Genave ENC-3300-DTMF User manual

ENC-3300-DTMF
User Guide,
Installation & Service Manual,
Pro rammin Guide
Universal DTMF Radio Encoder
Document 9000-0000-086 rev 4

ENC-3300-DTMF
Page Intentionally lank
Genave/NRC,Inc. 9000-0000-086 rev 4 Pg. 2

ENC-3300-DTMF
Important Safety Information
System Plannin
Proper plannin is the cornerstone to an effective warnin system. The Federal
Emer ency Mana ement A ency (FEMA) publishes the “Outdoor Warnin Guide” CPG
1-17, which should be used in plannin your system. In addition, you should reco nize
and understand the followin items:
•Outdoor warnin s sirens and equipment are not intended to be heard indoors.
Conversely indoor devices are not intended to cover outdoor environments. All
devices have specific purposes and distances that they can be considered effective.
Proper placement and selection of the correct equipment is necessary to cover a
desired area. Refer to the FEMA uide for placement uidelines.
•Trainin is necessary to ensure those responsible can correctly activate the system. It
is also necessary that everyone understand the purpose of the warnin system and the
protective actions they need to take when the system is activated. Periodic tests can
serve to accomplish the trainin for the operators, in addition to demonstratin the
various si nals to the public.
•All warnin systems must have contin ency plans in case equipment problems or
operator errors interfere with its performance. Just as with the primary warnin
system, the contin ency plans should be periodically tested to make sure those
responsible know how to implement them and the necessary response from the public
is achieved.
Genave/NRC,Inc. 9000-0000-086 rev 4 Pg. 3
Warnin
If incorrectly used, this equipment can cause severe injury.
Those who use and maintain the equipment should be trained in
its proper use, warned of its dan ers, and should read the
manuals before attemptin to set up, operate, adjust or service
the equipment. Keep this manual for future reference.

ENC-3300-DTMF
Installation & Service Precautions
•Electrocution, severe personal injury and dama e to equipment can
occur durin installation or servicin this equipment. All electrical work should be
performed by, or under the supervision of, an experienced electrician and in
accordance with all applicable electrical, fire, buildin and safety codes.
•This equipment can cause devices to start at any time from local
controls, automatic timers, radio remote, commands from a computer
and many other sources. The output of such equipment could cause hearin dama e,
while other attached equipment can cause personal injury when they en a e.
Whenever workin in or around the equipment you must assume it could activate at
any moment, and take appropriate precautions to protect yourself and others. You
should completely disable the equipment before workin on or in close proximity to
any part of it.
•You must test the system and equipment to ensure it is operatin correctly after the
installation, as well as after any work has been performed.
System Operation
•Trainin is necessary to ensure those responsible can correctly activate the system. It
is also necessary that everyone understand the purpose of the siren and the protective
actions they need to take when the system is activated. Periodic tests can serve to
accomplish the trainin for the operators, in addition to demonstratin the various
si nals to the public.
•You must carefully read and completely understand all the information about the
system includin its abilities and its limitations. Since no warnin system is infallible,
you must have contin ency plans for warnin in the event the primary systems do not
perform as expected, for any reason.
Genave/NRC,Inc. 9000-0000-086 rev 4 Pg. 4

