GeMNeXT EXT-UHBT100-R User manual

USER MANUAL
EXT-UHBT100-SET
HDBaseT Extender Set 100m
Ultra-Thin design
All Rights Reserved
Version: EXT-UHBT100-SET_2016V1.2

Preface
Read this user manual carefully before using this product. Pictures shown in this manual
is for reference only, different model and specifications are subject to real product.
This manual is only for operation instruction only, not for any maintenance usage. The
functions described in this version are updated till August 2016. Any changes of
functions and parameters since then will be informed separately. Please refer to the
dealers for the latest details.
All product function is valid till 2016-8-31.
FCC Statement
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. It has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a commercial
installation.
Operation of this equipment in a residential area is likely to cause interference, in which
case the user at their own expense will be required to take whatever measures may be
necessary to correct the interference
Any changes or modifications not expressly approved by the manufacture would void
the user’s authority to operate the equipment.

EXT-UHBT100-SET Ultra-Thin Extender Set
SAFETY PRECAUTIONS
To insure the best from the product, please read all instructions carefully before using
the device. Save this manual for further reference.
Unpack the equipment carefully and save the original box and packing material for
possible future shipment
Follow basic safety precautions to reduce the risk of fire, electrical shock and injury
to persons.
Do not dismantle the housing or modify the module. It may result in electrical shock
or burn.
Using supplies or parts not meeting the products’ specifications may cause damage,
deterioration or malfunction.
Refer all servicing to qualified service personnel.
To prevent fire or shock hazard, do not expose the unit to rain, moisture or install
this product near water.
Do not put any heavy items on the extension cable in case of extrusion.
Do not remove the housing of the device as opening or removing housing may
expose you to dangerous voltage or other hazards.
Install the device in a place with fine ventilation to avoid damage caused by
overheat.
Keep the module away from liquids.
Spillage into the housing may result in fire, electrical shock, or equipment damage. If
an object or liquid falls or spills on to the housing, unplug the module immediately.
Do not twist or pull by force ends of the optical cable. It can cause malfunction.
Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to
the device before cleaning.
Unplug the power cord when left unused for a long period of time.
Information on disposal for scrapped devices: do not burn or mix with general
household waste, please treat them as normal electrical wastes.

EXT-UHBT100-SET Ultra Thin Extender Set
Table of Contents
1. Introduction .................................................................................................... 5
1.1 Introduction to EXTUHBT100-SET...................................................... 5
1.2 Features ............................................................................................ .. 5
1.3 Package Contents ............................................................................ ... 5
2.Panel Description ............................................................................................ 6
2.1 EXT-UHBT100-T ................................................................................... 6
2.2 EXT-UHBT100-R .................................................................................. 7
2.3 Twisted Pair Cable Description ............................................................. 9
3. System Connection ........................................................................................ 10
3.1 Usage Precautions .................................................................................10
3.2 System Diagram .....................................................................................10
3.3 Connection Procedure ............................................................................11
3.4 Application ......................................................................................... ... 11
4. Specification ................................................................................................... 11
5. Panel Drawing ................................................................................................ 12
6. Troubleshooting & Maintenance .......................... .......................................... 13
7. After-sales Service ....................................... .................................................. 14

