter cartridges and tighten it.
6. Take down the old filter cartridges from RO system.
7. Connect new filter cartridges to RO system, and please make sure at right direction and position.
PS: Regarding direction and position of filter cartridges, please refer photos on page 8.
Change Membrane Procedure
1. Turn off water supply by turning handle on feed water diverter valve clockwise until
valve is fully closed.
2.Turn storage tank valve clockwise to close.
3.Open faucet to relieve pressure.
4.Remove quick connect fittings from R/O Membrane.
5.Insert RO element into housing with the small double o rings facing inward.
6.Install membrane housing cap and tighten with wrench provided.
7. Turn water supply back on and flush RO membrane 30 minutes before you connect pure
water to storage tank.
8.Turn storage tank valve to open position.
9.The first 2 tanks of water produced should be emptied and not used.
PS.Regarding point 4-6,please refer photos on page 7-8.
