Gefen EXT-3GSDI-2-HDMI1.3 User manual

®
3GSDI to
HDMI®1.3
Converter
EXT-3GSDI-2-HDMI1.3
User Manual
www.gefen.com

ASKING FOR ASSISTANCE
Rev B8
Technical Support:
Telephone [phone]
[phone]
Fax [phone]
Technical Support Hours:
8:00 AM to 5:00 PM Monday thru Friday, Pacific Time
Write To:
Gefen, LLC.
c/o Customer Service
20600 Nordhoff St
Chatsworth, CA 91311
www.gefen.com
[email protected]
Notice
Gefen, LLC reserves the right to make changes in the hardware, packaging and
any accompanying documentation without prior written notice.
3GSDI to HDMI 1.3 Converter is a trademark of Gefen, LLC
HDMI, the logo, and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing in the United States and
other countries.
© 2011 Gefen, LLC, All Rights Reserved
All trademarks are the property of their respective owners

CONTENTS
1 Introduction
2 Operation Notes
3 Features
4 Panel Layout
5 Panel Descriptions
6 Bottom Panel Layout
7 Bottom Panel Descriptions
8 Connecting And Operating The 3GSDI To HDMI 1.3 Converter
9 DIP Switch Features
11 Firmware Update
15 Specifications
1 Warranty

1
Congratulations on your purchase of the 3GSDI to HDMI 1.3 Converter. Your
complete satisfaction is very important to us.
Gefen
Gefen delivers innovative, progressive computer and electronics add-on solutions
that harness integration, extension, distribution and conversion technologies.
Gefen’s reliable, plug-and-play products supplement cross-platform computer
systems, professional audio/video environments and HDTV systems of all sizes
with hard-working solutions that are easy to implement and simple to operate.
The Gefen 3GSDI to HDMI 1.3 Converter
The Gefen 3GSDI to HDMI 1.3 Converter will take any SDI, HD-SDI, or 3G-SDI
video signal and convert it to HDMI 1.3. The SDI input resolution will simply be
converted to an HDMI signal. DIP switches on the unit will allow the user to select
features such as Deep Color conversion and colorspace. A useful 720p (60Hz)
test pattern is also available, without connecting an SDI source, for checking the
HDMI video output. An SDI loop out and 2 channel analog audio outputs are also
provided for monitoring the input SDI source.
How It Works
The 3GSDI to HDMI 1.3 Converter will convert the input SDI signal (SD/HD/3G)
to an HDMI compatible signal. Connect the SDI source device to the video input
on the unit. Connect an HDMI compatible device on the video output on the unit.
Adjust DIP switch features and connect the power supply. It’s that simple.
INTRODUCTION

2
READ THESE NOTES BEFORE INSTALLING OR
OPERATING THE 3GSDI TO HDMI 1.3 CONVERTER
• Supports the following SMPTE standards: 259M, 292M, SMPTE 274M,
SMPTE 296M, ITU-R BT.656 and ITU-R BT.601
• Handles 3G-SDI SMPTE 425-A and 425-B / formats 1080P 50/59.94/60.
• Support of 4 stereo 48 kHz audio streams.
• The 3GSDI to HDMI 1.3 Converter supports the following resolutions:
Video Resolution Refresh Rate (Hz) Rate
525i (NTSC) (480i) 59.94 SD
525p (480p) 59.94 SD
525p (480p) 60 SD
625i (PAL) (576i) 50 SD
625p (576p) 50 SD
720p 23.98 HD
24 HD
25 HD
29.97 HD
30 HD
50 HD
59.94 HD
60 HD
1080i 50 HD
59.94 HD
60 HD
1080p 23.98 HD
24 HD
25 HD
29.97 HD
30 HD
50 3G lev.A/B
59.94 3G lev.A/B
60 3G lev.A/B
2K 23.97 HD
24 HD
25 HD
OPERATION NOTES