EXT-UHBT100-SET Ultra Thin Extender Set
1. Introduction
1.1 Introduction to EXT-UHBT100-SET
EXT-UHBT100-SET is an ultra-thin HDBaseT Extender set consist of transmitter
(EXT-UHBT100-T) and receiver (EXT-UHBT100-R).
It distributes HDMI signal via CAT5e/CAT6a cable at 100m/PoE, and enables IR and
RS232 passthrough to control remote displays. It also supports 4 Ethernet interface for
network.
It provides a perfect long range transmission solution.
1.2 Features
Ultra-thin design.
The highest resolution is 4Kx2k/60Hz
HDCP2.2 compliant.
Maximum transmission distance is up to 70m for 4Kx2K
Maximum transmission distance is up to 100m for 1080p
Maximum extension distance is up to 100m for Ethernet.
Unidirectional PoE allows transmitters to power receiver
High bandwidth：10.2Gbps
Support IR/RS232 passthrough.
Use HDBaseT technology.
LED indicators show work status.
Note: Please use a CAT5e cable with low impedance (Shielded twisted pair will be
better and should be well grounded)for good transmission effect.
1.3 Package Contents
➢1 x Transmitter (EXT-UHBT100-T)
➢1 x Receiver(EXT-UHBT100-R)
➢4 x Mounting ears (Separated from EXT-UHBT100-SET)
➢8 x Black Plastic cushions
➢8 x Screws
➢2 x Power adapter (DC 24V 1.25A)
➢2 x RS232 cables
➢1 x User manual
Notes: If you find any defective or missing parts, please contact your local dealer.

EXT-UHBT100-SET Ultra Thin Extender Set
2. Panel Description
No.
Name
Description
①
LINK
HDBT Link status indicator:
➢OFF: No Link
➢GREEN:Link Successful
➢Blinking GREEN: Link abnormal
②
HDCP
HDCP compliant indicator
➢OFF: No HDMI traffic (no picture)
➢GREEN: Traffic with HDCP.
➢Blinking GREEN: Traffic without HDCP
③
Power
OFF: No power; RED: DC power present.
④
RS232
RS232 connector.
⑤
IR IN
Connect with 5V/12V IR receiver (with carrier) to collect infrared signal, work with
far-end IR OUT port
⑥
IR OUT
Connect with 5V/12V IREmitter to send infrared signal, work with far-end IR IN port
⑦
HDMI IN
Connect with HDMI source
⑧
HDBT OUT
Connect to the HDBT IN socket on the EXT-UHBT100-R via CAT5e/ CAT6a cable,
support unidirectional PoE.
⑨
ETHERNET
100M Ethernet interface, when need to work in a LAN, one of

EXT-UHBT100-SET Ultra Thin Extender Set
⑩
ETHERNET
these 4 ports (both the Ethernet ports of EXT-UHBT100-T and EXT-UHBT100-R)
should be used for internet access, and the others can be connected with
computers. If they are well connected, the yellow LED indicators on the
corresponding ports will keep blink and the green ones will keep on when
working.
⑪
DC 24V
Connect with DC24V 1.25A power adaptor.
Pictures shown in this manual are only for reference.
No.
Name
Description
①
LINK
HDBT Link status indicator:
➢OFF: No Link
➢GREEN:Link Successful
➢Blinking GREEN: Link abnormal
②
HDCP
HDCP compliant indicator
➢OFF: No HDMI traffic (no picture)
➢GREEN: Traffic with HDCP.
➢Blinking GREEN: Traffic without HDCP
③
Power
OFF: No power; RED: DC power present.
④
RS232
RS232 connector.
⑤
IR IN
Connect with 5V/12V IR receiver (with carrier) to collect infrared signal,
work with far-end IR OUT port
⑥
IR OUT
Connect with 5V/12V IR Emitter to send infrared signal, work with
far-end IR IN port
⑦
HDMI OUT
Connect with HDMI display

EXT-UHBT100-SET Ultra Thin Extender Set
⑧
HDBT IN
Connect to the HDBT OUT socket on the EXT-UHBT100-SET via CAT5e/
CAT6a cable.
⑨
ETHERNET
Ethernet ports, when need to work in a LAN, one of these 4 ports (both
the Ethernet ports of EXT-UHBT100-T and EXT-UHBT100-R) should be
used for internet access, and the others can be connected
⑩
ETHERNET
with computers. If they are well connected, the yellow LED indicators on
the corresponding ports will keep blink and the green ones will keep on
when working.
⑪
DC 24V
Connect with DC24V 1.25A power adaptor (Not necessary if
EXT-UHBT100-T connects with power).
Pictures shown in this manual are only for reference.