ENC-3300-DTMF
©2013, Genave/NRC, Inc.
RXC-3300-DTMF
Phone [phone]
Fax [phone]
PRINTED IN USA
The contents of this manual are the property of Genave/NRC, Inc. and are copyrighted. Any reproduction in whole or in part is strictly
prohibited. For additional copies of this manual or software, please contact Genave/NRC, Inc.
Warranty:
Genave/NRC, Inc. products are warranted to be free from defects in material and workmanship for a
period of ONE (1) year from the date of shipment. Genave, durin this period, will repair or replace any
parts, which upon our examination appear to be defective in materials or workmanship. This warranty
does not apply to defects, malfunctions or breaka e due to improper installation, servicin , handlin or
use thereof, nor to units that have been dama ed by li htenin or other “Acts of God”, excess current,
reversed supply connection, nor to units that have had their serial numbers altered or removed.
Equipment dama ed in Acts of War, abuse, misuse, tamperin , submersion or willful destruction will
also void this warranty.
Prior to returnin equipment for warranty repair, contact Genave Customer Service Department for an
RMA number. They can be reached by usin the telephone number or fax number listed above.
Genave/NRC, Inc. (Genave) and its licensers offer this warranty in lieu of any and all other uarantees or
warranties, either express or implied, includin without limitation the implied warranties of
merchantability and fitness for a particular purpose, re ardin hardware or software. Genave and its
licensors do not warrant, uarantee or make any representations re ardin the use or the results of the
use of the software or hardware in terms of its correctness, accuracy, reliability, most recent or
otherwise. You assume the entire risk as to the results and performance. The exclusion of implied
warranties is not permitted by some jurisdictions. The above exclusion may not apply to you.
In no event will Genave, its licensors, directors, officers, employees or a ents (collectively Genave’s licensor) be liable to you for
any consequential, incidental or indirect dama es (includin dama es for loss of business profits, business interruption, loss of
business information, and the like) arisin out of the use or inability to use the software or hardware even if Genave and/or its
licensor has been advised of the possibility of such dama es. Because some jurisdictions do not allow the exclusion or limitation
of liability for consequential or incidental dama es, the above limitations may not apply to you. Genave and its licensors liability to
you for actual dama es from any cause whatsoever, and re ardless of the form of the action (whether in contract, tort, (includin
ne li ence), product liability or otherwise), are expressly excluded.
Genave reserves the ri ht to make chan es in specifications at anytime and without notice. The information furnished by Genave
is believed to be accurate and reliable, however, no responsibility is assumed by Genave for its use, nor infrin ements of patents
or other ri hts of third parties resultin from its use. No license is ranted under any patents or patent ri hts of Genave/NRC, Inc.,
its licensors or suppliers.
Life Support Policy:
Genave/NRC, Inc. products are not authorized for use as critical components in life support devices or systems without the
express written approval of the president of Genave/NRC, Inc. As used herein:
1) Life support devices or systems are devices or systems which, (a) are intended for sur ical implants into the body, or (b)
support or sustain life, or whose failure to perform, when properly used in accordance with instructions, can reasonably be
expected to result in a si nificant injury to the user.
2) Critical component is any component of a life support device or system whose failure to perform can be reasonably expected to
cause the failure of the life support device or system, or to affect its safety or effectiveness.
RXC-3300, Genave Operatin System, and GOS are Trademarks of Genave/NRC, Inc. The Genave name and lo o are Re istered
trademarks of Genave/NRC, Inc. Touch-Tone is a Re istered trademark of American Telephone and Tele raph.
Other names used in this manual are trademarks of their respective companies.
Genave/NRC,Inc. 9000-0000-086 rev 4 Pg. 5

ENC-3300-DTMF
FCC Compliance Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause
undesired operation.
FCC WARNING
This equipment has been tested and found to comply with the limits for a Class digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the receiver.
•Connect the equipment into an outlet different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution:
To comply with the limits for an FCC Class computing device, always use the accessories supplied
with this unit.
The Federal Communications Commission warns that changes or modifications of the unit not
expressly approved by Genave could void the user’s authority to operate the equipment.
Genave/NRC,Inc. 9000-0000-086 rev 4 Pg. 6

ENC-3300-DTMF
Table of Contents
Specifications...................................................................................................................................... 9
Installation.......................................................................................................................................... 11
Output Connector............................................................................................................................11
Output Schematic............................................................................................................................ 12
Connector for J3......................................................................................................................... 12
Example connection................................................................................................................... 12
Power.............................................................................................................................................. 13
Audio connections to your Radio.....................................................................................................13
Adjust Audio Levels......................................................................................................................... 13
Programming................................................................................................................................... 14
Testing............................................................................................................................................. 14
Example connection – Motorola XPR-4350 in analog mode............................................................15
Example connection – Motorola CDM750.......................................................................................16
Example connection – Motorola M1225..........................................................................................17
Usin the ENC-3300........................................................................................................................... 18
Sending a signal or command.........................................................................................................18
Stopping a transmission in progress...............................................................................................18
ESC Button......................................................................................................................................... 19
System Clock – Adjustin Time and Date........................................................................................19
Pro rammin via SD Card................................................................................................................20
Active Upload Monitoring – Report File.......................................................................................20
Example - Successful Upload Report.....................................................................................20
Example – Upload Fail Report...............................................................................................21
Active Upload Monitoring - LCD..................................................................................................21
GP3 Programming File....................................................................................................................22
Filename Length.............................................................................................................................23
Comments....................................................................................................................................... 23
Activity Lo ........................................................................................................................................ 25
Filename......................................................................................................................................... 25
Example log file............................................................................................................................... 25
Formatting the Memory Card..........................................................................................................25
Power.................................................................................................................................................. 26
Radio Interface................................................................................................................................... 26
Input / Output Connector.................................................................................................................26
Relays............................................................................................................................................. 27
PTT – Relay 8............................................................................................................................. 27
Aux – Relay 7............................................................................................................................. 27
Audio............................................................................................................................................... 27
10 second test switch......................................................................................................................27
Carrier Detect.................................................................................................................................. 28
External Switches............................................................................................................................ 29
Genave/NRC,Inc. 9000-0000-086 rev 4 Pg. 7

