Gefei MIO-HDMI-CEXT User manual

MIO-HDMI-CEXT HDMI signal Extender
User Manual
www.gefei-tech.com
[Gefei Tech. Co., Ltd]

Copyright
Copyright © 2009 Gefei Tech. Co., Ltd All rights reserved. This document may not be
copied in whole or in part.
Trademarks
Gefei-Tech，Magi，MIO，VIO，XIO，MVS，MRS are either registered trademarks or
trademarks of Gefei Tech. Co., Ltd in China. Other trademarks used in this document are
either registered trademarks or trademarks of the manufacturers or vendors of the
associated products.
Disclaimer
Product options and specifications subject can be changed without notice. The
information in this manual is furnished for informational use only, is subject to change
without notice, and should not be construed as a commitment by Gefei Tech. Co., Ltd.
Gefei Tech. Co., Ltd assumes no responsibility or liability for any errors or inaccuracies
that may appear in this publication.
Revision Status
Rev Date
Description
May 23, 2009
Initial release of the MIO HDMI-CEXT User Manual V1.0

Contents
Product Description.................................................................................................................................1
Features........................................................................................................................................................1
MIO HDMI-CEXT panel Introduction.................................................................................................2
Application..................................................................................................................................................4
How To Connect the MIO HDMI-CEXT Extender System..........................................................4
Technical specifications .........................................................................................................................6
Contact Us.................................................................................................................................................10

MIOHDMI-CEXT User Manual Gefei-tech
© Beijing Gefei Tech. Co., Ltd 1 / 10
Product Description
MIO HDMI-CEXT is a DVI/HDMI coaxial cable extender, which is compose of a transmitter
and receiver. One converts the DVI/HDMI signal to serial data and transmits it via a coaxial
cable with BNC interface; the other receives the serial data and recovers the original
DVI/HDMI signal with high quality eventually. This extender avoids the serious issue of
signal attenuation caused by a long DVI/HDMI cable for long-distance transmission. The
maximum transmission distance is 100m (Belden 1694A).
MIO HDMI-CEXT supports DVI/HDMI input formats of 3G-SDI, HD-SDI, SD-SDI. Although
the device adopts DVI interface, the HDMI signal with embedded audio also can be
transmitted by using a DVI-to-HDMI adapter or cable, and the original signal, especially the
embedded audio, is recovered through the receiver with HDMI interface.
Features
Support DVI/HDMI input formats of 3G-SDI, HD-SDI, SD-SDI, and automatic input rate
detection
Extend DVI/HDMI signal up to 100m (Belden 1694A) without distortion
Support transmission of the HDMI signal with embedded audio
Adopt a coaxial cable with BNC interface to transmit the data safely
Provide a loop-out interface by receiver
Mini box structure easily installed inside frame racks, video walls and so on
Widely used in broadcasting system, studios and other professional fields

MIOHDMI-CEXT User Manual Gefei-tech
© Beijing Gefei Tech. Co., Ltd 2 / 10
MIO HDMI-CEXT panel Introduction
MIO HDMI-CEXT-T left panel interface
HDMI/DVI-IN: Support HDMI signal with embedded audio with a HDMI-to-DVI adapter.
Supports input resolution as following:
480i 60, 576i 50
720P50/59.94/60,
1080I50/59.94/60,
1080P30/29.97/25/24/23.98
1080P50/60
Power jack: standard power: 12V, 1A

MIOHDMI-CEXT User Manual Gefei-tech
© Beijing Gefei Tech. Co., Ltd 3 / 10
MIO HDMI-CEXT-T right panel interface
CABLE-OUT: Transmission adopts coaxial cable with standard BNC interface, maximum
transmission distance is 100 meters (Belden 1694)
MIO HDMI-CEXT-R panel Introduction
MIO HDMI-CEXT-R right panel interface
CABLE-IN: Receive the data transferred by coaxial cable with BNC interface, maximum
transmission distance is 100 meters (Belden 1694)
LOOP: Loops out the data from cable in, which could be used in cascade work type.