EXT-UHBT100-SET Ultra Thin Extender Set
2.3 Twisted Pair Cable Description
The twisted pair used this extender in MUST be a straight-through cable.
Notice: Cable connectors MUST be metal one,
the shielded layer of cable MUST be connected to
the connector’s metal shell, to make
a better transmission.
TIA/EIA T568A
TIA/EIA T568B
Pin
Cable
color
Pin
Cable
color
1
green
white
1
orange
white
2
green
2
orange
3
orange
white
3
green
white
4
blue
4
blue
5
blue
white
5
blue
white
6
orange
6
green
7
brown
white
7
brown
white
8
brown
8
brown
1st
Ground
4--5
1st
Ground
4--5
2nd
Ground
3--6
2nd
Ground
1--2
3rd
Group
1--2
3rd
Group
3--6
4th
Group
7--8
4th
Group
7--8

EXT-UHBT100-SET Ultra Thin Extender Set
3. System Connection
3.1 Usage Precautions
1) System should be installed in a clean environment and has a prop temperature
and humidity.
2) All of the power switches, plugs, sockets and power cords should be insulated
and safety.
3) All devices should be connected before power on.
4) Use shielded straight-thru CAT5e/CAT6a cable with TIA/EIA T568B
terminations for good transmission effect.
3.2 System Diagram

EXT-UHBT100-SET Ultra Thin Extender Set
3.3 Connection Procedure
Step1. Connect HDMI source (such as DVD player) to HDMI IN port of
EXT-UHBT100-T with HDMI cable.
Step2. Connect HDBT OUT port of EXT-UHBT100-T and HDBT IN port of
EXT-UHBT100-R with single CAT5e/CAT6a cable.
Step3. Connect HDMI displayer (such as HDTV) to HDMI OUT port of
EXT-UHBT100-R with HDMI cable.
Step4. Both EXT-UHBT100-T and EXT-UHBT100-R have IR IN and OUT.
When one model use for IR signal receiver, the IR signal must be sent out
by the other model.
For example: When “IR IN” of EXT-UHBT100-R connects with an IR
receiver, the IR Emitter must be connected to “IR OUT” of
EXT-UHBT100-T.
Step5. To set as a LAN, one of the four ETHERNET ports of EXT-UHBT100-T and
EXT-UHBT100-R should be used for Internet access, and the others can be
connected with computers.
Step6. Connect the RS232 port of the computer and the RS232 port of
EXT-UHBT100-T or EXT-UHBT100-R (any one is able to work as the
RS232 signal can be transmitted bi-directionally) by using a RS232 cable.
Step7. Connect with DC24V power adaptor(s) separately or only connect power
adaptor to EXT-UHBT100-T).
3.4 Application
EXT-UHBT100-SET has a good application in various occasions, such as
computer realm, monitoring, big screen displaying, meeting room, education and
bank & securities institution etc.

