GEMAR Lumitec GLT Audio AS-15 User manual

1
OPERATIONS MANUAL
GLT Audio AS-15
Code 102904
Introduction:
Congratulations on your purchase of the amplified loudspeaker; this speaker includes the very
latest t echnolo gy in ligh tweight ABS design. The trapezoidal design was used for a more
precise andaccurate sound and will add increased sound definition on vocal frequencies.
This state of the ar t speaker will give you years of enjoyment.
Features:
• Steel basket woofer
• High wattage powered amplifier
• Stand mounting socket
• Auxiliary Line Input
• Metal Grill
• High Temperature Voice coil
• Rubber Feet
• DSP Processor
• Bluetooth Pairing Button

2
Important Safety Instructions:
1. All operating instructions should be read before using this equipment.
2. To reduce the risk of elec tric shock, do not open the unit. There are no replaceable parts
inside. Please refer servicing to a qualified service technician.
3. Do not expose this unit to direct sunlight or to a heat source such as a radiator or stove.
4. This unit should be cleaned only with a damp cloth. Avoid solvents or other cleaning
detergents.
5. When moving this equipment, it should be placed in its original car ton and packaging.
This will reduce the risk of damage during transit.
6. Do not expose this unit to rain or moisture.
7. Do not use any spray cleaner or lubricant on any controls or switches.
8. Make sure all of your equipment is completely off and lower all volume, level & gain controls
before connecting the speaker.
9. Only line level signals can be sent to your speaker.
Failing to adhere to the cautions above will void the
manufacturer warranty!

3
Functions:
1. Bluetooth pairing button: Bluetooth can be found automatically and be
connected automatically from second time. If no connection, Bluetooth will be
off automatically after 2 seconds.
2. Start to Bluetooth pairing if press this button, then press again to play after
connected, and cancel pairing if press this button two or three seconds. LED
indicates the status: lighting says connected already, slow flash indicates the music
is playing, quick flash is means matching.
3. DSP Presets: Use this button to toggle through the four different settings.
4. FLAT: The frequency curve is flat, which is suitable for most places.
5. CONTOUR: A three-stage multi-band compressor. It can dynamically adjust the
level of each frequency band in accordance with the input volume of sound. When
the level is low, it can enhance the high and low frequencies. And the Level is
high, it also can reduce the amount of high level. Therefore, it is able to provide
the most appropriate and powerful sound sense of hearing in accordance with
the audience. For example, when listening to dance music, it will be very effective
if need to strengthen the rhythm.
6. SPEECH: Use this setting when the speaker is being used for Speech only or
Spoken Word applications and facing towards the audience.
7. EXT LF: Use this setting when the speaker is being used in conjunction with a
separate subwoofer. This preset enables a High Pass Filter(HPF) set at 100Hz.
8. Power indicator
9. Signal indicator: The LED lights up when signal input.
10. LIMIT Indicator: Illuminated just before the sub amplifier begins to clip and distort.
Adjust the sub level control and signal level from your source so this illuminates
only briefly on peaks in the music. Using the system with this on all or much of the
time will result in poor sound quality and damage the speakers and electronics.
11. Volume control for INPUT1: Control the volume for INPUT1 when using the INPUT1.
12. Volume control for INPUT2: Control the volume for INPUT2 when using the INPUT2.
13. MIC/LINE Switch: Use the MIC position (depressed) when a microphone is connected. Use
the LINE position(disengaged) when a line level source such as an audio mixing console, audio
playback device, or electronic musical instrument is connected.
14. MIC/LINE Switch: Use the MIC position (depressed) when a microphone is connected. Use
the LINE position(disengaged) when a line level source such as an audio mixing console, audio
playback device, or electronic musical instrument is connected.
15. MIC/LINE input for INPUT1: Use combination XLR or 1/4” Jack connector balanced or
unbalanced.
16. MIC/LINE input for INPUT2: Use combination XLR or 1/4” Jack connector balanced or
unbalanced.
17. MIX/INPUT2 output switch: MIX(depressed) is for INPUT1 and INPUT2 output. IN2(disengaged) is
for INPUT2.
18. MIX/INPUT2 output: Use XLR connector balanced or unbalanced.
19. Power Supply Switch

4
20. Power Supply Input Connector: Use with power cord.
Make sure ALL of your equipment is completely OFF and lower ALL VOLUME, LEVEL & GAIN
controls before connecting the speaker.
Connections:
1. For this unit you can connect a mixer, microphone or CD-Player directly into your speaker.
2. To connect a microphone use combination XLR or ¼” jack connector to connect to the
IN1(10) and IN2 (11) input.
3. You can LINK additional speakers using the MIX/IN2(13) connection. The amplifier on your
speaker will only power this speaker. If you LINK to additional speakers those speakers must
be self-amplified.
4. Turn on your mixer/microphones or other signal source, then turn on your
unit, the Power Indicator (3) will be lit. Now you can adjust your volume
controls to a reasonable level.
