Gefen ToolBox GTB-USB2.0-4LR User manual

USB 2.0 LR
4-Port Extender
GTB-USB2.0-4LR
User Manual
www.gefentoolbox.com

ASKING FOR ASSISTANCE
Rev A5
Technical Support:
Telephone [phone]
[phone]
Fax [phone]
Technical Support Hours:
8:00 AM to 5:00 PM Monday through Friday, Pacic Time.
Write To:
Gefen, LLC
c/o Customer Service
20600 Nordhoff St
Chatsworth, CA 91311
www.gefentoolbox.com
[email protected]
Notice
Gefen, LLC reserves the right to make changes in the hardware, packaging and
any accompanying documentation without prior written notice.
USB 2.0 LR 4-Port Extender is a trademark of Gefen, LLC
© 2011 Gefen, LLC. All rights reserved.
All trademarks are the property of their respective companies.

CONTENTS
1 Introduction
2 Operation Notes
3 Features
4 Sender Panel Layout
5 Sender Panel Descriptions
6 Receiver Panel Layout
7 Receiver Panel Descriptions
8 Connecting And Operating The USB 2.0 LR 4-Port Extender
9 Troubleshooting
10 Network Cable Wiring Diagram
11 Wiring Diagram
12 Specications
13 Warranty

1
Congratulations on your purchase of the GefenToolBox USB 2.0 LR 4-Port
Extender. Your complete satisfaction is very important to us.
About Gefen
We specialize in total integration for your home theater, while also focusing on
going above and beyond customer expectations to ensure you get the most from
your hardware. We invite you to explore our distinct product line. Please visit
http://www.gefen.com for the latest offerings in High-Denition signal solutions
or call us between the hours of 8:00 am and 5:00 pm Monday-Friday, Pacic
Standard Time for assistance with your A/V needs. We’ll be happy to assist you.
Why GefenToolBox?
The GefenToolBox line offers portable and easy-to-install solutions for common
A/V system integration setups using HDMI connectivity. GefenToolBox products
are wall-mountable and small in size. GefenToolBox products are easily
transported in the eld and are ready for immediate and simple installations in
working environments.
The GefenToolBox USB 2.0 LR 4-Port Extender
The USB 2.0 LR 4-Port Extender extends a USB source up to 330 feet (100
meters) using a single CAT-5 cable. This product supports USB 2.0 with data
rates up to 480 Mbps in addition to backward-compatibility with USB 1.1. The
Receiver Unit allows the connections of up to four (4) USB devices, providing
access to printers, scanners, cameras, external storage media, digital signage,
and automated control systems.
How It Works
Use the supplied USB cable to connect the USB 2.0 LR 4-Port Sender Unit to
the USB host (source) device. Connect the USB devices to the Receiver Unit.
Use a CAT-5 cable to connect the Sender Unit to the Receiver Unit. Connect the
included locking power supply to the Receiver Unit, then connect the power cord
to an available electrical outlet. The LED indicators on the Sender Unit and the
Receiver Unit provide status on power and data transmission activity.
INTRODUCTION

2
READ THESE NOTES BEFORE INSTALLING OR
OPERATING THE USB 2.0 LR 4-PORT EXTENDER
• Use industry standard CAT-5, CAT-5e or CAT-6. Gefen recommends using solid
core cabling for maximum performance.
• The USB 2.0 LR 4-Port Extender is backward-compatible with USB 1.1.
• The USB 2.0 LR 4-Port Extender can extend USB a maximum of 330 ft (100 m)
• Use only the AC adapter supplied with the USB 2.0 LR 4-Port Extender. Use
of substitute adapters may cause permanent damage to the system and will
void the warranty.
OPERATION NOTES

3
Features
• Extends USB 2.0 up to 330 feet (100 meters)
• Supports 480 Mbps using USB 2.0
• Backward-compatible with USB 1.1 devices
• Receiver supports up to four (4) USB devices
• Uses industry-standard CAT-5, CAT-5e, or CAT-6 cable
• Plug-and-Play
• Works with PC and Mac computers
• Locking Power Connectors
Package Includes
(1) USB 2.0 LR 4-Port Extender (Sender Unit)
(1) USB 2.0 LR 4-Port Extender (Receiver Unit)
(1) 6 ft. USB Cable (A-B)
(2) 5V DC Locking Power Supplies
(2) AC Power Cords
(1) Quick-Start Guide
FEATURES

4
Front Panel
Top Panel
4
SENDER UNIT LAYOUT
1 2 3

5
1 USB Input Port
Connect the USB host device to this port.
2 Host Connection Indicator
This LED will turn bright green once the host USB device has been connected.
to the Sender Unit.
3 CAT-5 Output Jack
Connects the Sender Unit to the Receiver Unit using CAT-5 cabling.
4 5V DC Locking Power Connector
This receptacle can be used to connect an additional 5V DC locking power
supply (sold separately) if the host computer does not provide enough power for
operation. Normally, only the Receiver is powered by an external 5V DC locking
power supply (included).
SENDER UNIT DESCRIPTIONS

6
RECEIVER UNIT LAYOUT
Front Panel
Top Panel
1 2 3 4
5