MIOHDMI-CEXT User Manual Gefei-tech
© Beijing Gefei Tech. Co., Ltd 4 / 10
MIO HDMI-CEXT-R left panel interface
HDMI/DVI-OUT: Support digital DVI or HDMI signal output with a female DVI-I interface.
Power jack: standard power: 12V, 1A
Application
Multi-viewer system
Computer
MIO HDMI-CEXT-T MIO HDMI-CEXT-R
LCD
Multi-format converter
HDMI
(DVI)
HDMI
(DVI)
Coaxial cable
How To Connect the MIO HDMI-CEXT Extender System
1.Connect the MIO HDMI-CEXT Extender transmitter (interface marked as HDMI/DVI-IN)
to the DVI/HDMI source device, and you need a HDMI-to-DVI adapter when input

MIOHDMI-CEXT User Manual Gefei-tech
© Beijing Gefei Tech. Co., Ltd 5 / 10
source is HDMI signal.
2.Connect the MIO HDMI-CEXT Extender transmitter (interface marked as CABLE-OUT)
and receiver (interface marked as CABLE-IN) together using a coax cable (maximum
transmission distance is 100 meters (Belden 1694)).
3.Connect MIO HDMI-CEXT Extender receiver (interface marked as HDMI/DVI-OUT) to
the DVI/HDMI display device or DVI/HDMI other device. And you need a
HDMI-to-DVI adapter if the device uses HDMI interface.
Connect MIO HDMI-CEXT Extender receiver (interface marked as LOOP) to the other
MIO HDMI-CEXT Extender receiver (interface marked as CABLE-IN) if needed.
4.Connect the included 12V DC power adapter to the MIO HDMI-CEXT.

MIOHDMI-CEXT User Manual Gefei-tech
© Beijing Gefei Tech. Co., Ltd 6 / 10
Technical specifications
MIO HDMI-CEXT-T
Input
Input interface: 1*DVI-I (digital signal), Female
Resolution: supports the resolutions as following:
480i 60, 576i 50
720P50/59.94/60,
1080I50/59.94/60,
1080P30/29.97/25/24/23.98
1080P50/60
Output
Output interface: 1* coaxial cable, BNC connector
Physical characteristics:
Size: 120 X 95 X 27 mm
Working temperature: 0-65˚C
Deposit temperature: -20 - +70 ˚C
Power: DC 12V 1A

MIOHDMI-CEXT User Manual Gefei-tech
© Beijing Gefei Tech. Co., Ltd 7 / 10
MIO HDMI-CEXT-R
Input
Input interface: 1* coaxial cable, BNC connector
Maximum transmission distance is 100 meters （Belden 1694）
Output
Output interface: 1* coaxial cable loop out, BNC connector
1*DVI-I (digital signal), Female
Physical characteristics:
Size: 120 X 95 X 27 mm
Working temperature: 0-65˚C
Deposit temperature: -20 - +70 ˚C
Power: DC 12V 1A

MIOHDMI-CEXT User Manual Gefei-tech
© Beijing Gefei Tech. Co., Ltd 8 / 10
PACKING LIST
PO No.
CUSTOMER:
CARRIER：SHIPPING DATE:
FROM TO
Device List
Name
Specification
Quantity
Remark
MIO HDMI-CEXT-T
MIO HDMI-CEXT-R
AC-DC Power
DVI (HDMI) TO Cable Transmitter
Cable TO DVI (HDMI) Receiver
12VDC 1A
1
1
2
Total
4

MIOHDMI-CEXT User Manual Gefei-tech
© Beijing Gefei Tech. Co., Ltd 9 / 10
Accessories List
Name
Specification
Quantity
Remark
Video Cable
-----------
-----------
Audio Cable
-----------
-----------
Power Cable
-----------
-----------
User’s Manual (or Disk)
1
Others
Total
1

MIOHDMI-CEXT User Manual Gefei-tech
© Beijing Gefei Tech. Co., Ltd 10 / 10
Contact Us
Technical support:
Tel: [phone]
Fax: [phone]
Website
www.gefei-tech.com
E-mail：swang[email protected]m