3
Features
• Field upgradable firmware using the built-in USB port.
• Supports a test pattern at 720P/60 without needing a valid source signal
• HMDI 1.3 compliant
• Support for YCbCr, RGB, 4:2:2, 4:4:4, and 8 to 10 bits output formats.
• Color space support: YCbCr, RGB.
• Color sampling: 4:2:2 and 4:4:4.
• Bit depth: 8, 10 bits.
• Auto-detects optimal monitor format with EDID display capability information.
• Support of 4 stereo 48 kHz audio streams.
• Supports up to 8 channels of PCM audio embedded into the HDMI output
signal
• Supports Dolby Digital/DTS AC3 encoded audio
• Automatic detection of SD, HD and 3G-SDI formats on the input
• A re-clocked copy of the SDI input is available on the output SDI connector.
• Audio from SDI input channels 1 & 2 can be monitored through 3.5mm mini-
stereo RCA-jack analog audio connectors
Package Includes
(1) 3GSDI to HDMI 1.3 Converter
(1) 5V DC Locking Power Supply
(1) User Manual
FEATURES

4
Back Panel
4 5 6 7 8 9
1 2 3
Front Panel
PANEL LAYOUT

5
1 Video Lock LED Indicator
This indicator will become active when the SDI input (SD/HD/3G) is locked.
2 3G LED Indicator
This indicator will become active when the SDI input is a 3G source.
3 Power LED Indicator
This indicator will become active when power is being supplied to the unit via the
included 5V DC power adapter.
4 Locking 5V DC Power Receptacle
This input will accept power via the included locking 5V DC power supply.
Connect the power supply between this input and an open wall power socket.
5 USB Update Port
This port is used to update firmware. For current firmware releases please see
the download section at www.gefen.com.
6 Analog RCA Audio Ouput
This input will output up to 2 channels of analog audio via 2 RCAstyle analog
audio connectors. This audio will be extracted from the incoming SDI source for
monitoring purposes.
7 SDI Input
This input will accept a single SDI video source. For acceptable input formats
please see page 2.
8 SDI Loop Output
This output will mirror the input SDI video source. This is useful for monitoring
the SDI input source.
9 HDMI Ouput
This output will accept a single HDMI typeAmale cable. The converted SDI
signal will be output through this port.Audio and video are both supported by
this port. For a complete listing of the acceptable SDI, audio and video formats
please see page 2.
PANEL DESCRIPTIONS

6
Bottom Panel
4567
12 3
BOTTOM PANEL LAYOUT

7
1 SDI Input Color Sampling LED Indicator
This LED indicator will relay the status of the incoming SDI input’s color
sampling. Options are either 4:4:4 (LED ON) or 4:2:2 (LED OFF).
2 SDI Input Color Space LED Indicator
This LED indicator will relay the status of the incoming SDI input’s color space.
Options are either RGB (LED ON) or YCbCr (LED OFF).
3 Configuration DIP Switches
This DIP (Dual In-line Packages) switches will enable disable features on the
3GSDI to HDMI 1.3 Converter. For a complete listing of DIP switch features and
functions please see page 9.
4 SDI Input Color Depth LED Indicator
This LED indicator will relay the status of the incoming SDI input’s color depth.
Options are either 12 bit (LED ON) or 8/10 bit (LED OFF).
5 HDMI Output Color Space LED Indicator
This LED indicator will relay the status of the outgoing HDMI output’s color
space. Options are either YCbCr (LED ON) or RGB (LED OFF).
6 HDMI Output Color Sampling LED Indicator
This LED indicator will relay the status of the outgoing HDMI output’s color
sampling. Options are either 4:4:4 (LED ON) or 4:2:2 (LED OFF).
7 HDMI Output Deep Color LED Indicator
This LED indicator will relay the status of Deep Color in the HDMI’s output.
Options are either Deep Color ON (LED ON) or Deep Color OFF (LED OFF).
BOTTOM PANEL DESCRIPTIONS

