Gemini 15 User manual

Gemini 15 / 17 / 19
Console with Modular KVM Switch
Quick Installation Guide
Rev 1.0

Gemini series QIG
2
Notes:
1. Please check all peripherals according the list before installation. To make sure
that the whole unit was not damaged and lost during shipping process. If you
encounter any problem, please contact your dealer.
2. Before installation, make sure all peripherals and computer have been turned
off.
Hardware kits contents:
1. Rail with front and rear bracket x 2
2. Bracket A x 2
3. Screw x 2
4. Screw (length = 6 mm) x 6
5. Key x 2

Gemini series QIG
3
Install console step:
1. Adjust rail with rear bracket to fit your cabinet
2. Install front and rear bracket on cabinet.
3. Repeat step 1~2 for the other side.
4. Push console into rails and push it to the end.
5. Install a screw to combine bracket A and console. (Both sides)
bracket A

Gemini series QIG
4
6. Install three screws (length = 6 mm) in rear of the console (Both sides) and finish
installation.
Gemini 15 / 17 / 19
Console with Modular KVM Switch
Quick Installation Guide
