Gemini GLS-550 User manual

Gigabeat Party System
GLS-550/GLS-880
DEAR CUSTOMER:
this unit. Retain this manual in a safe place for future reference.
Please carefully read and follow all instructions prior to using

Contents
Important safety instructions........................................................................................................................3
Panel...........................................................................................................................................................4
Remote control ...........................................................................................................................................5
Bluetooth pair and connect .......................................................................................................................5
Tws (true wireless stereo) mode ................................................................................................................5
Battery ........................................................................................................................................................6
Accessories .................................................................................................................................................6
Specifications ..............................................................................................................................................6
Special precautions......................................................................................................................................7
NO.2

NO.3
WARNING: SHOCK HAZARD - DO NOT OPEN
AVIS: RISQUE DE CHOC ÉLECTRIQUE - NE PAS OUVRIR
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the
user to the presence of uninsulated “dangerous
voltage” within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in
accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when
unused for long periods of time.
14) Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug
is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been
dropped.
CAUTION
To prevent electric shock hazard, do not connect to
mains power supply while grille is removed.minimum
distances 10cm around the apparatus for sufficient
ventilation;the ventilation should not be impeded by
covering the ventilation openings with items, such as
newspapers, table-cloths, curtains, etc.;no naked flame
sources, such as lighted candles, should be placed on
the apparatus;attention should be drawn to the
environmental aspects of battery disposal;the use of
apparatus in moderate climates.the apparatus shall not
be exposed to dripping or splashing and that no objects
filled with liquids, such as vases, shall be placed on the
apparatus.Where the MAINS plug or an appliance
coupler is used as the disconnect device, the disconnect
device shall remain readily operable.Batteries (battery
pack or batteries installed) shall not be exposed to
excessive heat such as sunshine, fire or the like.“To
reduce the risk of fire or electric shock, do not expose
this apparatus to rain or moisture”Caution Marking and
rating plate was located at rear enclosure of the
apparatus.
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
CAUTION
FCC warning:
Any Changes or modifications not expressly approved
by the party responsible for compliance could void the
user's authority to operate the equipment.
Note: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and
receiver.
-Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV
technician for help.
This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment.

EFFECTS
Panel
NO.4
1. FM ANTENNA : FM input socket
2. DC INPUT : DC input socket
3. MIC : Wired microphone input socket
4. GUITAR : Guitar input socket
5. LINE IN : Line input socket
6. CHARGING LIGHT
7. USB : USB input socket
8. POWER SWITCH : Switch power between ON or OFF.
9. LED DISPLAY : Display speaker status.
10. VOLUME/MULTI : Increase or decrease speaker main volume.
11. STANDBY
12. SOURCE : Press to change the source between BT, LINE, FM, USB
13. LIGHT MODE : Press to change the light mode between LED1,LED2,LED3,LED4,OFF
14. X DRIVE : on or off.Press to X DRIVE mode
15. PREV : Press this key to go to the previous track in USB/BT mode. In FM mode press to
tune to the previous channel.
16. PLAY/PAUSE/TWS : Press to play/pause a track. In FM mode press for the full automatic
search.Press to TWS (true wireless stereo) mode on or off.
17. In FM mode press to NEXT : Press this key to go to the next track in USB/BT mode.
tune to the next channel
18. EFFECTS: the menu MIC/GUITAR VOLUME, ECHO Press this key to change between
VOLUME,BASS, TREBLE.
Display" " mean for MIC/GUITER VOL 10, Rotate VOLUME/MULTI knob to adjust 0-30.
Display" " mean for ECHO VOL 10, Rotate VOLUME/MULTI knob to adjust 0-30.
Display" " mean for BASS 00, Rotate VOLUME/MULTI knob to adjust ± 6 dB.
Display" " mean for TREBLE 00, Rotate VOLUME/MULTI knob to adjust ± 6 dB.

Bluetooth pair and connect
● Turn off any Bluetooth devices previously paired (linked) with this unit.
● Turn on the Bluetooth features on your phone or music player.
● Turn on and set this unit to Bluetooth mode. The flashing blue light BT on the LED display
indicates it is in pairing mode.
● Set your phone or music player to search for Bluetooth devices.
● Select GEMINI GLS-550/GEMINI GLS-880 from search results on your phone or music
player.
● Select OK or YES to pair this unit with your phone or music player.
● If protected, enter 0000 for pass key. A steady blue blue light indicates successful
connection.
TWS (True Wireless Stereo) mode
1. Turn on 2 speakers and select both INPUT modes as Bluetooth
2. Press " " key on speaker set for 2 seconds and " " will be displayed. When the
display light is “ ” or a tone is heard from another device, the TWS is established.
3. Turn on the Bluetooth feature on your mobile phone to search for Bluetooth devices and
select “GEMINI GLS-550/GEMINI GLS-880" from the search result. Select OK or YES to
pair this unit with your mobile phone and a steady blue light will indicate a successful
connection. Once connected you can play music from your mobile phone.
4. Press " " key on the speaker unit for 2 seconds . Turn off the TWS features when
" " is displayed.
NO.5
Remote Control
/CH+/CH-
/TU+
/TU-
SOURCE
1. : Standby ON/OFF STANDBY .
2. 0~9 NUMERIC KEYS: These keys are used
to play a track directly in USB source mode.
Eg:To play 12th track in the USB playlist
press the key"1" followed by"2".numeric
3. VOL- To decrease the volume. :
4. /CH- : Play the previous song by pressing
" " in /CH- USB/BT input mode.
Choose previous channel by pressing
" /CH-" FM input mode.in
5. : Play / pause in USB/BT mode. In FM
mode press for full automatic search.
6. /TU- : Fast rewind a song by pressing
" " in USB input mode /TU- .
Choose tunning channel by pressing
" " in FM input mode/TU- .
7. /TU+ : Fast forward song by pressing
" " in USB input mode /TU+ .
Choose tunning channel by pressing
" " in FM input mode/TU+ .
8. /CH+ : Play the next song by pressing
" " in USB BT input mode /CH+ / .
/CH+ Choose next channel by pressing " "
in FM input mode .
9. VOL+ To increase the volume. :
10. MUTE Press ON/OFF. : to switch mute
11. REPEAT . : Choose repeat mode by pressing repeat key in USB input mode
12. SOURCE to change the source between : Press BT, LINE, FM, USB.

Accessories
Instruction Manual -------------------------------------------------------------------------------1 pc
FM Antenna ---------------------------------------------------------------------------------------1 pc
Remote control------------------------------------------------------------------------------------1 pc
Microphone --------------------------------------------------------------------------------------- 1 pc
Specifications
Frequency Response ---------------------------------------------------------------- 30Hz-20KHz
Power Source ---------------------------------------------------------------- 100-240V~,50/60Hz
Power Consumption ---------------------------------------------------------------80W(GLS-550)
Power Consumption -------------------------------------------------------------100W( )GLS-880
Due to continuous product development specifications and functions may be changed
without prior notice.
Battery
In AC ( power) mode the battery will automatically charge. A slow red flashing light indicates
that the battery is charging. When fully charged a green light will be displayed.
In DC ( battery) mode a green light indicates that the battery level is full. If the battery level is
low a red light will be displayed. This indicates that the battery must immediately be charged
or the speaker will turn off.
NO.6

NO.7
Special precautions
