USER MANUAL
LED-7100T
312 LED VARIABLE COLOR ON-CAMERA LIGHT

Thank you for choosing the Genaray LED-7100T
On-Camera Light. This product will provide you with
powerful, portable and dependable illumination that
can be used in a variety of settings. Featuring a super-
bright 312 LED lamp count, 3200K-5600K variable
color temperature, flicker-free dimmable features
and a removable magnetic diffuser with advanced
light dispersion capabilities, the Genaray LED-7100T
On-Camera Light is the perfect choice for professional
photographers and videographers alike.
LED-7100T - USER MANUAL
2
LED-7100T
INTRODUCTION

· 3200K-5600K Variable Color
Temperature
· Lightweight Design With
Powerful 312 Lamp Count
· Dual On-Board Batteries
& Battery Level Indicator
· Removable Snap-On Magnetic
Diffuser
· Compact Profile & Case
For Easy Transport
· 312 LED Light
· Magnetic Diffuser
· 2 NP-F550 Batteries
· AC/DC Dual Battery Charger
· AC Adapter
· Car Adapter
· Ball Head Mount
· Carrying Case
· Manual
KEY FEATURES PRODUCT CONTENTS
LED-7100T - USER MANUAL
3
Features

SAFETY
WARNINGS
· Do not attempt to disassemble,
repair or perform any unauthorized
modifications on device
· Do not handle with wet hands,
immerse in liquids or expose to water
and rain; electric shock or fire may
result
· Device contains small parts which
may pose a choking hazard; keep out
reach of children
· Do not operate device in presence of
flammable gas or vapors
· Do not use product if it emits smoke
or a strange odor; disconnect power
source immediately to avoid personal
injury and contact place of purchase
· Observe caution when handling
batteries; only use batteries approved
by the manufacturer of this product
· Batteries are prone to leakage when
fully discharged; to avoid damaging
product be sure to remove batteries
when leaving product unattended
· Do not intentionally stare or gaze at
LED-7100T - USER MANUAL
4
saFety Warnings

LED light for prolonged periods while
device is on
· During operation, do not cover the
ventilation grille found at the rear of
device and ensure light is cool before
storing
· Do not use or leave device in
conditions of extreme heat, severe
cold or high humidity
· Unit will display a decrease in
brightness when the battery runs
low; be sure to replace battery when
necessary to avoid affecting recording
quality
· When cleaning the device, use only a
mild detergent solution and quickly
wipe dry with a soft cloth
· Dispose of used batteries, packaging
and old devices in accordance
with appropriate environmental
regulations
LED-7100T - USER MANUAL
5
saFety Warnings

LED-7100T - USER MANUAL
6
Filter
Mounting
Magnet
LED Array Included
Ball Head
Mount
1/4 20
Threaded Mount
PRODUCT
OVERVIEW

LED-7100T - USER MANUAL
7
Battery 1
Mounting
Area
Battery 2
Mounting Area
Battery
Release
Button 1 Battery
Release
Button 2
Power &
Dimming
Knob
Battery Level
Indicator
Color
Variation
Knob
DC
Input
PrODuCt OvervieW

MOUNTING LIGHT
UNIT DIRECTLY
ON TRIPOD
MOUNTING LIGHT
UNIT ON BALL HEAD
MOUNT
LED-7100T - USER MANUAL
8
· For basic tripod installation, insert 1/4 20
screw found on tripod head into the 1/4 20
threading mount found on bottom of light
unit; then tighten securely
Light can also be fastened
to included ball head mount,
which can then be installed on
cold shoe found on cameras or
similar devices; see ball head
mounting instructions
· Included ball head mount is designed to
provide user with a 180° tilt/360° rotating
angle feature that can be used on both
cameras and other devices featuring a
cold shoe
· Begin by inserting 1/4 20 screw found atop
ball head mount into the 1/4 20 threading
found on bottom of LED light unit and
fasten securely
· Tighten adjustment locking knob so light
unit does not wobble during remainder of
mounting process
· Ensure cold shoe foot is firmly secured to
ball head mount device and loosen locking
collar found on base of ball head device
Note
instruCtiOns