8
How to Connect the 3GSDI to HDMI 1.3 Converter
1. Connect the SDI source (SD/HD/3G) to the SDI input on the 3GSDI to HDMI
1.3 Converter using a user supplied SDI cable.
2. Optionally, connect an SDI capable output device to the SDI loop out
connector for monitoring of the SDI input signal.
3. Optionally connect a 2 channel analog audio device to the 2 RCA style
analog audio connectors for monitoring of the audio from the SDI input.
4. Connect an HDMI capable output device to the HDMI output port on the
3GSDI to HDMI 1.3 Converter using a user supplied HDMI cable.
NOTE: By default, the features in the EDID of the sink device are used to
configure the output color space, sampling, and bit depth. These features can be
overridden by adjusting the DIP switches on the bottom panel of the 3GSDI to
HDMI 1.3 Converter. Please see page 9 for more information.
5. Connect included 5V DC power supply to the locking power receptacle of the
3GSDI to HDMI 1.3 Converter and an open wall power socket.
Wiring Diagram for the Gefen 3GSDI to HDMI 1.3 Converter
CONNECTINGAND OPERATINGTHE 3GSDITOHDMI 1.3CONVERTER
EXT 3GSDI 2 HDMI1 3
Converter
3GSDI Source
HD Display
Co
ANALOG AUDIO (RCA) CABLE
3G-SDI CABLE
HDMI CABLE
Powered
Speakers

9
DIP SWITCH FEATURES
The 3GSDI to HDMI 1.3 Converter has a series of DIP switches that will allow
manual configuration of the HDMI’s output video signal. There is also a DIP
switch to display a test pattern through the HDMI output. Please see the next
page for DIP switch features and operation.
Switch Description OFF
(Factory Default) On
1 Test pattern Off On
2 EDID Auto Manual
3HDMI Out
Sampling 4:4:4 4:2:2
4HDMI Out Color
Space RGB YCbCr
5HDMI Out RGB
Range Limited Full
6HDMI Out Deep-
Color Off Deep
7HDMI Out Bit
Depth 12b 10b
8 Spare Unused N/A N/A
1 The color bar test pattern is in 720p (60Hz) format. No valid input is
necessary at the SDI connector to use the test pattern.
2 When this switch is turned OFF (Auto), the HDMI output is configured
according to what is reported inside the HDMI sink EDID connected to the
mini converter. When turned ON(Manual), the switches 3 to 7 are used
instead for the configuration of the HDMI link.

10
DIP SWITCH FEATURES
3 When the EDID switch is ON (set to manual), this switch sets the output
sampling of the video: 4:2:2 or 4:4:4.
4 When the EDID switch is ON (set to manual), this switch sets the output
color space of the video: YCbCr or RGB.
5 When the EDID switch is ON (set to manual), and the HDMI output color
is RGB, this switch specifies the video range: limited (16-235) or full range
(0-255).
6 When the EDID switch is ON (set to manual), this switch forces the output
into Deep Color,12-bits or into 8 bits.
7 When the EDID switch is ON (set to manual) and DIP switch 6 is set to ON
(Deep Color), this switch forces the output into 10-bit or 12-bit.
LED INDICATORS

FIRMWARE UPDATE
Things you’ll need:
• Computer running Windows XP or Vista
• 3GSDI Converter Firmware Loader 1.1.18 software
• USB cable (to-male)
• Firmware files contained in 3GSDI To HDMI Converter Firmware 1.1.5
1. Download 3GSDI Converter Firmware Loader 1.0.18 from
http://www.gefen.com/kvm/support/download.jsp
a. Create a new folder and decompress the downloaded file
Mini_Updater_Release_1_0_18.zip into the newly created folder.
b. Read and follow instructions on the Installation Guide.txt for installing
the firware loader software.
2. Connect the USB cable between your PC and the EXT-3GSDI-2-HDMI1.3
a. Check Device Manager on Windows to find the correct COM port
number for the USB connection. Remember this COM port number
for use in step #4.
11

FIRMWARE UPDATE
3. Download and decompress 3GSDI to HDMI Converter Firmware 1.1.5 from
http://www.gefen.com/kvm/support/download.jsp to the new folder created in
Step #1.
4. After installing the Firmware Loader described in Step #2, run the
program via the Windows Start Menu….Start/Programs/Gefen/Mini Updater/
Mini Updater.
a. Use the drop-down arrow to choose the COM port shown in Step #2.
5. Browse for the file
Mini3GSDI_TO_HDMI_1_1_5.ini
in the new folder created in Step#1
6. Once the file is found, click Update Device.
12

FIRMWARE UPDATE
13
7. After pressing Update Device, you should see this window confirming the
correct COM port, the detected device, and the firmware binary file.
8. Another window will pop-up showing the firmware loader program doing a
communication check

