Gefen GTB-UHD-HBT User manual

GTB-UHD-HBT
User Manual
Release A0.6
HDBaseT Extender
w/ RS-232, 2-way IR and POH
™
60Hz, 4:2:0

ii
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this product near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install or place this product near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the third prong are provided for
your safety. If the provided plug does not t into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. To reduce the risk of electric shock and/or damage to this product, never handle or
touch this unit or power cord if your hands are wet or damp. Do not expose this
product to rain or moisture.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does not operate normally,
or has been dropped.
15. Batteries that may be included with this product and/or accessories should never be
exposed to open ame or excessive heat. Always dispose of used batteries
according to the instructions.
Important Safety Instructions

iii
Warranty Information
Gefen/Core Brands, LLC warrants the equipment it manufactures to be free from defects
in material and workmanship. If equipment fails because of such defects and Gefen LLC
is notied within the specied warranty period* from the documented** date of purchase,
Gefen will, at its option, repair or replace the equipment, provided that the equipment
has not been subjected to mechanical, electrical, or other abuse or modications. This
warranty is in lieu of all other warranties expressed or implied, including without limitation,
any implied warranty or merchantability or tness for any particular purpose, all of which
are expressly disclaimed. Warranty period begins on the date of purchase by the original
end-purchaser, as indicated on the proof of purchase document**. This Limited Warranty
extends to the original end-user purchaser of the product, and is not transferrable to any
subsequent purchaser(s) or owner(s). Customers outside the continental United States of
America are responsible for shipping charges to and from Gefen.
* Warranty period:
Passive Copper Cables without any electronic circuitry: 30 days. Cables must be in their
original condition.
Electronics:
•2 years unless specied otherwise.
•3 years if specically noted as such on Gefen web-page of a product.
Documented** purchases made on or after March 29, 2017 only.
** Proof of purchase must be a written document, as deemed acceptable by Gefen/Core
Brands, LLC.

iviv
Contacting Gefen Technical Support
Technical Support
[phone] [phone]
8:00 AM to 5:00 PM Monday - Friday, Pacic Time
Email
[email protected]
Web
http://www.gefen.com
Mailing Address
Gefen
Core Brands, LLC
c/o Customer Service
1800 S McDowell Blvd
Petaluma, CA 94954 USA
Product Registration
Register your product here: http://www.gefen.com/kvm/Registry/Registration.jsp

vv
Operating Notes
•Gefen recommends using CAT-5e (or better) cables.
• Resolution will affect extension distance. 1080p Full HD can be extended up to 495
feet (150 meters) and is limited to 8-bit color depth. 4K resolutions can be extended
up to 330 feet (100 meters). See HDBT (HDBaseT™) Mode (page 17) for details.
•Power Over Line (POL) is a Gefen proprietary technology that provides power over a
single CAT-5e (or better) cable. A power supply (1 pc included) can be connected to
either the Sender or Receiver unit.
• This product passes through the display’s EDID to the source. If the display is capable
of accepting Deep Color, the source must be manually congured to output 8-bit color.
This is only applicable when using 4K x 2K resolutions and “long-run” modes.
See HDBT (HDBaseT™) Mode (page 17) for more information.
•This product supports sources up to 4K 300 MHz (60 Hz 4:2:0 or 30 Hz 4:4:4). It is not
compatible with sources that are capable of HDR or 4K 600 MHz (60 Hz 4:4:4).
•For Standard Range operation for up to 100m/330ft maximum distance, please make
sure that the DIP Switch # 3 on the bottom of the Sender unit is in “OFF” position.
To enable the Extended Range (up to 150m/495ft) mode, ip the DIP switch to “ON”.
Please see DIP Switch Conguration (page 14) for information on all DIP switches.
• The information in this manual has been carefully checked and is believed to be
accurate. However, Gefen assumes no responsibility for any inaccuracies that may be
contained in this manual. In no event will Gefen be liable for direct, indirect, special,
incidental, or consequential damages resulting from any defect or omission in this
manual, even if advised of the possibility of such damages.
•The technical information contained herein regarding the features and specications is
subject to change without notice.
• For the latest warranty coverage information, refer to the Warranty and Return Policy
under the Support section of the Gefen Web site at www.gefen.com.
© 2017 Gefen, LLC. All Rights Reserved. All trademarks are the property of their respective owners.
Gefen, LLC reserves the right to make changes in the hardware, packaging, and any accompanying documentation
without prior written notice.
This product uses UL-Listed power supplies

vi
Features
• Extends 4K Ultra HD (3840 x 2160 @ 60Hz, 4:2:0 or @ 30Hz, 4:4:4), RS-232, and
Bi-Directional R over a single CAT-5e cable up to 330 feet/100 meters (8-bit color)
• Extends 4K Cinema (DCI) (4096 x 2160 @ 24 or 30Hz 4:4:4), RS-232, and
Bi-Directional IR over a single CAT-5e cable up to 330 feet/100 meters (8-bit color)
• Extends HDMI at 1080p Full HD, RS-232, and Bi-Directional IR over a single CAT-5e
cable up to 330 feet/100 meters (up to 12-bit Deep Color)
• Extends HDMI at 1080p Full HD, RS-232, and Bi-Directional IR over a single CAT-5e
cable up to 495 feet/150 meters (8-bit color)
• HDMI Features Supported:
► HDMI 2.0
►HDCP 2.2 and 1.4
►12-bit Deep Color
► LPCM 7.1 audio, Dolby® TrueHD, and DTS-HD Master Audio™ pass-through
►3DTV pass-through
►CEC pass-through
► Lip Sync pass-through
• RS-232 Extension
• IR extension from Sender to Receiver and from Receiver to Sender
• Gefen Bi-Directional POL feature provides power to the Sender or the Receiver unit
over the link cable - only one side needs external power
• Uses Gefen’s implementation of HDBaseT™ technology
• Advanced EDID Management
• Firmware upgradable via RS-232
• Locking power connector
• Surface mountable
Features and Packing List
1080P
60Hz, 4:2:0
HDCP
2.2
HDCP
2.2
4K
CINEMA
DCI, 4096 x 2160, 30Hz
4K
CINEMA
DCI, 4096 x 2160, 30Hz

vii
Packing List
The following items are shipped with the 4K Ultra HD HDBaseT Extender w/ RS-232,
2-way IR and POL. If any of these items are not present in the box when you rst open it,
immediately contact your dealer or Gefen.
•1 x 4K Ultra HD HDBaseT™ Extender w/ RS-232, 2-way IR and POL - Sender unit
(GTB-UHD-HBT-S)
•1 x 4K Ultra HD HDBaseT™ Extender w/ RS-232, 2-way IR and POL - Receiver unit
(GTB-UHD-HBT-R)
•1 x 6 ft. locking HDMI cable, M-M (CAB-HD-LCK-06MM)
•1 x IR extender (EXT-RMT-EXTIRN)
•1 x IR emitter (EXT-IREMIT)
•1 x Adapter: 3-pin Phoenix-to-DB-9, M-F (ADA-PH-2-DB9-MF-AA or DA-PH-2-DB9-
MF-AB)
•1 x Adapter: 3-pin Phoenix-to-DB-9, M-M (ADA-PH-2-DB9-MM-AA or ADA-PH-2-DB9-
MM-AB)
•1 x 24V DC locking power supply (EXT-PS24U1AIP-6)
•1 x Quick-Start Guide (QSG-GTB-UHD-HBT)
Features and Packing List

viii