ENC-3300-DTMF
DTMF Code Strin s........................................................................................................................... 30
Standard codes...............................................................................................................................30
Pauses............................................................................................................................................ 30
eep................................................................................................................................................ 30
Send text to LCD............................................................................................................................. 31
Manual Transmitter Control ............................................................................................................31
[R8=0] Disengages relay 8 which unkeys the transmitter......................................................31
[R8=1] Engages relay 8 and keys-up the transmitter.............................................................31
Aux Relay Control .......................................................................................................................... 32
[R7=0] Disengages relay 7....................................................................................................32
[R7=1] Engages relay 7..........................................................................................................32
Alert Tones...................................................................................................................................... 33
SYS – System..................................................................................................................................... 34
FILENAME...................................................................................................................................... 34
UNITID............................................................................................................................................ 34
KLIGHT......................................................................................................................................... 34
WELCOME1.................................................................................................................................... 34
WELCOME2.................................................................................................................................... 35
LOG................................................................................................................................................ 35
DE OUNCE.................................................................................................................................... 35
PGMUPLOAD................................................................................................................................. 35
PGMLOCK...................................................................................................................................... 36
DFRONT......................................................................................................................................... 36
D ACK............................................................................................................................................ 36
DMARK........................................................................................................................................... 36
DSPACE.......................................................................................................................................... 36
CDWAIT – Carrier Detect wait time in seconds...............................................................................37
SIDETONE...................................................................................................................................... 37
BUTTONx............................................................................................................................................ 38
ENA LED....................................................................................................................................... 39
QUIET............................................................................................................................................. 39
LCDNAME...................................................................................................................................... 39
DTMF ............................................................................................................................................. 39
ENDTEXT....................................................................................................................................... 40
LOGOUT......................................................................................................................................... 40
OUTPUT......................................................................................................................................... 40
Enable........................................................................................................................................ 41
Disable....................................................................................................................................... 41
PRIORITY....................................................................................................................................... 41
INITIAL............................................................................................................................................ 41
Sample File......................................................................................................................................... 42
Output Schematic.............................................................................................................................. 45
Genave/NRC,Inc. 9000-0000-086 rev 4 Pg. 8

ENC-3300-DTMF
Specifications
Volta e In: 11 to 14 volts dc.
Current requirements:
209 ma Quiescent
250 ma Active
300 ma Max
Output Connector:
16 – 26 AWG
3.5 mm pin spacing
125v @ 5 amps
DC Connector:
2.1 mm x 5.5mm arrel
Center pin positive
DTMF Si nal:
Max Vpp: 5.20 Vp-p
Max Vrms: 3.78 Vrms
Audio Output:
600 ohm
Transformer isolated
Wei ht:
3.2 lbs (1.45 kg)
Dimensions:
Height 11.5 inches (29.3 cm)
Width 7.0 inches (17.8 cm)
Depth 7.0 inches (17.8 cm)
Environmental:
Operating Temperature 0 deg C to +60 c
Humidity 0-95% Non-condensing
Relay Outputs:
Form C, Sealed, 5 amp max
Genave/NRC,Inc. 9000-0000-086 rev 4 Pg. 9

