Gefen Gef-3gsdi-16416-pb User manual

Audio

Embedder

3GSDI

16 16

SOURCES DISPLAYS

3G-SDI Matrix

w/ Push Button Controls

Release A2

User Manual

GEF-3GSDI-16416-PB

16x16 3G-SDI Matrix w/ Push Button Controls

Important Safety Instructions

GENERAL SAFETY INFORMATION

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this product near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s

instructions.

8. Do not install or place this product near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including ampliers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized

plug has two blades with one wider than the other. A grounding type plug has two

blades and a third grounding prong. The wide blade or the third prong are provided for

your safety. If the provided plug does not t into your outlet, consult an electrician for

replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs,

convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specied by the manufacturer.

12. To reduce the risk of electric shock and/or damage to this product, never handle or

touch this unit or power cord if your hands are wet or damp. Do not expose this

product to rain or moisture.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualied service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is

damaged, liquid has been spilled or objects have fallen into the apparatus,

the apparatus has been exposed to rain or moisture, does not operate normally,

or has been dropped.

15. Batteries that may be included with this product and/or accessories should never be

exposed to open ame or excessive heat. Always dispose of used batteries

according to the instructions.

RACK MOUNT SAFETY INFORMATION

a. Maximum recommended ambient temperature: 40 ˚C (104 ˚F).

b. Increase the air ow as needed to maintain the recommended temperature

inside the rack.

c. Do not exceed maximum weight loads for the rack. Install heavier equipment in the

lower part of the rack to maintain stability.

16x16 3G-SDI Matrix w/ Push Button Controls

Warranty Information

Gefen warrants the equipment it manufactures to be free from defects in material and

workmanship.

If equipment fails because of such defects and Gefen is notied within two (2) years from

the date of shipment, Gefen will, at its option, repair or replace the equipment, provided

that the equipment has not been subjected to mechanical, electrical, or other abuse or

modications. Equipment that fails under conditions other than those covered will be

repaired at the current price of parts and labor in effect at the time of repair. Such repairs

are warranted for ninety (90) days from the day of reshipment to the Buyer.

This warranty is in lieu of all other warranties expressed or implied, including without

limitation, any implied warranty or merchantability or tness for any particular purpose, all of

which are expressly disclaimed.

1. Proof of sale may be required in order to claim warranty.

2. Customers outside the US are responsible for shipping charges to and from Gefen.

3. Copper cables are limited to a 30 day warranty and cables must be in their original

condition.

The information in this manual has been carefully checked and is believed to be accurate.

However, Gefen assumes no responsibility for any inaccuracies that may be contained

in this manual. In no event will Gefen be liable for direct, indirect, special, incidental, or

consequential damages resulting from any defect or omission in this manual, even if

advised of the possibility of such damages. The technical information contained herein

regarding the features and specications is subject to change without notice.

For the latest warranty coverage information, refer to the Warranty and Return Policy under

the Support section of the Gefen Web site at www.gefen.com.

PRODUCT REGISTRATION

Please register your product online by visiting the Register Product page under the

Support section of the Gefen Web site.

iii

16x16 3G-SDI Matrix w/ Push Button Controls

Gefen, LLC

c/o Customer Service

20600 Nordhoff St.

Chatsworth, CA 91311

Telephone: (818) 772-9100

(800) 545-6900

Fax: (818) 772-9120

Email: [email protected]

Visit us on the Web: www.gefenpro.com

Technical Support Hours: 8:00 AM to 5:00 PM Monday - Friday, Pacic Time

For 24 / 7 support, see the back of the product for the

support number

16x16 3G-SDI Matrix w/ Push Button Controls is a trademark of Gefen, LLC.

Important Notice

Gefen, LLC reserves the right to make changes in the hardware, packaging, and any

accompanying documentation without prior written notice.

All trademarks are the property of their respective owners.

Contacting Gefen Technical Support

3GSDI Audio Embedder

• There is no internal scaling in the 16x16 3G-SDI Matrix w/ Push Button Controls. All

of the attached monitors must be able to display the output resolutions of the source

devices. For maximum compatibility it is recommended that only one compatible/

common resolution be used by all of the source devices.

• Routing features can be accessed using RS-232 or IP control. See page 30 for more

information.

Operating Notes

16x16 3G-SDI Matrix w/ Push Button Controls

Features

• Supports resolutions up to 1080p, 1920x1200, and 2K.

• Front panel control buttons for local switching.

• Serial interface for remote control via a computer or control automation devices

supports RS-232 and RS-485 protocols.

• IP Control

• Discrete IR remote control

• Redundant Internal AC power supply

• Output masking command

• Standby mode

• Grounding pin

• IR Sensor

• IR Extender

• Power On/Off switch

• Status LCD (shows routing status)

• Rack mountable

Packing List

The 16x16 3GSDI Matrix ships with the items listed below. If any of these items are not

present in your box when you rst open it, immediately contact your dealer or Gefen.

• 1 x GefenPRO 16x16 3GSDI Matrix w/ Push Button Controls

• 1 x IR Remote Control unit

• 1 x AC Power Cord

• 1 x Set of rack ears

• 1 x Quick-Start Guide

16x16 3G-SDI Matrix w/ Push Button Controls

Features and Packing List

1080P

vii

3GSDI Audio Embedder16x16 3G-SDI Matrix w/ Push Button Controls

Table of Contents

viii

01 Getting Started

Panel Layout ......................................................................................................... 2

Front.............................................................................................................. 2

Back .............................................................................................................. 3

IR Remote Control Unit ......................................................................................... 4

Front.............................................................................................................. 4

Back .............................................................................................................. 5

Installing the Battery...................................................................................... 6

Setting the IR Channel .................................................................................. 6

Installation ............................................................................................................. 7

Connecting the 16x16 3G-SDI Matrix ........................................................... 7

Sample Wiring Diagram ................................................................................ 7

02 Operating the 16x16 3G-SDI Matrix

Front Panel Controls ........................................................................................... 10

Front Panel Buttons .................................................................................... 10

Front Panel LCD Screen ............................................................................. 11

Routing Basics .................................................................................................... 12

Routing Inputs to Outputs ........................................................................... 12

Getting the Current Routing Status ............................................................. 14

One-to-One Routing.................................................................................... 15

Saving the Current Routing State ............................................................... 16

Recalling a Saved Routing State ................................................................ 18

Masking............................................................................................................... 19

Masking Outputs ......................................................................................... 19

Getting the Current Masking Status ............................................................ 21

Unmasking Outputs..................................................................................... 22

Locking the Matrix ............................................................................................... 24

Communication Settings ..................................................................................... 25

Setting the Communication Mode ............................................................... 25

Using the IR Remote Control .............................................................................. 26

Routing Sources using the IR Remote Control ........................................... 26

03 Advanced Operation

RS-232 and IP Conguration .............................................................................. 30

RS-232 Interface ......................................................................................... 30

RS232 Settings ........................................................................................... 30

IP Conguration .......................................................................................... 31

RS-232 / IP Commands ...................................................................................... 32

Web Interface ...................................................................................................... 42

Using the built-in Web Server ..................................................................... 42

View Matrix Status ...................................................................................... 42

Masking....................................................................................................... 44

IP Conguration .......................................................................................... 46

16x16 3G-SDI Matrix w/ Push Button Controls

Table of Contents

04 Appendix

Warning Messages.............................................................................................. 50

System Failure ............................................................................................ 50

Firmware Upgrade Procedure............................................................................. 51

Fuse Replacement .............................................................................................. 52

Specications ...................................................................................................... 53