EXT-UHBT100-SET Ultra Thin Extender Set
4. Specification
EXT-UHBT100-T EXT-UHBT100-R
INPUT
Input Signal
1 x HDMI, 1 x IR in,
1 x RS232
1 x IR in, 1 x HDBaseT,
1 x RS232
Input Connector
1 x HDMI female
1 x 3.5mm mini jack
1 x 3P captive connector
1 x 3.5mm mini jack
1 x RJ-45,
1 x 3P captive connector
Video Signal
HDMI 1.4a
HDMI 1.4a
Audio Signal
Digital audio transmit
through HDMI audio
Digital audio transmit
through HDMI audio
OUTPUT
Output Signal
1 x HDBaseT, 1 x IR in,
1 x RS232
1 x HDMI, 1 x IR out,
1 x RS232
Output Connector
1 x RJ-45
1 x 3.5mm mini jack
1 x 3P captive connector
1 x HDMI female
1 x 3.5mm mini jack
1 x 3P captive connector
Ethernet Port
Ethernet Connector
1 x Black RJ45, with dual
color indicator (Green &
Yellow)
2 x Black RJ45, with
dual color indicator
(Green & Yellow)
Transmission Speed
Adaptive 10M/100M (max), full duplex or half duplex
General
Transmission Mode
HDBaseT
Resolution
800x600@60Hz, 1024x768@60Hz,
1280x720@60Hz, 1280x1024@60Hz,
1366x768@60Hz, 1600x1200@60Hz,
1920x1080@60Hz, 1920x1200@60Hz, 3D, 4Kx2K
Transmission Distance
1080p: 100 meter –4K x 2K: 70 meter
Bandwith
10.2Gbps
HDMI Standard
HDCP 2.2
Impedance
75Ω
Temperature
0 ~ 50°C
Humidity
0% ~ 90%
Power Consumption
10W
Power Supply
Input: 100VAC~240VAC, 50/60Hz;
Output: 24VDC 1.25A
Dimension (W*H*D)
152mmx16mmx84mm
Net Weight
186 gram
196 gram
NOTE: All nominal levels are at ±10%.

EXT-UHBT100-SET Ultra Thin Extender Set
5. Panel Drawing
EXT-UHBT100-T
EXT-UHBT100-R

EXT-UHBT100-SET Ultra Thin Extender Set
6. Troubleshooting & Maintenance
Problems
Causes
Solutions
Output images in
display show with ghost
Incorrect setting on the
display
Check the display’s setting
A cable of bad quality
Try another high quality
connection cable
No output image when
switching
No signal at the input / output
end
Check with oscilloscope or
multimeter if there is any
signal at the input / output
end.
Fail or loose connection
Make sure the connection
is good
The extender is broken
Send it to authorized dealer
for repairing.
Cannot control the
device by control
device (e.g. a PC)
through RS232 port
Wrong RS232
communication parameters
Make sure the RS232
communication parameters
are correct.
The device has already been
broken
Send it to
authorized dealer
for repairing.
Cannot recognize
device connected to the
ETHERNET port
The connected device has
the same IP address with the
extender
Change the IP address of
the extender or the
connected device.
Static becomes stronger
when connecting the
video connectors
Bad grounding
Check the grounding and
make sure it is connected
well.
Cannot control the
device by RS232 / IR
The device has already been
broken
Send it to authorized dealer
for repairing.
If your problem persists after following the above troubleshooting steps, seek further
help from authorized dealer or our technical support.

EXT-UHBT100-SET Ultra Thin Extender Set
7. After-sales Service
If there appear some problems when running the device, please check and deal with
the problems reference to this user manual. Any transport costs are borne by the users
during the warranty.
1) Product Limited Warranty: GeMNeXT warrants that its products will be free from
defects in materials and workmanship for three years, which starts from the first
day the product leaves warehouse (check the SN mark on the product).
Proof of purchase in the form of a bill of sale or receipted invoice must be presented
to obtain warranty service.
2) What the warranty does not cover:
Warranty expiration.
Factory applied serial number has been altered or removed from the product.
Damage, deterioration or malfunction caused by:
Normal wear and tear
Use of supplies or parts not meeting our specifications
No certificate or invoice as the proof of warranty.
The product model showed on the warranty card does not match with the
model of the product for repairing or had been altered.
Damage caused by force majeure.
Servicing not authorized
Any other causes which does not relate to a product defect
Delivery, installation or labor charges for installation or setup of the product
3) Technical Support: Email to our after-sales department or make a call, please
inform us the following information about your cases.
Product version and name.
Detailed failure situations.
The formation of the cases.
Remarks: For any questions or problems, please try to get help from your local
distributor or contact GeMNeXT at www.GeMNeXT.com

www.GeMNeXT.com
GeMNeXT rights owned by AVDIS B.V.
Tel: [phone]
Email: [e-mail]
Website: www.gemnext.com
Ambachtstraat 3A
3732 CN De Bilt
The Netherlands