ENC-3300-DTMF
Page Intentionally lank
Genave/NRC,Inc. 9000-0000-086 rev 4 Pg. 10

ENC-3300-DTMF
Installation
The ENC-3300 attaches to a customer supplied two-way
radio to generate over-the-air DTMF signals intended to
control remote equipment and pagers.
Audio, PTT and carrier detect lines from the radio are
attached to the ENC-3300 using connector J3.
Access to connector J3, testing and adjustment controls
is performed by removing two screws from the bottom of
the door, then pulling the lower edge of the door forward
and out and setting the access door aside.
Output Connector
Connect the appropriate wires between your radio to the encoder. See the Output Schematic on page
44 or Radio Interface on page 25 for additional information.
The ENC-3300 includes a 9 position depluggable connector for connections to the external radio.
Connectors and cables for specific radios are not included with the encoder.
Genave/NRC,Inc. 9000-0000-086 rev 4 Pg. 11
Depluggable Connector J3

ENC-3300-DTMF
Output Schematic
Connector for J3
The 9 pin connector is keyed to fit only one direction.
Example connection
This example shows a common wiring connection that can be used
for many different types of radios, although you must check your
radio for proper application. Numbers and colors in the table are for
instructional purposes and do not appear on the connector.
Genave/NRC,Inc. 9000-0000-086 rev 4 Pg. 12
J3 Pin Purpose
1 Audio Output 1
2 Audio Output 2
3 Carrier Detect Input
4 Relay 7 - Common
5 Relay 7 – Normally Open
6 Relay 8 - Common
7 Relay 8 – Normally Closed
8 Relay 8 – Normally Open
9 Signal Common Ground
J3 Pin Wire Color Purpose
1 White Audio output to transmitter
2 Yellow Audio output to transmitter
3 lue Carrier detect from radio
8 Orange Transmitter key-up / push-to-talk
9 lack Common signal ground

ENC-3300-DTMF
Power
Attach 11 to 14 volts DC to power connector J7. Connector is 2.1mm x 5.5mm. Center pin positive.
Audio connections to your Radio
It's beyond the scope of this manual to address the programming of individual two-way radio models,
however its generally best to begin with your radio set to transmit flat audio response and to disable
AGC and other settings which may affect the inbound audio from the ENC-3300.
Adjust Audio Levels
After connecting your radio, use a communications service meter and adjust the output deviation on
your radio to the correct level.
1. Press and release SW10 “10 sec Test” to transmit a test tone.
2. Adjust POT1 “TX Audio Level” to the correct level while the radio is transmitting.
Genave/NRC,Inc. 9000-0000-086 rev 4 Pg. 13

ENC-3300-DTMF
Programming
If the encoder is not yet programmed, insert the 2G SD memory card containing
the DTMF settings then reset power to the encoder. The program information will
be transferred to the encoder as it starts.
Open the access door on the ENC-3300 to
insert or remove the memory card.
To insert, slide the card into the card holder
until it latches into place.
To remove, lightly press the memory card
down to release it from the card holder. It will
pop up slightly and can then be removed.
During a program upload the encoder actively
monitors the new data as it arrives and
searches for possible errors or corrupted data. It saves the results of the search in a report file on the
SD card. The report file has the same name as the file just uploaded, but with a suffix of .RPT (Report)
instead of .GP3. To verify the transfer it's recommended this report be examined with a text editor such
as Windows Notepad after an upload.
See Programming via SD Card on page 20 for additional information.
Testing
Reattach the access door. Test the encoder and radio completely before placing into service. Check
the transmitter deviation, signal symmetry, and all codes and actions using a communications service
monitor, oscilloscope and associated test equipment.
Genave/NRC,Inc. 9000-0000-086 rev 4 Pg. 14

ENC-3300-DTMF
Example connection Motorola XPR-4350 in analog mode
This is an example only. Your radio may vary in firmware, hardware or programming.
Consult your radio's service manual for specific details on setup and operation.
Genave/NRC,Inc. 9000-0000-086 rev 4 Pg. 15
Wiring to J3 connector
Motorola accessory connector attached to radio.
Accessory connector bottom view

ENC-3300-DTMF
Example connection Motorola CDM750
This is an example only. Your radio may vary in firmware, hardware or programming.
Consult your radio's service manual for specific details on setup and operation.
Genave/NRC,Inc. 9000-0000-086 rev 4 Pg. 16
Wiring to J3 connector
Accessory connector bottom view Motorola accessory connector attached to radio.

ENC-3300-DTMF
Example connection Motorola M1225
This is an example only. Your radio may vary in firmware, hardware or programming.
Consult your radio's service manual for specific details on setup and operation.
Genave/NRC,Inc. 9000-0000-086 rev 4 Pg. 17
Wiring to J3 connector
Motorola accessory connector attached to radio.