LED-7100T - USER MANUAL
9
· Slide entire male cold shoe into female cold
shoe of camera or other mounting device;
then fasten locking collar securely
· Loosen adjustment locking knob by
twisting counterclockwise and rotate ball
head mount to position light at desired
angle; twist locking knob clockwise to hold
light unit firmly in position
Cold shoe mount can also
be removed to reveal an
integrated1/4 20 threading
mount
· To reveal ball head mount's integrated 1/4
20 threading mount for fastening to tripod,
twist locking ring resting above cold shoe
counterclockwise until entire shoe comes
out; insert 1/4 20 screw found on tripod
head into the 1/4 20 threading mount; then
follow remaining adjustment steps above
Note
instruCtiOns

POWERING
DEVICE
LED-7100T - USER MANUAL
10
· Begin by holding a fully-charged battery
in position over Battery 1 Mounting Area,
leaving only a small gap between conductor
contacts found on battery and metal prongs
found on unit
· Push battery down and lock into place by
sliding it inwards along grooves until an
audible click is heard; repeat sequence
with second battery over Battery 2
Mounting Area
Only one battery is technically
required to operate light
· Twist the power & dimming switch
clockwise to turn LED lights on
· Press the built-in battery level indicator
button to instantly view the power
remaining in both batteries; each indicator
circle represents approximately 25% of
battery capacity; the showing of 4 lit circles
combined will represent a fully charged
battery
For an accurate reading of
battery levels, it is best to turn
off light unit before using battery
level indicator feature
· Rechargeable batteries can be removed
by firmly pushing down on dual battery
release buttons
· The DC input found on rear of device
connects directly to the included AC power
adapter or car charger and can provide
continuous power when battery is low or
not working
·
· --
·
· --
· ADD
·
CUSTOMER SUPPORT
For more information about this product or to contact the Genaray Customer
Support Center with any questions, please send your email correspondence to:
[e-mail].
Note
Note
instruCtiOns

Bulb Type: 156 Daylight & 156 Tungsten LEDs
Brightness: 1400 lux @ 3'
Color Temperature: 3200K - 5600K
Voltage: 7.4-14.8V
Weight: 0.76 lbs
Dimension: 7.5" x 4.5" x 1.75"
PRODUCT
SPECIFICATIONS
ADJUSTING
FEATURES
LED-7100T - USER MANUAL
11
· To adjust the 3200K-5600K variable
color temperature range, simply rotate
color variation knob until desired
effect is achieved
· To adjust the flicker-free dimmable
features, simply rotate the power &
dimming knob until desired effect
is achieved
· To install magnetic snap-on diffusion
filter, hold diffuser over LED panel with
silver magnetized posts facing inwards;
then quickly snap it into place
CUSTOMER SUPPORT
For more information about this product or to
contact the Genaray Customer Support Center
with any questions, please send your email
correspondence to: [e-mail].
sPeCiFiCatOns

ONE-YEAR LIMITED WARRANTY
Genaray provides a limited warranty that this product is free from defects in
materials and workmanship to the original purchaser under normal use for a period
of one (1) year from the original purchase date or thirty (30) days after replacement,
whichever occurs later (the “Warranty Period”). Our responsibility with respect
to this limited warranty shall be limited solely to repair or replacement, at its
option, of any product which fails during normal consumer use. To obtain warranty
coverage during the Warranty Period, contact your place of purchase (“Seller”) to
obtain a return merchandise authorization (“RMA”) number, and return to Seller the
defective product along with proof of purchase and the RMA number. This warranty
does not extend to damage or failure which results from misuse, neglect, accident,
alteration, abuse, improper installation or maintenance. EXCEPT AS PROVIDED
HEREIN, GENARAY MAKES NEITHER ANY EXPRESS WARRANTIES NOR ANY
IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This warranty
provides you with specific legal rights, and you may also have additional rights which
vary from state to state. © Copyright 2013 Genaray