FIRMWARE UPDATE
9. If all steps are PASS, the firmware upload process can continue. Click YES to
continue the update. If there is a FAIL, repeat steps #2-7.
10. After clicking YES, this window will appear twice showing th upload progress.
11. Once the upload process is complete, another window will pop up showing
the message “Update finished”.”.
14

16
Max. image output resolutions: ............................2K (2048x1080), 1920x1080/60
Input Connector: ...........................................(1) BNC female SDI/HD-SDI/3G-SDI
Input Connector: ............................................(1) Locking 5V DC power connector
Input Connector: ..................................(1) USB connector (for firmware upgrades)
Output Connector: ...........(1) BNC female SDI/HD-SDI/3G-SDI (w/buffered input)
Output Connector: ..............................................(1) HDMI 1.3 Type A 19-pin Male
Output Connectors: ...................................(2) L+R analog audio jacks (RCA-type)
Input Video Bandwidth: .................................up to 3.0 Gbps (Single Link 3G-SDI)
Output Video Bandwidth: ....................................225 MHz (Single Link HDMI 1.3)
SDI Compliant: .......................................................SMPTE 259M, up to 360 Mb/s
HD-SDI Compliant ..............................................SMPTE 292M, up to 1.485 Gbps
3G-SDI Compliant..........................................SMPTE 424M/425M, up to 3.0 Gbps
Power Supply: .......................................................5V DC locking type, 2.5W each
Dimensions: ........................................................................8.2’’ W x 1.1’’H x 7.5’’D
Rack Size: ........................................................................................1U (half-width)
Operating Temp.: ............................................................................0-40 degrees C
Shipping Weight ............................................................................................. 4 lbs
HDMI 1.3 Compliant
SPECIFICATIONS

17
WARRANTY
G
e
f
en warrants the equipment it manu
f
actures to be
f
ree
f
rom de
f
ects in material
and workmanship.
I
f
equipment
f
ails because o
f
such de
f
ects and
G
e
f
en is noti
fi
ed within two
(
2
)
y
ears
f
rom the date o
f
shipment,
G
e
f
en will, at its option, repair or replace the
e
quipment, provided that the equipment has not been sub
j
ected to mechanical,
e
lectrical, or other abuse or modi
fi
cations. Equipment that
f
ails under conditions
other than those covered will be repaired at the current price o
f
parts and labor in
eff
ect at the time o
f
repair.
S
uch repairs are warranted
f
or ninet
y
(
90
)
da
y
s
f
rom
the da
y
o
f
reshipment to the Bu
y
er.
This warrant
y
is in lieu o
f
all other warranties expressed or implied, includin
g
without limitation, an
y
implied warrant
y
or merchantabilit
y
or
fi
tness
f
or an
y
p
articular purpose, all o
f
which are expressl
y
disclaimed.
1. Proo
f
o
f
sale ma
y
be required in order to claim warrant
y
.
2.
C
ustomers outside the U
S
are responsible
f
or shippin
g
char
g
es to and
f
rom
G
e
f
en.
3
.
C
opper cables are limited to a 30 da
y
warrant
y
and cables must be in their
ori
g
inal condition.
The in
f
ormation in this manual has been care
f
ull
y
checked and is believed to
be accurate. However,
G
e
f
en assumes no responsibilit
y
f
or an
y
inaccuracies
that ma
y
be contained in this manual. In no event will
G
e
f
en be liable
f
or
direct, indirect, special, incidental, or consequential dama
g
es resultin
g
f
rom
an
y
de
f
ect or omission in this manual, even i
f
advised o
f
the possibilit
y
o
f
such
dama
g
es. The technical in
f
ormation contained herein re
g
ardin
g
the
f
eatures and
s
peci
fi
cations is sub
j
ect to chan
g
e without notice.
For the latest warrant
y
covera
g
e in
f
ormation, please visit
G
e
f
en’s Warrant
y
web
p
a
g
e at http:
//
www.
g
e
f
en.com
/
kvm
/
aboutus
/
warrant
y
.
j
s
p
P
RODUCT REGISTRATIO
N
P
lease re
g
ister
y
our product online b
y
visitin
g
Gefen’s web site at
http://www.
g
efen.com/kvm/Re
g
istr
y
/Re
g
istration.
j
sp