ENC-3300-DTMF
Usin the ENC-3300
The encoder should be placed on a flat surface.
Sending a signal or command
• Make sure the encoder is powered and ready. Also make sure the two-way radio is turned on,
working and the correct channel is selected on the radio.
• Firmly press then release the button on the ENC-3300 to initiate the transmission sequence. The
button should be pressed for at least 1/2 second or until the unit beeps. The red “ usy” indicator will
turn on.
• If the button has been programmed to require a second press (Tap-2™) before sending the signal, a
15 second countdown timer will appear and the internal speaker will beep every second. The signal
will not be sent unless the button is pressed again before the timer expires.
• The “Tx” indicator will turn on when the encoder begins generating the DTMF code string.
• The LCD screen will indicate the progress and completion of the action.
• After completion of the transmission, both the usy and Tx indicators will turn off and you are free to
begin another activation. After a short period the encoder returns to its welcome screen if no other
buttons are pressed.
Stopping a transmission in progress
Press and release the ESC button to stop a transmission in progress. This will stop further signals or
actions, however it will not retrieve signals already sent.
Genave/NRC,Inc. 9000-0000-086 rev 4 Pg. 18

ENC-3300-DTMF
ESC Button
The ESC button located on the keyboard has several duties.
1) Press and release while the RXC is running to stop actions including button countdowns,
uncompleted transmissions and other activities.
2) Pressing and holding the ESC button for at least four seconds will result in the RXC prompting you
to release the button to adjust the clock.
3) Press and hold the ESC button for at least eight seconds to perform a reboot that will also
reinitialize the network and SD memory card interface. It has the same effect as removing and
reapplying power.
4) While the ENC-3300 is powering up, press and hold the ESC key. After a few seconds the LCD
screen will display a countdown timer. If the button is still pressed when the timer expires the program
in the ENC-3300 memory will be transferred to the SD memory card. The new file will overwrite any
file on the SD card with the same name.
The download feature can be disabled by using the SYS,PGMLOCK command. See PGMLOCK on
page 35.
No countdown or option to download the program information will occur if PGMLOCK is enabled.
System Clock – Adjustin Time and Date
Press and hold the ESC button for at least four seconds. When you initially press the ESC button the
lcd screen will display “Release ESC button.” After four seconds a countdown timer will begin and the
lcd screen will display “Release ESC now to set clock”. Release the Esc button to enter the clock
adjust mode.
The top line of the lcd screen shows text information describing the values on line 2.
Use keyboard buttons 1 and 2 to move the cursor on line two left and ri ht respectively.
When the cursor is under the digit to be changed, use keyboard buttons 5 and 6 respectively to
increase and decrease the value. Repeatedly pressing the increase value (button 5) will roll the digit
from its maximum value back to zero.
After completing all changes, press keyboard button 8 to save the changes.
The encoder will exit without saving the changes if there have not been any button presses for several
minutes or if the ESC button is pressed.
Genave/NRC,Inc. 9000-0000-086 rev 4 Pg. 19

ENC-3300-DTMF
Pro rammin via SD Card
Programming changes are accomplished using a 2G micro SD memory card with
FAT16 formatting. This method makes field changes fast and easy since no computer
is required on-site. Memory cards can be sent to customers so they can make the
changes themselves.
After making program changes and saving them to the SD card, the card is inserted into the ENC-
3300 and the new settings upload the encoder as the encoder starts. The encoder retains the data in
memory when power is removed so the SD card can be removed after the program upload is
completed.
Active Upload Monitorin – Report File
During a program upload the encoder actively monitors the new data as it arrives and searches for
possible errors or corrupted data. It saves the results of the search to a report file on the SD card. The
report file has the same name as the file just uploaded, but with a suffix of .RPT (Report) instead of
.GP3.
The report is a standard text file and can be viewed with programs such as
•Microsoft: Notepad, Wordpad or Word.
•Multi OS: OpenOffice or LibreOffice.
•Apple: TextEdit.
•Linux/Unix: gedit, vi, nano.
Example - Successful Upload Report
The above report indicates no errors were detected,
Genave/NRC,Inc. 9000-0000-086 rev 4 Pg. 20
